1 Internal features of Heart Dr. Sama ul Haque

2 Objectives  List the chambers of the heart.  Describe the internal features of right atrium.  Describe the internal features of the right ventricle.  Discuss internal features of the left atrium.  Discuss the internal features of the left ventricle.  Differentiate between right and left ventricles.  Define conducting system of the heart.

3 Chambers of Heart 1.Right Atrium 2.Right Ventricle 3.Left Atrium 4.Left Ventricle

4 Chambers of Heart

5 Internal Structure of Heart

6 Right Atrium Crista Terminalis Musculi pectinati (Pectinate muscles) 1.Rough anterior part. 2.Smooth posterior part. 1 2

7 Posterior wall of the right atrium: Opening of the superior vena cava Opening and valve of the inferior vena cava Opening and valve of the coronary sinus Fossa ovalis and the limbus fossa ovalis Anterior wall of the right atrium: Pectinate muscles Crista terminalis Right Atrium

8 Right Ventricle

9 Tricuspid valve has three cusps: anterior, septal, and posterior. Three papillary muscles: anterior, septal, and posterior. The anterior papillary muscle is the largest and most prominent. Trabeculae carneae (rough muscular ridges). Right Ventricle

10 The septomarginal trabecula (moderator band): extends from the interventricular septum to the base of the anterior papillary muscle. The conus arteriosus (infundibulum): is the cone-shaped portion of the right ventricle inferior to the opening of the pulmonary trunk. The pulmonary valve: consists of three semilunar cusps: anterior, right, and left. Right Ventricle

11

12 Left Atrium Receives blood from lungs: Through 4 pulmonary veins (2 right & 2 left) Bicuspid valve: blood passes through it into left ventricle (mitral valve has two cusps).

13 Aortic valve: has three semilunar valve cusps: right, left, and posterior. Left atrioventricular valve (bicuspid valve or mitral valve): has anterior & posterior cusps. Left Ventricle

14 Anterior papillary muscle and the posterior papillary muscle: the chordae tendineae of each papillary muscle attach to both valve cusps. Trabeculae carneae. Left Ventricle

15 Left Ventricle have thick muscular wall

16 Valves of the Heart Right Atrioventricular (Tricuspid) 2.Left Atrioventricular (Bicuspid or Mitral) 3.Pulmonary 4.Aortic

17 Fibrous Skeleton of the Heart Dense collagenous fibrous tissue framework lies at the junction of the atria with the ventricles. Includes: 1-Tricuspid fibrous annulus: 2-Mitral fibrous annulus 3-Pulmonary fibrous annulus: 4-Aortic fibrous annulus Functions: 1-Supports the valves. 2-Electrically separetes atria from ventricles.

18 Valves of the Heart

19 Valves of Heart in Diastole (Viewed from base with atria removed)

20 Valves of Heart in Systole (Viewed from base with atria removed)

21

22

23 Direction of blood flow

24 Sinu-Atrial Node (S-A Node) Sinu-Atrial Node (S-A Node) Atrio-ventricular Node (A-V Node) Atrio-ventricular Node (A-V Node) Atrio-ventricular Bundle Atrio-ventricular Bundle Right and left Bundle branch Right and left Bundle branch Purkinje Fibers Purkinje Fibers Conducting system of Heart

25 S-A Node A-V Node

26 Conducting system of Heart PF

27 Conducting system of Heart

28 Thank You
