1 CONTAINER TERMINAL FSC Container Terminal FSC Company Presentation December 2010

2 CONTAINER TERMINAL FSC Company Presentation 2 Content UCL Holding Overview Business Areas Main Assets Stevedoring Division Container Terminal FSC Transportation Network Terminal Layout Facilities and Equipment Terminal Services IT solutions Photo gallery Further development till 2014 Facilities and Equipment Master Plan Contacts

3 CONTAINER TERMINAL FSC Company Presentation 3 UCL Holding Overview Business Areas Port Operations Solid presence in 4 key Russian seaports Total throughput in 2009 – 31,3 mln. tons Over 10 km of quay length Sea & river cargo shipping Short-sea and river transportation Dry and liquid cargo 460 vessels Passenger shipping Leading positions in main Russian cities Three travel companies 69 ships Railway Operations Own rolling stock – 5,000 railcars. Shipbuilding and ship repairing Ship building capacity up to 12 vessels per year Five ship repair facilities throughout Russia

4 CONTAINER TERMINAL FSC Company Presentation 4 UCL Holding Overview Main Assets 4 Saint- Petersburg Ust-Luga Sea Port of Saint-Petersburg Ust-Luga Multipurpose Reloading Complex Transportation Assets Management Moscow Volga Shipping Nizhny Novgorod Taganrog Commercial Sea Port Tuapse Commercial Sea Port Western Shipping Kaliningrad Volgo-Baltic Logistics Vodohod Saint-Petersburg Nevsky Shipyard Shipyard OKA Tuapse Taganrog ManagementStevedoringShipping and Shipbuilding Vodohod Moscow 4

5 CONTAINER TERMINAL FSC Company Presentation 5 UCL Holding Overview Stevedoring Division Sea Port of St Petersburg Group of Companies General and dry bulk facilities (metals, coal, fertilizers, reefer, alumina) 300 specialized cranes, 80 gantry cranes with the lifting capacity up to 40 tons, floating crane with the lifting capacity of 300 tons Land area over 150 ha, berth total length of m Throughput in mln. tons Ust-Luga Universal Transshipping Complex Dry bulk facility 9 gantry cranes with the lifting capacity of tons, 9 fork lift trucks with the lifting capacity of tons Land area 16 ha, berth total length of 585 m Installed capacity 4 mln. tons Tuapse Commercial Sea Port General, liquid and dry bulk facilities (metals, oil, coal, grain, sugar) 29 gantry cranes with the lifting capacity of 6-60 tons, 44 specialized cranes Berth total length of m Throughput in 2009 about 18,5 mln. tons Taganrog Commercial Sea Port General, liquid, dry bulk, and container facilities Equipment with the lifting capacity of 5-32 tons Berth total length of m Throughput in 2009 above 1,3 mln. tons

6 CONTAINER TERMINAL FSC Company Presentation 6 Container Terminal FSC Transportation Network ESTONIA 150 km High Speed Motor-roads Baltic Sea Gulf of Finland Federal Highways MOSCOW 710 km LATVIA 520 km Container Terminal FSC Railways City prospects M 11M 20M 10 Railhead AVTOVO Highways code M 20 2 km Western High Speed Diameter (in 2014) FINLAND 200 km Port St. Petersburg Area

7 CONTAINER TERMINAL FSC Company Presentation 7 Container Terminal FSC Terminal Layout Customs Office Clients Services Main Gate Clients Parking Customs Inspection Area Internal Railways Terminal Office Trailer Parking

8 CONTAINER TERMINAL FSC Company Presentation 8 Container Terminal FSC Terminal Specifications Total area sq. m Quay length m Max. depth - 11 m Max. vessel length m Storage capacity TEUs Reefer plugs units Railway lines - 2 х 480 m Designed capacity TEUs EquipmentQuantity Ship-to-Shore (STS) Gantry Cranes 4 Rubber-Tyred Gantry (RTG) Cranes 10 Terminal tractors 12 Empty container handlers 2 Reachstackers 2 Facilities and Equipment

9 CONTAINER TERMINAL FSC Company Presentation 9 Containers handling Storage Customs, veterinary and pre-trip inspections Weighting of containers Energy supply and monitoring of refrigerated containers Real-time container tracking Offices for rent Security Container Terminal FSC Terminal Services

10 CONTAINER TERMINAL FSC Company Presentation 10 Container Terminal FSC Digital signature solutions decrease terminal’s costs on stuff and minimize time for containers handling operations Ability to receive notification from linear agents through EDIFACT exchange protocols minimizes time for document processing, reduces data input errors For terminal customers web service provides on-line information on operations and container movements carried out 24 hours Timeslot and auto-visit systems reduce downtime of vessels, trains and trucks and speed up freight turnover IT Solutions

11 CONTAINER TERMINAL FSC Company Presentation 11 Container Terminal FSC Photo gallery

12 CONTAINER TERMINAL FSC Company Presentation 12 Further development till 2014 Terminal Specifications Total area sq. m Quay length m Max. depth - 14 m Max. vessel length m Storage capacity TEUs Reefer plugs units Railway lines - 2 х m Designed capacity TEUs Equipment Quantity Ship-to-Shore (STS) Gantry Cranes 10 Rubber-Tyred Gantry (RTG) Cranes 38 Rail Mounted Gantry Cranes 5 Terminal tractors 91 Empty container handlers 9 Straddle Carriers 3 Reachstackers 6 Facilities and Equipment

13 CONTAINER TERMINAL FSC Company Presentation 13 Further development till 2014 Current Terminal Area Master Plan

14 CONTAINER TERMINAL FSC Company Presentation 14 Contacts UCL Holding Alexander Scherbinin +7 (495) Forth Stevedoring Company Olga Ansberg +7 (812)
