Legg-Calve-Perthes Disease (coxa plana, osteochondrosis capitis femoris avascular necrosis of the femoral head)

Similar presentations


Presentation on theme: "Legg-Calve-Perthes Disease (coxa plana, osteochondrosis capitis femoris avascular necrosis of the femoral head)"— Presentation transcript:

1 Legg-Calve-Perthes Disease (coxa plana, osteochondrosis capitis femoris avascular necrosis of the femoral head)

2 Definition Idiopathic osteonecrosis of the capital femoral epiphysis of the femoral head of unknown aetiology. It is a self-limited disease.

3 Etiology Infection, trauma, synovitis Infection, trauma, synovitis Disruption of blood flow to capital femoral epiphysis (CFE)‏ Disruption of blood flow to capital femoral epiphysis (CFE)‏ Systemic disorder (delayed skeletal maturation, abnormalities of thyroid hormone and insulin like growth factor Systemic disorder (delayed skeletal maturation, abnormalities of thyroid hormone and insulin like growth factor Hereditary influence, environmental influence, hyperactivity Hereditary influence, environmental influence, hyperactivity

4 Blood flow to CFE

5 Epidemiology One in 1200 children younger than 15 years is affected by LCPD One in 1200 children younger than 15 years is affected by LCPD Males are affected 4-5 times more often than females Males are affected 4-5 times more often than females LCPD most commonly is seen in persons aged 4-8 (2-12) years, with a average age of 7 years LCPD most commonly is seen in persons aged 4-8 (2-12) years, with a average age of 7 years Bilateral involvment % Bilateral involvment %

6 Pathology The blood supply to the capital femoral epiphysis is interrupted (arteries and veins). The blood supply to the capital femoral epiphysis is interrupted (arteries and veins). Bone infarction occurs, especially in the subchondral cortical bone, while articular cartilage continues to grow. (Articular cartilage grows because its nutrients come from the synovial fluid.)‏ Bone infarction occurs, especially in the subchondral cortical bone, while articular cartilage continues to grow. (Articular cartilage grows because its nutrients come from the synovial fluid.)‏ Revascularization occurs, and new bone ossification starts. Revascularization occurs, and new bone ossification starts. Changes to the epiphyseal growth plate occur secondary to the subchondral fracture. Changes to the epiphyseal growth plate occur secondary to the subchondral fracture.

7 Symptoms Painless limp Painless limp Hip or groin pain, which may be referred to the thigh Hip or groin pain, which may be referred to the thigh Mild or intermittent pain in anterior thigh or knee Mild or intermittent pain in anterior thigh or knee Usually no history of trauma Usually no history of trauma

8 Symptoms Decreased range of motion (ROM), particularly with internal rotation and abduction Decreased range of motion (ROM), particularly with internal rotation and abduction Painful gait Painful gait Atrophy of thigh muscles secondary to disuse Atrophy of thigh muscles secondary to disuse Muscle spasm- mild hip contracture of degrees may be present Muscle spasm- mild hip contracture of degrees may be present

9 Symptoms Leg length inequality due to collapse Leg length inequality due to collapse Thigh atrophy: Thigh circumference on the involved side will be smaller than on the unaffected side secondary to disuse (Trendelenburg sign)‏ Thigh atrophy: Thigh circumference on the involved side will be smaller than on the unaffected side secondary to disuse (Trendelenburg sign)‏

10 Trendelenburg sign

11 Diagnosis Clinical presentation, physical examination Clinical presentation, physical examination RTG- A-P, frog-leg lateral views (every 6 weeks at the beginning, every 3-6 months later)‏ RTG- A-P, frog-leg lateral views (every 6 weeks at the beginning, every 3-6 months later)‏ USG- synovitis USG- synovitis MRI, artrography MRI, artrography

12 Stages – radiographic presentation 1. Ischaemia / Necrosis 2. Fragmentation / Resorption 3. Reossification / Healing 4. Residual stage

13 Initial stage- necrosis Decreased size of ossification center Decreased size of ossification center Lateralization of femoral head Lateralization of femoral head Subchondral fracture Subchondral fracture Physeal irregularity Physeal irregularity

14 Fragmetation- resorption Fragmented epiphysis Fragmented epiphysis More irregular acetabular contour More irregular acetabular contour

15 Reossification- healing New bone formation- the bone density returns New bone formation- the bone density returns

16 Residual stage Reossified femoral head Reossified femoral head Remodeling of the head shape Remodeling of the head shape Remodeling of the acetabulum Remodeling of the acetabulum

17 Catterall classification Stage 1: Antero-medial portion of head involved and no collapse, metaphyseal changes do not occur and the epiphyseal plate is not involved Antero-medial portion of head involved and no collapse, metaphyseal changes do not occur and the epiphyseal plate is not involved Heal without significant sequelae Heal without significant sequelae Stage 2: More head involved and may - fragmentation of the involved segment More head involved and may - fragmentation of the involved segment The involved segment shows increased density and uninvolved pillars of normal bone prevent significant collapse - regeneration without much loss of height and the end result is usually good. Metaphyseal reaction localised The involved segment shows increased density and uninvolved pillars of normal bone prevent significant collapse - regeneration without much loss of height and the end result is usually good. Metaphyseal reaction localised

18 Catterall classification Stage 3: More of the head involved - collapse as uninvolved pillars not large enough t prevent collapse More of the head involved - collapse as uninvolved pillars not large enough t prevent collapse May show head within a head May show head within a head The metaphysis is usually diffusely involved - broad neck and the epiphyseal plate is unprotected and also usually involved - results poorer The metaphysis is usually diffusely involved - broad neck and the epiphyseal plate is unprotected and also usually involved - results poorer Stage 4: Whole head involvement and severe collapse occurs early and restoration of the femoral head usually less complete Whole head involvement and severe collapse occurs early and restoration of the femoral head usually less complete The metaphyseal changes may be extensive The metaphyseal changes may be extensive The epiphyseal plate is often involved - abnormal growth (coxa magna, coxa breva, coxa vara and coxa valga) The epiphyseal plate is often involved - abnormal growth (coxa magna, coxa breva, coxa vara and coxa valga)

19 Herring classification Lateral pillar clasification Lateral pillar clasification Detrmine treatment and prognosis Detrmine treatment and prognosis

20 Salter - Thompson Classification Stage A: - Lateral portion of femoral capital epiphysis present - less than 50% head involved Stage A: - Lateral portion of femoral capital epiphysis present - less than 50% head involved Stage B: - Lateral portion of femoral capital epiphysis absent - more than 50% head involved (Lateral margin of epiphysis protects epiphysis from stress)‏ Stage B: - Lateral portion of femoral capital epiphysis absent - more than 50% head involved (Lateral margin of epiphysis protects epiphysis from stress)‏

21 Differential diagnosis

22 Mose method If head conforms to a single ring in both X- Ray planes - good prognosis If head conforms to a single ring in both X- Ray planes - good prognosis If head varies from perfect circle by no more than 2mm - fair results If head varies from perfect circle by no more than 2mm - fair results If head varies by more than 2mm in any plane - poor results If head varies by more than 2mm in any plane - poor results

23 Neck-shaft angle

24 Centre-edge angle (Wiberg`s angle)

25 Centre-edge angle 5-8 years ~19 degrees 5-8 years ~19 degrees 9-12 years ~25 degrees 9-12 years ~25 degrees years degrees years degrees

26

27

28

29

30 Goal of treatment Preservation of the roundness of the femoral head and prevention of deformity while the condition runs its course. Preservation of the roundness of the femoral head and prevention of deformity while the condition runs its course.

31 Conservative treatment Relieve weight bearing Relieve weight bearing Achieve and maintain ROM Achieve and maintain ROM Containment of the femoral epiphysis within the confines of the acetabulum (Petrie-style casts, Atlanta /Scottish Rite/ brace, Toronto brace and other orthotic devices)‏ Containment of the femoral epiphysis within the confines of the acetabulum (Petrie-style casts, Atlanta /Scottish Rite/ brace, Toronto brace and other orthotic devices)‏

32 Conservative treatment

33

34

35 Surgical treatment Femoral osteotomy = varus +/- derotation to reduce the degree of anteversion & extension. Femoral osteotomy = varus +/- derotation to reduce the degree of anteversion & extension. Pelvic osteotomy (Salter, Chiari, Shelf) or Femoral osteotomy have similar results Pelvic osteotomy (Salter, Chiari, Shelf) or Femoral osteotomy have similar results

36 Surgical treatment Shelf acebuloplasty

37 Surgical treatment Salter osteotomy Salter osteotomy

38 Very good radiographic results befrore surgery (7 years 2 months)‏

39 Very good radiographic results 3 years after surgery

40 Very good radiographic results 6 years after surgery

41 Poor radiographic result before surgery (7 years 8 months)‏

42 Poor radiographic result 6 months after surgery

43 Poor radiographic result 8 years after surgery
