1 Engine Choose a Number 23 End = Esc

2 PISTON

3 CYLINDER

4 Combustion Chamber

5 LUBRICATION

6 Oil Pan Crank Shaft PISTON

7 The Crank shaft rotates in the oil pan and splashes Oil on to the pistons.

8 Both sides are lubricated in order to Reduce friction.

9 Basic Operaion A motor has several cavitvities called cylinders. The piston moves up and down in the cylinder Thus converting vertical movement into rotary movement. This rotary movement is transfered to The wheels through a gear box to the wheels

10 The fuel is mixed with air in the carburetor. The air/ fuel mixture is Then put in the cylinders. This is called the Intake Stroke

11 Now the explosive mixture is in the cylinder, it must be crompressed prior to combustion. The piston compresses, thie mixture. This is called the: Compression Stroke

12 At an exact time, the spark plug ignites the mixture. This is called the: Ignition. Stroke

13 The piston is forced down violently during the ignition stroke then rises again to expell the Burned gasses. This is the: Exhaust Stroke

14 Four Valves

15 Direct injection: JTD, TDI, HDI

16 Crank shaft and piston

17 MOTOR TURBOCHARGER

18 TWIN TURBO: There are two turbine wheels on one axis. One is driven by the exhaust fumes, the other sucks the mixture and pumps it into the cylinder.

19 This increases the amount of air that injected into combustion chamber.

20 Before the INVENTION of the Turbo more cylinders were needed to boost performance.

21 Principle of the direct injection: the mixture is injected directly into the cylinder. The direct injection is possible by the use of a high pressure pump.

22 This is an example of an IN-LINE 4 CYLINDER Engine

23 The Cooling System
