1

2 Chapter Basic Refrigeration Cycle 11

3 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Objectives Draw a diagram of the basic refrigeration cycle. Describe the condition of the refrigerant in each component. Explain the purpose of each component of the refrigeration system. Identify refrigeration system component variations.

4 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Basic Refrigeration System All systems control refrigerant flow Basic refrigeration cycle –Refrigerant absorbs unwanted heat at one location and releases it at another location Refrigerants absorb heat by evaporating and release heat through condensing A thorough understanding of system operation is needed to be a technician

5 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Refrigeration System Components

6 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Evaporator A heat-exchanging device located in the conditioned space Performs the main purpose of the system: refrigeration Liquid refrigerant entering the evaporator leaves as a vapor

7 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Superheat Temperature above saturation point Normal superheat at the evaporator outlet is 10°F (5.5°C) –Provides maximum cooling effect and prevents liquid from leaving the evaporator

8 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Evaporator Temperature Difference Refrigerant inside evaporator tubing is in a low-temperature, low-pressure saturated condition Evaporator temperature difference (td) must exist for heat to transfer from hot to cold

9 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Suction Line Usually made of copper tubing Connects evaporator outlet to compressor inlet Insulated to prevent condensation and additional, unwanted superheat Contains low-temperature, low-pressure superheated vapor

10 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Compressor Separates low-pressure from high-pressure side Removes vapor from evaporator to maintain its low boiling point Compresses and moves gas through system Reciprocating type is most common

11 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Hot-Gas Discharge Line Copper tubing that carries discharged hot gas from the compressor to the condenser Smaller than suction line because the gas has been compressed to a smaller volume and higher pressure Hottest part of the system outside the compressor

12 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Condenser A heat exchanger, designed to release heat Purpose is to remove heat from the superheated refrigerant vapor –Causing vapor to condense back to a liquid Can be air-cooled or water-cooled

13 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. High Pressure in Condenser Raises the saturation point of the refrigerant so that ambient air can: –Remove superheat to the saturation point (sensible heat, lowering temperature) –Remove enough heat to cause the refrigerant to condense back to a liquid (latent heat) –Remove enough heat to partially subcool the liquid before it leaves the condenser (sensible heat, lowering temperature again)

14 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Liquid Line Copper tubing line connects the condenser outlet to the refrigerant metering device Should contain only liquid refrigerant (no vapor) subcooled 10°F (5.5°C) Liquid refrigerant is still under high pressure, and tubing is slightly warm to the touch Refrigerant inside is a high-temperature, high- pressure, subcooled liquid

15 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Refrigerant Metering Device Controls the flow of liquid refrigerant into the evaporator to ensure that all liquid is boiled off before it enters the suction line Second division point: between the high- and low- pressure sides of the system Various types of refrigerant metering devices available for different applications

16 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Condition of Refrigerant in Each Component

17 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Evaporators Manufactured in many shapes and sizes to fill specific design or operational needs Can operate on the principles of conduction or convection Convection can be natural or forced Classified into five types –Shell, Shelf, Wall, Plate, Finned-tube with forced convection

18 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Evaporator Types Shell-type –Tubing run along the inner wall of freezing compartment to form a shell Shelf-type –Aluminum tubing forms shelves inside a freezer Wall-type –Used in chest-type domestic freezers –Tubing attached to the surface of inner cabinet

19 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Evaporator Types (Cont.) Plate-Type –Not commonly used –Refrigerant flows through plates –Uses natural convection Finned tube with forced convection –Most widely used in all applications –Allows much refrigeration with a small evaporator –Fins increase surface area

20 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Suction Line Factors determining size of suction line –Refrigerant velocity, pressure, volume, density, and pressure drop Very long line or having many bends can increase pressure drop Line should be installed to help all circulating oil return to the compressor

21 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Suction Line Insulation To limit uncontrolled superheating of gas that would reduce compressor efficiency To eliminate condensation that could cause frost and ice problems

22 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Compressor Styles Open –Belt-driven or directly driven (using a coupling) by an external electric motor Semihermetic –Electric motor and compressor sealed within –May be disassembled and opened for service Hermetic –Motor and compressor sealed in a solid steel body –May not be opened for service

23 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Condensers Must remove heat from refrigerant at same rate heat is being absorbed For proper condenser operation, compressor must increase refrigerant pressure to saturation temperature –30°F to 35°F (17°F to 19°C) higher than ambient air entering the condenser (for air-cooled) –20°F (11°C) higher than temperature of the water exiting the condenser (water-cooled)

24 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Condenser Cooling Stages First, the superheat of the gas is removed, cooling the gas down to the saturation point –Sensible heat removed Second, the gas is condensed to a liquid –Latent heat removed Third, the liquid is subcooled below its saturation point –Sensible heat removed

25 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Domestic Condensers Finned-tube, forced convection –Most commonly used condenser –Fan creates airflow for convection Wire static –Natural convection with wires attached to tubing Wall static –Natural convection with a box inside a box, having condenser tubing mounted along outer wall

26 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Commercial Air-Cooled Condensers Heat is removed through airflow Most common type is forced convection Vary greatly in size, style, and capacity Some mounted vertically, some horizontally

27 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Commercial Water-Cooled Condenser Heat is removed through conduction into flowing water Very efficient at cooling refrigerant Water-related problems Types available –Tube-in-a-tube –Tube-in-a-shell –Coil-in-a-shell

28 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Cooling Tower Lowers water temperature for reuse in a water-cooled condenser Usually located outdoors where ambient air can cool the water

29 Copyright Goodheart-Willcox Co., Inc. May not be posted to a publicly accessible website. Water-Regulating Valve Controls amount of water traveling through the condenser A bellows and diaphragm assembly connects by capillary tube to the high-pressure side of the compressor As head pressure increases, the valve opens more to permit more waterflow Spring tension is adjustable and permits control of head pressure
