Emergency Radiology What to order, When DR ADNAN AHMED MBBS, FCPS Assistant Professor Department of Radiology and Imaging LUMHS, Jamshoro.

Similar presentations


Presentation on theme: "Emergency Radiology What to order, When DR ADNAN AHMED MBBS, FCPS Assistant Professor Department of Radiology and Imaging LUMHS, Jamshoro."— Presentation transcript:

1

2 Emergency Radiology What to order, When DR ADNAN AHMED MBBS, FCPS Assistant Professor Department of Radiology and Imaging LUMHS, Jamshoro

3 Emergency Radiology What are the different Radiological investigation to order In different Emergency situations

4 Emergency Radiology Common Topics CNS Emergencies Face & Neck Emergencies. Spinal Emergencies. Chest Emergencies. Cardiovascular Emergencies. Abdominal Emergencies. Gynecological & Obstetrical Emergencies. Male Genitourinary Emergencies. Pelvic Emergencies. Extremities Emergencies. Pediatric Emergencies

5 Emergency Radiology CNS Emergencies: Skull Fractures Hemorrhage: (Traumatic–NonTraumatic) Extra-axial Parenchymal Cerebral infarction. Spinal trauma

6 Emergency Radiology CNS Emergencies: Skull Fractures: What to order: Plain X-ray of the skull (AP-lateral view) Computed tomography of the Brain (Axial – Coronal) (bone window) When: History of trauma – evident injury of the scalp

7 Emergency Radiology Skull fractures (Plain X-ray)

8 Emergency Radiology Skull Fractures (CT Scan)

9 Emergency Radiology Skull Fractures (CT Scan)

10 Emergency Radiology CNS Emergencies: Hemorrhage: Traumatic and Non Traumatic What to order: Computed tomography (CT) of the Brain Plain. When: Head trauma – focal neurological defect.

11 Emergency Radiology CNS Emergencies: Hemorrhage: Traumatic Findings in: Extra Dural Blood Sub dural Blood. Cerebral contusion.

12 Emergency Radiology

13

14

15

16

17

18

19 CNS Emergencies: Hemorrhage: Non Traumatic Findings in: Subarachnoid Blood Intraparenchymal Blood. Intraventricular Blood

20 Emergency Radiology

21

22

23

24 CNS Emergencies: Cerebral Infarction: What to order: Computed tomography (CT) of the Brain Magnetic Resonance Imaging (MRI) : DWI When: Focal neurological defect - Stroke

25 Emergency Radiology

26

27

28

29 Facial Emergencies: What to order? Plain X-ray of the Skull (Lateral view – PA view) Computed Tomography of the facial bones Bone window–Axial & coronal–3D recon.) When? History of trauma to the face – disfigurement – Severe facial contusions

30 Emergency Radiology

31

32

33

34

35

36

37 Orbital Injuries: What to order? Plain X-ray of the Skull (Lateral view – PA view) Computed Tomography of the Orbit (Axial Coronal - Bone & Soft tissue settings) When? History of trauma to the orbit – History of FB to the eye

38 Emergency Radiology

39

40

41

42 Spinal Emergencies: Trauma Vertebral fracture (Varieties) Spinal cord injuries.

43 Emergency Radiology Spinal trauma: What to order? Plain X-ray of the spine (Lateral view – AP view) Computed Tomography of the Spine (Bone & Soft tissue settings–3D recon.) MRI of the spine. (for cord injury) When? History of trauma – Falling from height.

44 Emergency Radiology

45

46

47

48

49

50

51

52 Chest Emergencies: Chest Trauma Rib fractures – Traumatic Hemothorax – pneumothorax – pneumomediastinum – pulmonary contusion, laceration & hematoma – Esophageal injury – diaphragmatic injury – etc. Airway Foreign Body.

53 Emergency Radiology Chest Emergencies: What to order? Plain X-ray of the Chest (PA view – Lateral view) Computed Tomography of the Chest Angiography (Aortography) When? History of trauma – Difficulty of breathing.

54 Emergency Radiology

55

56

57

58

59

60

61

62

63

64

65

66

67 Chest Emergencies: FB of the Airway: What to order? Plain X-ray of the Chest (PA view - Lateral view) Computed Tomography of the Chest When? Children – difficulty in breathing – Unconscious patient

68 Emergency Radiology

69

70

71

72 Cardiovascular Emergencies: CHF Pericardial effusion Aortic dissection, trauma. Pulmonary Edema Pulmonary Embolism. Peripheral ischemia (acute) DVT.

73 Emergency Radiology Cardiovascular Emergencies: CHF: What to order? Plain X-ray of the Chest (PA view - Lateral view) Echocardiography When? Dyspnea – signs of low cardiac output

74 Emergency Radiology

75

76 Cardiovascular Emergencies: Pericardial effusion: What to order? Plain X-ray of the Chest (PA view - Lateral view) Echocardiography When? Chest pain – friction rub – faint heart sounds on auscultation.

77 Emergency Radiology

78

79

80

81 Cardiovascular Emergencies: Aortic dissection: What to order? Plain X-ray of the Chest (PA view–Lat. view) CT scan. MRI Aortography When? Sudden severe tearing substernal chest pain

82 Emergency Radiology

83

84

85

86 Cardiovascular Emergencies: Acute peripheral ischemia: What to order? Arteriography Color doppler Ultrasound (chronic) When? Sudden onset of severe pain, coldness, numbness or pallor in a portion of an extremity.

87 Emergency Radiology

88

89 Cardiovascular Emergencies: DVT (Deep Vein Thrombosis): What to order? Color Doppler Ultrasound. Venography When? Asymptomatic – pain – edema – skin discoloration.

90 Emergency Radiology

91

92

93 Abdominal Emergencies: Abdominal Trauma Hemoperitonium Visceral injuries (Liver, Spleen, Kidney, UB, etc.) Non-Traumatic emergencies. Intestinal obstruction, Appendicitis, GUT perforation, Ascites, Jaundice, peritonitis, GI bleeding

94 Emergency Radiology Abdominal Emergencies: Abdominal trauma: What to order? Chest & Abdominal radiographs. Ultrasound (FAST) CT scan Arteriorgraphy. When? History of trauma to the abdomen – Motor vehicle accidents

95 Emergency Radiology

96

97

98

99

100

101

102

103

104

105

106 Abdominal Emergencies: Intestinal Obstruction What to order? Abdominal radiograph. CT scan When? Crampy abdominal pain – nausea & vomiting – abdominal tenderness.

107 Emergency Radiology

108

109

110

111

112

113

114 Abdominal Emergencies: Gut Perforation (e.g. Perforated DU) What to order? Abdominal radiograph (Erect). US CT scan When? History of peptic ulceration – signs of peritonitis

115 Emergency Radiology

116

117

118

119

120

121

122

123

124 Abdominal Emergencies: Jaundice What to order? Ultrasound CT scan PTHC ERCP When? Yellowish discoloration of the skin – dark urine – pale stools

125 Emergency Radiology

126

127

128

129

130

131

132 Abdominal Emergencies: Appendicitis What to order? Abdominal radiograph. Ultrasound CT scan When? Sudden onset of RIQ pain – rebound tenderness.

133 Emergency Radiology

134

135

136

137

138

139

140 Abdominal Emergencies: Cholecystitis What to order? Ultrasound (Gold standard) When? Sudden onset of epigastric pain – rebound tenderness

141 Emergency Radiology

142

143

144

145 Genitourinary Emergencies: UT stones Hematuria Urinary tract trauma. Urethral Injuries, stones (male) Scrotal injuries, swellings, testicular torsion, epididymitis (male)

146 Emergency Radiology Genitourinary Emergencies: Ureteric Stones (Renal Colic): What to order? Plain X-ray of the urinary tract (PUT) Ultrasound Intravenous Urography (IVU) CT of the abdomen When? Sudden onset of loin pain radiating to the groin.

147 Emergency Radiology

148

149

150

151

152

153

154 Genitourinary Emergencies: Hematuria (Painful-Painless): What to order? Plain X-ray of the urinary tract (PUT). Ultrasound. Intravenous Urography (IVU). CT of the abdomen. Cystogram. When? Passage of blood or blood clots with urination (either painful or painless).

155 Emergency Radiology

156

157

158

159

160

161

162

163

164

165

166

167 Genitourinary Emergencies: Urinary tract trauma (Renal Bladder male urethra): What to order? Plain X-ray of the urinary tract (PUT) Ultrasound Intravenous Urography (IVU) CT of the abdomen Ascending urethrocystography When? History of blunt trauma to the abdomen – Falling astride.

168 Emergency Radiology

169

170

171

172

173

174

175 Genitourinary Emergencies: Scrotal emergencies: What to order? Ultrasound with color Doppler. When? Acute scrotal pain – trauma to testis.

176 Emergency Radiology

177

178

179

180

181

182

183

184 Gyncological & Obstetric Emergencies: Ovarian Torsion PID Abortion Ectopic pregnancy Placenta Previa

185 Emergency Radiology Gyncological & Obstetric Emergencies: What to order? Ultrasound (Color Doppler) When? Lower abdominal pain – fever – vaginal discharge

186 Emergency Radiology

187

188

189 Obstetric Emergencies: What to order? Ultrasound (Color Doppler) When? Bleeding in early / late pregnancy

190 Emergency Radiology

191

192

193

194

195

196

197

198 Muscloskeletal Emergencies: Upper & lower extremities Fractures & dislocations Pelvic Fractures. Joint injuries Ligaments and tendons injuries.

199 Emergency Radiology Muscloskeletal Emergencies: What to order? Plain X-ray. CT scan. MRI When? History of trauma.

200 Emergency Radiology

201

202

203

204

205

206

207

208

209

210

211

212 Pediatric Emergencies: Neonatal emergencies (intestinal obstruction, Intussception.) Foreign body aspiration. Bone injuries.

213 Emergency Radiology

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231
