1 Topic 22 Plankton GEOL 2503 Introduction to Oceanography

2 Characteristics Floating organisms that drift with currents (although some forms are weak swimmers) Generally microscopic although some forms larger Largest biomass on the planet 2

3 A micrometer (  m) is one millionth of a meter, one thousandth of a millimeter 3

4 4

5 Reason for small size Related to buoyancy. The smaller an organism the greater the surface area relative to weight Surface area often increased by development of pores or spines Flotation sometimes improved by secretion of low density oil Rely on turbulence to stay afloat 5

6 Bacterioplankton Kingdom Monera, smallest living organisms. Difficult to capture even with finest net Most abundant organisms (planet & ocean) Live at all ocean depths as free-living decomposers 6

7 Phytoplankton Floating plants 99.9% of the food source in the oceans Mainly protista living in epipelagic zone Diatoms—siliceous plants Dinoflagellates—microscopic with flagella for minor locomotion Cocolithophores—calcareous plants 7

8 Plankton are an energy source for marine ecosystems Many plankton are primary producers. Over 90% of marine primary production (energy produced) is from phytoplankton! The rest is from marine plants and other sources. This map shows productivity in the Oceans. Red and yellow are most productive, followed by green and blue. Black is least productive. Photo: NOAA 8

9 9

10 10 Coccolithophore: calcareous phytoplankton

11 Diatoms Single celled photosynthetic Protista which secrete small shell of SiO 2 Reproduce by cell division until organism becomes too small; then develop auxospore May discolor water during large blooms 11

12 Marine diatoms as seen through a microscope. Image ID: corp2365, NOAA At The Ends of the Earth Collection Photographer: Dr. Neil Sullivan, University of Southern Calif. 12

13 Centric diatoms Chain diatoms 13

14 Diatoms and other phytoplankton can divide many times per day producing large blooms that are sometimes visible from space. Blooms 14

15 Dinoflagellates Single celled Protista (most but not all photosynthetic) Naked cell or covering of cellulose Two whip-like flagella allow motility Some forms bioluminescent Blooms responsible for toxic red tides 15

16 16

17 17

18 18

19 Sargassum--brown algae 19

20 Zooplankton Floating animals (consumers) Most abundant in epipelagic zone but also occur in mesopelagic zone Foraminifera—single celled, calcareous Radiolaria—single celled, siliceous Krill—shrimp-like, food for baleen whales Jellyfish—multicellular, colonial 20

21 Foraminifera & Radiolaria Microscopic Protista which feed on phytoplankton Foraminifera secrete shell of CaCO 3 Radiolaria secrete shell of SiO 2 21

22 Foraminifera—calcareous zooplankton 22

23 Foraminifer 23

24 24

25 Radiolaria—siliceous zooplankton 25

26 26 A living radiolaria

27 Medusa jellyfish 27

28 Moon Jelly Gelatinous zooplankton common in temperate and tropical waters, stinging cells are not toxic and don’t sting like other jellyfish, 95% water but serve as food for many animals including turtles, feed by producing a sticky mucus that traps other plankton Image ID: reef2547, NOAA's Coral Kingdom Collection Photographer: Florida Keys National Marine Sanctuary Staff Credit: Florida Keys National Marine Sanctuary (moon jelly) 28

29 Siphonophore 29

30 30 Comb jelly

31 31 Simple crustacean with jointed exoskeleton Use enlarged first antenna to swim Among the most common animals on Earth (most abundant of the net zooplankton) Image ID: fish3229, NOAA's Fisheries Collection Photographer: Matt Wilson/Jay Clark, NOAA NMFS AFSC Copepod

32 Not as abundant as copepods they aggregate into huge, dense schools, prefer colder polar waters, feed on diatoms and solid wastes of other zooplankton, important food for whales, tread water to stay afloat. Image ID: sanc0126, NOAA's Sanctuaries Collection Location: Gulf of the Farallones National Marine Sanctuary Photographer: Jamie Hall 32 Krill

33 Pteropods (mollusks) 33

34 Holoplankton Regular old plankton Spend their entire life cycle as plankton Examples include: dinoflagellates, diatoms, foraminifera, krill 34

35 Meroplankton Planktonic larval stages of animals which are not planktonic as adults Larvae of snails, fish, barnacles, coral, etc. Egg cases 35

36 Crab Larva Some invertebrates have a whole series of different larval stages Charleston Bump Expedition. Zooplankton. Crab larva. Image ID: expl0215, Voyage To Inner Space - Exploring the Seas With NOAA Collect Location: Southeast of Charleston, South Carolina Photo Date: 2003 August 10 Photographer: Jerry Mclelland Credit: Charleston Bump Expedition 2003. NOAA Office of Ocean Exploration; Dr. George Sedberry, South Carolina DNR, Principal Investigator 36

37 Brittle star larvaSkate egg case 37

38 Octopus Larva Temporary members of the plankton, octopus and squid become nektonic (free swimming) and benthic (crawling). Giant squid are the largest invertebrates in the ocean Zooplankton. Octopus larva. Image ID: fish3612, NOAA's Fisheries Collection Photographer: Matt Wilson/Jay Clark, NOAA NMFS AFSC 38

39 Barnacle Larva 39

40 40 Fish Larvae Coastal waters are rich in meroplankton (temporary members of the plankton) Nearly all marine fish have planktonic larvae Fish larvae may change from herbivores to carnivores as they grow Image ID: fish3363, NOAA's Fisheries Collection Photographer: Matt Wilson/Jay Clark, NOAA NMFS AFSC
