1 DESIGN OF AIRFOILS FOR WIND TURBINE BLADES Presented by Parezanovic Vladimir Faculty of Mechanical Engineering Belgrade University

2 The Objectives Simulate the airflow around selected well- known airfoils Obtain sufficient level of agreement between experimental and simulated data Introduce “Virtual Prototyping” into the design process

3 The process Importing or designing the geometry Generating the mesh Computational model setup Iteration and monitoring Results Post-processing

4 Geometry and airfoils Geometry is designed or imported Airfoils investigated:  NACA 63(2)215  FFA-W3-211  A-Airfoil

5 Mesh generation The resolution of the mesh can affect computations in many ways, most important are:  Accuracy  Computing time Some facts about mesh used:  Around 14000 elements  160 elements on the airfoil  Quadrilateral shaped cells  Cell size varies from 0.002 m 2 up to 1.6 m 2

6 Flow conditions Conditions corresponding to those in wind tunnel experiments:  Low Reynolds number (1.8 - 3.0x10 6 )  Free flow velocities around 25m/s  Low turbulence intensity

7 Numerical model What kind of flow is modeled? To what level of approximation? What is expected to happen? Setup in this case: For NACA 63(2)215 and FFA-W3-211 model is fully turbulent Laminar/turbulent transition modeled for A-Airfoil k-ω SST turbulence model is used in all cases

8 Lift and pitching moment coeff. curves (left), Drag coefficient curve (right) (A-Airfoil) A-Airfoil Lift and pitching moment coeff. curves (left), Drag coefficient curve (right) NACA63(2)215 NACA63(2)215 Results Lift and pitching moment coeff. curves (left), Drag coefficient curve (right) (FFA-W3-211) FFA-W3-211

9 Interpretation Simulation results agree with experimental data to within 10% The model is more exact for airfoils less susceptible to laminar/turbulent transition effects Lift easier to predict than drag A model with the ability to predict laminar/turbulent transition is needed

10 So, you’ve gotten your results… Then what?

11 What was all this about? MONEY! EFFICIENCY ENVIRONMENT

12 QUESTIONS?
