1 AMSZ – OPTRON Presentation Etienne Coetzee

2 Page 2 of 2 Index Trimble Overview Optron Overview Total Stations – Trimble M3 DR Total Station – Nikon Nivo C Total Station – Trimble Access – PROMINE GNSS Solutions – GNSS overview Scanning – Overview – Void Scanner – Quarryman – Bore Track

3 Page 3 of 3 Trimble Overview Founded in 1978 as early GPS pioneer Global leadership in core markets, with 900 patents Complete suite of hardware and software solutions Value proposition – transformation of work processes that drive productivity and profitability Track record of consistent financial performance > 3500 employees worldwide

4 Page 4 of 4 Optron Overview Established in 1986 Trimble dealer for 24 years (1989) Staff complement of > 50 people, 45% of staff have professional/technical degrees/diplomas – tertiary qualifications Offices in Centurion, Cape Town, Durban and a network of re- sellers/agents throughout sub-Saharan Africa Factory trained, certified and dedicated Technical Support Services personnel - Level 3 certified service centre

5 Page 5 of 5 Mechanical Total Stations

6 Page 6 of 6 Trimble DR M3 Total Station Compact lightweight and reliable Total Station Excellent for demanding survey applications Ensure productivity with powerful Trimble Access onboard Now also available with PROMINE underground software

7 Page 7 of 7 M3 Positioning Performance Up to 500m DR measurements 3000m Prism distance 2mm + 2ppm Available in multiple angle accuracies (1”, 2”, 3” and 5”) Choices between Optical and Laser Plummet

8 Page 8 of 8 Nikon Nivo C series Total Station Extended EDM Range : 500m Reflectorless 5000m Single Prism 5” / 3” / 2” / 1” Models Distance ±(2+2ppm x D) mm High Quality NIKON Optics

9 Page 9 of 9 Trimble Access Field Software Powerful, functional, modular field software Familiar workflows Easy-to-use interface Streamlined workflows for specialized applications -Roads -Tunnels -Land Seimic

10 Page 10 of 10 Station Set-up BS Check BS Check + Resection Traverse / Peg Survey Multiple BS / FS Option Line Pegs Grades Grade Lines FIELD Application

11 Page 11 of 11 Advanced Features include: Detailed User Set-Up / Security o Password Protection o Tolerance Profile o Permissions / Access Control User-definable Tolerance Profiles (Administrator) Control File Easy-to-use Graphic Interface FIELD Application

12 Page 12 of 12 Off-Sets Stake-Out Coordinates Raw Data Reference Line Remote Height Height Transfer Remote Line FIELD Application

13 Page 13 of 13 GNSS Portfolio

14 Page 14 of 14 GNSS Portfolio Overview Trimble R10Trimble R8Trimble R6Trimble R4 Channels Tracking TechnologyTrimble 360 R-Track GPSL1/L2/L2C/L5 L1/L2/L2C GLONASS●●$$$ GALILEO●●$$$ BEIDOU●●$$$ QZSS●●●● Internal Memory4 GB56 MB11 MB HD-GNSS●--- SurePoint●--- xFill●--- Update Rate20 Hz 10 Hz Web UI●●-- Remote Configuration●●-- Internal Rx Radio●●●● Internal Tx Radio●●$$$ ControllerTSC3 / Tablet / TCU Trimble Slate Field SoftwareTrimble Access Trimble Access (GNSS only)

15 Page 15 of 15 Scanning:

16 Page 16 of 16 Under Ground Scanning Major safety concern is the presence of open stopes (voids) 3D laser based surveying instruments are the standard for stope (cavity) surveying. 3D scanning greatly improved safety and quality of stope surveys - Standard method - Over 200 systems deployed in Australia 3D Scanning Improves Safety

17 Page 17 of 17 Void Scanner VS-150 Mk VS-150 – Underground in South Africa 150m Range to Passive Targets Accuracy typical 5cm Range resolution 1cm Scan rate 200 points per second Horizontal scan 360° Vertical scan 270° Red Laser Pointer

18 Page 18 of 18 Quarryman Applications: 3D mapping of entire quarry / mine sites 3D rock face profiling Blast design and volumetric surveying of stockpiles and reserves Drilling and blasting burden determination Blast evaluation Earth moving and land reclamation surveys Tunnel profiling A reflectorless rock profiling and 3D laser scanning system

19 Page 19 of 19 Borehole Tracking for Drill and Blasting The cable and Rodded Boretrak® systems have been developed as a means of auditing the results of drilling activity quickly and accurately. Cabled Boretrak®Rodded Boretrak®

20 Page 20 of 20 Other Solutions:

21 Page 21 of 21 Optron’s Monitoring Solutions Trimble hardware Trimble software Optron’s enclosures Optron’s system integration Optron’s maintenance and support

22 Page 22 of 22 TOP Design

23 Page 23 of 23 QUESTIONS ? Thank you
