Presentation on theme: "HP MSA P2000 G3 Family Presentation"— Presentation transcript:
1 HP MSA P2000 G3 Family Presentation NameTitleDate
2 Agenda HP MSA P2000 G3 Concept and portfolio Use Cases Which customer pain points does MSA solve?HP Technology ServicesMaintaining the customer experience
3 HP Storage Array portfolio Enterprise Application ConsolidationVirtual IT DeploymentData Center ConsolidationRemote office consolidation/Low cost consolidationCloud/ Service ProvidersMSA P20003PAR StoreServEVA P6000XP P9500StoreVirtualLow cost storage consolidationWEB, Exchange, SQLController-based snapshot/clone/ mirroringWindows, Linux, VMwareFC, iSCSI, SASSFF & LFF drivesSAS & SATA togetherScale-out SAN for Virtualized ITClustered architecture with multi-site high availabilityAll Inclusive SoftwareCost effective ROBO DRBest BladeSystem SANVMware, Citrix, Hyper-V, Windows, LinuxiSCSISAS, SATATier 1 Storage for Cloud and Utility ComputingClustered architectureLeading virtualization & VMware integrationBest Thin ProvisioningAutonomic TieirngAutonomic Management & multi-tenant capabilityFC & iSCSI host portsSDD, FC & SATA HDDTrusted Enterprise Application ConsolidationStorage consolidation + disaster recoverySimplification through virtualizationBest BladeSystem Matrix IntegrationWindows, VMware HP-UX, Linux, + moreFC & iSCSI host portsSAS and Midline SAS HDDConsolidate Mission Critical Storage & maintain application SLAsData center consolidation + disaster recoveryLarge-scale Oracle/SAP applicationsAutomated TieringAPEX application QOSHP-UX, Windows, + 20 more, including NonStop & mainframeSSD, SAS, Midline HDDHP MSA P2000: Elevator PitchThe P2000 G3 MSA arrays are :Designed for entry-level customersThe latest in functionality and host-connect technologyExcellent price/performanceIdeal for :companies with small budgets or limited IT expertiseLarger companies with departmental or remote requirementsEasy to deploy, secure, and with low management costsRapid return on investment through efficient storage consolidation3
4 HP MSA P2000 G3 StorageMSA Family has shipped its 300,000th unit in Q2 2012Reliably meets the needs of customers for 10+ yearsFlexibility & Scalability MSA P2000 G3 has shaped the Low-End SAN Segment since its introductionMid-Range Features – Entry-Level Budget P2000 continues to deliver new functionalityData Security Built-in Controller-based snapshots Local Snapshots Volume Copy Remote ReplicationRespond to Change Scale and evolve as your needs grow Investment Protection Data in place upgradesMSA P2000 G3 Family Value PropositionThe MAS P2000 G3 is the most competitive entry-level storage array in the market.Flexibility and ScalabilityLFF 12- and SFF 24-drive bay chassis, AC and DC power versionsSAS, SAS MDL, and SATA MDL drives to match customer needsStart small with a single controller, and a couple of drives, and grow with your needs and budgetHigh PerformanceThe P2000 G3 models deliver dramatically increased throughput compared to older generationsThe P2000 G3 family brings the latest technology (10Gb iSCSI, 8Gb FC, 6Gb SAS, 8Gb FC/1Gb iSCSI Combo controller) to the entry segment that has previously only been available in the mid- and high-end marketStrengthen Data SecurityIncreased snapshots and added Remote SnapAll P2000 G3 models include Snapshot & Clone standardAll P2000 G3 models include 2GB read/write cache – no expensive upgradeUnmatched compatibilityMatch all your components from ProLiant and BladeSystem servers, switches, and arrays from one source for unmatched compatibilityHP MSA P2000 G3Ideal solution for entry level server consolidationCustomers looking for simplified managementCustomers with budget limitationsStart small and grow with your needs
5 Key MSA P2000 G3 Product Highlights 11 April 2017Key MSA P2000 G3 Product HighlightsDual controller active-active architecture5 controller types: 8Gb FC, 1GbE or10GbE iSCSI, Combo (8Gb FC/1GbE iSCSI), 6Gb SAS6Gb SAS internal infrastructure (to the drives)Support for LFF and/or SFF hard drivesExcellent scalability/investment protection – up to 96 LFF, 149 SFF drives, data-in-place upgradesIndustry Leading Hardware Architecture – G3 ArchitectureReleased snapshot services (local and remote) – all controllers (Remote Snap not support on SAS)64 Snapshots and Volume Copy standard, upgradeable to 512 SnapsEmbedded SMI-S storage management providerDrive spin down feature: policy based feature saves powerSoftware Features and Data ServicesWed-based GUI: full configuration, provisioning, metrics, robust CLI command setEmbedded and host-based management tools (FW Advisor, Performance Monitoring)Management Interfaces/ToolsHP Confidential
6 MSA P2000 G3 Platform - Controllers New Product IntroductionMSA P2000 G3 Platform - Controllers1MSA P2000 G3 8Gb FC/iSCSI ComboWhen to use: Latest 8Gb FC AND 1GbE iSCSI enabling shared storage between departments needing high performance, and small budget constrained entities. Also perfect enabler for snap replication over Ethernet.MAS P2000 G3 8Gb FCWhen to use: Latest 8Gb FC, high performance with a mature topology. Compatible with huge FC infrastructure installed base.MSA P2000 G3 10GbE iSCSIWhen to use: Latest 10GbE iSCSI, high performance with a heretofore high-end enterprise class topology, now available in the entry-level.MSA P2000 G3 1GbE iSCSIWhen to use: Bringing the cost efficiencies and ease-of-use advantages of 1GbE iSCSI shared storage to the entry-level SAN segment with a powerful 4-port iSCSI controller.MSA P2000 G3 6Gb SASWhen to use: Latest 6Gb SAS host connect for blazingly fast transmission rates with low cost connections. Four ports per controller support a highly efficient direct connect configuration.FCCOMBO2x8Gb + 2x1GbE ports per controllerFC2x 8Gb ports per controlleriSCSI2x10GbE ports per controlleriSCSI4x1GbE ports per controllerSAS4x 6Gb ports per controller
7 New Product Introduction MSA P2000 G3 PlatformTwo Base Chassis (2U)2P2000 G3 Array 2.5” SFF 24 DrivesP2000 G3 Array 3.5” LFF 12 DrivesExpansion JBODs (2U)3D2700 SFF JBOD 6Gb SAS (max 5)Up to 149 SFF DrivesP2000 LFF JBOD 6Gb SAS (max 7)Up to 96 LFF DrivesSupported LFF/SFF Hard Drive Types4SAS drives • MDL SAS drives • MDL SATA drives
8 MSA P2000 G3 Basic Software Features Software Features and Data ServicesSnapshot Data ServicesLocal Snapshots – all controllers64 Snapshots and Volume Copy standardUpgradeable to 512 SnapsRemote Snapshot - licensed feature - optionalRemote Snap not supported on SAS modelsEmbedded SMI-S 1.5 providerDrive Spin Down feature – policy based feature saves powerManagement Interfaces/ToolsWed-based GUI - Full configuration, provisioning, metricsRobust CLI command setEmbedded and Host-based Management Tools (FW Advisor, Performance Monitor)- Local snapshots allow for quick point-in-time recovery thereby reducing RTO (Recovery Time Objective) and giving greater volume management flexibility. This can then be coupled with the benefit of off-site data protection recovery and recovery using the license-able Remote Snap feature.These snapshots can then be asynchronously replicated to a remote Disaster Recovery site (DR).The copied volume and snapshots can be mounted and used for recovery, or they can be actively used. Upon failback the source volume is updated with that changed data.- SMI-S is a feature which allows for the management of an array or a pool of multiple arrays based on industry defined standards and commands. It allows administrators greater flexibility and simplifies the job of managing multiple systems.
9 MSA P2000 G3 Enterprise-Enabled Features VMware and Microsoft Integration, Performance Monitoring, FW UpdatesEarly (T230)VMware (All G3 Arrays)vStorage VAAI plug-ins (ESX 4.1, 5.0)VMware vCenter Array ProvisioningMicrosoft Hyper-VSCOMPerformance MonitoringHistorical Performance Collection Tool (Host SW)FW Update ToolPro-Active Notification Tool for Multiple Arrays (Host SW)June (T240)VMware IntegrationVMware Site Recovery Manager support with Remote Snap (FC, iSCSI, Combo)*VASA Support for all G3 arraysSCVMM12Historical Performance Monitoring in the Web GUI (SMU)Other FeaturesSMI-S 1.5 providerVariable Chunk SizeVmwareStrong cohesion within the VMware ecosystem1. VAAI supportT230:Thin provisioning is not supprtedBenefit: offload data transfer - that is typically done on the server side – to storage arrayDownload VAAI plugin from hp.com, install, use2. vCenter integrationManagement solution for VMware environmentsUse case: customer having a bunch of VMs which all need some storage. That can be provisioned directly from vCenter.Provisioning (/provide) of storage on the array3. VMware Site Recovery ManagerT240:Remote snap is used to copy dataApplication within Vmware suite allowing for data recovery on the P2000And also failbacks (once site A works again switch from site B to site A)SRM streamlines the process to manage failovers (site A fails, move to site B)4. VASAReports problems from array to vCenter (health report)Additional layer of monitoring that is now supported on P2000Next Release:ESX 5.0 Suppoerted in web based GUIHP is very committed to VMware and will enable additional features and functions to further integrate the P2000 with vCenterPerformance MonitoringOptimize array configuration for varied workloadsHistorical performance collection tool (dowlnoad at hp.com)Software allowing customers to monitor historical performance of multiple P2000 arrays at the same timeMetrics available in command line interface (CLI)Metrics exportable to excel for analysisSurface that into the web interface/web GUIMore array metrics collactableIntegration into Array AdvisorFirmware Update ToolProactive awareness and process simplificationNeeds to be driven manuallyThe tool discovers all arrays in the environment, checks the FW on each array and suggests upgradeschallenge: updating multiple arrays with new firmwareDownload at hp.comAutomated notificationAdds the ability to raise a notification to the customer if an array needs to update FWMicrosoftMicrosoft developed MS System Center as an equivalent to VmwareIncreased integration with Microsoftcustomers now have one single application to manage VMs and create and deploy storageSupport for Windows Server 2012ReleasedReleased
10 MSA Upgrades – Unmatched Investment Protection New Product IntroductionMSA Upgrades – Unmatched Investment ProtectionHP's MSA 2000 supports upgrades between the generations AND between protocolsUpgrade your MSA 2000 G1 to MSA P2000 G3 - With full data in place support!Change3Gb SAS to 6Gb SAS backendSupport for SFF drivesChoose from five different G3 controller types4Gb FC host interconnect to 8Gb FCHigher port countsFeatures: Snapshots (local and remote), fleet new management tools, virtualization integration pointsCustomer Benefit200% performance improvementsNew flexibilityMore host interconnectsSimple ManagementIncreased data protectionEnhanced data center integration
11 MSA Upgrades – Unmatched Investment Protection New Product IntroductionMSA Upgrades – Unmatched Investment ProtectionHP's MSA 2000 supports upgrades between the generations AND between protocolsUpgrade your MSA 2000 G2 to MSA P2000 G3 - With full data in place support!Change3Gb SAS to 6Gb SAS backend2 – 3 x increased iSCSI performnace10Gb iSCSI controllerFC/iSCSI combo controllerFeatures: Snapshots (local and remote), fleet new management tools, virtualization integration pointsCustomer BenefitMore performanceMore flexibilitySimple ManagementIncreased data protectionEnhanced data center integration
12 Investment Protection through Upgrade Paths HP's MSA 2000 supports upgrades between the generations AND between protocolsAll the upgrades are data in placeFrom any interface to any interfaceUpgrade MSA2000 G1 to P2000 G3 WhitepaperUpgrade MSA2000 G2 to P2000 G3 WhitepaperMSA2000fc G1MSA2000fc G2P2000 G3 FCMSA2000i G1MSA2000i G2P2000 G3 iSCSIMSA2000sa G1MSA2000sa G2P2000 G3 SASIn most cases, the chassis is able to be configured with modules and components from any generation, though there are limitations in that using older controllers will only give you the features found within them. Certain drives are also not supported in the older enclosures even when using G3 controllers.
14 Better Together for already 15 years HP Servers & StorageBetter Together for already 15 years+HP’s Server portfolio integrates closely with the MSA P2000 G3for an easy transition from DAS to entry shared storage solutions!Natural transitions from DAS to SANCommon look and feel of interfaces and support toolsets for firmware management (Smart Components)One stop shop – reliable end to end support with HP
15 MSA P2000 G3 Use Cases - Entry-Level Consolidation Scenario/Customer Pain PointsCustomers are typically looking to make the transition from a number of point solutions to a shared, centralized storage solutionCustomers are not always storage experts – Need slightly more guidance/education/simple managementTypical Solution Attributes:Some will be leveraging virtualization technologies as a part of the consolidation effortBackup, Disaster Recovery and Business Continuance infrastructure is often evolving to take advantage of D2D and Snapshot technologyThe P2000 and Entry-Level ConsolidationExcellent price/performance and price/capacity metricsOften coupled with server refresh activities – leverage Gen8 server pushOpportunities with this use case are very big with our partners. This use case is more than 40% of our business
16 MSA P2000 G3 Use Cases – Remote Office/Branch Office Scenario/Customer Pain PointsRemote/Branch solution is, by nature, duplicated X timesStorage solution must be cost effective – Savings here a multiplied by X sitesROBO Solutions (Compute, Network, Storage) – Again multiplied by X sitesCentralizing control, facilitating simple day-to-day remote office interactionsRepeatability is criticalTypical Solution Attributes:Most leverage virtualization for management simplicitySolution defined by HQ IT, deployed, managed locally (with oversight from HQ)The P2000 and ROBO DeploymentsExcellent price/performance and price/capacity metricsStrong management toolsetVirtualization integrationProven ROBO track recordHP solution support infrastructureAny solution where the customer needs storage in different places. RoBo happens every day and P2000 is the perfect solution for that.Multiply it by the number of offices you have – in a consistent way.Multiple offices, multiple stores centralizing the storage is not possible. Each store needs to have local storage so they can do file shares etc.
17 MSA P2000 G3 Use Cases – Departmental Block Storage Scenario/Customer Pain PointsUsers typically have solid understanding of Mid-Range and/or Enterprise Storage but need a solid block-level storage array to meet a departmental needCustomer’s departmental requirement must “align” with the datacenter infrastructure – Need to “Fit In”Typical Solution Attributes:Virtualization is almost standard and fairly “evolved”Backup, Disaster Recovery and Business Continuance infrastructure usually existsThe P2000 and Departmental Use CasesExcellent price/performance and price/capacityFlexibility with Host Interface connectionsData Recovery functionality bundled inAdvanced virtualization integrationCustomer: full sized data centerLots of consolidation in the datacenterBut need a piece of storage for e.g. marketing to hold some websidesWhich introduces risk to his bigger storageBut anything they do on their centralized storage they do with caution.They don‘t only require a JBOD but a piece of shared storage that fits into their IT environment.
18 Investment Protection HP MSA P2000 G3 SummaryPositioningConcept and ModelsUseCasesInvestment Protection
20 HP Support for your HP P2000 environment HP Technology Services are personalized.You decide how, when, and where you receive support for your HP P2000 MSA ArrayOur approach is proactive.Leveraging products, tools, and technology to avoid problems and optimize performance.Our portfolio is simplified.With straightforward choices to reduce complexity and risk, plus a single point of contact* you can count on throughout the support lifecycle .*Available with HP Proactive Care Service
21 HP Support for your HP P2000 environment Choose from three levels of care for your HP P2000 environmentOptimized care Maintain optimum levels of storage performance and availability: • HP Proactive Care 24x7 with 40 HP Proactive Select service credits per year – Standard care Maintain high levels of storage availability: • HP Proactive Care 24x7 with 30 Proactive Select service credits per year – Basic care Maintain storage with basic recommended support levels: • HP Support Plus 24 with 10 Proactive Select service credits per year –
23 Further Resources P2000 G3 MSA Firmware Download Site – General T240 Firmware – Link tbd* *Pending release, planned early March 2012Tools LinksTools Whitepaper - linkDevice Discovery Tool (sorry I drew a blank on name) - linkFirmware Update Tool (host based) - linkPerformance Monitor Tool (host based) - link VMware LinksHP Insight Control Storage Module for vCenter Plug-in - linkvSphere 4.1 VAAI Plug-in Download - linkvSphere5.0 VAAI Plug-in Download - linkHP P2000 VMware vSphere 4.1 VAAI White Paper - link
24 P2000 G3 Saleable SKUs requiring RoHS Compliance DescriptionOld Saleable SKUNew Saleable SKUHP P2000 G3 MSA Fibre Channel ControllerAP836AAP836BHP P2000 G3 SAS 24x300GB SAS SFF BundleBV908ABV908BHP P2000 G3 MSA FC/iSCSI ControllerAP837AAP837BHP P2000 G3 SAS 24x600GB SAS SFF BundleBV909ABV909BHP P2000 LFF Modular Smart Array ChassisAP838AAP838BHP P2000 G3 iSCSI 24x300 SAS SFF BundleBV911ABV911BHP P2000 SFF Modular Smart Array ChassisAP839AAP839BHP P2000 G3 FC 12x300GB SAS SFF BundleBV913ABV913BHP P2000 DC-power LFF ChassisAP840AAP840BHP P2000 G3 FC 12x600GB SAS SFF BundleBV914ABV914BHP P2000 DC-power SFF ChassisAP841AAP841BHP P2000 G3 SAS 12x300GB SAS SFF BundleBV917ABV917BHP P2000 Dual I/O LFF Drive EnclosureAP843AAP843BHP P2000 G3 SAS 12x600GB SAS SFF BundleBV918ABV918BHP P2000 LFF Drive Enclosure I/O ModuleAP844AAP844BHP P2000 G3 iSCSI 12x300 SAS SFF BundleBV919ABV919BHP P2000 G3 MSA FC Dual Cntrl LFF ArrayAP845AAP845BHP P2000 G3 iSCSI 12x600 SAS SFF BundleBV920ABV920BHP P2000 G3 MSA FC Dual Cntrl SFF ArrayAP846AAP846BHP P2000 G3 FC 24x900GB SAS SFF BundleQR517AQR517BHP P2000 G3 MSA FC/iSCSI DC LFF ArrayAW567AAW567BHP P2000 G3 Combo 24x900 SAS SFF BundleQR518AQR518BHP P2000 G3 MSA FC/iSCSI DC SFF ArrayAW568AAW568BHP P2000 G3 SAS 24x900GB SAS SFF BundleQR519AQR519BHP P2000 G3 SAS MSA ControllerAW592AAW592BHP P2000 G3 iSCSI 24x900GB SAS SFF BundleQR520AQR520BHP P2000 G3 SAS MSA Dual Cntrl LFF ArrayAW593AAW593BHP P2000 G3 FC 24x1TB SAS SFF BundleQR521AQR521BHP P2000 G3 SAS MSA Dual Cntrl SFF ArrayAW594AAW594BHP P2000 G3 Combo 24x1TB SAS SFF BundleQR522AQR522BHP P2000 G3 10GbE iSCSI MSA ControllerAW595AAW595BHP P2000 G3 iSCSI 24x1TB SAS SFF BundleQR524AQR524BHP P2000 G3 10GbE iSCSI MSA DC LFF ArrayAW596AAW596BHP P2000 G3 FC 12x900GB SAS SFF BundleQR525AQR525BHP P2000 G3 10GbE iSCSI MSA DC SFF ArrayAW597AAW597BHP P2000 G3 Combo 12x900 SAS SFF BundleQR526AQR526BHP P2000 G3 iSCSI MSA Controller BK829ABK829BHP P2000 G3 SAS 12x900GB SAS SFF BundleQR527AQR527BHP P2000 G3 iSCSI MSA 2-cntrl LFF ArrayBK830ABK830BHP P2000 G3 iSCSI 12x900GB SAS SFF BundleQR528AQR528BHP P2000 G3 iSCSI MSA 2-cntrl SFF ArrayBK831ABK831BHP P2000 G3 FC 12x1TB SAS SFF BundleQR529AQR529BHP P2000 Dual I/O DC-power CG SFF EncBV921ABV921BHP P2000 G3 Combo 12x1TB SAS SFF BundleQR530AQR530BHP MSA2 1TB 7.2K rpm 3.5 inch SATA HDDAJ740AAJ740BHP P2000 G3 SAS 12x1TB SAS SFF BundleQR531AQR531BHP P2000 2TB 3G SATA 7.2K 3.5in MDL HDDAW556AAW556BHP P2000 G3 iSCSI 12x1TB SAS SFF BundleQR532AQR532BHP P2000 G3 FC MSA 2-cntrl LFF SAN KitAP847AAP847BHP P2000 G3 FC 24x300GB SAS SFF BundleQW945AQW945BHP P2000 G3 FC MSA 2-cntrl SFF SAN KitAP848AAP848BQW949AQW949BHP P2000 G3 FC 24x146GB SAS SFF BundleBV901ABV901BQW951AQW951BBV902ABV902BHP P2000 G3 iSCSI 12x300GB SAS SFF BundleQW952AQW952BHP P2000 G3 FC 24x600GB SAS SFF BundleBV903ABV903B
25 10GbE iSCSI The P2000 G3 Family - Comparison - use case examples - TechnologyFeatures8G FC6G SASFC/iSCSI10G iSCSI1G iSCSIStorage ControllersDual Active/Active Hot Swap8Gb FC2 ports/Controller6Gb SAS4 ports/Controller8Gb FC & 1Gb E4 ports/Controller (2xFC & 2x1GbE)10GbE iSCSI1GbE iSCSICache (per Controller)2GB StandardEnclosure Form Factor2UMax. Drives per Enclosure12 LFF/24 SFF12 LFF/24SFF112 LFF/24SFFDrives Supported2.5” SAS Ent, SAS MDL & SATA MDL 3.5” SAS Ent, SAS MDL & SATA MDL (Supports SAS and SATA drives in the same enclosure)2.5” SAS Ent, SAS MDL & SATA MDL 3.5” SAS Ent, SAS MDL & SATA MDL(Supports SAS and SATA drives in the same enclosure)2.5” SAS, SATA,& SAS & SATA MDL3.5” SAS & SATA & SAS & SATA MDLScalability96 LFF drives149 SFF drivesStorage Capacity89.4 TB (using SAS)192 TB (using SATA)192 T B (using SATA)Power Supply& FanHot swap, RedundantRAID0, 1, 3, 5, 6, 10, 50- use case examples -
26 Connectivity & Availability The P2000 G3 Family - Comparison10GbE iSCSIConnectivity & AvailabilityFeatures8G FC6G SASFC/iSCSI10G iSCSI1G iSCSI# of LUNs supported512511LUN Size16TBHBAsEmulex, Brocade & Qlogic (8Gb FC & 4Gb FC)HP SC08e 6Gb SAS HBAEmulex, Brocade & Qlogic ((8Gb FC & 4Gb FC)Industry standard 1GbE NICsIndustry standard 10 GbE NICsIndustry standard 1 GbE NICsExpansion1+7Host Support64 (single path)32 (dual path)8 (single path)4 (dual path)# of Cluster NodesW2k3=8, W2k8=16RH=16SuSE16VMware=16W2k3=8, W2k8=8RH=8SuSE=8VMware=8(this support does not reflect Blades configuration)Supported JBODsD2700 6G (SFF)P2000 6G JBOD (LFF)MSA70 3G (SFF)MSA2000 3G (LFF)Power Supply& FanHot swap, Redundant- use case examples -
27 Storage Management and Optional Software Features8G FC6G SASFC/iSCSI10G iSCSI1G iSCSIManagement Software InterfacesStorage Management Utility (SMU)Out-of-bandCLI, FTP, SNMP & web-based Interface (WBI)Multipath SupportMPIO DSMSnapshot64 snaps (Standard)512 Max (Optional)Volume Copy128 Copies (Standard)Remote Snap (Optional)SupportedN/ADrive Spin Down (DSD)StandardOnline Firmware Upgrade (Controller)Non-disruptive w/ dual controller Config onlyFirmware Smart Component InstallersWin/Linux smart components available for new firmware updatesWin/Linux smart components available for new firmware updates 10GbE iSCSI- use case examples -
28 Storage Management and Optional Software The P2000 G3 Family - Comparison10GbE iSCSIStorage Management and Optional SoftwareFeatures8G FC6G SASFC/iSCSI10G iSCSI1G iSCSIvStorageSupportedVDS/VSS SupportSupported and available on the webSoftware Support CDShips with Array &DownloadableDiscovery Tool for ArraysMSA Support Pack (MSP)USB DrivervCenter- use case examples -
