1 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 1 Cisco Data Center The Platform of Innovation Mónica Leal Virtual Engineering DC SE moleal@cisco.com

2 Cisco Confidential 2 © 2013-2014 Cisco and/or its affiliates. All rights reserved. Cisco Nexus 5000 Cisco Nexus 7000 Cisco Nexus 3000 Cisco Nexus 2000 Expanding DC and Cloud Networking Portfolio Cisco Nexus 5600 NEW! Cisco Nexus 3100 Cisco Nexus 6000 Cisco Nexus 1000V OPEN APIs/ Open Source/ Application Policy Model HIGH PERFORMANCE FABRIC 1/10/40/100 GE SCALABLE SECURE SEGMENTATION VXLAN DELIVERING TO YOUR DATA CENTER NEEDS Resilient, Scalable Fabric Workload Mobility Within/ Across DCs LAN/SAN Convergence Operational Efficiency—P-V-C Architectural Flexibility Cisco Nexus 7706 55K+ NX-OS customers 17K+ FEX customers 8.5K+ Nexus 1KV customers3K+ Fabric Path customers

3 Cisco Confidential 3 © 2013-2014 Cisco and/or its affiliates. All rights reserved. N2K – N7K Switching Portfolio Adoption Cisco Unified Fabric Switching Innovations LAN/SAN SAN From Hypervisor to Core Single Pane of Management CISCO NX-OS: From Hypervisor to Core CISCO DCNM: Single Pane of Management Cisco MDS 9200 Series Cisco ® MDS 9500 Series Cisco Nexus 1000V Cisco Nexus ® 1010 Cisco Nexus 4000 Cisco MDS 9100 Series Cisco Nexus 5000 Cisco Nexus 2000 Cisco Nexus 6000 Cisco MDS 9250i Multiservice Switch Cisco MDS 9700 Series Cisco Nexus 7000/7700 Cisco Nexus 3500 and 3000 LAN/SAN SAN From Hypervisor to Core Single Pane of Management CISCO NX-OS: From Hypervisor to Core CISCO DCNM: Single Pane of Management Cisco MDS 9200 Series Cisco ® MDS 9500 Series Cisco Nexus 1000V Cisco Nexus ® 1010 Cisco Nexus 4000 Cisco MDS 9100 Series Cisco Nexus 5000 Cisco Nexus 2000 Cisco Nexus 6000 Cisco MDS 9250i Multiservice Switch Cisco MDS 9700 Series Cisco Nexus 7000/7700 Cisco Nexus 3500 and 3000 50,000+ Customers 17,000+ FEX Customers 78% 10G Market Share Purpose-Built Fixed Switching 83% 10G Market Share Modular Switching 3,000+ OTV Customers 3,000+ FabricPath Customers 600,000+ Chassis Shipped

4 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 4

5 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 5 Consolidated Infrastructure Simplified Management Reduced Cost Investment Protection Evolves With Business Geographic Span Integrated Application Delivery Seamless VM Networking VM-aware Security Consistent Networking Across Physical, Virtual and Cloud Scale Convergence Intelligence

6 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 6

7 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 7 Priority Flow Control IEEE 802.1Qbb creates lossless Ethernet with classes of service Bandwidth Management IEEE 802.1Qaz allows flexible bandwidth sharing for LAN and SAN Data Center Bridging Exchange Protocol IEEE 802.1Qaz provides device- device communication on resources IEEE DCB Fibre Channel Traffic FCoE  Mapping of Fibre Channel frames over Ethernet  Enables Fibre Channel to run on a lossless Ethernet Ethernet Header FCoE Header FC Header FC Payload CRC EOF FCS Byte 0 Byte 2229 Operational Efficiency & Cost Optimization Nexus Enables DataCenter Bridging (DCB) DCB Enables FCoE

8 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 8  Virtual Port Channels overcomes Spanning tree protocol limitations  Nexus Platforms have delivered VPC to allow efficient Data Center designs  Both links are active on all VLANs with no reliance on STP Traditional STP Based Network Nexus VPC Based Network Blocked Links L2 L3 L2 L3

9 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 9

10 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 10  De-Coupling and optimization of the Layer 1 and Layer 2 Topologies  Simultaneous support of EoR, MoR and ToR  Reduction in the number of management points for ToR architectures  Support for Rack and Blade server connectivity Virtualized Access Switch...

11 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 11  Flexible LAN & storage convergence based on business needs  Service can be adjusted based on the demand for specific traffic  Convert protocol support on the same port dynamically  All ports on 5596  16 port Expansion Module on 5548 and 5596  Simplify switch purchase - remove ports ratio guess work  Increase design flexibility  Remove specific protocol bandwidth bottlenecks Unified Port Native Fiber Channel Lossless Ethernet: 1/10GbE, FCoE, iSCSI, NAS BenefitsUse-cases

12 Cisco Confidential 12 © 2014 Cisco and/or its affiliates. All rights reserved. Nexus 5500 & 5600

13 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 13 Nexus 5500 Platform Nexus 5548UP 1RU Switch (Unified Ports) Nexus 5596UP 2RU Switch (Unified Ports) Nexus 5548 Layer 3 Daughter Card Nexus 5596 Layer 3 Expansion Module Nexus 5500 Unified Ports Expansion Module

14 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 14 Benefits / Use-cases  Investment protection in action!  Proven, resilient NX-OS, designs  Low, predictable latency at scale  High density 1RU/2RU ToR Switches  10GE / 1GE / FCoE / 8G FC  Reverse airflow / DC-power  1G support on all N5K ports Innovations  Unified Port capability  Layer-3 support  Increased FEX scale (24)  FCoE innovator (Multi-hop)  Adapter-FEX  Cisco FabricPath  VM-FEX Lowest TCO for the Virtualized Datacenter

15 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 15 Nexus 5600 is the Next Generation of Nexus 5500 - 3 rd Generation Product in the Nexus 5K family Nexus 5600 is optimized for 10G and supports on all the functionality of the Nexus 5500 Nexus 5600 hardware also has next generation features: VXLAN Bridging & Routing, NVGRE, Cisco’s DFA Innovations, Advanced Data Analytics for Network visibility & Programmability Nexus 5600 also provides better Performance & Scale -Integreated Line Rate Layer 3 -True 40G uplinks -Bigger buffers & Table sizes

16 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 16 Nexus 56128P 2RU - Upto 96 ports 10G Ethernet/FCoE, 12 ports 40G Ethernet/FCoE Unified Port on Modules. Nexus 5672UP 1 RU - 48 port 10G Ethernet (16 Ports Unified) 6 port 40G NEXUS ADVANTAGE New Form Factors Chassis New Form Factors and Higher Port Density Orderable Feb CY14

17 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 17 BACK OF SWITCH FRONT OF SWITCH Redundant Fan Modules Mgmt 0, Console, USB NEXUS 5600 SERIES Nexus 5672UP Chassis Compact 1RU Switch in the Nexus 5600 Platform 48 Fixed 1/10G SFP+ Ports of which 16 Ports Unified 16 Unified Ports provide 2/4/8G FC, 10/40G Ethernet/FCoE Traditional Ethernet or FCoE or FC Redundant 1+1 AC/DC Power Supplies 6x 40G QSFP+ Ports Flexibility to use 4x10G or 40G Choice of Reversible Airflow

18 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 18 BACK OF SWITCH FRONT OF SWITCH NEXUS 5600 SERIES Nexus 56128P Chassis Compact 2RU Switch in the Nexus 5600 Platform Redundant Fan Modules Mgmt 0, Console, USB 48 Fixed 10G SFP+ Ports 2 Expansion Slots Expansion module provides 24 Unified ports 10G Ethernet/FCoE or 2/4/8G FC and 2 ports 40G Ethernet/FCoE Redundant n+1 AC/DC Power Supplies 4x 40G QSFP+ Ports Flexibility to use 4x10G or 40G Upto 8x 40G ports and 96x 10G ports Choice of Reversible Airflow

19 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 19 NEXUS FIXED SERIES Comparison Portfolio Nexus 5600 SeriesNexus 5500 Series Switch Fabric Throughput Upto 1.44 TbpsUpto 960 Gbps Port-to-Port Latency~ 1us~ 1.8us Layer 3 CapabilityIntegrated Line RateL3 Module VXLAN Unified Ports MAC Table256K MAC/ARP (flexible)32K MAC/ARP IP Unicast Routes32K (v4) or 8K (v6)8K (v4) or 4K (v6) IP Hosts128K (v4) or 64K (v6)16K (v4) or 8K (v6) IP Multicast routes32K (v4) or 16K (v6)8K (v4) or 4K (v6) Buffers25MB (12p X 10G)640KB/10G port IGMP Snooping Groups 32K*8K VRFs4K1K SPAN31, 16 Can Be ERSPAN4

20 Cisco Confidential 20 © 2014 Cisco and/or its affiliates. All rights reserved. Nexus 2000

21 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 21 N2K-C2232TM-10GE RJ45 downlinks N2K-C2248TP-1GE N2K-C2224TP-1GE N2K-C2248TP-E-1GE Expanded Memory FEX SFP+ downlinks N2K-C2232PP-10GE N2K-C2232TM-E-10GE RJ45 downlinks N2K-C2248PQ 48 port 1/10G FEX SFP+ + 4xQSFP Blade FEX 1/10G FEX 100M/1G FEX 2013 2012 2011 2010 2009 B22 Dell FEX 1/10G FEX for Dell Blade servers B22 FTS FEX 1/10G FEX for Fujitsu Blade servers B22 HP FEX 1/10G FEX for HP Blade servers

22 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 22 Unified access platform for any POD designs - across rack, blade, 100M, 1G, 10G, FCoE, copper, Fiber, ToR and EoR architectures, Layer 2/Layer 3 solutions, traditional or virtualized workloads Nexus 2000 100M/1GE Rack Mount Servers Nexus 2000 1/10GE/FCoE Rack Mount Servers Cisco UCS Nexus 7000 Unified Access Layer Nexus 5000/5500 1/10GE/FCoE UCS Compute Blade 1/10GE/FCoE Third Party Blade Servers Nexus 2000 Parent Switch 1/10G/FCoE UCS Compute Rack Nexus 2000 UCS

23 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 23 Support for Nexus 5000 and Nexus 7000 Up to 24 FEX per N5K parent switch Up to 48 FEX per N7K parent switch Up to 2048 1GE interfaces managed through upstream parent switch Up to 1536 10GE interfaces managed through upstream parent switch Cisco Nexus ® 7000 + Cisco Nexus ® 2000 FEX 24xFEX Cisco Nexus ® 5000

24 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 24 Top of Rack (ToR) Cost effective cabling Local copper cabling host/ToR switches Fiber uplinks from ToR switches End of Row (EoR) Simple management, efficient Copper/Fiber cabling from hosts to EoR switches Fewer devices to manage No Layer 2 interconnect (no STP) Traffic in rack switched locally Animated Slide!

25 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 25 Model Nexus 2224TPNexus 2248TPNexus 2248TP-E Product ShippingYes (Q4CY10)Yes (Q2CY10)Yes (Q4CY11) Form Factor1 RU Uplink Ports2x 10GbE SFP+4x 10GbE SFP+ Uplink Transceivers Supported Copper CX-1 (passive): 1m, 3m, 5m. Copper CX1 (active): 7m, 10m Optical: FET, SR, LR, ER Host Facing Ports24x 100/1000BASE-T RJ4548x 100/1000BASE-T RJ45 FCoEN/A Buffer Ingress buffer (Host  Network/H2N): 480KB per port group (8) Egress buffer (N2H): 800KB per port group (8) Ingress buffer (Host  Network/H2N): 480KB per port group (8) Egress buffer (N2H): 800KB per port group (8) 32MB shared buffer Typical Power 80W95W Enhanced Counters Standard Enhanced Parent SwitchNexus 5K, Nexus 6K, Nexus 7K Number of FEX24 FEX per N5500 24 FEX per N6K 48 FEX per N7K 100M/1GE platform

26 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 26 Model Nexus 2232PPN2248PQNexus 2232TMNexus 2232TM-E Product ShippingYes (Q2CY10)Yes (Q1CY13)Yes (Q3CY11)Yes (Q3CY12) Form Factor1 RU Uplink Ports 8x 10GbE SFP+4 x QSFP+ 8x 10GbE SFP+ Uplink Transceivers Supported Copper CX-1 (passive): 1m, 3m, 5m. Copper CX1 (active): 7m, 10m Optical: FET, SR, LR* Host Facing Ports32x SFP/SFP+ (1/10G)48 x SFP/SFP+ (1/10G)32x 1/10GBASE-T RJ45 FCoEYes NoCapable Buffer Ingress buffer (Host  Network /H2N): 1280KB per port group (8) Egress buffer (N2H): 1280KB per port group (8) Ingress buffer (Host  Network /H2N): 1280KB per port group (8) Egress buffer (N2H): 1280KB per port group (8) 2x16M Shared buffer Ingress buffer (Host  Network /H2N): 1280KB per port group (8) Egress buffer (N2H): 1280KB per port group (8) Ingress buffer (Host  Network /H2N): 1280KB per port group (8) Egress buffer (N2H): 1280KB per port group (8) Typical Power 210W175W280W@30M, 350W@100M 210W@30M, 240W@100M Enhanced Counters Standard Parent SwitchNexus 5K, Nexus 6K, Nexus 7K, UCS FI Nexus 5K, Nexus 6KNexus 5K, Nexus 6K, Nexus 7K Nexus 5K, Nexus 6K Number of FEX24 FEX per N5500 24 FEX per N6K 48 FEX per N7K 24 FEX per N5500 24 FEX per N6K 24 FEX per N5500 24 FEX per N6K 48 FEX per N7K 24 FEX per N5500 24 FEX per N6K 1/10GE platform

27 Cisco Confidential 27 © 2014 Cisco and/or its affiliates. All rights reserved. Nexus 3000

28 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 28 Nexus 3064-E 28-Port 1RU Switch Nexus 3048TP 48-Port 1RU Switch Nexus 3016Q 16-Port 1RU Switch Nexus 3064-X Integrated Phy vPC, Precision Time Protocol, Configurable Control Plane Policing Power-on auto-provisioning, Encapsulated Remote Switched Port Analyzer Wired-network rate L2/L3 feature set, IPv4/v6 User programmable: python scripting, EEM, NETCONF Robust Cisco ® NX-OS with Differentiated Feature Set Customers Industry’s leading Ultra Low Latency Platform 2011 2013 2012 Nexus 3548 48-Port 1RU Switch Latency: 190 ns !! Nexus 3064-T 48-Port 10G-BaseT Nexus 3172PQ Nexus 3132Q

29 Cisco Confidential 29 © 2014 Cisco and/or its affiliates. All rights reserved. Nexus 6000

30 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 30 High Performance High Scalability Feature-Rich Visibility and Analytics Line-rate L2 and L3 with all ports and all features and all frame sizes 1.2-microsecond port- to-port latency with all frame sizes 40G Flows Optimized 16 Bi-Directional Line- rate SPAN Sessions Sampled NetFlow* Micro-burst, buffer, and latency monitoring* Full L2 Switching Full Layer 3 Routing FEX, vPC, FabricPath 10/40G FCoE 96x 40GE QSFP in 4RU 384x 10GE SFP+ in 4RU 32K IPv4 Routes 16K IPv6 Routes * NX-OS 7.0 – Q1 2014

31 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 31 20 SFP+ Unified Ports 160-ports Per 6004 Chassis Supports 1/10GE SFP/SFP+ Supports 2/4/8G FibreChannel Offer same LAN and SAN features consistent with Nexus 5000 Supports OIR March 2014

32 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 32 Choice of Reversible Airflow Back of Switch Front of Switch 48 Fixed 1/10G SFP+ Ports Line Rate Layer 2 / Layer 3 Traditional Ethernet or Fibre Channel over Ethernet 4 40G QSFP+ Ports Flexibility to use 4x10G or 40G Redundant 1+1 AC Power Supplies Redundant Fan Modules Mgmt 0, Console, USB Compact 1RU switch in the Nexus 6000 Platform

33 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 33 QSFP Ports QSFP+ 40GBASE-SR4 (optical) QSFP+ 4xSFP10G (copper) QSFP+ 40GBASE-CR4 (copper) QSA – QSFP to SFP+ Adapter Supports 1G SFPs and 10G SFP+s (optical/copper) MPO-to-8xLC (10GSR) (optical)

34 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 34 High Performance High Scalability Feature-Rich Visibility and Analytics Line-rate L2 and L3 with all ports and all features and all frame sizes 1.2-microsecond port- to-port latency with all frame sizes 16 Bi-Directional Line- rate SPAN Sessions Sampled NetFlow* Micro-burst, buffer, and latency monitoring* Full L2 Switching Full Layer 3 Routing FEX, vPC, FabricPath 10/40G FCoE 48x 1/10GE RJ45 4x 40GE QSFP 32K IPv4 Routes 16K IPv6 Routes Front-to-Back airflow (port-side exhaust) Back-to-Front airflow (port-side intake) Air-Flow Options * NX-OS 7.0 – Q1 2014

35 Cisco Confidential 35 © 2014 Cisco and/or its affiliates. All rights reserved. Nexus 7000 & 7700

36 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 36 9,000+ Customers 45,000+ Chassis 8 Million+ Ports Shipped Cisco Nexus F3-Series Modules Cisco Nexus 7700 Platform Switches Cisco Nexus ® 7000 Series Industry’s Most Proven Data Center Switching Platform Cisco Nexus 7000 Series Switches NEW Common Cisco ® NX-OS Common Fabric Architecture Common Cisco’s Custom Silicon

37 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 37

38 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 38 Cisco Nexus 7700 10-Slot Cisco Nexus ® 7700 18-Slot 26 RU 14 RU Cisco Nexus 7700 6-Slot 9 RU Environmental EFFICIENCY True front-to-back airflow Smaller FOOTPRINT 33% more compact Fabric BANDWIDTH 1.32 Tbps Nexus 7718Nexus 7710Nexus 7706 100G Density1929648 40G density38419296 1G / 10G density 768384192

39 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 39 Deploy Anywhere No learning curve: familiarity with architectures Classic Layer2 & Layer3 FabricPath, VXLAN, LAN-SAN Convergence Hitless ISSU, VDC Nexus 7000/7700 powered by F3 Spine / Aggregation Robust & Scalable Routing MPLS 10G/40G/100G Hitless ISSU, VDC Nexus 7000/7700 powered by F3 DC Core OTV, LISP EoMPLS, VPLS Hitless ISSU, VDC Nexus 7000/7700 powered by F3 DC Interconnect

40 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 40 VDC – Virtual Device Context Flexible separation/distribution of hardware resources and software components Complete data plane and control plane separation Complete software fault isolation Securely delineated administrative contexts Forwarding engine scalability with appropriate interface allocation Infrastructure Kernel VDC 1 VDC 2 VDC 3 Layer 2 ProtocolsLayer 3 Protocols VLAN PVLAN OSPF BGP EIGRP GLBP HSRP IGMP UDLD CDP 802.1XSTP LACPPIMCTSSNMP … … VDC 1 VDC 4 Layer 3 Protocols OSPF BGP EIGRP GLBP HSRP IGMP PIMSNMP … VDC 2 Layer 2 Protocols VLAN PVLAN UDLD CDP 802.1XSTP LACPCTS …

41 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 41 Transport Infrastructure OTVOTVOTVOTV MAC TABLE VLANMACIF 100MAC 1Eth 2 100MAC 2Eth 1 100MAC 3IP B 100MAC 4IP B MAC 1  MAC 3 IP A  IP B MAC 1  MAC 3 MAC TABLE VLANMACIF 100MAC 1 IP A 100MAC 2 IP A 100MAC 3 Eth 3 100MAC 4 Eth 4 Layer 2 Lookup 5 IP A  IP B MAC 1  MAC 3 Layer 2 Lookup 1 Encap 2 Decap 4 MAC 1  MAC 3 West Site West Site MAC 1 MAC 3 East Site East Site 3 6 IP AIP B Ethernet traffic between sites is encapsulated in IP: “MAC in IP” Dynamic encapsulation based on MAC routing table No Pseudo-Wire or Tunnel state maintained

42 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 42 Nexus L2/L3 Fabric Scaling Layer 2 Domains—Available on Cisco Nexus ® 7000, 6000 and 5000 Series Layer 2 Strengths Simple configuration Flexible provisioning Low cost Layer 3 Strengths All links active Fast convergence Highly scalable Scalable virtualization pods Massively scalable L2 fabric L2 interconnect with dark fibre High-bandwidth HPC USE CASES Simplicity High resiliency―Eliminate Spanning Tree Protocol (STP) Flexibility Revolutionary scale—12,000+ 10 GE with Cisco ® FEX RESULTS

43 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 43 Fabric Management WorkloadAutomationWorkloadAutomation Virtual Fabrics OptimisedNetworkingOptimisedNetworking  Device Auto- Configuration  Cabling Plan Consistency Check  Common point of fabric access  Automated Network Provisioning  Any workload, anywhere, anytime  Open orchestration integration  Automated scalable provisioning  Any subnet, anywhere  Reduced failure domains  Extensible scale & resiliency  Any workload, any vfabric  Scalable secure virtual fabrics  Virtual fabric tenant visibility  Routing & switching segmentation

44 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 44 LAYER 2 SCALE SPANNIDFATREE ST P VIRTUAL PORT CHANNEL VP C FABRIC PATH FP Dynamic Fabric Automation DF A INFRASTRUCTURE VIRTUALISATION CAPACITY

45 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 45 40G BiDi Optics 40G Over 10G Multimode Fiber Available across the Cisco Nexus Portfolio Removes the need for 10G fiber rip- and-replace Priced comparably to 10G Optics Speed adoption of 40G by removing cabling barriers to adoption

46 Cisco Confidential 46 © 2014 Cisco and/or its affiliates. All rights reserved. Nexus 1000

47 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 47 Available

48 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 48 Tenant A Hypervisor agnostic multi-service platform Nexus 1000V Distributed switch NX-OS consistency Security Zone-based FW Edge FW vNAM Traffic visibility Application performance vWAAS WAN optimization CSR 1000V (Cloud Router) WAN L3 gateway Routing and VPN ASA 1000V Cloud Firewall Cisco Virtual Security Gateway (VSG) vWAAS Citrix NetScaler VPX Imperva SecureSphere WAF Cloud Services Router 1000V Zone A Zone B vPath VXLAN Multi-Hypervisor (VMware, Microsoft*, RedHat*, Citrix*) EcosystemServices Citrix NetScaler VPX virtual ADC Imperva Web App. Firewall Physical Infrastructure (Compute, Network, Storage)

49 Cisco Confidential 49 © 2014 Cisco and/or its affiliates. All rights reserved. Summary

50 © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 50 Nexus offers different tools for different needs, all of them oriented for effective and efficient DC networking Focus first on the architecture, choose afterwards the right products (not the other way round) Cisco supports multiple designs and requirements for different customers: “it’s all about choice!” (therefore the rich switching portfolio)

51 Thank you.
