Presentation on theme: "G.E. UPS Productline. Uninterruptible Power Supplies | 1 Phase Delivering reliable power in a compact footprint LP11 / LP31T / LP31 Series Application."— Presentation transcript:

1 G.E. UPS Productline

2 Uninterruptible Power Supplies | 1 Phase Delivering reliable power in a compact footprint LP11 / LP31T / LP31 Series Application Medium data networks, telecom equipment, local site protection Double conversion, high efficiency (up to 97%) and redundant parallel capable, with galvanic isolation and GE’s battery management for load security. Line Interactive topology, automatic voltage regulation, step-wave output with internal hot swappable batteries. IT & Match Series Application Point-of-sale (POS), ISDN switches PCs, routers, & small IT servers Application Healthcare & marine, wind turbine, controls, all IT & high speed processing VH Series GT Series Double conversion, parallel-ready technology with modular battery and power components for easy expansion and retrofit. Application Telecom equipment, server racks, small to medium data networks Double conversion technology, hardened design, peak load handling, and wide temperature operating range. RatingOutputCert. 600 VA – 2 kVA120 VacUL 500 VA – 3 kVA230 VacCE RatingOutputCert. 1 – 2kVA120 VacUL 3kVA120/208 VacUL kVA120/208/240 VacUL 6 & 10kVA220/230/240 VacCE RatingOutputCert kVA120/208/240 VacUL & CE 3-10 kVA220/230/240 VacCE 5-20 kVA220/230/240 VacCE RatingOutputCert. 2 kVA208/220/230/240 VacUL 700 VA-3 kVA208/220/230/240 VacCE

3 Uninterruptible Power Supplies | 3 Phase Clean, reliable and energy efficient power The high efficiency SG series provides fast step/transient load response while eliminating single points of failure. SG Series Application Enterprise class data networks, large data centers, healthcare equipment The LP33 series is a transformer-less design reducing install footprint and installation time. LP33 Series Application Large data networks, telecom equipment The SitePro model is a robust, double conversion UPS that provides true on- line operation and galvanic isolation. SitePro Application Manufacturing & process control healthcare equipment, data centers Leading the industry through innovation Redundant Parallel Architecture (RPA) Increasing reliability by eliminating single points of failure. Paralleling multiple UPS’ for true redundancy without adding complexity. ECO Mode Power supplied from mains via UPS bypass circuit. Immediate transfer to inverter power during disturbance. Energy efficiency of up to 98.5%. PurePulse ® Delivers pure clean waveform from the mains, reducing sizing of upfront equipment and eliminating additional input filters. RatingOutputCert kVA 480 VacUL kVA 400 VacCE RatingOutputCert kVA 208 VacUL kVA 380/400/415 VacCE RatingOutputCert kVA380/400/415 VacCE

4 TLE Series Platform 225 – 1500 kW GE Critical Power

5 Page 5 GE– Internal & Confidential TLE Series kVA/kW UL TLE Series platform Introducing TLE Series UPS What is it? TLE Series is a new high power transformer less 3 phase UPS platform with best in class multi-mode efficiency (eBoost and double conversion), and modular scalable from 200 kW up to 1500 kW for global UPS markets (CE and UL). Why is it important? This TLE platform establishes GE technology leadership in mid/high power UPS applications with industry leading differentiation in efficiency, output power capacity and footprint. Differentiated Value Proposition Best in class multi-mode efficiency 96.5% Double Conversion mode (VFI) 99.0% eBoost mode (VFD) Highest output power (up to 1.5 MW) High reliability: Improved serviceability and lower MTTR Standard building blocks 250 kw Inherent redundancy inside UPS module High power density and small foot print Excellent input, output performance

6 Page 6 GE– Internal & Confidential TLE Series kVA/kW UL Ultra High Efficiency Excellent Performance Improved Diagnostic High Reliability High output power Improved Serviceability Creating Value – Low TCO

7 Page 7 GE– Internal & Confidential TLE Series kVA/kW UL Creating Value – Low TCO Ultra high Efficiency 1

8 Page 8 GE– Internal & Confidential TLE Series kVA/kW UL Double conversion Efficiency – 96.5% High Efficiency at all loads Reduced customer operation costs and cost saving in air conditioning design High efficiency performances High efficiency at full and partial loads for real benefit in operating conditions Energy cost saving Reduced cost of customer equipment operation at all loads Air conditioning cost saving Reducing size and cost of air condition system Reducing consumption and related operating cost GE Sets the Bar for highest UPS Operating Efficiency

9 Page 9 GE– Internal & Confidential TLE Series kVA/kW UL High Efficiency – eBoost mode eBoosthigh efficiency (up to 99%) fast transfer to inverter <2ms "GE's eBoost feature expands a classic mode On-Line Double Conversion UPS System to a multi-mode UPS capable of maximizing operating efficiency commensurate with the stability of utility voltage and frequency eBoost can be operated in RPA mode, up to 6 UPS modules in parallel, with all units operating and switching as one through redundant communication bus

10 Page 10 GE– Internal & Confidential TLE Series kVA/kW UL High Efficiency – Low TCO High efficiency up to 96.5% Considerable life cycle cost savings Reduction in UPS operating cost Reduction in cooling cost 5 MW IT load - TLE series life cycle savings of $1.5 MM while operating in VFI mode Assumptions: Power cost = $ 0.10 /kw-hr Operating hours/year = 8760 Cooling factor = 0.35 Configuration = S+S operating at 50% load 93% 96.5% 99%

11 Page 11 GE– Internal & Confidential TLE Series kVA/kW UL High Efficiency – Low TCO High efficiency up to 96.5% Considerable life cycle cost savings Reduction in UPS operating cost Reduction in cooling cost Assumptions: Power cost = $ 0.10 /kw-hr Operating hours/year = 8760 Cooling factor = 0.35 Configuration = 500 kW 50% load TLE Series UPS annual savings Compared to 92% efficiency UPS > $ 14,980 94% efficiency UPS > $ 8,140 95% efficiency UPS > $ 4,830

12 Page 12 GE– Internal & Confidential TLE Series kVA/kW UL Creating Value – Low TCO Excellent Performance 2

13 Page 13 GE– Internal & Confidential TLE Series kVA/kW UL UPS input performances Total Current Harmonic Distortion – THDi <5% UPS input power factor: 0.99 Constant behavior at all loads Negligible harmonics contents at full and partial loads Programmable Soft Start Feature Benefit on input mains Saving in the sizing of upfront equipment e.g. GenSet, cablings, circuit breakers, … No disturbances to nearby equipment Saving cost due to additional filters Best in class input performance

14 Page 14 GE– Internal & Confidential TLE Series kVA/kW UL High input performance means saving: GenSet size ( From 2 X Load kVA to 1.3 X Load kVA) - Stable & longer life due to absence of harmonics Circuit breaker size Cabling section/size Investment & space Improved life for nearby equipments No reactive power – saves on power compensation Input performances benefit

15 Page 15 GE– Internal & Confidential TLE Series kVA/kW UL Power capability – Unity power factor (kVA = kW) Designed to supply real power for Unity power factor data centers load Suitable for modern power supply application with unit or capacitive power factor (e.g. new servers generation), crest factor up to 3:1 UPS output power capability 11% more kW power compared to UPS with PF=0.9 No output voltage distortion with linear and non- linear loads Voltage distortion - linear loads: THDv <2-3% - non-linear loads:THDv < 5%

16 Page 16 GE– Internal & Confidential TLE Series kVA/kW UL UPS Input-Output Performance Module size optimization/ Electrical infrastructure utilization 4000 A Input Bus 6 x TLE 500 kW 4 x TLE 750 kW 3 x TLE 1000 kW 2 x 1500 KW 3 MW Power 3000 A Input Bus 4 x TLE 500 kW 3 x TLE 750 kW 2 X 1000 kW 2.25 / 2 MW Power 2000 A Input Bus 3 x TLE 500 kW 2 x TLE 750 kW 1 x 1500 kW 1.5MW Power 11% more kW power compared to UPS with PF=0.9 Competitors units with 0.9 power factor provides less output power from same input bus size

17 Page 17 GE– Internal & Confidential TLE Series kVA/kW UL Creating Value – Low TCO Improved Diagnostic High Reliability 3

18 Page 18 GE– Internal & Confidential TLE Series kVA/kW UL New FLEX DSP board: the black-box Waveform capture, diagnostic and trend analysis Simultaneous acquisition of 32 channels Sampling frequency up to 10kHz Smart trigger capability with up to 16 indipendent trigger sources to record only specific events with pre/post trigger data acquisition Buffer depth of 1000 samples per channel: each event is recorded for s.f. 10kHz 8 buffers to record up to 8 events without losing older events – can be extended with external USB mass storage devices WAVEFORMS Inverter voltages Bypass voltages Input mains voltages Output voltages: Output current Phases: Input capacitors “Cin” voltages: Inverter primary current: Input current: IDC current: Battery current: Bypass current: UDC Communication status RPA Auxiliary status SSM status Fuses status Phase error slave master.

19 Page 19 GE– Internal & Confidential TLE Series kVA/kW UL Creating Value – Low TCO Ease of Installation Improved Serviceability 4

20 Page 20 GE– Internal & Confidential TLE Series kVA/kW UL Reduced footprint Compact design saving space in installation kW: (w x d x h) 44.4 x 33.9 x 75.1 inch kW: 66.9 x 33.9 x 75.1 inch Standard Top-bottom cable entry Easier to handle High power density Savings in installation space Compact design 1907 / 75.1” 1100 / 43.3” TLE Series 250 kW

21 Page 21 GE– Internal & Confidential TLE Series kVA/kW UL Improved serviceability Improving Mean Time to Repair & Installation Front access construction/design Draw out construction for fans & power modules Common 250 kW power block & common components Faster power block MTTR Easy access to customer connections Easy access to connectivity Improved diagnostic capability iUPS Guard – Remote monitoring Standard back feed protection Internal Option - Q2 (TLE ) External Option – Q2 (TLE )

22 Page 22 GE– Internal & Confidential TLE Series kVA/kW CE Installation flexibility – RPA Cable Saver 1A 2A 3A 1B 2B 3B Bypass input to UPS Output from UPS Competitors – 1A=2A=3A and 1B=2B=3B or max 10% difference TLE Series with inductor = allows variation up to 20-25% (depends on UPS rating & cable section

23 Page 23 GE– Internal & Confidential TLE Series kVA/kW UL Menu driven touch screen 7” display Critical measurement of input, output and battery included with mimic diagram Quick operational status Different access level for user and service Different mimic diagram based on configuration Multilanguage communication interface Advanced User Interface Metering Alarm Set up Command RPA System

24 Page 24 GE– Internal & Confidential TLE Series kVA/kW UL Advanced User Interface Menu driven touch screen display

25 Page 25 GE– Internal & Confidential TLE Series kVA/kW UL Advanced User Interface Menu driven touch screen display Separate screen for RPA system with status and measurements Metering screen by tabs Home button inside each screen Improved alarm and events screen Easy to use set up screen

26 Page 26 GE– Internal & Confidential TLE Series kVA/kW UL Creating Value – Low TCO Summary 5

27 Page 27 GE– Internal & Confidential TLE Series kVA/kW UL Differentiated TLE Series UPS Efficiency Black Box Limited life component monitoring High Reliability Small foot print Product options Font access New control panel Draw out construction 96.5% THDi 3-5%, Input pf 0.99 Output pf -1

28 Page 28 GE– Internal & Confidential TLE Series kVA/kW UL TLE Series UPS Differentiating: Best in class double conversion efficiency - up to 96.5% Ultra high efficiency in eBoost mode of operation - up to 99% Static bypass inductor Compact foot print provides very high power density Excellent input, output performance Improved diagnostic capability with black box Ease of installation and Improved serviceability

29 Page 29 GE– Internal & Confidential TLE Series kVA/kW UL 3-Level topology High Efficiency at all loads Reduced customer operation costs and cost saving in air conditioning design High efficiency performances The TLE Series UPS uses a three level technology with an Advanced Neutral Point Clamped topology implemented with true Reverse Blocking IGBT. These result in reduced switching and filter losses with respect to a standard two level technology

30 Page 30 GE– Internal & Confidential TLE Series kVA/kW UL Improved diagnostic, High Reliability Improving Mean Time to Repair Wave form capture capability Fan failure detection Improving Reliability & Diagnostic AC Capacitor health monitoring Component life time counters Dedicated supply path for bypass logic Redundant Isolated power supply Robust RPA communication No total OFF button to avoid human error Heat sink & input, output filter coils temperature monitoring

31 Page 31 GE– Internal & Confidential TLE Series kVA/kW UL Double conversion (VFI) technology Automatic bypass for overloads, short circuit and UPS disturbances conditions Manual bypass Q2 (optional) for UPS maintenance operations without load interruption ( kW internal option) Standard common mains Number of battery blocks – back feed protection K6 standard UPS configuration Optional – TLE Series kW TLE Series kW

32 Page 32 GE– Internal & Confidential TLE Series kVA/kW UL Supplemental Cabinetry VRLA Battery Cabinet Systems Flywheel DC Energy Storage 480/480V External Maintenance Bypass 480/208V External Maintenance Bypass (250kw max) Optional Equipment 480/415VAC Input Isolation Xfmr 600VAC Input Isolation Xfmr Remote Alarm Status Panel Dual Input RPA Card for parallel operation eBoost Software for multi-mode operation Installation flexibility - Product options ISM (intelligent Synchronization module) – not supported

33 Page 33 GE– Internal & Confidential TLE Series kVA/kW UL Remote monitoring – TLE Series iUPSGuard – Remote monitoring Improved response time 24 x7 monitoring & alarm notification of UPS Improved pre dispatch diagnostic & first time fix Regular status reports Highly secure communication

34 Page 34 GE– Internal & Confidential TLE Series kVA/kW UL Customer Connectivity Easy integration with Building Management System (BMS) Customer interface UPS supervision capability 1x RS232 Serial Communication Port 6 programmable potential free alarm contacts: - D plug - Terminals blocks 1x Emergency Power OFF contact 1x Gen-ON Input contact 1x Control Input contact Additional interface: SNMP Interface Card (10/100Mbps auto-select) MODBUS Interface (RS232 or RS485) iUPSGuard (free license during warranty) - SNMP card required for iUPSGuard

35 Page 35 GE– Internal & Confidential TLE Series kVA/kW UL Configurable up to 6 units in parallel Future expansion Safe and reliable power supply Redundant Communication Bus Redundant Parallel Architecture Easy to install and maintain Easy system upgrade/downgrade Maintenance operation without load interruption RPA cable saver allows installation flexibility System reliability improved by RPA

36 Page 36 GE– Internal & Confidential TLE Series kVA/kW UL
