National Women’s Antenatal Screening Dr Emma Parry CMFM Clinical Director Maternal-Fetal Medicine National Women’s Health.

Similar presentations


Presentation on theme: "National Women’s Antenatal Screening Dr Emma Parry CMFM Clinical Director Maternal-Fetal Medicine National Women’s Health."— Presentation transcript:

1 National Women’s Antenatal Screening Dr Emma Parry CMFM Clinical Director Maternal-Fetal Medicine National Women’s Health

2 National Women’s What is Screening? Screen: an apparatus used in the sifting of grain, coal etc Shorter Oxford Dictionary A pathway, not a test Screening is a health service in which members of a defined population…are offered a test to identify those who are more likely to be helped than harmed by further tests… to reduce the risk of a disease or its complications. ( National Health Committee 2003)

3 National Women’s Criteria to be satisfied for screening Condition is suitable for screening There is a suitable test There is effective treatment for the condition There is high quality evidence (RCTs etc) that mortality/morbidity is reduced Potential benefits of screening outweight any harms caused The Health care system is capable of supporting all necessary parts of the screening pathway There is consideration of social and ethical issues There is consideration of cost-benefit issues

4 National Women’s What is a screening programme? A coordinated system of: Pretest counselling Testing with follow up Quality assurance audits of test performance Post test counselling Audits of detection rates Audits of patient satisfaction Regular review and updating as necessary

5 National Women’s Effect of choice of cut-off on test performance x minimises false positives z minimises false negatives

6 National Women’s Screening Tests Sensitivity a/(a+c) test Specificity d/(b+d) test +ve pred valuea/(a+b) cond -ve pred valued/(c+d) cond Prevalence condition in population (a+c)/(a+b+c+d) LR+ = sens/(1- spec) LR- = (1-sens)/spec ab cd test condition present absent +ve -ve

7 National Women’s Current Standard Screening Programmes Infection: –Rubella –Hepatitis B –Syphilis Malformation: –Aneuploidy –Structural –Syndromic Red Cell Antibodies

8 National Women’s Variable Screening Programmes HIV Thalassaemia CMV Smear Swabs for infection

9 National Women’s Areas of Difficulty Consistency of approach to counseling Aneuploidy Screening –Evolving results –Soft markers on anomoly scan –Multiple pregnancy –Diabetes –Late Booker –High risk result: normal karyotype HIV: late booker/ in labour

10 National Women’s OSCAR in Calgary* One Stop Clinic for Assessment of Risk Southern Alberta Centre for MFM (NT clinic + Astraia) + (DELFIAXpress + Lifecycle) = OSCAR Woman arrives Pre-test counselling* Blood sample Ultrasound Examination Risk Assessment Post-test counselling Woman departs Free b HCG PAPP-A *1-1 counselling, video, pamphlets U/S data Invasive testing usually not same day

11 National Women’s Areas of Difficulty Consistency of approach to counseling Aneuploidy Screening –Evolving results –Soft markers on anomoly scan –Multiple pregnancy –Diabetes –Late Booker –High risk result: normal karyotype HIV: late booker/ in labour

12 National Women’s Aneuploidy Screening Evolving results Soft markers on anomoly scan Multiple pregnancy Diabetes Late booker High risk result: normal karyotype

13 National Women’s 2 nd Trimester USS markers Concept of prior risk Can include –Maternal age –NT +/- NB, TR –Serum analytes: 1 st +/or 2 nd trimester Bayseian technique to allow risk adjustment ‘USS soft markers lead to a small increase in detection malformations and large increase in false positives’ Boyd et al, Lancet 1998

14 National Women’s Absent NB X83 Hypoplastic NB (16/40<3.0mm)* (20/40<4.5mm)* Increased NFX17 Echogenic bowelX6 Short femurX2.7 Short humerusX7.5 PyelectasisX1 Bethune 2007 Aus Radiol 51;

15 National Women’s Echogenic intracardiac focus –Micro-calcifications in papillary muscle –No effect per se –Small association Trisomy 21 in high risk –No increase in unselected populations –LR X 1 CP cysts –Associated with Trisomy 18 –Will nearly always have another feature eg clenched hands Bethune 2007 Aus Radiol 51;

16 National Women’s Aneuploidy Screening Evolving results Soft markers on anomoly scan Multiple pregnancy Diabetes Late booker High risk result: normal karyotype

17 National Women’s Aneuploidy Screening Evolving results Soft markers on anomoly scan Multiple pregnancy Diabetes Late booker High risk result: normal karyotype

18 National Women’s Nuchal Translucency

19 National Women’s Nuchal Translucency Designed for low risk women (<40 years?)‏ USS measurement –TA or TV –Registered user (FMF)‏ –Ongoing audit 11+3 to 13+6 Bayes theory Result is a RISK- not a diagnostic test Trisomy 13 and 18 Detection for Trisomy 21 is 85%

20 National Women’s Nuchal Translucency Nasal Bone Tricuspid Regurgitation Fronto- Maxillary facial angle DV Soft tissue thickness Aberrant subclavian artery Others?

21 National Women’s Increased NT + Normal Karyotype 15%46.2%19.0%64.5%>6.4 30%24.2%10.1%50.5% %18.5%3.4%33.3% %10.0%2.7%21.1% A&WMajor Anom Fetal Death Chrom Abn NT (mm)‏

22 National Women’s Case 1 44 year old grand multip –Pacific islander –All NVD Keen to avoid invasive testing NT 1.1mm = T21 risk 1:143

23 National Women’s Case 1 Combined with 2 nd trimester screen –A-FP, Oestriol, free bHCG Risk T21 1:140 Risk T18 1:8 Risk NTD 1:2900

24 National Women’s Case 2 Primigravida age 29 Unplanned pregnancy but wanted Epilepsy on Valproate 1000mg Family history Talipes

25 National Women’s Case 2 Wants Screening NT risk 1:2500 –Routine 2 nd trimester screening Risk T21 1:5400 Risk T18 1:12000 Risk NTD 1:4

26 National Women’s Case 2 Anomoly scan at 18/40 –Difficult views –Lemon shape head and banana cerebellum –3D volumes = Sacral open NTD with cord tethering

27 National Women’s Case 3 37 year old primigravida Fertility treatment Low risk NT Very low risk combined –Risk 1 in 8000 At anomoly scan Nasal bone short?

28 National Women’s

29

30 Why screen for aneuploidy? Provide information about risk to patients Describe choices for invasive testing Ensure this information is accurate Reassure the majority of women at an early stage Include most affected pregnancies in a ‘high risk’ group

31 National Women’s ONTD Screening Total hCG Total hCG free  hCG Second trimester: AFP Only Second trimester: AFP Only 1st Trimester free  hCG 1st Trimester free  hCG 1st Trimester PAPP-A 1st Trimester PAPP-A 1st Trimester Nuchal Translucency 1st Trimester Nuchal Translucency ADAM12 / PP13 Advances in screening for trisomy 21 NB / TR / DV Integrated Combined Sequential Mat age

32 National Women’s Maternal Serum analytes 1 st Trimester –PAPP-A –Free B-HCG 2 nd Trimester –Alpha Fetoprotein)) –Oestriol) Triple Test) –Free B-HCG)) –Inhibin-A) Quadruple Test

33 National Women’s Free ßhCG (SD) % Trisomy 21 Normal PAPP-A (SD) % Normal Trisomy 21 First trimester screening for trisomy 21 Detection rates at 12 weeks are similar to those at 16 weeks Detection rates at 12 weeks are similar to those at 16 weeks Biochemical changes are independent of fetal NT thickness Biochemical changes are independent of fetal NT thickness NT, free ß-hCG and PAPP-A identifies 90% of cases for FPR of 5% NT, free ß-hCG and PAPP-A identifies 90% of cases for FPR of 5% Maternal serum free ß-hCG & PAPP-A

34 National Women’s Free ß-hCG & Inhibin A % AFP & uE3 % Tr 21 FPR 5% 59% 63%63%67%72% MA and AFP & hCG MA and AFP & hCG & uE3 MA and AFP & ß-hCG MA and AFP & ß-hCG & uE3 MA and AFP & ß-hCG & uE3 & I A Cuckle 2001 DR 65% Second trimester screening for trisomy 21 Detection rates

35 National Women’s So what does it all mean? Combined 1 st Trimester screening –NT + 1 st trimester analytes Integrated Screening –NT + 1 st & 2 nd trimester analytes Sequential Screening –NT + 1 st trimester analytes High risk invasive testing Low risk 2 nd trimester analytes Contingent Screening –NT + 1 st trimester analytes High risk invasive testing Moderate risk 2 nd trimester analytes Very low risk (eg <1:1500) no further testing

36 National Women’s Which approach is best? Acceptable false positive rate and unnecessary intervention Acceptable false negative and risk of failure to detect aneuploidy Patient acceptability –Early results –Later results, increased accuracy –Concept of evolving risk Cost & availability non-invasive testing Late bookers Invasive testing issues –Availability –Complications

37 National Women’s Combined first trimester screening AuthorGest (wks)NDetection rate Krantz et al ,80930/33 (91%) Bindra et al ,38374/82 (90%) Spencer et al 2000; ,10523/25 (92%) Schuchter et al ,80212/14 (86%) Wapner et al ,51448/61 (79%) Perni et al ,88320/22 (91%) O’Leary et al ,28050/60 (83%) Total /297 (87%)

38 National Women’s FASTER Trial: Trisomy 21 n=86, Normal n=32,269 Integrated: 11-13w NT & PAPP-A 15-18w AFP, hCG, E 3, I A 4.9% 88% Sequential: 11-13w NT & PAPP-A, ßhCG Risk >1 in 30 positive(1.2%) Risk <1 in 30: 15-18w AFP, hCG, E 3, I A 5.1% 92% Cuckle, Malone, Write et al 2008 Contingent: 11-13w NT & PAPP-A, ß-hCG Risk >1 in 30 positive (1.2%) Risk 1/30 to 1/1500 (23%): 15-18w AFP, hCG, E 3, I A 4.5% 91% FPR DR

39 National Women’s Gestation (wks)) Deaths / 100,000 abortions Bartlett et al 2004 Induced abortion-related maternal mortality: USA

40 National Women’s What is Screening? Why screen for aneuploidy? Options for Screening: –Maternal serum analytes –Ultrasound markers 1 st Trimester 2 nd Trimester –Combining tests Horizon scanning –New tests –New techniques

41 National Women’s 2 nd Trimester USS markers

42 National Women’s 2 nd Trimester USS markers Concept of prior risk Can include –Maternal age –NT +/- NB, TR –Serum analytes: 1 st +/or 2 nd trimester Bayseian technique to allow risk adjustment ‘USS soft markers lead to a small increase in detection malformations and large increase in false positives’ Boyd et al, Lancet 1998

43 National Women’s Absent NB X83 Hypoplastic NB (16/40<3.0mm)* (20/40<4.5mm)* Increased NFX17 Echogenic bowelX6 Short femurX2.7 Short humerusX7.5 PyelectasisX1 Bethune 2007 Aus Radiol 51;

44 National Women’s Echogenic intracardiac focus –Micro-calcifications in papillary muscle –No effect per se –Small association Trisomy 21 in high risk –No increase in unselected populations –LR X 1 CP cysts –Associated with Trisomy 18 –Will nearly always have another feature eg clenched hands Bethune 2007 Aus Radiol 51;

45 National Women’s What is Screening? Why screen for aneuploidy? Options for Screening: –Maternal serum analytes –Ultrasound markers 1 st Trimester 2 nd Trimester –Combining tests Horizon scanning –New tests –New techniques

46 National Women’s New Tests ADAM 12 PAPP-A –Earlier gestation increases accuracy: 8/40 –Repeated testing New markers?

47 National Women’s Laigaard et al / 2006 An extra serum marker: ADAM12 Performance <11 weeks: TestSensFPR A1278%1.5% A12 / BhCG/ PaPPA85%1.5% Triple biochem / NT92%0.8%

48 National Women’s New Techniques Bloodspots  Simplified blood collection and transport  Eliminates broken transport tubes  Reduced biohazard  Eliminates need for centrifugation  Can be finger prick or venous sample  Can be self-sampling or by a phlebotomist  Suitable for large scale automation and regional screening modalities

49 National Women’s OSCAR in Calgary* One Stop Clinic for Assessment of Risk Southern Alberta Centre for MFM (NT clinic + Astraia) + (DELFIAXpress + Lifecycle) = OSCAR Woman arrives Pre-test counselling* Blood sample Ultrasound Examination Risk Assessment Post-test counselling Woman departs Free b HCG PAPP-A *1-1 counselling, video, pamphlets U/S data Invasive testing usually not same day

50 National Women’s Screening for Aneuploidy Good reasoning Complex haphazard introduction of tests Tests initially hailed ‘100% accurate’ Have we opened Pandora’s box?
