1 www.planet.com.tw Wireless LAN Copyright © PLANET Technology Corporation. All rights reserved.

2 www.planet.com.tw 2 / 59 Introduction Advantage of PLANET ’ s Solution Product Overview Product Features Solutions Roadmap

3 www.planet.com.tw 3 / 59 PLANET Advantages Full Range of Products for Indoor/ Outdoor WLAN Applications Access Points/ Bridge Routers Adapters Reliable Protection for Secure WLAN Communication Wireless Protected Setup (WPS) Wi-Fi Protected Access (WPA/ WPA2) WPA-PSK (Pre-Shared Key) 802.1x Authentication Wired Equivalent Privacy (WEP) Encryption Advanced Technologies Deployment 300Mbps 802.11n MIMO (Multiple Input, Multiple Output)

4 www.planet.com.tw 4 / 59 Outdoor Wireless Indoor Wireless 802.11n Indoor Wireless 802.11b/g Wireless Mesh Network Wireless Adapter Product Overview ModelDescription MAP-3100 Layer 2 / Layer 3 802.11a/b/g Indoor MESH AP (Multiple VLAN/SSID) MAP-3020 Layer 2 802.11a/b/g Outdoor MESH AP (Multiple VLAN/SSID, High Power) MAP-3120 Layer 2 802.11a/b/g Indoor MESH AP (Multiple VLAN/SSID) MAP-2100 Layer 3 802.11a/b/g Indoor MESH AP MAP-2000 / MAP-2000R Layer 3 802.11a/b/g Outdoor MESH AP (IP66, -20~70 o C) MAP-2105 Mobile IP Roaming Gateway for Wireless MESH Network Wireless Mesh Network

5 www.planet.com.tw 5 / 59 Outdoor Wireless Indoor Wireless 802.11n Indoor Wireless 802.11b/g Wireless Mesh Network Wireless Adapter Product Overview ModelDescription WAP-8000 802.11a/b/g High Power Wireless LAN Outdoor AP / Bridge (WISP support) WAP-7000802.11a Wireless LAN Outdoor Bridge WAP-6000802.11g Wireless LAN Outdoor AP / Bridge WAP-6100 802.11g Wireless LAN Outdoor AP / Bridge (12db patch antenna) WAP-6200 802.11g High Power Wireless LAN Outdoor AP / Router (14db patch antenna, WISP support) Outdoor Wireless

6 www.planet.com.tw 6 / 59 Outdoor Wireless Indoor Wireless 802.11n Indoor Wireless 802.11b/g Wireless Mesh Network Wireless Adapter Product Overview ModelDescription WNAP-3000PE 802.11n Gigabit PoE Enterprise Wireless AP (3T3R) WNAP-1120 WNAP-1120PE 802.11n Wireless AP (2T2R) WNRT-630 802.11n Wireless Gigabit Router (2T3R, Giga WAN, Giga LAN) WNRT-625G 802.11n 3G Broadband Router (2T2R, 3G mobile) WNRT-625 802.11n Wireless Router (2T2R, WISP support) WNRT-626 802.11n Wireless Router (1T1R, WISP support) Indoor Wireless 802.11n

7 www.planet.com.tw 7 / 59 Outdoor Wireless Indoor Wireless 802.11n Indoor Wireless 802.11b/g Wireless Mesh Network Wireless Adapter Product Overview ModelDescription WAP-4033PE54Mbps PoE Wireless AP WAP-4033 54Mbpw Wireless AP (AP/ AP Client/ Bridge PtP, PtMP/ WDS/ Repeater) WAP-4036 54Mbps Wireless AP (AP/AP Client/ WDS/ AP+WDS/ Repeater) WRT-41454Mbps Wireless Router (QoS / WISP support) WRT-41654Mbps Wireless Router (WISP support) WPG-11054Mbps Wireless Presentation Gateway ADW-4401A54Mbps Wireless ADSL 2/2+ Router WSG-40454Mbps Wireless Hot Spot Gateway WLS-1280 Wireless LAN Switch / Security Gateway (Central Managed APs: WAP-4060PE/4033/4033PE) Indoor Wireless 802.11b/g

8 www.planet.com.tw 8 / 59 Outdoor Wireless Indoor Wireless 802.11n Indoor Wireless 802.11b/g Wireless Mesh Network Wireless Adapter Product Overview ModelDescription 802.11n Wireless Adapter WNL-U552 802.11n Wireless USB Adapter (2T2R) WNL-U554 802.11n Wireless USB Adapter (1T1R) WNL-U554A 802.11n Wireless USB Adapter ( 1T1R, RP-SMA connector ) WNL-9320 802.11n Wireless PCI card (2T3R) WNL-9330 802.11n Wireless PCI card (1T2R) WNL-9500 802.11n Wireless PCI Express Card ( 2T3R ) 802.11g Wireless Adapter WL-3560 Super G 54 / 108Mbps 802.11g Wireless PCI Adapter WL-8317 802.11g Wireless PC card Wireless Adapter

9 www.planet.com.tw 9 / 59 Features Wireless Mesh Network Outdoor Wireless LAN Indoor Wireless LAN Wireless Adapter

10 www.planet.com.tw 10 / 59 Features Brief Outdoor Mesh APIndoor Mesh AP MAP-3020MAP-2000MAP-3100MAP-3120MAP-2100 System Specification Operating Frequency2.4/5.8GHz Ethernet PortLAN x 1, Public x1WAN x 1, LAN x 1WAN x 1, LAN x 4LAN x 5WAN x 1, LAN x 1 WiFi Clients AccessIEEE 802.11a/b/g WiFi Backhaul RoutingIEEE 802.11a or g Mesh Operating ModeGateway, Relay Gateway, Relay, Client Relay Gateway, Relay Mesh ControlLayer 2Layer 3Layer 2/3Layer 2Layer 3 IEEE 802.3af (PoE)Vprivate PoEVV- System Services Captive Portal-VV-V Centralized LoginVVVVV QoS Level--4 Levels-- iPass-VV-- Security Firewall Firewall - VV - - WPA/ WPA2, WEP, 802.1x WPA/ WPA2, WEP, 802.1x V VV V - MAC Access Control MAC Access Control V-V V- ESSID Suppress ESSID Suppress V VV V - Multiple SSID Support Multiple SSID Support V-V V- Wireless Separation Wireless Separation V VV V - Wireless Mesh Access Points (1/2)

11 www.planet.com.tw 11 / 59 Features Brief Outdoor Mesh APIndoor Mesh AP MAP-3020MAP-2000MAP-3100MAP-3120MAP-2100 Protocol Support DHCP-Server / Client - VV - V PPPoE (RFC 2516) V VV V V VPN (IPSec with encryption) - -V - - VPN (L2TP) - -V - - VPN (PPTP) - VV - V VLAN V-VV- Mobile IP (RFC 2005) V VV* V V IAPP V VV V V QoS, IEEE 802.11e - -V - - DFS, IEEE 802.11hV-VV- Wireless Interface Transmitter Power Transmitter PowerMax. 26dbmMax. 20dbm Max. 17dbmMax. 20dbm Management Local Web Space Local Web Space-VV-- Web-based Management Web-based ManagementVVVVV Wireless Mesh Access Points (2/2)

12 www.planet.com.tw 12 / 59 Features MAP-2000/2000R Outdoor Mesh AP MAP-2000 Outdoor Mesh AP (Relay mode) MAP-2000R  Dual wireless interfaces for independent Backhaul link and local clients connection 2 x IEEE802.11a/b/g adapters 2 x N-type connector  Supports full dynamic routing (layer 3) between all node APs MDOLSR, modified dynamic optimized link state routing protocol  Adjustable output power: 50mW, 25mW, 13mW, and 6mW  Central management software AES backhaul communication  Supports 802.1x/ WPA/ WPA2 mechanisms  Supports QoS, SNMP v2/v3  Power over Ethernet capable (with the proprietary injector)  IP-66 protection housing  Operating temperature: -20~70 degree C MAP-2000 / MAP-2000R Management Utility

13 www.planet.com.tw 13 / 59 Features MAP-2000 Typical installation Sector Coverage with VSAT Backbone Sector Area – Wireless Mesh Network Coverage Backbone Access by VSAT MAP-2000 (Gateway) MAP-2000 (Relay) Backend Internet connection Headquarter Server Farm

14 www.planet.com.tw 14 / 59 Comparison MAP-2000 Brand Features PLANET MAP-2000 FireTide Hotport 3100 Tropos 3210 Architecture 1 box Operating Frequency 2.4/5.0 GHz 2.4Ghz LAN Extension port 141 WiFi Clients Access 11a/b/g-11b/g Mesh Control Layer 3 System Services DHCP-Server VVV DHCP-Client VVV PPPoE V-- DNS-Client VVV VPN VVV Firewall VVV NAT VVV NTP-Client VV- Captive Portal V-- VLAN Next ReleaseVV Mobile IP V-V IAPP V-- Traffic shaping V-- QoS 4 levels3 levels-

15 www.planet.com.tw 15 / 59 Comparison MAP-2000 Brand Features PLANET MAP-2000 FireTide Hotport 3100 Tropos 3210 Security WPA V-V WPA2 V-V WEP VVV 802.1x V-V MAC Access Control V-V ESSID Suppress V-V AES VVV Web-based Management VVV Standalone Management Software VV- Firmware UpgradeableVVV SNMP1, 2c, 3-2c

16 www.planet.com.tw 16 / 59 Features MAP-3100 L2/L3 Indoor Mesh AP  Dual wireless interfaces for independent Backhaul link and local clients connection 2 x IEEE802.11a/b/g adapters 2 x RP-SMA connectors  Supports both Layer 2 and Layer 3 Operations OLSR, stateful dynamic optimized link state routing protocol for L3 Client Relay mode for efficient network routing and installation Layer 2 Mesh supports AODV protocol  Adjustable output power: 20dbm ~ 1dbm  Central management software AES backhaul communication PPTP, IPSEC VPN support  Supports Multi-SSID/VLAN, 802.1x/ WPA/ WPA2 mechanisms  Supports QoS, SNMP v2/v3  802.3af Power over Ethernet capable MAP-3100

17 www.planet.com.tw 17 / 59 Features MAP-3120 / MAP-3020 L2 Indoor / Outdoor Mesh AP  Dual wireless interfaces for independent Backhaul link and local clients connection 2 x IEEE802.11a/b/g adapters 2 x RP-SMA connectors  Supports Layer 2 Operation Better performance Single IP segment to ease the management task Suitable for smaller network  Adjustable output power : 20dbm ~ 1dbm (MAP-3120) 26dbm ~ 1dbm (MAP-3020)  Central management software AES backhaul communication  Supports 802.1x/ WPA/ WPA2 mechanisms  802.3af Power over Ethernet capable  High power design (MAP-3020) MAP-3120 L2 Indoor Mesh AP MAP-3020 L2 Outdoor Mesh AP

18 www.planet.com.tw 18 / 59 Indoor Mesh AP  Same as MAP-2000 but with palm-sized plastic enclosure  Dual wireless interfaces for independent Backhaul link and local clients connection 2 x IEEE802.11a/b/g adapters 2 x RP-SMA for different type antenna  Supports full dynamic routing (layer 3) between all node APs MDOLSR, modified dynamic optimized link state routing protocol  Adjustable output power: 50mW, 25mW, 13mW, and 6mW  Central management software AES backhaul communication  Supports 802.1x/ WPA/ WPA2 mechanisms  Supports QoS, SNMP v2/v3  Operating temperature: 0~50 degree C Features MAP-2100 MAP-2100

19 www.planet.com.tw 19 / 59 Mobile IP Roaming Gateway  Purpose: Provide full “ Mobility ” to all users in MESH network Not like the layer-2 only capability in ordinary AP, the “mobility” defined in Mobile IP Gateway is the ability of a user to change its attached node from one mesh AP to another while maintaining all existing communications and using the same IP address at this new link all the time.  Advantage: Users can have continuous network services, such as VoIP communications and file transfers, while roaming from node to node without the fear of connection broken.  Features:  Provides 1 WAN port for Internet connection  Secured HTTP management  Supports VPN client  Optimized for up to 500 users Features MAP-2105 MAP-2105

20 www.planet.com.tw 20 / 59 Features Wireless Mesh Network Outdoor Wireless LAN Indoor Wireless LAN Wireless Adapter

21 www.planet.com.tw 21 / 59 Features Brief Model Feature WAP-8000WAP-7000WAP-6000WAP-6100WAP-6200 Wireless Standard 802.11a/b/g802.11a802.11g / Super G 802.11g Frequency Band 2.4 / 5GHz5GHz2.4GHz Max. Data Rate 108 Mbps 54 Mbps Operatio n Mode AP--VVV BridgeVVVVV Repeater--VVV AP ClientV-VVV Security WPA -PSKV-VVV WPA2-PSKV---V WEPVVVVV 802.1x----V Clear Channel Auto SelectVVVVV Adjustable Output PowerVVVVV SNMP SupportVV--- WISPV---V Routing Function----V Outdoor Wireless Access Points / Bridges

22 www.planet.com.tw 22 / 59 802.11a/b/g 108Mbps Outdoor WLAN AP  2.4/5GHz operating frequency with less interference  Super A/G mode, Data rate up to 108Mbps  Available channels selectable  High Power design up to 400mW, with multiple Adjustable output power  Case designed with IP 68 code for waterproof  Power over Ethernet capable (with the proprietary injector)  SNMP management  Operating temperature: -40~85 degree C Features WAP-8000 WAP-8000

23 www.planet.com.tw 23 / 59 802.11a 54Mbps Outdoor WLAN Bridge  5GHz operating frequency with less interference  Available channels selectable conforming to local radio restrictions on 802.11a standard  Adjustable output power: 100mW, 50mW, 25mW, 13mW, and 6mW  Theoretically, the operating range can up to 17KM at 6Mbps data rate when installing with 5GHz 18dBi antenna  Power over Ethernet capable (with the proprietary injector)  Operating temperature: -20~70 degree C Features WAP-7000 WAP-7000 Extend the wireless connection with antenna

24 www.planet.com.tw 24 / 59  Operation modes: AP, Bridge, Wireless client, Repeater  Robust WLAN security support : WPA (Wi-Fi Protected Access) WPA-PSK (Pre-Shared Key) WEP encryption  Adjustable output power: 65mW, 32mW, 16mW, 8mW, and 4mW  Theoretically, the operating range can up to 18KM at 6Mbps data rate when installing with ANT-SE18 (18dBi antenna)  Power over Ethernet capable (with the proprietary injector)  Operating temperature: -20~70 degree C Features WAP-6000 WAP-6000 802.11g 54Mbps Outdoor WLAN AP with Bridge

25 www.planet.com.tw 25 / 59  Operation modes: AP, Bridge, Wireless client, Repeater  Robust WLAN security support : WPA (Wi-Fi Protected Access) WPA-PSK (Pre-Shared Key) WEP encryption  Adjustable output power: full, half, quarter, eighth, minimum  Built-in 12dBi patch antenna  Power over Ethernet capable (with the proprietary injector)  Operating temperature: -10~70 degree C Features WAP-6100 WAP-6100 802.11g 54Mbps Outdoor WLAN CPE AP

26 www.planet.com.tw 26 / 59  Operation modes: AP, WDS (Bridge), AP+WDS, Wireless client, Repeater & WISP  Robust WLAN security with WEP, WPA, WPA-PSK, WAP2, WPA2-PSK, 802.1x  Adjustable output power: 400mW,200mW, 100mW, 50mW, 25mW  Built-in 14dBi patch antenna  Power over Ethernet capable (with the proprietary injector)  Operating temperature: -10~60 degree C Features WAP-6200 WAP-6200 802.11g Outdoor WLAN CPE AP/ Router

27 www.planet.com.tw 27 / 59 Features Wireless Mesh Network Outdoor Wireless LAN Indoor Wireless LAN  802.11n AP/ Router  802.11g AP/ Router  Wireless LAN Switch  Hot-Spot Gateway Indoor Wireless Adapter

28 www.planet.com.tw 28 / 59 Features Brief Model Feature WNAP-3000PE WNAP-1120 WNAP-1120PE WNRT-630WNRT-625GWNRT-625WNRT-626 Wireless Standard 802.11n 3G protocol 802.11n Frequency Band2.4GHz Data Rate 300Mbps 150Mbps Operation Mode APVVVVVV BridgeVVVVVV RepeaterVVVVVV AP clientVVVVVV WISP---VVV Security WEPVVVVVV 802.1xVVVVVV WPA / WPSVVVVVV Features Hardware RF ON/OFF ---VVV QOS-VVVVV PoEVV (PE model)---- 802.11n Indoor Wireless AP/Router

29 www.planet.com.tw 29 / 59 Features WNAP-3000PE 802.11n Gigabit PoE Wireless AP  300Mbps for high speed wireless connection 3T3R technology  802.11n draft 2.0 compliant wireless technology backward compatible with 802.11b/g standards  IEEE 802.3af compliant  Multiple Wireless mode: AP, AP Client, Bridge P2P/P2mP, Repeater  Supports WPA (PSK)/WPA2 (PSK) & 64/128-bit WEP & 802.11x Encryption  Supports SNMP v1,v2,v3  Multiple-SSID / 802.11Q tagging function  SSL Web-based advanced user interface, Telnet/CLI  Universal Plug and Play (UPnP) WNAP-3000PE

30 www.planet.com.tw 30 / 59  IEEE 802.11n provides data rate up to 300Mbps  IEEE 802.3af compliant (WNAP-1120PE)  Supports Wi-Fi Protected Setup (WPS)  Four operating modes: AP, AP client, Bridge, WDS, Repeater  Support WPA (Wi-Fi Protected Access) for 802.1x and WPA-PSK  Multiple SSID / 802.11Q tagging function  Built-in Radius Server function Features WNAP-1120 / WNAP-1120PE WNAP-1120 WNAP-1120PE 802.11n 300Mbps WLAN AP with Bridge

31 www.planet.com.tw 31 / 59 Features WNRT-630 802.11n Wireless Router  300Mbps for high speed wireless connection Giga Port at WAN and LAN ports MIMO 2T3R technology  802.11n draft 2.0 compliant wireless technology backward compatible with 802.11b/g standards  Breakthrough wireless performance at wired speed  Multiple Wireless mode: AP, AP Client, Bridge P2P/P2mP, Repeater  Supports WPA (PSK)/WPA2 (PSK) & 64/128-bit WEP & 802.11x Encryption  Double firewalls: NAT and SPI  Web-based advanced user interface  Universal Plug and Play (UPnP)  QoS controls network bandwidth WNRT-630

32 www.planet.com.tw 32 / 59 Features WNRT-625G 802.11n Wireless Router  Dual WAN Interfaces: WAN port for cable or wired DSL service + 3G mobile connection  Supports UMTS/HSDPA Mobile Internet Service  300Mbps for high speed wireless connection 2T2R technology  802.11n draft 2.0 compliant wireless technology backward compatible with 802.11b/g standards  Breakthrough wireless performance at wired speed  Supports WPA (PSK)/WPA2 (PSK) & 64/128-bit WEP & 802.11x Encryption  Double firewalls: NAT and SPI  Web-based advanced user interface  Universal Plug and Play (UPnP)  QoS controls network bandwidth WNRT-625G

33 www.planet.com.tw 33 / 59 Features WNRT-625 802.11n Wireless Router  300Mbps for high speed wireless connection 2T2R technology  802.11n draft 2.0 compliant wireless technology backward compatible with 802.11b/g standards  Breakthrough wireless performance at wired speed  Multiple Wireless mode: AP, AP Client, Bridge P2P/P2mP, Repeater, WISP  Supports WPA (PSK)/WPA2 (PSK) & 64/128-bit WEP & 802.11x Encryption  Double firewalls: NAT and SPI  Web-based advanced user interface  Universal Plug and Play (UPnP)  QoS controls network bandwidth WNRT-625

34 www.planet.com.tw 34 / 59 Features WNRT-626 802.11n Cost Effective Wireless Router  802.11n high speed wireless connection 11n 1T1R technology  802.11n draft 2.0 compliant wireless technology backward compatible with 802.11b/g standards  Breakthrough wireless performance at wired speed  Multiple Wireless mode: AP, AP Client, Bridge P2P/P2mP, Repeater, WISP  Supports WPA (PSK)/WPA2 (PSK) & 64/128-bit WEP & 802.11x Encryption  Double firewalls: NAT and SPI  Web-based advanced user interface  Universal Plug and Play (UPnP)  QoS controls network bandwidth WNRT-626

35 www.planet.com.tw 35 / 59 11n 300Mbps Wireless Network WNL-U552 WNL-U554 WNL-9320 WNRT-630 300Mbps High Speed 3x Wireless Coverage

36 www.planet.com.tw 36 / 59 Features Brief Model Feature WAP-4033PEWAP-4033WAP-4035WAP-4036 Wireless Standard 802.11g Frequency Band 2.4GHz Max. Data Rate 54 Mbps PoE SupportV--- WISP Support---V Operation Mode APVVVV BridgeVVVV RepeaterVVVV AP clientVVVV Security WEPVVVV 802.1xVVV- WPAVVVV 802.11g Indoor Wireless Access Points

37 www.planet.com.tw 37 / 59 802.11g WLAN AP  IEEE 802.11b/g dual standards compatible  Provide data rate up to 54Mbps, auto rate fallback  Support WPA, WPA2, 64/128-bit WEP encryption, and MAC Filter  With SMA connector for external antenna connection  Operation modes: AP, Bridge, Repeater, AP client  Support 802.3af PoE (WAP-4033PE)  Provide 5 LAN ports (WAP-4035)  RADIUS server built-in (WAP-4035) Features WAP-4033/4033PE/4035/4036 WAP-4035 WAP-4033 WAP-4033PE WAP-4036

38 www.planet.com.tw 38 / 59 Features Brief Model Feature WRT-414WRT-416ADW-4401A/B Wireless Standard802.11g Max. Data Rate54 Mbps WAN PortRJ-45 or RF (WISP mode)RJ-45RJ-11 ADSL Standard--ADSL 2/2+ Operating Mode WISP, AP, AP Client, Bridge, WDS Repeater AP, Bridge, WDS RepeaterAP Wireless Security WEP VVV WPA-PSK VVV WPA-RADIUS V-- VPN FeatureVPN Pass-ThroughVPN Pass-through4 IPSec / 4 PPTP tunnels DMZVVV Virtual ServerVVV Filters MAC filter, IP filter, URL blocking, QoS MAC filter, URL blocking MAC filter, TCP/UDP port filter, IP filter, Packet filter Market PositionSOHO / Home Use / WISP CPE SOHO / Home Use 802.11g Indoor Wireless Routers

39 www.planet.com.tw 39 / 59 802.11g 54Mbps WLAN Broadband Router  IEEE 802.11b/g dual standard compatible  Operation modes: AP, Bridge, AP client  Wireless WAN for WISP CPE application  Built-in 4-port switch allows wireless clients share the same broadband Internet connection  Supports WPA, WPA 2, 64/128-bit WEP encryption and MAC filter to secure WLAN information  Support QoS, UPnP, DMZ, VPN pass through  Support DHCP server Features WRT-414 WRT-414 Signal 70% Signal 20% Outdoor AP

40 www.planet.com.tw 40 / 59 Cost-effective 802.11g 54Mbps WLAN Broadband Router  IEEE 802.11b/g dual standard compatible  Built-in 4-port switch allows wireless clients share the same broadband Internet connection  Supports AP / WDS / AP+WDS mode  Supports WPA, 64/128-bit WEP encryption and MAC filter to secure WLAN information  Support DDNS, DMZ, VPN pass through  Support DHCP server Features WRT-416 WRT-416

41 www.planet.com.tw 41 / 59 Feature ADW-4401A 802.11g Wireless ADSL 2/2+ Router  IEEE 802.11b/g standards compatible  Compliant with ADSL 2+ standard  Backward compatible with ADSL, ADSL 2 standard  Data transmission up to 24Mbps downstream and 3.5Mbps upstream  Built-in 4-port switch with auto MDI/MDI-X capability  Supports IPSec and PPTP VPN  Supports NAT, DHCP, DMZ, virtual server  Supports Firewall, Access Control, Packet Filter  Supports Dynamic DNS server and UPnP  SNMP management with SNMPv2 ADW-4401A (Annex A, POTS)

42 www.planet.com.tw 42 / 59 Features WLS-1280 IPSec VPN Encrypted Network Wireless LAN Switch  Manageable 12 APs include WAP-4033, WAP-4033PE and WAP-4060PE  Supports up to 120 concurrent users  Provides 500 local accounts and 2000 on-demand accounts  Multiple User login method via local database, RADIUS, POP3, NT domain  Role-based and Policy-based access control, bandwidth control  Supports monitor IP on 3rd party Access Points  Managed APs support WEP, WPA, and WPA2  Supports VPN termination of IPSec tunnels for secured wired/wireless connection  Supports MAC Access Control List WLS-1280 LAN WAN

43 www.planet.com.tw 43 / 59 Features WSG-404 54 Mbps 11g Hot Spot Wireless Subscriber Gateway  Plug-n-Play IP Internet access, no configuration changes required  Comply with 802.11g wireless standard Work with any WiFi adapters such as Centrino Notebook, 11g 54Mbps adapters or 11b adapters  Built-in or RADIUS AAA support (Authentication, Authorization and Accounting)  Built-in RC4 WEP Encryption, secure HTML login page (SSL), VLAN Security for Wireless, VPN (IPSec/PPTP) Pass through  Operate with the compact thermal printer (WSG-ACG4) to print out billing information in a minute  Right for any places that provide public access to the Internet, such as Cyber Caf é, Airport, Government, and etc. WSG-404

44 www.planet.com.tw 44 / 59 Features Wireless Mesh Network Outdoor Wireless LAN Indoor Wireless LAN Wireless Adapter

45 www.planet.com.tw 45 / 59 USB Adapter Features 802.11n WLAN Adapter  IEEE 802.11b/g standards compatible  Compliant with 802.11n draft2.0 standard  8x coverage farther than standard 802.11g with improved reliability and fewer drops  6x speed greater than standard 802.11g  Supports Software AP mode  WMM & power save features  Supports WPS (Wi-Fi Protected Setup)  USB 2.0/1.1 interface  Supports popular OS: Vista, XP, 2000 WNL-U554 WNL-U552 WNL-U554A

46 www.planet.com.tw 46 / 59 Features 802.11n WLAN Adapter  IEEE 802.11b/g standards compatible  Compliant with 802.11n draft2.0 standard  8x coverage farther than standard 802.11g with improved reliability and fewer drops  6x speed greater than standard 802.11g Supports Software AP mode  WMM & power save features  Supports WPS (Wi-Fi Protected Setup)  PCI 2.2 / PCI Express interface  Supports popular OS: Vista, XP, 2000 WNL-9330 PCI Bus Adapter PCI Express Adapter WNL-9320 WNL-9500

47 www.planet.com.tw 47 / 59  IEEE 802.11b/g standards compatible  Base on 2.4GHz DSSS (Direct Sequence Spread Spectrum) technology and support the modulation of OFDM mode  Super G mode provide data rate up to 108Mbps  Support eXtended Range mode  Supports WPA for 802.1x and WPA-PSK  Driver supports most of the popular operating systems Features Super G WLAN Adapter PCMCIA Adapter WL-3560

48 www.planet.com.tw 48 / 59  IEEE 802.11g standards compatible  Provide data rate up to 54Mbps  Supports WPA-PSK and 64/128-bit WEP encryption  Driver supports most popular operating systems Features 11g WLAN Adapter WL-8317 PCI Bus Adapter

49 www.planet.com.tw 49 / 59 Accessories Booster Model Feature WBT-200WBT-1000WBT-1000A Frequency band (MHz) 2400~2500 5150~5850 Application IndoorOutdoor Connector type SMAN-type Case PlasticMetal Output power (mW) 100/200/500 adjustable1000 Receiver gain (dB) 1215

50 www.planet.com.tw 50 / 59 Model Feature ANT-YG20ANT-YG13ANT-SE18ANT-FP18 Antenna Type Uni-directional, Yagi Uni-directional, Sector Uni-directional, Flat panel Gain (dBi) 201312-1818 Beamwidth degree Horz. 202560-12030 Vert. 15 1020 Mounting Type Mast Mount Mast/ Wall MountWall Mount Model Feature ANT-OM15ANT-OM8ANT-OM5ANT-OM5NANT-OM5A Antenna Type Omni-directional, General purpose Omni-directional, General purpose Omni-directional, Desktop Omni-directional For 802.11n devices Dual band Omni-directional, Desktop Gain (dBi) 158552.4 / 5Hz 3/5 Beamwidth degree Horz. 360 Vert. 10 603225 Mounting Type Mast Mount Magnetic bottom Desktop stand 2.4GHz Antennas Accessories Antennas

51 www.planet.com.tw 51 / 59 Model Feature ANT-SE17AANT-FP18AANT-OM10AANT-OM5A Antenna Type Uni-directional, Sector Uni-directional, Flat panel Omni-directional Dual band Omni-directional, Desktop Gain (dBi) 16.518102.4 / 5Hz 3/5 Beamwidth degree Horz. 12010360 Vert. 10 625 Mounting Type Pole or Wall Mount Pole or Wall Mount Pole or Wall Mount Desktop stand Accessories Antennas 5GHz Antennas

52 www.planet.com.tw Solutions

53 www.planet.com.tw 53 / 59 Wireless Mesh Network Solutions The highly scalable, cost-effective solution offers users a secure and seamless roaming beyond traditional WLAN boundaries. 1.Wireless mesh backbone link to replace old-fashioned cable connection 2.Self-healing and self-adaption via Layer-3 Routing Protocol 3.Secures data integrity and controls traffic flowing over wireless links Enhanced mobility for clients: Always-on, anytime, anywhere access RADIUS, PPPoE, VPN Server: Incorporates security mechanisms to authorize access for end users Management Server: Centralized monitoring and managing network operations

54 www.planet.com.tw 54 / 59 Outdoor Inter-Building Wireless Solution Compared with traditional T1/E1 line, the wireless bridge application provides a fast and cost-effective solution for inter-building connection. Outdoor AP Solutions Central site Along with the Omni-directional antenna, the WAP-6000 can provide 360º wireless coverage for remote clients. Satellite sites With built-in 12dBi patch antenna, the WAP-6100 in satellite site can directly point to the destination bridge, thus reduce the unnecessary signal scattering.

55 www.planet.com.tw 55 / 59 WISP Solutions WISP (AP-AP Client Connection)  Flexible in installation  Flexible in wiring distance  Saving wiring cost WISP Provider WISP mode When WISP mode is enabled, CPE AP router acts as an AP client to connect the building to local WISP provider or nearby AP.

56 www.planet.com.tw 56 / 59 RADIUS AAA support Authentication and Accounting service “Zero configuration” Internet access WSG-404’s unique IP Plug&Play (iPnP) technology allows subscribers to obtain broadband access without re-configuration of their device IP settings including DHCP, DNS, Proxy and dynamic and static IP address assignments. Optional Account Generator for billing Wireless Hot Spot Solutions

57 www.planet.com.tw 57 / 59 Enterprise WLAN Solutions 300Mbps high speed Wireless backbone with PoE WPA security Cooperating with the RADIUS server in LAN, WNAP-3000PE can effectively control the user authentication. Wireless VLANs Separate wireless subnets can be defined for various class-of-service and security policies.

58 www.planet.com.tw 58 / 59 2009/Q32009/Q4 Roadmap Wireless Adapter/ Accessories Indoor WLAN AP/Router Outdoor WLAN AP/ Bridge 11n 300Mbps AP WNAP-1120/1120PE 11a Outdoor AP High/Normal power, Low Cost 11n 3G Router 300Mbps WNRT-625G 11g PCI/PCI-E adapter WNL-9320 / WNL-9500 1T1R 11n USB adapter WNL-U554 / WNL-U554A Outdoor L2 Mesh AP MAP-3020 11n PCI-E Ralink / Realtek, 2T2R Cost down 11n PCI Ralink / Realtek, 2T2R Cost down Outdoor 11a/b/g AP/ Bridge WAP-8000 11n Router cost effective WNRT-626 Dual band 11n 300Mbps Router WDRT-600 11n Outdoor AP High power 11n Indoor AP 11n 2T2R, 1 WAN + 1 LAN, PoE, WNAP-2000PE 11n Gigabit /PoE AP WNAP-3000PE Outdoor Dual Radio AP / Bridge 11b/g AP Router WAP-6200

59 www.planet.com.tw
