Introduction to the Cray XK7

Introduction to the Cray XK7
Jeff Larkin Cray Supercomputing Center of Excellence

NCRC Fall User Training 2012
Agenda Cray XK7 Architecture AMD Interlagos Processor Cray Gemini Interconnect Nvidia Kepler Accelerator Lustre Filesystem Basics Cray Programming Environment Available Compilers Cray Scientific Libraries Cray MPICH2 Cray Performance Tools Cray Debugging Tools It’s unlikely we’ll get through all the slides, these are meant to serve as a reference for you after this workshop. NCRC Fall User Training 2012

Titan Configuration Name Titan Architecture XK7 Processor AMD Interlagos Cabinets 200 Nodes 18,688 CPU Memory/Node 32 GB GPU Memory/Node 6 GB Interconnect Gemini GPUs Nvidia Kepler 10-20 Petaflops 25x8x24 3D torus (22.5 TB/s global bandwidth) 128 I/O blades ( GB/s bidir) 1,278 TB of memory 4,352 sq. ft. 10 MW Transition Out: There are 6 primary, representative applications that will be developed, tested, and improved on the Titan system <click> NCRC Fall User Training 2012

Cray XK7 Architecture AMD Interlagos Processor Cray Gemini Interconnect Nvidia Kepler Accelerator Lustre Filesystem Basics

XE6 Node (Gaea) Gemini Cray Baker Node Characteristics Number of Cores
HT 3 HT 3 Gemini Cray Baker Node Characteristics Number of Cores 32* Peak Performance ~300 Gflops/s Memory Size 64 GB per node Memory Bandwidth 85 GB/sec 10 12X Gemini Channels (Each Gemini acts like two nodes on the 3D Torus) High Radix YARC Router with adaptive Routing 168 GB/sec capacity NCRC Fall User Training 2012

Cray XK7 Architecture NVIDIA Kepler GPU 6GB GDDR5; 138 GB/s PCIe Gen2 HT3 HT3 AMD Series 6200 CPU Click: We start by taking a best in class HPC processor in the AMD Opteron 6200 Click: We then tightly integrate an accelerator designed for HPC computing in the NVIDIA Tesla processor Click: Host memory is 1600 MHz DDR3 and has configurations of 16, 32, or 64 GB Click: Accelerator memory is pushed to the physical limits with 6GB of GDDR5 memory available at 138 GB/s with ECC protection Click: And of course all of this is brought together with the fantastic and award winning Gemini High Speed Interconnect The host memory, the processor, and the accelerator are all upgradeable. Transition Out: We can pack 4 of these nodes onto 1 blade that can get you…<click> 1600 MHz DDR3; 32 GB Cray Gemini High Speed Interconnect NCRC Fall User Training 2012 Cray Proprietary

XK7 Node Details Shared L3 Cache DDR3 Channel Shared L3 Cache HT3 PCIe HT3 1 Interlagos Processor, 2 Dies 8 “Compute Units” 8 256-bit FMAC Floating Point Units 16 Integer Cores 4 Channels of DDR3 Bandwidth to 4 DIMMs 1 Nvidia Kepler Accelerator Connected via PCIe Gen 2 To Interconnect NCRC Fall User Training 2012 Cray Proprietary

AMD Interlagos Processor
Chapter 8: Single-node Optimization AMD Interlagos Processor NCRC Fall User Training 2012 TR-XEP_BW-A Cray Private

Interlagos Core Definition
Chapter 8: Single-node Optimization Interlagos Core Definition In order to optimize the utilization of the shared and dedicated resources on the chip for different types of applications, modern x86 processors offer flexible options for running applications. As a result, the definition of a core has become ambiguous. Definition of a Core from Blue Waters proposal: Equivalent to an AMD “Interlagos” Compute Unit, which is an AMD Interlagos “Bulldozer module” consisting of: one instruction fetch/decode unit, one floating point scheduler with two FMAC execution units, two integer schedulers with multiple pipelines and L1 Dcache, and a L2 cache. This is sometimes also called a “Core Module.” A “core” = “compute unit” = “core module.” NCRC Fall User Training 2012 TR-XEP_BW-A Cray Private

Interlagos Processor Architecture
Chapter 8: Single-node Optimization Interlagos Processor Architecture Shared L2 Cache Fetch Decode Shared L3 Cache and NB FP Scheduler 128-bit FMAC L1 DCache Pipeline Int Scheduler Int Core 0 Int Core 1 Dedicated Components Shared at the module level Shared at the chip level Interlagos is composed of a number of “Bulldozer modules” or “Compute Unit” A compute unit has shared and dedicated components There are two independent integer units; shared L2 cache, instruction fetch, Icache; and a shared, 256-bit Floating Point resource A single Integer unit can make use of the entire Floating Point resource with bit AVX instructions Vector Length 32 bit operands, VL = 8 64 bit operands, VL = 4 NCRC Fall User Training 2012 TR-XEP_BW-A Cray Private

Building an Interlagos Processor
Chapter 8: Single-node Optimization Building an Interlagos Processor Each processor die is composed of 4 compute units The 4 compute units share a memory controller and 8MB L3 data cache Each processor die is configured with two DDR3 memory channels and multiple HT3 links Shared L3 Cache Memory Controller NB/HT Links NCRC Fall User Training 2012 TR-XEP_BW-A Cray Private

Interlagos Die Floorplan
Chapter 8: Single-node Optimization Interlagos Die Floorplan NCRC Fall User Training 2012 TR-XEP_BW-A Cray Private

Chapter 8: Single-node Optimization
Interlagos Processor Shared L3 Cache NB/HT Links Memory Controller Shared L3 Cache NB/HT Links Memory Controller Two die are packaged on a multi-chip module to form an Interlagos processor Processor socket is called G34 and is compatible with Magny Cours Package contains 8 compute units 16 MB L3 Cache 4 DDR or memory channels TR-XEP_BW-A Cray Private

Interlagos Caches and Memory
L1 Cache 16 KB, 4-way predicted, parity protected Write-through and inclusive with respect to L2 4 cycle load to use latency L2 Cache 2MB, Shared within core-module 18-20 cycle load to use latency L3 Cache 8 MB, non-inclusive victim cache (mostly exclusive) Entries used by multiple core-modules will remain in cache 1 to 2 MB used by probe filter (snoop bus) 4 sub-caches, one close to each compute module Minimum Load to latency of cycles Minimum latency to memory is cycles NCRC Fall User Training 2012

Two MPI Tasks on a Compute Unit ("Dual-Stream Mode")
Chapter 8: Single-node Optimization Two MPI Tasks on a Compute Unit ("Dual-Stream Mode") An MPI task is pinned to each integer unit Each integer unit has exclusive access to an integer scheduler, integer pipelines and L1 Dcache The 256-bit FP unit, instruction fetch, and the L2 Cache are shared between the two integer units 256-bit AVX instructions are dynamically executed as two bit instructions if the 2nd FP unit is busy When to use Code is highly scalable to a large number of MPI ranks Code can run with a 2GB per task memory footprint Code is not well vectorized Shared L2 Cache Fetch Decode FP Scheduler 128-bit FMAC L1 DCache Pipeline Int Scheduler Int Core 0 Int Core 1 MPI Task 0 Shared Components MPI Task 1 TR-XEP_BW-A Cray Private

One MPI Task on a Compute Unit ("Single Stream Mode")
Chapter 8: Single-node Optimization One MPI Task on a Compute Unit ("Single Stream Mode") Only one integer unit is used per compute unit This unit has exclusive access to the 256-bit FP unit and is capable of 8 FP results per clock cycle The unit has twice the memory capacity and memory bandwidth in this mode The L2 cache is effectively twice as large The peak of the chip is not reduced When to use Code is highly vectorized and makes use of AVX instructions Code benefits from higher per task memory size and bandwidth Shared L2 Cache Fetch Decode FP Scheduler 128-bit FMAC L1 DCache Pipeline Integer Scheduler Integer Core 0 Integer Core 1 Idle Components Active Components TR-XEP_BW-A Cray Private

Chapter 8: Single-node Optimization
One MPI Task per compute unit with Two OpenMP Threads ("Dual-Stream Mode") An MPI task is pinned to a compute unit OpenMP is used to run a thread on each integer unit Each OpenMP thread has exclusive access to an integer scheduler, integer pipelines and L1 Dcache The 256-bit FP unit and the L2 Cache is shared between the two threads 256-bit AVX instructions are dynamically executed as two 128-bit instructions if the 2nd FP unit is busy When to use Code needs a large amount of memory per MPI rank Code has OpenMP parallelism at each MPI rank Shared L2 Cache Fetch Decode FP Scheduler 128-bit FMAC L1 DCache Pipeline Int Scheduler Int Core 0 Int Core 1 OpenMP Thread 0 Shared Components OpenMP Thread 1 TR-XEP_BW-A Cray Private

AVX (Advanced Vector Extensions)
Chapter 8: Single-node Optimization AVX (Advanced Vector Extensions) Max Vector length doubled to 256 bit Much cleaner instruction set Result register is unique from the source registers Old SSE instruction set always destroyed a source register Floating point multiple-accumulate A(1:4) = B(1:4)*C(1:4) + D(1:4) ! Now one instruction Both AMD and Intel now have AVX Vectors are becoming more important, not less NCRC Fall User Training 2012 TR-XEP_BW-A Cray Private

Running in Dual-Stream mode
Dual-Stream mode is the current default mode. General use does not require any options. CPU affinity is set automatically by ALPS. Use the aprun -d option to set the number of OpenMP threads per process. If OpenMP is not used, no -d option is required. The aprun –N option is used to specify the number of MPI processes to assign per compute node or -S to specify the number of MPI processes per Interlagos die. These options are generally only needed in the case of OpenMP programs or programs needed more memory per process. NCRC Fall User Training 2012

Running in Single-Stream mode
Single-Stream mode is specified through the -j aprun option. Specifying -j 1 tells aprun to place 1 process or thread on each compute unit. When OpenMP threads are used, the -d option must be used to specify how many threads will be spawned per MPI process. See the aprun(1) man page for more details. The aprun –N option may be used to specify the number of MPI processes to assign per compute node or -S to specify the number of processes per Interlagos die. Also, the environment variable $OMP_NUM_THREADS needs to be set to the correct number of threads per process. For example, the following spawns 4 MPI processes, each with 8 threads, using 1 thread per compute unit. OMP_NUM_THREADS=8 aprun -n 4 -d 8 -j 1 ./a.out NCRC Fall User Training 2012

aprun Examples (XK7) No-OpenMP, 16 MPI processes per node <default> No-OpenMP, 8 MPI processes per node -j 1 OpenMP, 2 MPI processes, 8 threads per process -d 8 OpenMP, 2 MPI processes, 4 threads per process -d 4 -j 1 OpenMP, 1 MPI process, 16 threads -d 16 OpenMP, 1 MPI process, 8 threads -d 8 -j 1 NCRC Fall User Training 2012

NUMA Considerations An XK7 compute node with 1 Interlagos processors has 2 NUMA memory domains, each with 4 Bulldozer Modules. Access to memory located in a remote NUMA domain is slower than access to local memory. Bandwidth is lower, and latency is higher. OpenMP performance is usually better when all threads in a process execute in the same NUMA domain. For the Dual-Stream case, 8 CPUs share a NUMA domain, while in Single-Stream mode 4 CPUs share a NUMA domain. Using a larger number of OpenMP threads per MPI process than these values may result in lower performance due to cross-domain memory access. When running 1 process with threads over both NUMA domains, it’s critical to initialize (not just allocate) memory from the thread that will use it in order to avoid NUMA side effects. NCRC Fall User Training 2012

Cray Gemini Interconnect
Chapter 8: Single-node Optimization Cray Gemini Interconnect NCRC Fall User Training 2012 TR-XEP_BW-A Cray Private

Cray Network Evolution
SeaStar Built for scalability to 250K+ cores Very effective routing and low contention switch Gemini 100x improvement in message throughput 3x improvement in latency PGAS Support, Global Address Space Scalability to 1M+ cores Aries Cray “Cascade” Systems Funded through DARPA program Details not yet publically available NCRC Fall User Training 2012 Cray Proprietary

Cray Gemini 3D Torus network Supports 2 Nodes per ASIC 168 GB/sec routing capacity Scales to over 100,000 network endpoints Link Level Reliability and Adaptive Routing Advanced Resiliency Features Provides global address space Advanced NIC designed to efficiently support MPI Millions of messages/second One-sided MPI UPC, FORTRAN 2008 with coarrays, shmem Global Atomics Hyper Transport 3 NIC 0 Hyper Transport 3 NIC 1 Netlink 48-Port YARC Router NCRC Fall User Training 2012 26

Gemini Advanced Features
Globally addressable memory provides efficient support for UPC, Co-array FORTRAN, Shmem and Global Arrays Cray Programming Environment will target this capability directly Pipelined global loads and stores Allows for fast irregular communication patterns Atomic memory operations Provides fast synchronization needed for one-sided communication models NCRC Fall User Training 2012 Cray Proprietary

Gemini NIC block diagram
FMA (Fast Memory Access) Mechanism for most MPI transfers Supports tens of millions of MPI requests per second BTE (Block Transfer Engine) Supports asynchronous block transfers between local and remote memory, in either direction For use for large MPI transfers that happen in the background CQ (Completion Queue) - an event notification block used when processor needs to be notified that BTE or FMA transactions have completed. NAT (Network Address Translation) - responsible for validating and translating addresses from the network address format to an address on the local node. AMO (Atomic Memory Operation) - responsible for AMO type of transactions. ORB (Outstanding Request Buffer) - processes requests to the network and matches responses from the network to the original requests. RMT (Receive Message Table) - tracks groups of packets, or sequences, transmitted from remote nodes of the network SSID (Synchronization Sequence Identification) - Tracks all of the request packets that originate and all of the response packets that terminate at the NIC, in order to perform completion notifications for transactions. Assists in the identification of SW operations and processes impacted by errors Monitors error detected by other NIC blocks NCRC Fall User Training 2012

Gemini vs SeaStar – Topology
Module with SeaStar Y X Z Gemini Gemini Module with Gemini NCRC Fall User Training 2012 Cray Proprietary

A Question About the Torus…
It looks like for each x,y,z coordinate, there are two node numbers associated. Is there some reason for this? Is each node number actually indicating 8-cores rather than 16? Node X Y Z Unlike the XT-line of systems, where each node had an idividual SeaStar, a Gemini services 2 compute nodes. So, 2 compute nodes will have the same dimensions in the torus in an XE or XK system.

Nvidia Kepler Accelerator
Chapter 8: Single-node Optimization Nvidia Kepler Accelerator Some slides taken from Nvidia GTC2012 “Inside Kepler” talk by Stephen Jones and Lars Nyland (NVIDIA) NCRC Fall User Training 2012 TR-XEP_BW-A Cray Private

CPU/GPU Architectures
Cache Control ALU Cache Control ALU Cache Every GPU talk/paper seems to have a diagram like this, so many will likely have seen it already. It’s very simplistic, but gets the architectural differences across. CPU: (Only dual-core shown) Large RAM, directly accessible by all. CPU RAM cheap. Large, shared cache. All cores can share through. Coherent per-core caches. Each core has own control units Fetch/decode Memory control Prefetching Branch Prediction … Each core has own ALUs Cores can work on totally different streams of execution, but also synchronize and share data GPU: (Only 3SMs shown) Smaller main memory, faster but more expensive Totally managed by CPU over PCIe Many groups of processors Each group has a shared cache Each group shares simplified control structure Fetch & Decode 1 instruction for the entire group Memory accesses coalesced within group Compute cores within group work in lockstep Space between groups indicative of no synchronization between groups No guaranteed order of execution Not safe to synchronize via RAM. Sharing control structures allows more silicon to be dedicated to compute cores. RAM Cache RAM NCRC Fall User Training 2012

CPU/GPU Architectures
Large memory, directly accessible Each core has own, independent control logic Allows independent execution Coherent caches between cores Can share & synchronize Fixed number of registers per core Context switches expensive Relatively small memory, must be managed by CPU Groups of compute cores share control logic Saves space, power, … Shared cache & synchronization within groups None between groups Fixed number of registers per block (32768) Context switched cheap NCRC Fall User Training 2012

Play to your strengths CPU GPU Tuned for serial execution with short vectors Multiple independent threads of execution Branch-prediction Memory latency hidden by cache & prefetching Requires regular data access patterns Tuned for highly parallel execution Threads work in lockstep within groups Much like vectors Serializes branchy code Memory latency hidden by swapping away stalled threads Requires 1000s of concurrent threads NCRC Fall User Training 2012

GPU Glossary: Hardware
Global Memory is the GPU’s main memory. It’s shared across the entire device. The device has some number of Streaming Multiprocessors (SM), which work in parallel with each other. Each SM has 32 CUDA cores, where the work happens. CUDA cores within an SM work on the same instruction in a SIMD manner. Each SM has a 64KB fast memory, which is split between a L1 cache a user managed shared memory. Every GPU talk/paper seems to have a diagram like this, so many will likely have seen it already. It’s very simplistic, but gets the architectural differences across. CPU: (Only dual-core shown) Large RAM, directly accessible by all. CPU RAM cheap. Large, shared cache. All cores can share through. Coherent per-core caches. Each core has own control units Fetch/decode Memory control Prefetching Branch Prediction … Each core has own ALUs Cores can work on totally different streams of execution, but also synchronize and share data GPU: (Only 3SMs shown) Smaller main memory, faster but more expensive Totally managed by CPU over PCIe Many groups of processors Each group has a shared cache Each group shares simplified control structure Fetch & Decode 1 instruction for the entire group Memory accesses coalesced within group Compute cores within group work in lockstep Space between groups indicative of no synchronization between groups No guaranteed order of execution Not safe to synchronize via RAM. Sharing control structures allows more silicon to be dedicated to compute cores. Cache RAM NCRC Fall User Training 2012

GPU Glossary = X Let’s imagine we want to multiply the Blue matrix and Red matrix to make the Purple matrix. The code that will run on the GPU to perform this calculation is a kernel. The act of copying input data to the device, executing the kernel, and copying results back is executed in a stream. So, what is a thread? NCRC Fall User Training 2012

GPU Glossary: Thread = X A thread is the most atomic unit of calculation, so in this case, it is a single element of the result (Purple) matrix. In the case of these 12 x 12 matrices, there will be 144 threads, but a real kernel will likely spawn thousands of threads. Unlike CPU threads, GPU threads a very lightweight and can be made active or inactive without a costly context switch. Each thread gets executed on a CUDA Core on the hardware. NCRC Fall User Training 2012

GPU Glossary: Thread block
Below I have a 4 x 3 x 1 thread block Threads get put together into thread blocks. Threads within a thread block: Run on the same Streaming Multiprocessor Can share data within a very fast, 64KB shared memory Can synchronize with each other Thread blocks can be 1D, 2D, or 3D and have at most 1024 threads on the current hardware. What if I need more threads? NCRC Fall User Training 2012

Below I have a 3 x 4 grid of 4 x 3 x 1 thread blocks
GPU Glossary: Grid Below I have a 3 x 4 grid of 4 x 3 x 1 thread blocks Multiple thread blocks for a grid to solve the full problem. An entire grid is running the same kernel, but there is no guaranteed order execution for the thread blocks. So what the heck is a WARP??? NCRC Fall User Training 2012

GPU Glossary: Warp NOTE: The scale has changed, we’re now looking at 1 thread block. The hardware always issues instructions (SIMD) and requests memory for a group of 32 threads, known as a warp. Think of a warp like a vector with length 32. When a warp stalls waiting for a memory reference, the hardware will find another warp on the SM that can run and swap it on to the hardware If a branch occurs within a warp, each branch will execute one after the other, while the other branch stalls. This is known as warp divergence. When enough warps can fit on an SM to hide all memory requests, it has 100% occupancy. NCRC Fall User Training 2012

GPU Glossary Hardware Software (CUDA) Core Thread/Work Unit Streaming Multiprocessor (SM) Thread Block/Work Group A Grid is a group of related Thread Blocks running the same kernel A Warp is Nvidia’s term for 32 Threads running in lock-step Warp Diversion is what happens when some threads within a warp stall due to a branch Shared Memory is a user-managed cache within a Thread Block 64KB memory per SM, split 48/16 between SM and L1 (configurable) Occupancy is the degree to which all of the GPU hardware can be used in a Kernel Heavily influenced by registers/thread, threads/block, and SM used Higher occupancy results in better hiding latency to GPU memory Stream is a series of data transfers and kernel launches that happen in series Multiple streams can run concurrently on the device Streams allow overlapping of PCIe transfers and GPU execution NCRC Fall User Training 2012

Nvidia Kepler Specifics
NCRC Fall User Training 2012

Lustre Filesystem Basics

Key Lustre Terms Term Meaning Purpose MDS Metadata Server Manages all file metadata for filesystem. 1 per FS OST Object Storage Target The basic “chunk” of data written to disk. Max 160 per file. OSS Object Storage Server Communicates with disks, manages 1 or more OSTs. 1 or more per FS Stripe Size Size of chunks. Controls the size of file chunks stored to OSTs. Can’t be changed once file is written. Stripe Count Number of OSTs used per file. Controls parallelism of file. Can’t be changed once file is writte. NCRC Fall User Training 2012

Lustre File System Basics

File Striping: Physical and Logical Views
Figure 2: Logical and Physical views of striping. Four application processes write a variable amount of data sequentially within a shared file. This shared file is striped over 4 OSTs with 1 MB stripe sizes. This write operation is not stripe aligned therefore some processes write their data to stripes used by other processes. Some stripes are accessed by more than one process (which may cause contention). Additionally, OSTs are accessed by variable numbers of processes (3 OST0, 1 OST1, 2 OST2 and 2 OST3). NCRC Fall User Training 2012

Lustre: Important Information
Use the lfs command, libLUT, or MPIIO hints to adjust your stripe count and possibly size lfs setstripe -c -1 -s 4M <file or directory> (160 OSTs, 4MB stripe) lfs setstripe -c 1 -s 16M <file or directory> (1 OST, 16M stripe) export MPICH_MPIIO_HINTS=‘*: striping_factor=160’ Files inherit striping information from the parent directory, this cannot be changed once the file is written Set the striping before copying in files NCRC Fall User Training 2012

Cray Programming Environment
Available Compilers Cray Scientific Libraries Cray MPICH2 Cray Performance Tools Cray Debugging Tools

Compiler Wrappers Cray Systems come with compiler wrappers to simplify building parallel applications (similar the mpicc/mpif90) Fortran Compiler: ftn C Compiler: cc C++ Compiler: CC Using these wrappers ensures that your code is built for the compute nodes and linked against important libraries Cray MPT (MPI, Shmem, etc.) Cray LibSci (BLAS, LAPACK, etc.) … Choosing the underlying compiler is via the PrgEnv-* modules, do not call the PGI, Cray, etc. compilers directly. Always load the appropriate xtpe-<arch> module for your machine Enables proper compiler target Links optimized math libraries Cray Compiler wrappers try to hide the complexities of using the proper header files and libraries So does autoconf (./configure) and CMake, so unfortunately, sometimes these tools need massaging to work with compiler wrappers, especially in a cross-compiling environment, like titan NCRC Fall User Training 2012

Compiler Choices – Relative Strengths
…from Cray’s Perspective PGI – Very good Fortran and C, pretty good C++ Good vectorization Good functional correctness with optimization enabled Good manual and automatic prefetch capabilities Very interested in the Linux HPC market, although that is not their only focus Excellent working relationship with Cray, good bug responsiveness OpenACC support for accelerators Intel – Good Fortran, excellent C and C++ (if you ignore vectorization) Automatic vectorization capabilities are modest, compared to PGI and CCE Use of inline assembly is encouraged Focus is more on best speed for scalar, non-scaling apps Tuned for Intel architectures, but actually works well for some applications on AMD Does not support the Interlagos FMA instruction, so achievable floating point performance is cut in half Personal Notes: I’ve never seen a C++ code using pathscale. I don’t know what exactly is different about pathscale’s OMP implementation, but it’s different so it’s worth trying PGI tends to favor precision over performance, Pathscale tends to favor performance over precision. NCRC Fall User Training 2012 Cray Proprietary

Compiler Choices – Relative Strengths
…from Cray’s Perspective GNU pretty-good Fortran, outstanding C and C++ (if you ignore vectorization) Very good scalar optimizer Vectorization capabilities focus mostly on inline assembly De-facto C++ compiler (for better or worse) CCE – Outstanding Fortran, very good C, and okay C++ Very good vectorization Very good Fortran language support; only real choice for Coarrays C support is quite good, with UPC support Very good scalar optimization and automatic parallelization Clean implementation of OpenMP 3.0, with tasks Sole delivery focus is on Linux-based Cray hardware systems Best bug turnaround time (if it isn’t, let us know!) Cleanest integration with other Cray tools (performance tools, debuggers, upcoming productivity tools) No inline assembly support OpenACC support for accelerators Personal Notes: For C++ codes, GNU is the most common. This is kinda perpetuates itself because it often results in codes with GNU-C++ rather than standard. CCE probably has the weakest C++ support, but we’re working on it. NCRC Fall User Training 2012 Cray Proprietary

Starting Points for Each Compiler
PGI -fast –Mipa=fast(,safe) If you can be flexible with precision, also try -Mfprelaxed Compiler feedback: -Minfo=all -Mneginfo man pgf90; man pgcc; man pgCC; or pgf90 -help Cray <none, turned on by default> Compiler feedback: -rm (Fortran) -hlist=m (C) If you know you don’t want OpenMP: -xomp or -Othread0 man crayftn; man craycc ; man crayCC GNU -O2 / -O3 Compiler feedback: -ftree-vectorizer-verbose=2 man gfortran; man gcc; man g++ Intel -fast Compiler feedback: man ifort; man icc; man iCC This slide isn’t worth reading to the audience. Tell them that we’ll leave these slides with them and they can refer back to them. Mention that the best turnaround time comes from Cray and PGI compilers. NCRC Fall User Training 2012 Cray ConfidentialCray Proprietary

PGI Compiler NCRC Fall User Training 2012

PGI Optimization Options
Traditional (scalar) optimizations are controlled via - O# compiler flags Default: -O2 More aggressive optimizations (including vectorization) are enabled with the -fast or - fastsse metaflags These translate to: -O2 -Munroll=c:1 -Mnoframe -Mlre –Mautoinline -Mvect=sse -Mscalarsse -Mcache_align -Mflushz –Mpre Interprocedural analysis allows the compiler to perform whole-program optimizations. This is enabled with –Mipa=fast See man pgf90, man pgcc, or man pgCC for more information about compiler options. NCRC Fall User Training 2012

PGI: Other Important Options
Compiler feedback is enabled with -Minfo and - Mneginfo This can provide valuable information about what optimizations were or were not done and why. To debug an optimized code, the -gopt flag will insert debugging information without disabling optimizations It’s possible to disable optimizations included with - fast if you believe one is causing problems For example: -fast -Mnolre enables -fast and then disables loop redundant optimizations To get more information about any compiler flag, add - help with the flag in question pgf90 -help -fast will give more information about the -fast flag OpenMP is enabled with the -mp flag NCRC Fall User Training 2012

PGI: Optimizations and Accuracy
Some compiler options may effect both performance and accuracy. Lower accuracy is often higher performance, but it’s also able to enforce accuracy. -Kieee: All FP math strictly conforms to IEEE 754 (off by default) -Ktrap: Turns on processor trapping of FP exceptions -Mdaz: Treat all denormalized numbers as zero -Mflushz: Set SSE to flush-to-zero (on with -fast) -Mfprelaxed: Allow the compiler to use relaxed (reduced) precision to speed up some floating point optimizations Some other compilers turn this on by default, PGI chooses to favor accuracy to speed by default. NCRC Fall User Training 2012

Cray Compiler Environment

Cray Opteron Compiler: How to use it
To access the Cray compiler module load PrgEnv-cray (most likely module swap from current environment) To target the various chip module load craype-interlagos (loaded by default) To enable OpenACC module load craype-accel-nvidia35 Once you have loaded the module “cc” and “ftn” are the Cray compilers Recommend just using default options Use –rm (fortran) and –hlist=m (C) to find out what happened man crayftn NCRC Fall User Training 2012

Cray Opteron Compiler: Current Capabilities
Excellent Vectorization Vectorize more loops than other compilers OpenMP 3.0 Task and Nesting OpenACC 1.0 PGAS: Functional UPC and CAF available today C++ Support Automatic Parallelization Modernized version of Cray X1 streaming capability Interacts with OMP directives Cache optimizations Automatic Blocking Automatic Management of what stays in cache Prefetching, Interchange, Fusion, and much more… NCRC Fall User Training 2012

Cray Opteron Compiler Strengths
Loop Based Optimizations Vectorization OpenMP Autothreading Interchange Pattern Matching Cache blocking/ non-temporal / prefetching Fortran 2003 Standard; most of Fortran 2008 PGAS (UPC and Co-Array Fortran) Optimized for Gemini Interconnect Optimization Feedback: Loopmark Close integration with Cray Performance Tools NCRC Fall User Training 2012

Cray Opteron Compiler: Directives
Cray compiler supports a full and growing set of directives and pragmas !dir$ concurrent !dir$ ivdep !dir$ interchange !dir$ unroll !dir$ loop_info [max_trips] [cache_na] ... Many more !dir$ blockable man directives man loop_info NCRC Fall User Training 2012

Loopmark: Compiler Feedback
Compiler can generate an filename.lst file. Contains annotated listing of your source code with letter indicating important optimizations %%% L o o p m a r k L e g e n d %%% Primary Loop Type Modifiers a - vector atomic memory operation A - Pattern matched b - blocked C - Collapsed f - fused D - Deleted i - interchanged E - Cloned m - streamed but not partitioned I - Inlined p - conditional, partial and/or computed M - Multithreaded r - unrolled P - Parallel/Tasked s - shortloop V - Vectorized t - array syntax temp used W - Unwound w - unwound NCRC Fall User Training 2012

Example: Cray loopmark messages for Resid
ftn –rm … or cc –hlist=m … 29. b < do i3=2,n3-1 30. b b-----< do i2=2,n2-1 31. b b Vr--< do i1=1,n1 32. b b Vr u1(i1) = u(i1,i2-1,i3) + u(i1,i2+1,i3) 33. b b Vr > u(i1,i2,i3-1) + u(i1,i2,i3+1) 34. b b Vr u2(i1) = u(i1,i2-1,i3-1) + u(i1,i2+1,i3-1) 35. b b Vr > u(i1,i2-1,i3+1) + u(i1,i2+1,i3+1) 36. b b Vr--> enddo 37. b b Vr--< do i1=2,n1-1 38. b b Vr r(i1,i2,i3) = v(i1,i2,i3) 39. b b Vr > a(0) * u(i1,i2,i3) 40. b b Vr > a(2) * ( u2(i1) + u1(i1-1) + u1(i1+1) ) 41. b b Vr > a(3) * ( u2(i1-1) + u2(i1+1) ) 42. b b Vr--> enddo 43. b b-----> enddo 44. b > enddo NCRC Fall User Training 2012

Example: Cray loopmark messages for Resid (cont)
ftn-6289 ftn: VECTOR File = resid.f, Line = 29 A loop starting at line 29 was not vectorized because a recurrence was found on "U1" between lines 32 and 38. ftn-6049 ftn: SCALAR File = resid.f, Line = 29 A loop starting at line 29 was blocked with block size 4. ftn-6289 ftn: VECTOR File = resid.f, Line = 30 A loop starting at line 30 was not vectorized because a recurrence was found on "U1" between lines 32 and 38. ftn-6049 ftn: SCALAR File = resid.f, Line = 30 A loop starting at line 30 was blocked with block size 4. ftn-6005 ftn: SCALAR File = resid.f, Line = 31 A loop starting at line 31 was unrolled 4 times. ftn-6204 ftn: VECTOR File = resid.f, Line = 31 A loop starting at line 31 was vectorized. ftn-6005 ftn: SCALAR File = resid.f, Line = 37 A loop starting at line 37 was unrolled 4 times. ftn-6204 ftn: VECTOR File = resid.f, Line = 37 A loop starting at line 37 was vectorized. NCRC Fall User Training 2012

Byte Swapping -hbyteswapio Link time option Applies to all unformatted fortran IO Assign command With the PrgEnv-cray module loaded do this: setenv FILENV assign.txt assign -N swap_endian g:su assign -N swap_endian g:du Can use assign to be more precise NCRC Fall User Training 2012

OpenMP OpenMP is ON by default Optimizations controlled by –Othread# To shut off use –Othread0 or –xomp or –hnoomp Autothreading is NOT on by default; -hautothread to turn on Modernized version of Cray X1 streaming capability Interacts with OMP directives If you do not want to use OpenMP and have OMP directives in the code, make sure to make a run with OpenMP shut off at compile time NCRC Fall User Training 2012

Cray Scientific Libraries (Libsci)

What are libraries for? Building blocks for writing scientific applications Historically – allowed the first forms of code re-use Later – became ways of running optimized code These days the complexity of the hardware is very high Cray PE insulates the user from that complexity Cray module environment CCE Performance tools Tuned MPI libraries (+PGAS) Optimized Scientific libraries Cray scientific libraries are designed to give maximum possible performance from Cray systems with minimum effort NCRC Fall User Training 2012

What makes Cray libraries special
Node performance Highly tune BLAS etc at the low-level Network performance Optimize for network performance Overlap between communication and computation Use the best available low-level mechanism Use adaptive parallel algorithms Highly adaptive software Using auto-tuning and adaptation, give the user the known best (or very good) codes at runtime Productivity features Simpler interfaces into complex software NCRC Fall User Training 2012

Cray Scientific Libraries
FFT CRAFFT FFTW P-CRAFFT Dense BLAS LAPACK ScaLAPACK IRT CASE Sparse CASK PETSc Trilinos IRT – Iterative Refinement Toolkit CASK – Cray Adaptive Sparse Kernels CRAFFT – Cray Adaptive FFT CASE – Cray Adaptive Simple Eigensolver NCRC Fall User Training 2012

Libsci Usage all fits on one slide
The drivers should do it all for you. Don’t explicitly link. For threads, set OMP_NUM_THREADS Threading is used within libsci. If you call within parallel region, single thread used -Wl, -ydgemm_ reveals where the link was resolved FFTW module load fftw (there are also wisdom files you can pick up) PETSc module load cray-petsc (or module load cray-petsc- complex) Use as you would your normal petsc build Trilinos module load cray-trilinos CASK – no need to do anything you get optimizations free NCRC Fall User Training 2012

Your friends TUNER/STUNER> module avail PrgEnv PrgEnv-cray/ PrgEnv-gnu/4.0.12A PrgEnv-pathscale/3.1.37G PrgEnv-cray/3.1.37AA PrgEnv-gnu/4.0.26A PrgEnv-pathscale/3.1.49A PrgEnv-cray/3.1.37C PrgEnv-gnu/4.0.36(default) PrgEnv-pathscale/3.1.61 PrgEnv-cray/3.1.37E PrgEnv-intel/ PrgEnv-pathscale/4.0.12A PrgEnv-cray/3.1.37G PrgEnv-intel/3.1.37AA PrgEnv-pathscale/4.0.26A PrgEnv-cray/3.1.49A PrgEnv-intel/3.1.37C PrgEnv-pathscale/4.0.36(default) PrgEnv-cray/ PrgEnv-intel/3.1.37E PrgEnv-pgi/3.1.35 PrgEnv-cray/4.0.12A PrgEnv-intel/3.1.37G PrgEnv-pgi/3.1.37AA PrgEnv-cray/4.0.26A PrgEnv-intel/3.1.49A PrgEnv-pgi/3.1.37C PrgEnv-cray/4.0.36(default) PrgEnv-intel/ PrgEnv-pgi/3.1.37E PrgEnv-gnu/ PrgEnv-intel/4.0.12A PrgEnv-pgi/3.1.37G PrgEnv-gnu/3.1.37AA PrgEnv-intel/4.0.26A PrgEnv-pgi/3.1.49A PrgEnv-gnu/3.1.37C PrgEnv-intel/4.0.36(default) PrgEnv-pgi/3.1.61 PrgEnv-gnu/3.1.37E PrgEnv-pathscale/ PrgEnv-pgi/4.0.12A PrgEnv-gnu/3.1.37G PrgEnv-pathscale/3.1.37AA PrgEnv-pgi/4.0.26A PrgEnv-gnu/3.1.49A PrgEnv-pathscale/3.1.37C PrgEnv-pgi/4.0.36(default) PrgEnv-gnu/ PrgEnv-pathscale/3.1.37E module command (module --help) PrgEnv modules : Component modules csmlversion (tool) Cray driver scripts ftn, cc, CC /opt/cray/modulefiles xt-libsci/ xt-libsci/ xt-libsci/ xt-libsci/ xt-libsci/ xt-libsci/ (default) NCRC Fall User Training 2012

Check you got the right library!
Add options to the linker to make sure you have the correct library loaded. -Wl adds a command to the linker from the driver You can ask for the linker to tell you where an object was resolved from using the –y option. E.g. –Wl, -ydgemm_ Note : explicitly linking “-lsci” is bad! This won’t be found from libsci 11+ (and means single core library for 10.x!) .//main.o: reference to dgemm_ /opt/xt-libsci/ /cray/73/mc12/lib/libsci_cray_mp.a(dgemm.o): definition of dgemm_ NCRC Fall User Training 2012

Threading LibSci is compatible with OpenMP Control the number of threads to be used in your program using OMP_NUM_THREADS e.g. in job script setenv OMP_NUM_THREADS 16 Then run with aprun –n1 –d16 What behavior you get from the library depends on your code No threading in code The BLAS call will use OMP_NUM_THREADS threads Threaded code, outside parallel region Threaded code, inside parallel region The BLAS call will use a single thread NCRC Fall User Training 2012

Emphasis A large subset of HPC customers care very deeply about each of the following BLAS – explicit calls in their code LAPACK – linear solvers LAPACK – eigensolvers ScaLAPACK Serial FFT Our job is to make them work at extreme performance on Cray hardware A flaming-hot GEMM library can support wide usage GEMM NCRC Fall User Training 2012

Threaded LAPACK Threaded LAPACK works exactly the same as threaded BLAS Anywhere LAPACK uses BLAS, those BLAS can be threaded Some LAPACK routines are threaded at the higher level No special instructions NCRC Fall User Training 2012

ScaLAPACK ScaLAPACK in libsci is optimized for Gemini interconnect New collective communication procedures are added Default topologies are changed to use the new optimizations Much better strong scaling It also benefits from the optimizations in CrayBLAS IRT can provide further improvements (see later) NCRC Fall User Training 2012

Iterative Refinement Toolkit
Mixed precision can yield a big win on x86 machines. SSE (and AVX) units issue double the number of single precision operations per cycle. On CPU, single precision is always 2x as fast as double Accelerators sometimes have a bigger ratio Cell – 10x Older NVIDIA cards – 7x New NVIDIA cards (2x ) Newer AMD cards ( > 2x ) IRT is a suite of tools to help exploit single precision A library for direct solvers An automatic framework to use mixed precision under the covers Note that mixed – precision itself does not only affect flop bound codes but memory bound (and network bandwidth bound) codes. IRT library is a tool that assists flop-bound DLA. MXP can help both flop bound and memory bound. NCRC Fall User Training 2012

Iterative Refinement Toolkit - Library
Various tools for solves linear systems in mixed precision Obtaining solutions accurate to double precision For well conditioned problems Serial and Parallel versions of LU, Cholesky, and QR 2 usage methods IRT Benchmark routines Uses IRT 'under-the-covers' without changing your code Simply set an environment variable Useful when you cannot alter source code Advanced IRT API If greater control of the iterative refinement process is required Allows condition number estimation error bounds return minimization of either forward or backward error 'fall back' to full precision if the condition number is too high max number of iterations can be altered by users NCRC Fall User Training 2012 Cray ConfidentialCray Proprietary

IRT library usage Decide if you want to use advanced API or benchmark API benchmark API : setenv IRT_USE_SOLVERS 1 advanced API : locate the factor and solve in your code (LAPACK or ScaLAPACK) Replace factor and solve with a call to IRT routine e.g. dgesv -> irt_lu_real_serial e.g. pzgesv -> irt_lu_complex_parallel e.g pzposv -> irt_po_complex_parallel Set advanced arguments Forward error convergence for most accurate solution Condition number estimate “fall-back” to full precision if condition number too high Note : “info” does not return zero when using IRT !! NCRC Fall User Training 2012

FFTW Cray’s main FFT library is FFTW from MIT Some additional optimizations for Cray hardware Usage is simple Load the module In the code, call an FFTW plan Cray’s FFTW provides wisdom files for these systems You can use the wisdom files to skip the plan stage This can be a significant performance boost FFTW includes Cray optimizations for IL processors NCRC Fall User Training 2012

Cray Adaptive FFT (CRAFFT)
Serial CRAFFT is largely a productivity enhancer Also a performance boost due to “wisdom” usage Some FFT developers have problems such as Which library choice to use? How to use complicated interfaces (e.g., FFTW) Standard FFT practice Do a plan stage Do an execute CRAFFT is designed with simple-to-use interfaces Planning and execution stage can be combined into one function call Underneath the interfaces, CRAFFT calls the appropriate FFT kernel NCRC Fall User Training 2012 Cray ConfidentialCray Proprietary Cray ConfidentialCray Proprietary 87

CRAFFT usage Load module fftw/3.2.0 or higher. Add a Fortran statement “use crafft” call crafft_init() Call crafft transform using none, some or all optional arguments (as shown in red) In-place, implicit memory management : call crafft_z2z3d(n1,n2,n3,input,ld_in,ld_in2,isign) in-place, explicit memory management call crafft_z2z3d(n1,n2,n3,input,ld_in,ld_in2,isign,work) out-of-place, explicit memory management : crafft_z2z3d(n1,n2,n3,input,ld_in,ld_in2,output,ld_out,ld_out2,isign,work) Note : the user can also control the planning strategy of CRAFFT using the CRAFFT_PLANNING environment variable and the do_exe optional argument, please see the intro_crafft man page. NCRC Fall User Training 2012

Parallel CRAFFT Parallel CRAFFT is meant as a performance improvement to FFTW2 distributed transforms Uses FFTW3 for the serial transform Uses ALLTOALL instead of ALLTOALLV where possible Overlaps the local transpose with the parallel communications Uses a more adaptive communication scheme based on input Lots of more advanced research in one-sided messaging and active messages Can provide impressive performance improvements over FFTW2 Currently implemented complex-complex Real-complex and complex-real 3-d and 2-d In-place and out-of-place 1 data distribution scheme but looking to support more (please tell us) C language support for serial and parallel Generic interfaces for C users (use C++ compiler to get these) NCRC Fall User Training 2012

parallel CRAFFT usage Add “use crafft” to Fortran code Initialize CRAFFT using crafft_init Assume MPI initialized and data distributed (see manpage) Call crafft, e.g. (optional arguments in red) 2-d complex-complex, in-place, internal mem management : call crafft_pz2z2d(n1,n2,input,isign,flag,comm) 2-d complex-complex, in-place with no internal memory : call crafft_pz2z2d(n1,n2,input,isign,flag,comm,work) 2-d complex-complex, out-of-place, internal mem manager : call crafft_pz2z2d(n1,n2,input,output,isign,flag,comm) 2-d complex-complex, out-of-place, no internal memory : crafft_pz2z2d(n1,n2,input,output,isign,flag,comm,work) Each routine above has manpage. Also see 3d equivalent : man crafft_pz2z3d work is optional argument – if you don’t add it then memory management is internal Output is optional – if you don’t add it then you go in-place NCRC Fall User Training 2012

Cray Adaptive Sparse Kernel (CASK)
Sparse matrix operations in PETSc and Trilinos on Cray systems are optimized via CASK CASK is a product developed at Cray using the Cray Auto-tuning Framework Offline : ATF program builds many thousands of sparse kernel Testing program defines matrix categories based on density, dimension etc Each kernel variant is tested against each matrix class Performance table is built and adaptive library constructed Runtime Scan matrix at very low cost Map user’s calling sequence to nearest table match Assign best kernel to the calling sequence Optimized kernel used in iterative solver execution NCRC Fall User Training 2012 Cray ConfidentialCray Proprietary

LibSci for Accelerators
Provide basic libraries for accelerators, tuned for Cray Must be independent to OpenACC, but fully compatible Multiple use case support Get the base use of accelerators with no code change Get extreme performance of GPU with or without code change Extra tools for support of complex code Incorporate the existing GPU libraries into libsci Provide additional performance and usability Maintain the Standard APIs where possible! NCRC Fall User Training 2012

Three interfaces for three use cases
Simple interface dgetrf(M, N, A, lda, ipiv, &info) dgetrf(M, N, d_A, lda, ipiv, &info) Device interface dgetrf_acc(M, N, d_A, lda, ipiv, &info) CPU interface dgetrf_cpu(M, N, A, lda, ipiv, &info) GPU + CPU ? ? CPU ? GPU NCRC Fall User Training 2012

Usage - Basics Supports Cray and GNU compilers. Fortran and C interfaces (column-major assumed) Load the module craype-accel-nvidia35. Compile as normal (dynamic libraries used) To enable threading in the CPU library, set OMP_NUM_THREADS E.g. export OMP_NUM_THREADS=16 Assign 1 single MPI process per node Multiple processes cannot share the single GPU Execute your code as normal NCRC Fall User Training 2012

Libsci_acc Example Starting with a code that relies on dgemm. The library will check the parameters at runtime. If the size of the matrix multiply is large enough, the library will run it on the GPU, handling all data movement behind the scenes. NOTE: Input and Output data are in CPU memory. call dgemm('n','n',m,n,k,alpha,& a,lda,b,ldb,beta,c,ldc) NCRC Fall User Training 2012

Libsci_acc Example If the rest of the code uses OpenACC, it’s possible to use the library with directives. All data management performed by OpenACC. Calls the device version of dgemm. All data is in CPU memory before and after data region. !$acc data copy(a,b,c) !$acc parallel !Do Something !$acc end parallel !$acc host_data use_device(a,b,c) call dgemm_acc('n','n',m,n,k,& alpha,a,lda,& b,ldb,beta,c,ldc) !$acc end host_data !$acc end data !$acc data copy(a,b,c) !$acc parallel !Do Something !$acc end parallel !$acc host_data use_device(a,b,c) call dgemm ('n','n',m,n,k,& alpha,a,lda,& b,ldb,beta,c,ldc) !$acc end host_data !$acc end data NCRC Fall User Training 2012

Libsci_acc Example Libsci_acc is a bit smarter that this. Since ‘a,’ ‘b’, and ‘c’ are device arrays, the library knows it should run on the device. So just dgemm is sufficient. !$acc data copy(a,b,c) !$acc parallel !Do Something !$acc end parallel !$acc host_data use_device(a,b,c) call dgemm ('n','n',m,n,k,& alpha,a,lda,& b,ldb,beta,c,ldc) !$acc end host_data !$acc end data !$acc data copy(a,b,c) !$acc parallel !Do Something !$acc end parallel !$acc host_data use_device(a,b,c) call dgemm_acc('n','n',m,n,k,& alpha,a,lda,& b,ldb,beta,c,ldc) !$acc end host_data !$acc end data NCRC Fall User Training 2012

Tuning requests CrayBLAS is an auto-tuned library Generally, excellent performance is possible for all shapes and sizes However, even the adaptive CrayBLAS can be improved by tuning for exact sizes and shapes Send your specific tuning requirements to Just send the routine name, and the list of calling sequences NCRC Fall User Training 2012

Cray Message Passing Toolkit

Cray MPT Features Full MPI2 support (except process spawning) based on ANL MPICH2 Cray used the MPICH2 Nemesis layer for Gemini Cray-tuned collectives Cray-tuned ROMIO for MPI-IO If you need thread safety Set MPICH_MAX_THREAD_SAFETY to the value you will pass to MPI_Thread_init Tuned SHMEM library module load cray-shmem NCRC Fall User Training 2012

MPICH_GNI_MAX_EAGER_MSG_SIZE
MPICH2 for Performance Workshop 2010 July 21, 2010 MPICH_GNI_MAX_EAGER_MSG_SIZE Default is 8192 bytes Maximum size message that can go through the eager protocol. May help for apps that are sending medium size messages, and do better when loosely coupled. Does application have a large amount of time in MPI_Waitall? Setting this environment variable higher may help. Max value is bytes. Remember for this path it helps to pre-post receives if possible. Note that a 40-byte CH3 header is included when accounting for the message size. NCRC Fall User Training 2012 Cray Proprietary

MPICH_GNI_RDMA_THRESHOLD
Controls the crossover point between FMA and BTE path on the Gemini. If your messages are slightly above or below this threshold, it may benefit to tweak this value. Higher value: More messages will transfer asynchronously, but at a higher latency. Lower value: More messages will take fast, low-latency path. Default: 1024 bytes Maximum value is and the step size is 128. NCRC Fall User Training 2012

MPICH2 for Performance Workshop 2010
July 21, 2010 MPICH_GNI_NUM_BUFS Default is 64 32K buffers ( 2M total ) Controls number of 32K DMA buffers available for each rank to use in the Eager protocol described earlier May help to modestly increase. But other resources constrain the usability of a large number of buffers. NCRC Fall User Training 2012 Cray Proprietary

Cray Performance Tools

Design Goals Assist the user with application performance analysis and optimization Help user identify important and meaningful information from potentially massive data sets Help user identify problem areas instead of just reporting data Bring optimization knowledge to a wider set of users Focus on ease of use and intuitive user interfaces Automatic program instrumentation Automatic analysis Target scalability issues in all areas of tool development Data management Storage, movement, presentation NCRC Fall User Training 2012

Strengths Provide a complete solution from instrumentation to measurement to analysis to visualization of data Performance measurement and analysis on large systems Automatic Profiling Analysis Load Imbalance HW counter derived metrics Predefined trace groups provide performance statistics for libraries called by program (blas, lapack, pgas runtime, netcdf, hdf5, etc.) Observations of inefficient performance Data collection and presentation filtering Data correlates to user source (line number info, etc.) Support MPI, SHMEM, OpenMP, UPC, CAF Access to network counters Minimal program perturbation NCRC Fall User Training 2012

Strengths (2) Usability on large systems Client / server Scalable data format Intuitive visualization of performance data Supports “recipe” for porting MPI programs to many-core or hybrid systems Integrates with other Cray PE software for more tightly coupled development environment NCRC Fall User Training 2012

The Cray Performance Analysis Framework
Supports traditional post-mortem performance analysis Automatic identification of performance problems Indication of causes of problems Suggestions of modifications for performance improvement pat_build: provides automatic instrumentation CrayPat run-time library collects measurements (transparent to the user) pat_report performs analysis and generates text reports pat_help: online help utility Cray Apprentice2: graphical visualization tool NCRC Fall User Training 2012

The Cray Performance Analysis Framework (2)
CrayPat Instrumentation of optimized code No source code modification required Data collection transparent to the user Text-based performance reports Derived metrics Performance analysis Cray Apprentice2 Performance data visualization tool Call tree view Source code mappings NCRC Fall User Training 2012

Steps to Using the Tools

Application Instrumentation with pat_build
pat_build is a stand-alone utility that automatically instruments the application for performance collection Requires no source code or makefile modification Automatic instrumentation at group (function) level Groups: mpi, io, heap, math SW, … Performs link-time instrumentation Requires object files Instruments optimized code Generates stand-alone instrumented program Preserves original binary NCRC Fall User Training 2012

Application Instrumentation with pat_build (2)
Supports two categories of experiments asynchronous experiments (sampling) which capture values from the call stack or the program counter at specified intervals or when a specified counter overflows Event-based experiments (tracing) which count some events such as the number of times a specific system call is executed While tracing provides most useful information, it can be very heavy if the application runs on a large number of cores for a long period of time Sampling can be useful as a starting point, to provide a first overview of the work distribution NCRC Fall User Training 2012

Program Instrumentation Tips
Large programs Scaling issues more dominant Use automatic profiling analysis to quickly identify top time consuming routines Use loop statistics to quickly identify top time consuming loops Small (test) or short running programs Scaling issues not significant Can skip first sampling experiment and directly generate profile For example: % pat_build –u –g mpi my_program NCRC Fall User Training 2012

Where to Run Instrumented Application
MUST run on Lustre ( /mnt/snx3/… , /lus/…, /scratch/…,etc.) Number of files used to store raw data 1 file created for program with 1 – 256 processes √n files created for program with 257 – n processes Ability to customize with PAT_RT_EXPFILE_MAX NCRC Fall User Training 2012

CrayPat Runtime Options
Runtime controlled through PAT_RT_XXX environment variables See intro_craypat(1) man page Examples of control Enable full trace Change number of data files created Enable collection of HW counters Enable collection of network counters Enable tracing filters to control trace file size (max threads, max call stack depth, etc.) NCRC Fall User Training 2012

Example Runtime Environment Variables
Optional timeline view of program available export PAT_RT_SUMMARY=0 View trace file with Cray Apprentice2 Number of files used to store raw data: 1 file created for program with 1 – 256 processes √n files created for program with 257 – n processes Ability to customize with PAT_RT_EXPFILE_MAX Request hardware performance counter information: export PAT_RT_HWPC=<HWPC Group> Can specify events or predefined groups NCRC Fall User Training 2012

pat_report Performs data conversion Combines information from binary with raw performance data Performs analysis on data Generates text report of performance results Formats data for input into Cray Apprentice2 NCRC Fall User Training 2012

Why Should I generate an “.ap2” file?
The “.ap2” file is a self contained compressed performance file Normally it is about 5 times smaller than the “.xf” file Contains the information needed from the application binary Can be reused, even if the application binary is no longer available or if it was rebuilt It is the only input format accepted by Cray Apprentice2 NCRC Fall User Training 2012

Files Generated and the Naming Convention
File Suffix Description a.out+pat Program instrumented for data collection a.out…s.xf Raw data for sampling experiment, available after application execution a.out…t.xf Raw data for trace (summarized or full) experiment, available after application execution a.out…st.ap2 Processed data, generated by pat_report, contains application symbol information a.out…s.apa Automatic profiling pnalysis template, generated by pat_report (based on pat_build –O apa experiment) a.out+apa Program instrumented using .apa file MPICH_RANK_ORDER.Custom Rank reorder file generated by pat_report from automatic grid detection an reorder suggestions NCRC Fall User Training 2012

Program Instrumentation - Automatic Profiling Analysis
Automatic profiling analysis (APA) Provides simple procedure to instrument and collect performance data for novice users Identifies top time consuming routines Automatically creates instrumentation template customized to application for future in-depth measurement and analysis NCRC Fall User Training 2012

Steps to Collecting Performance Data
Access performance tools software % module load perftools Build application keeping .o files (CCE: -h keepfiles) % make clean % make Instrument application for automatic profiling analysis You should get an instrumented program a.out+pat % pat_build –O apa a.out Run application to get top time consuming routines You should get a performance file (“<sdatafile>.xf”) or multiple files in a directory <sdatadir> % aprun … a.out+pat (or qsub <pat script>) NCRC Fall User Training 2012

Steps to Collecting Performance Data (2)
Generate report and .apa instrumentation file % pat_report –o my_sampling_report [<sdatafile>.xf | <sdatadir>] Inspect .apa file and sampling report Verify if additional instrumentation is needed NCRC Fall User Training 2012

APA File Example # You can edit this file, if desired, and use it
# to reinstrument the program for tracing like this: # # pat_build -O standard.cray-xt.PE HD.pgi-8.0.amd64.pat Oapa.512.quad.cores.seal mpi.pat_rt_exp=default.pat_rt_hwpc=none xf.xf.apa # These suggested trace options are based on data from: # /home/users/malice/pat/Runs/Runs.seal.pat Apr04/./pat.quad/homme/stand ard.cray-xt.PE HD.pgi-8.0.amd64.pat Oapa.512.quad.cores.seal mpi.pat_rt_exp=default.pat_rt_hwpc=none xf.xf.cdb # # HWPC group to collect by default. -Drtenv=PAT_RT_HWPC=1 # Summary with TLB metrics. # Libraries to trace. -g mpi # User-defined functions to trace, sorted by % of samples. # The way these functions are filtered can be controlled with # pat_report options (values used for this file are shown): # s apa_max_count= No more than 200 functions are listed. # s apa_min_size= Commented out if text size < 800 bytes. # s apa_min_pct= Commented out if it had < 1% of samples. # s apa_max_cum_pct=90 Commented out after cumulative 90%. # Local functions are listed for completeness, but cannot be traced. -w # Enable tracing of user-defined functions. # Note: -u should NOT be specified as an additional option. # 31.29% bytes -T prim_advance_mod_preq_advance_exp_ # 15.07% bytes -T prim_si_mod_prim_diffusion_ # 9.76% bytes -T derivative_mod_gradient_str_nonstag_ . . . # 2.95% bytes -T forcing_mod_apply_forcing_ # 2.93% bytes -T column_model_mod_applycolumnmodel_ # Functions below this point account for less than 10% of samples. # 0.66% bytes # T bndry_mod_bndry_exchangev_thsave_time_ # 0.10% bytes # T baroclinic_inst_mod_binst_init_state_ # 0.04% bytes # T prim_state_mod_prim_printstate_ # 0.00% 118 bytes # T time_mod_timelevel_update_ # -o preqx.cray-xt.PE HD.pgi-8.0.amd64.pat x+apa # New instrumented program. /.AUTO/cray/css.pe_tools/malice/craypat/build/pat/2009Apr03/2.1.56HD/amd64/hom me/pgi/pat /homme/2005Dec08/build.Linux/preqx.cray-xt.PE HD.pgi amd64.pat x # Original program.

Generating Profile from APA
Instrument application for further analysis (a.out+apa) % pat_build –O <apafile>.apa Run application % aprun … a.out+apa (or qsub <apa script>) Generate text report and visualization file (.ap2) % pat_report –o my_text_report.txt [<datafile>.xf | <datadir>] View report in text and/or with Cray Apprentice2 % app2 <datafile>.ap2 NCRC Fall User Training 2012

-g tracegroup (subset)
blas Basic Linear Algebra subprograms CAF Co-Array Fortran (Cray CCE compiler only) HDF5 manages extremely large and complex data collections heap dynamic heap io includes stdio and sysio groups lapack Linear Algebra Package math ANSI math mpi MPI omp OpenMP API omp-rtl OpenMP runtime library (not supported on Catamount) pthreads POSIX threads (not supported on Catamount) shmem SHMEM sysio I/O system calls system system calls upc Unified Parallel C (Cray CCE compiler only) For a full list, please see man pat_build NCRC Fall User Training 2012

Specific Tables in pat_report
pat_report -O –h pat_report: Help for -O option: Available option values are in left column, a prefix can be specified: ct O calltree defaults <Tables that would appear by default.> heap O heap_program,heap_hiwater,heap_leaks io O read_stats,write_stats lb O load_balance load_balance O lb_program,lb_group,lb_function mpi O mpi_callers --- D1_D2_observation Observation about Functions with low D1+D2 cache hit ratio D1_D2_util Functions with low D1+D2 cache hit ratio D1_observation Observation about Functions with low D1 cache hit ratio D1_util Functions with low D1 cache hit ratio TLB_observation Observation about Functions with low TLB refs/miss TLB_util Functions with low TLB refs/miss NCRC Fall User Training 2012

MPI Rank Placement Suggestions

Automatic Communication Grid Detection
Analyze runtime performance data to identify grids in a program to maximize on-node communication Example: nearest neighbor exchange in 2 dimensions Sweep3d uses a 2-D grid for communication Determine whether or not a custom MPI rank order will produce a significant performance benefit Grid detection is helpful for programs with significant point-to-point communication Doesn’t interfere with MPI collective communication optimizations NCRC Fall User Training 2012

Automatic Grid Detection (cont’d)
Tools produce a custom rank order if it’s beneficial based on grid size, grid order and cost metric Summarized findings in report Available if MPI functions traced (-g mpi) Describe how to re-run with custom rank order NCRC Fall User Training 2012

Example: Observations and Suggestions
MPI Grid Detection: There appears to be point-to-point MPI communication in a 22 X 18 grid pattern. The 48.6% of the total execution time spent in MPI functions might be reduced with a rank order that maximizes communication between ranks on the same node. The effect of several rank orders is estimated below. A file named MPICH_RANK_ORDER.Custom was generated along with this report and contains the Custom rank order from the following table. This file also contains usage instructions and a table of alternative rank orders. Rank On-Node On-Node MPICH_RANK_REORDER_METHOD Order Bytes/PE Bytes/PE% of Total Bytes/PE Custom 7.80e % 3 SMP 5.59e % 1 Fold 2.59e % 2 RoundRobin 0.00e % 0 NCRC Fall User Training 2012

MPICH_RANK_ORDER File Example
# The 'Custom' rank order in this file targets nodes with multi- core # processors, based on Sent Msg Total Bytes collected for: # # Program: /lus/nid00030/heidi/sweep3d/mod/sweep3d.mpi # Ap2 File: sweep3d.mpi+pat t.ap2 # Number PEs: 48 # Max PEs/Node: 4 # To use this file, make a copy named MPICH_RANK_ORDER, and set the # environment variable MPICH_RANK_REORDER_METHOD to 3 prior to # executing the program. # The following table lists rank order alternatives and the grid_order # command-line options that can be used to generate a new order. … NCRC Fall User Training 2012

Example 2 - Hycom ================ Observations and suggestions ======================== MPI grid detection: There appears to be point-to-point MPI communication in a 33 X 41 grid pattern. The 26.1% of the total execution time spent in MPI functions might be reduced with a rank order that maximizes communication between ranks on the same node. The effect of several rank orders is estimated below. A file named MPICH_RANK_ORDER.Custom was generated along with this report and contains the Custom rank order from the following table. This file also contains usage instructions and a table of alternative rank orders. Rank On-Node On-Node MPICH_RANK_REORDER_METHOD Order Bytes/PE Bytes/PE% of Total Bytes/PE Custom 1.20e % 3 SMP 8.70e % 1 Fold 3.55e % 2 RoundRobin 1.99e % 0 ================ End Observations ==================================== NCRC Fall User Training 2012

Example 2 - Hycom Run on 1353 MPI ranks, 24 ranks per node Overall program wallclock: Default MPI rank order: 1450s Custom MPI rank order: 1315s ~10% improvement in execution time! Time spent in MPI routines: Default rank order: 377s Custom rank order: 303s NCRC Fall User Training 2012

Loop Work Estimates NCRC Fall User Training 2012

Loop Work Estimates Helps identify loops to optimize (parallelize serial loops): Loop timings approximate how much work exists within a loop Trip counts can be used to help carve up loop on GPU Enabled with CCE –h profile_generate option Should be done as separate experiment – compiler optimizations are restricted with this feature Loop statistics reported by default in pat_report table Next enhancement: integrate loop information in profile Get exclusive times and loops attributed to functions NCRC Fall User Training 2012

Collecting Loop Statistics
Load PrgEnv-cray software Load perftools software Compile AND link with –h profile_generate Instrument binary for tracing pat_build –u my_program or pat_build –w my_program Run application Create report with loop statistics pat_report my_program.xf > loops_report NCRC Fall User Training 2012

Example Report – Loop Work Estimates
Table 1: Profile by Function Group and Function Time% | Time | Imb. | Imb. | Calls |Group | | Time | Time% | | Function | | | | | PE=HIDE | | | | | Thread=HIDE 100.0% | | -- | -- | |Total | | 85.3% | | -- | -- | 8.0 |USER || | 85.0% | | | 14.4% | 2.0 | jacobi_.LOOPS ||======================================================================= | 12.2% | | -- | -- | |MPI | 11.9% | | | 67.1% | | mpi_waitall | 2.4% | | -- | -- | |MPI_SYNC | 2.4% | | | 99.3% | | mpi_allreduce_(sync) |======================================================================== NCRC Fall User Training 2012

Cray Performance Tools
There’s a lot more to cover about CrayPAT and Apprentice2 than we have time for today. See OLCF website for help and talks from previous workshops. Contact your liaison or me for help if you need it. NCRC Fall User Training 2012

Cray Debugging Tools STAT ATP NCRC Fall User Training 2012

Stack Trace Analysis Tool (STAT)
My application hangs! NCRC Fall User Training 2012

What is STAT? Stack trace sampling and analysis for large scale applications from Lawrence Livermore Labs and the University of Wisconsin Creates a merged stack trace tree Groups ranks with common behaviors Fast: Collects traces for 100s of 1000s of cores in under a second Compact: Stack trace tree only a few mega bytes Extreme scale Jaguar: 200K cores Hopper: 125K cores NCRC Fall User Training 2012

Merged stack trace trees
Sampling across ranks Sampling across time Scalable visualization Shows the big picture Pin points subset for heavy weight debuggers NCRC Fall User Training 2012

Stack Trace Merge Example
MRNet Overview 10 April 2017 Stack Trace Merge Example NCRC Fall User Training 2012 © Barton P. Miller

2D-Trace/Space Analysis
MRNet Overview 10 April 2017 2D-Trace/Space Analysis Appl Appl Appl … Single sample, multiple processes: - Loosely synchronized distributed snapshot - Inconclusive information Appl Appl NCRC Fall User Training 2012 © Barton P. Miller

NERSC Plasma Physics Application
Production, plasma physics PIC ( Particle in Cell) code, run with 120K cores on hopper, and using HDF5 for parallel I/O Mixed MPI/OpenMP STAT helped them to see the big picture, as well as eliminate code possibilities since they were not in the tree NCRC Fall User Training 2012

STAT module load stat man STAT STAT <pid_of_aprun> Creates STAT_results/<app_name>/<merged_st_file> statview <merged_st_file> STATGUI Scaling no longer limited by number file descriptors NCRC Fall User Training 2012

Abnormal Termination Processing (ATP)
My application crashes! NCRC Fall User Training 2012

The Problem Being Solved
Applications on Cray systems use hundreds of thousands of processes On a crash one, many, or all of them might trap No one wants that many core files No one wants that many stack backtraces They are too slow and too big. They are too much to comprehend NCRC Fall User Training 2012

ATP Description System of light weight back-end monitor processes on compute nodes Coupled together as a tree with MRNet Automatically launched by aprun Leap into action on any application process trapping Stderr backtrace of first process to trap STAT like analysis provides merged stack backtrace tree Leaf nodes of tree define a modest set of processes to core dump Or, a set of processes to attach to with a debugger NCRC Fall User Training 2012

ATP – Abnormal Termination Processing
Write Modify Port App runs (verification) Compile & Link (production) Optimize Debug Normal Termination ATP Stacktrace (atpMergedBT.dot) STATview Exit Abnormal NCRC Fall User Training 2012 Cray ConfidentialCray Proprietary

ATP Components Application process signal handler (atpAppSigHandler) triggers analysis Back-end monitor (atpBackend) collects backtraces via StackwalkerAPI forces core dumps as directed using core_pattern Front-end controller (atpFrontend) coordinates analysis via MRNet selects process set that is to dump core Once initial set up complete, all components comatose NCRC Fall User Training 2012

ATP Communications Tree
FE Front-end Back-end App BE CP … NCRC Fall User Training 2012

ATP Since We Were Here Last Year
Added support for: Dynamic Applications Threaded Applications Medium memory model compiles Analysis on queuing system wall clock time out Eliminated use of LD_LIBRARY_PATH Numerous bug fixes. NCRC Fall User Training 2012

Current Release: ATP 1.4.3 Automatic ATP module loaded by default Signal handler added to application and registered Aprun launches ATP in parallel with application launch Run time enabled/disabled via ATP_ENABLED environment variable (can be set by site) Provides: backtrace of first crash to stderr merged backtrace trees dumps core file set (if limit/ulimit allows) Tested at 15K PEs NCRC Fall User Training 2012

Introduction to the Cray XK7

Similar presentations

Presentation on theme: "Introduction to the Cray XK7"— Presentation transcript:

Similar presentations

About project

Feedback

Log in

Auth with social network:

Introduction to the Cray XK7

Similar presentations

Presentation on theme: "Introduction to the Cray XK7"— Presentation transcript:

Similar presentations

About project

Feedback
