1 July / Corporate Background Established : 1986 Headquarter : Wu-Ku Industry Park, Taipei County Chairman : Mr. Marcell Jean General Manager : Mr. Genn Renn Capital : US$ 12 Million (2003) Revenue : US$ 52 Million (2002) Employees : Over 700 worldwide (2003) ISO 9001 : 1998 IPO : 2001

2 July / Company Profile Founded in 1986, Edimax is dedicated to the development, design and Manufacturing, marketing of innovative networking products. With our dedication and diligent working philosophy, Edimax has emerged as a major contributor in the networking industry. Edimax is a public listed company in Taiwan stock & exchange market (TSE). Since its inception, the marketing focus has been towards the OEM & distribution channels. We have excellent engineering and operational teams committed in ensuring our customers receive the highest quality products. Edimax products includes : Wireless LAN, Broadband Router, Gigabit series, Management switches, Print Server, PC Card, Switches from 5 to 32 ports, PCI / ISA/USB NIC, hubs and network peripheral products… You are welcome to surf our web site of for detailed product information.

3 July / Edimax headquarter is located in Taipei Taiwan with branch offices located in Netherlands, UK, China and USA. With an advancement of technology, Edimax is rapidly expanding it's product line to high- performance, high bandwidth and wireless market to cater to SOHO, workgroup and enterprise. Strong Technical Support assures user’s full satisfaction. Edimax now owns two state of art manufacturing facilities in Taiwan and China. To expand our production capacity and efficiency, a new 30,000 square meter manufacturing plant in China facilitates and ensures highest quality at the best price. Our quality control system is fully compliant with the ISO9001/2000 standardized process. Detailed operation standard and procedures have been setup for every production step from product design, procurement, to QC testing. Company Profile

4 July / Global Manufacturing / Logistic H / Q : Wu Ku Taipei / Taiwan ● ● ● ● Netherlands / Europe U.K. Miami / Latin America Warehouse & Service Sites ● ● San Jose / USA China Factory / Dong Guan

5 July / Edimax Milestones 1986 Edimax Technology was established Established US Branch Office 1993 Joined PCMCIA Association 1996 Launched Print Server to product line 1997 Added Fast Ethernet Hub 1997 Established China branch in Beijing, China 1997 Joined the PCI Association / Gigabit Ethernet Alliance 1998 Setup Wu-Ku factory #2 Dong-Guan (China) factory #3 European Head Office (The Netherlands) 1998 ISO-9001 Certified

6 July / Edimax Milestones Awarded the Symbol of Excellence Products 2000 Awarded the National Award of SME 2001 IPO (OTC) / Aug.2002 : TSEC-Listed (#3047) 2002 Acquired Alcatel-ABST Telecom Subsidiary 2002 Setup new Factories : Taiwan and Dong-Guan 2002 Extended Products Lines : Broadband and WLAN 2002 Launched Industrial #1 Realtek Chipset Wireless LAN card 2003 Joined WiFi Association

7 July / ~2003 Capital / Revenue (est.) CapitalRevenue Unit: US$M 59% 20% 12% Growth Chart

8 July / Company Organization Edimax Computer (USA) Edimax BVI (Hong Kong) Edimax Europe (Netherlands) / UK Edimax Latin America ( Miami, USA) General Manager Special Supporting Team Mr. Gene Renn Mr. Marcell Jean / Mr. Francisco Lee / Mr. Hanson Hsieh Edimax BVI (Virgin Island) R&D MIS PM Marketing Finance Admin. TaiwanChina Manufacturing Sales QC/QATech Support OEM/ODM OBM Domestic Directors Board

9 July / R&D Organization Vice General Manager Mr. Peter L.J. Pan Hardware LAN Wireless LAN LayoutMechanismFirmwareDriverApplication Lab Software Product Assurance Testing Customer Service

10 July / Revenue Analysis Taiwan Europe America Asia(SE) Asia(NE) Others 30.07% 26.21% 22.00% 6.94% 8.46% 6.32% OEM / ODM 55% OBM 45% Territory OEM vs. OBM

11 July / Products Revenue Analysis Broadband 5.8% Wireless 3.1% Wired 80.0% Others 11.1% 2002’ Broadband 15% Wireless 15% Wired 60% Others 10% 2003’

12 July / Manufacturing Organization Engineering Department Production Department Factory Material Department Material Controller Planner Warehouse Procurement DIP/ Assembly SMT Packing Test RMA Repair Center Manufacturing Engineering

13 July / Production Flow SMT DIP Test Assembly Package QC Shipment

14 July / Manufacturing & QC Process Material DeliveryReceiving Warehouse Kitting IQC SMTDIPAssembly Pre-Test IPQC Burn-In IPQC Warehouse Final Test Packing Warehouse Export Shipping FQC OQC

15 July / Product Schedule b+ 22Mb Wireless LAN EW-7205AP b+ Wireless LAN Access Point 64/128/256bit WEP Data Encryption EW b+ Wireless LAN PCI Card 64/128/256bit WEP Data Encryption EW-7105PC b+ Wireless LAN PC Card Supports 32bit Cardbus interface

16 July / Product Schedule b 11Mb Wireless LAN EW-7106PC b Wireless LAN Cardbus EW-7117U b Wireless LAN Mini USB Adapter EW b Wireless LAN PCI Adapter EW-7101PCG g Wireless CardBus Adapter

17 July / Product Schedule b 11Mb Wireless LAN AP EW-7206APB b Wireless WDS Access Point DHCP Support Web-Based Configuration EW-7205APL b Wireless WDS Access Point Building to Building Bridging, WDS Repeater, IEEE-802.1x, DHCP Support Web-Based Configuration

18 July / Wireless AP + Broadband Router BR-6104WB b Wireless AP Broadband Router 4 x LAN + 1 x WAN Supporting Multimedia Applications UPNP, VPN, IEEE-802.1x Support BR-6104WG (Print Server) g Wireless AP Broadband Router 4 x LAN + 1 x WAN Supporting Multimedia Applications UPNP, VPN, IEEE-802.1x Support

19 July / Product Schedule Broadband Router BR-6542 Multi-Homing Broadband Router 4 x WAN + 1 x LAN + 1 x Monitor Port QOS Bandwidth Management, SPI Firewall, DDNS Support BR-6104S / BR-6104P (Print Server) Broadband Router 4 x LAN + 1 x WAN Supporting Multimedia Applications UPNP, VPN, DDNS, IEEE-802.1x Support

20 July / Gigabit Backbone Switches ES-5500S Desktop 5 Port Gigabit Smart Switch VLAN, Trunking, QoS, Port Mirror ES-5800S Desktop 8 Port Gigabit Smart Switch VLAN, Trunking, QoS, Port Mirror ES-5800D+/R+ 8 Port Gigabit Backbone Smart Switch VLAN, Trunking, QoS, Port Mirror ES-5224RF+ / RE+ / R+ 2 Port Gigabit + 24 Port Smart Switch VLAN, Trunking, QoS, Auto-MDI/MDI-X

21 July / Product Schedule Gigabit Management Switches ES-5224RM (UTP) 2 x Gigabit + 24 Port Management Switch SNMP/MIB/RMON/Web-Based VLAN, Trunking, QoS, Bandwidth Control ES-5224RFM (Fiber) 2 x Gigabit + 24 Port Management Switch SNMP/MIB/RMON/Web-Based VLAN, Trunking, QoS, Bandwidth Control ES-5224REM 2 x Module + 24 Port Management Switch SNMP/MIB/RMON/Web-Based VLAN, Trunking, QoS, Bandwidth Control)

22 July / Product Schedule ES-3132RL / 3124RL / 3116RL 32/24/16 Port Fast Ethernet Switch Auto-MDI/MDI-X 19 “ Rackmount Switches ES-3116RE+ / ES-3124RE+ 16 / x Expansion Slots Smart Switch VLAN / Trunking / QoS ES-3124REM Slots Management Switch SNMP/MIB/RMON/Web-Based VLAN / Trunking / QoS

23 July / Product Schedule SOHO Desktop Switches ES-3105P 5 Port 10/100 Fast Ethernet Switch Auto-MDI/MDI-X, Store and Forward ES-3108P 8 Port 10/100 Fast Ethernet Switch Auto-MDI/MDI-X, Store and Forward ES-3116P 16 Port 10/100 Fast Ethernet Switch Auto-MDI/MDI-X, Store and Forward

24 July / Product Schedule Gigabit Fast Ethernet Adapter EN-9220F-64 (Fiber Optic) PCI 32/64bit 1000Base-SX Gigabit NIC EN-9230TX64 (Copper) PCI 32/64bit 1000Base-SX Gigabit NIC EN-9230TX32 (Copper) PCI 32-bit 1000Base-SX Gigabit NIC

25 July / Product Schedule Fast Ethernet Print Server PS-1203m 1 Port 10/100 Fast Ethernet Print Server TCP/IP, NetBEUI, IPP, IPX, AppleTalk PS Port 10/100 Fast Ethernet Print Server TCP/IP, NetBEUI, IPP, IPX, AppleTalk PS-3103 / PS-3103P 3 Port 10/100 Fast Ethernet Print Server TCP/IP, NetBEUI, IPP, IPX, AppleTalk

26 July / Product Schedule Fast Ethernet Series EN-9130TXA / TX / TXL PCI 10/100M Fast Ethernet Adapter Web-Based Management EP-4103DL (32Bit) / EP-4101DL Dongle-less Fast Ethernet PC Card Hot-Swap, Plug-and-Play installation EU-4202 USB 2.0 to Fast Ethernet Adapter Hot-Swap, Plug-and-Play installation

27 July / Product Schedule b Wireless IP Camera EW-ICAM / EL-ICAM (Wired Version) Wire / Wireless Internet IP Camera Provide I/O connectors to send and receive digital signals to a variety of external alarm devices Managed remotely over the Internet Browser IPView Application For MPEG-4 AVI Video Recording Frame rate setting: 1, 5, 7, 15, 20, auto Up to 16 simultaneous Cameras Video resolution up to 640 x 480 pixel

28 July / Product Schedule SOHO KVM Switch Series EK-PC2C 2 Port KVM Switch With Cable 200MHz Bandwidth, Auto Scan Mode EK-PC4P / EK-PC2P 4 Port / 2 Port SOHO KVM Switch Video Resolution Up To 1920 x MHz Bandwidth, Auto Scan Mode EK-PC4K / EK-PC2K (With 2 Cable) 4 Port / 2 Port SOHO KVM Switch Kit Video Resolution Up To 1920 x MHz Bandwidth, Auto Scan Mode

29 July / Product Schedule Professional KVM Switch EK-PS4D / EK-PS2D 4 Port / 2 Port Desktop KVM Switch Video Resolution Up To 1920 x MHz Bandwidth, Auto Scan Mode compact size design, easy portable EK-08RO / EK-16RO 8 Port / 16 Port O.S.D. KVM Switch Video Resolution Up To 1920 x MHz Bandwidth, Auto Scan Mode 19 inch Rackmount size with OSD (On Screen Display)

30 July / Product Schedule USB Application Series EU-RD06 USB 6 in 1 Card Reader / Writer Support Compact Flash, Smart Media, IBM Micro drive,, Multi Media Cards, SD Cards and Memory Stick, Reading / Writing with LED Display in each slot EU-SD4P / EU-SD2P 4 / 2 Port USB 2.0 Sharing Station Make Two or Four Computers able to share one USB 2.0 or 1.1 device or Extend USB down stream ports with 4 or 7 port USB Hub for more USB devices sharing

31 July / Product Schedule USB 2.0 Application Series EU-CV4P / EU-CV2P 4 Port / 2 Port USB 2.0 PCI Adapter Support Win98/Me/2000/XP, Linux EU-PC2P 2 Port USB 2.0 Cardbus Adapter Hot-Swap, External Power Adapter EU-HB4S USB 2.0 HUB With Power Adapter Support Win98/Me/2K/XP, Linux & Mac

32 July / ET-9003SCM/STM Fast Ethernet Fiber Media Converter (Multi-Mode) ET-9003SCS-15 Fiber Media Converter 15Km (SC) ET-9003SCS-30 Fiber Media Converter 30Km (SC) ET-9003SCS-60 Fiber Media Converter 60Km (SC) FE-C107SC 10/100m Fiber Media Converter SC FE-C10TST 10/100m Fiber Media Converter ST ET-9003MTS-15 Fast Ethernet Fiber Media Converter 15Km (MT-RJ) ET-9006SCSX Gigabit Fiber Media Converter (SC) ET-9006SCLX-15 Gigabit Fiber Media Converter 15Km (SC) Media Converter Series

33 July / Features ITU-T H.323 v3 / SIP compliance Support H.235 security function Automatically Gatekeeper Discovery Alternate Gatekeeper selection Provide Peer-to-Peer Mode (Non Gatekeeper needed) selection Line polarity reversal generation Provide call progress tone PPPoE (option) Behind NAT router or IP sharing device E.164 Dial Plan DTMF detection/generation TFTP/FTP software upgrade Remote configuration/reset LED indication for system status MS-NetMeeting v3.0 compatible Support Fix IP and DHCP Support QOS by setting TOS (Type Of Service) parameters of VoIP packet 2 port FSX 2/4 port FSX Voice Over IP Series

34 July / Features ITU-T H.323 v2/v3/v4 compliance Support SIP protocol Automatically Dial Path Selection (IP or PSTN) PSTN Line switch to telephone set when power is failure. PPPoE Behind NAT router or IP sharing device DNS server inquiry Automatically Gatekeeper Discovery Provide Peer-to-Peer Mode (Non Gatekeeper needed) selection E.164 Dial Plan DTMF detection/generation TFTP/FTP software upgrade Remote configuration/reset LED indication for system status MS-NetMeeting v3.0 compatible Support Fix IP and DHCP Parameters of VoIP packet 1 port FSX 1 port FX0 2 ports FXS 2 ports FXO Voice Over IP Series

35 July / ITU-T H.323 v3 / SIP compliance (**) Behind NAT router or IP sharing device Automatically Gatekeeper Discovery Provide peer-to-peer mode (Non Gatekeeper needed) selection Support auto-attendant (Tone or voice greeting) Line hunting PSTN Polarity Reversal Detection 4 RJ-11 FXO ports Provide 2nd dial tone to PSTN E.164 Common Dial Plan DTMF Dialing & DTMF detection / generation TFTP/FTP software upgrade Remote configuration / reset LED indication for system status LAN interface : One RJ-45 connector for 10Base-T MS-NetMeeting v3.0 compatible Support Fix IP and DHCP Provide QOS function with TOS (Type of Services) setting Provide T.38/FAX and voice Auto-Switching 2/4/6 ports FXO Voice Over IP Series

36 July / Product Schedule Thank You ! Why Edimax is your right choice ? System Integration Ability to provide best price-performance products Total Networking Solution Provider Providing Global Logistic Service Long-term Partnership with chipset vendors Dedicated Project Supporting Team for instant service
