1 B6: Beginners Guide to OpenEdge ® SQL via ODBC or JDBC Richard Banville Technical Fellow

2 © 2008 Progress Software Corporation 2 Agenda: OpenEdge SQL Component overview Initial connection OpenEdge database Setup and maintenance –Control and performance OpenEdge SQL specifics Tools Applications Goal: Make you successful with SQL applications!

3 © 2008 Progress Software Corporation 3 OpenEdge is Open SSL HTTP HTTP/S HTML.NET Java HTML Open Clients (Non-OpenEdge) OpenEdge ABL Clients ODBC Clients Service Interfaces OpenEdge DataServers OpenEdge ABL Server OpenEdge SQL Server JDBC Clients Oracle ® MSSQL ODBC ABL: Open Clients: Java.NET Web services (ABL works with relational DBs) OpenEdge SQL Crystal Reports WebSphere ® JBOSS / JRun Java / JDBC apps J2EE / JTA.NET / ODBC apps ADO.NET / VB Data is fully interoperable: ABL & SQL (works with OpenEdge RDBMS) OpenEdge RDBMS Other RDBMS

4 © 2008 Progress Software Corporation 4 Getting Connected – Client side: ODBC and JDBC drivers

5 © 2008 Progress Software Corporation 5 CLASSPATH ( run sql_env) Class loader (Loading the JDBC driver) URL for JDBC DriverManager.getConnection JDBC: Pure Java Driver Type 4 JDBC driver (10.1a+) jdbc:datadirect:openedge://localhost:6748;databaseName=db1 $DLC/java: openedge.jar, util.jar, base.jar CLASS.FORNAME com.ddtek.jdbc.openedge.OpenEdgeDriver

6 © 2008 Progress Software Corporation 6 ODBC DSN – single connection

7 © 2008 Progress Software Corporation 7 ODBC: Multi-Database configuration (10.1B)

8 © 2008 Progress Software Corporation 8 ODBC DSN - Advanced Tab Isolations: defaults have changed between versions T w/TZ: determines native or varchar storage Wide char: varchar: SQL_WVARCHAR vs SQL_VARCHAR Fetch Array Size: Max # rows driver fetches from server

9 © 2008 Progress Software Corporation 9 NoneShareExclusiveSIX Serializable ShareISExclusiveIX Repeatable Read ShareISExclusiveIX Read Committed NoLock --- Read Uncommitted Record Lock Table Lock Record Lock Table Lock Isolation Level FetchUpdate Isolation Level Affect on Lock Type

10 © 2008 Progress Software Corporation 10 Connection – server side

11 © 2008 Progress Software Corporation 11 Default server setup SQL Servers SQL client ABL client SQL client ABL client Shared Memory ABL Servers DB SQL & ABL Broker

12 © 2008 Progress Software Corporation 12 Recommended server setup SQL Servers SQL client ABL client ABL only Broker SQL only Broker SQL client ABL client Shared Memory ABL Servers DB

13 © 2008 Progress Software Corporation 13 Recommended parameters example Separating ABL and SQL brokers/servers example proserve myDB -S H localhost -ServerType 4GL -Mi 1 -Ma 5 -minport maxport Mpb 4 -Mn 8 -B -L... Start a primary ABL broker Start a secondary SQL broker proserve myDB -S H localhost -ServerType SQL -Mi 5 -Ma 10 -minport maxport Mpb 2 –m3 Secondary broker uses 1 –Mn for itself

14 © 2008 Progress Software Corporation 14 Security Authentication Authenticate then authorize Identify who I am Validate I am who I say I am Authorization Being I am who I say I am… What am I allowed to do

15 © 2008 Progress Software Corporation 15 Database authentication Performed at connection SQL –User ID and password required to authenticate ABL –User ID and password NOT required Security ID and passwords

16 © 2008 Progress Software Corporation 16 SQL Authentication (Am I who I say I am?) Case 1: Users have not been created (no rows in _User table) No password validation at connection –You are not authenticated –You can pretend to be someone you are not Unable to do much (not authorized) UNLESS –You created the database –You know an authorized user Database creator Someone who was granted privileges ID and passwords scenarios

17 © 2008 Progress Software Corporation 17 SQL Authentication (Am I who I say I am?) Case 2: Users have been created (rows exist in _User table) Password validation at connection Valid users defined by a DBA or SA –Can be created by SQL or ABL –Make sure existing SQL DBA has userid/pswd Invalid login/password error message: –Access denied (Authorisation failed). (8933) ID and passwords scenarios…contd

18 © 2008 Progress Software Corporation 18 Authorization – What am I allowed to do? SQL follows GRANT security model By default, a connected userid is not authorized to do anything. Exceptions: – the DBA account (full operations) – the TABLE owner DBA controls operation privileges with GRANT / REVOKE syntax

19 © 2008 Progress Software Corporation 19 Comparing ABL & SQL Security Systems ABLSQL Security modelGRANT Default DBAn/a SYSPROGRESS Default security administrator *n/a Default table access* Default field access*

20 © 2008 Progress Software Corporation 20 Encountering data access errors Possible reasons for this: No authorization privileges Schema scope Access denied (Authorization failed) (7512) select count(*) from customer;

21 © 2008 Progress Software Corporation 21 Authorization – What can I do? Database wide (system admin or general creation) GRANT { DBA, RESOURCE } TO user_name [, user_name ], …; Privileges syntax: GRANT (2 types) Can do anything Can CREATE stuff

22 © 2008 Progress Software Corporation 22 Authorization – What can I do? Database wide (system admin or general creation) GRANT { DBA, RESOURCE } TO user_name [, user_name ], …; GRANT { privilege [, privilege ], … | ALL } ON table_name TO { user_name [, user_name ], … | PUBLIC } [ WITH GRANT OPTION ]; Privileges syntax: GRANT (2 types) For specified Tables or Views –Where privilege is: { SELECT | INSERT | DELETE | INDEX | UPDATE [ ( column, column,... ) ] | REFERENCES [ ( column, column,... ) ] }

23 © 2008 Progress Software Corporation 23 Authorization – What can I do? For specified Tables or Views - Example See PSDN whitepaper on authorization for additional details. Example Syntax: GRANT GRANT select ON PUB.Customer TO richb; GRANT select ON PUB.Order-line TO PUBLIC; COMMIT WORK; ROLLBACK WORK;

24 © 2008 Progress Software Corporation 24 Encountering data access errors Possible reasons for this: No authorization privileges Schema scope Access denied (Authorization failed) (7512) select count(*) from customer; Schema scope

25 © 2008 Progress Software Corporation 25 Schema: a logical grouping PUB schema Customer table #1 Mysports database In the SQL world schema is NOT meta data nor is it Area 6 Order table #2 Order-line table #3 richb schema Customer table #4 Contacts table #5 Friends table #6

26 © 2008 Progress Software Corporation 26 Users have a default schema attached to their ID. richb.customer ABL uses one hidden schema – PUB Use PUB.customer for access from SQL Avoiding schema qualification in SQL: Can set it as a registry entry in ODBC dsn definition Schemas CREATE PUBLIC SYNONYM customer FOR pub.customer; What is a default schema?

27 © 2008 Progress Software Corporation 27 Solving data access errors Access denied (Authorization failed) (7512) select count(*) from customer; SELECT count(*) FROM pub.customer; SET SCHEMA pub; SELECT count(*) FROM customer; Solution #1: SELECT count(*) FROM richb.customer; Solution #2: Solution #3:

28 © 2008 Progress Software Corporation 28 Four level naming convention 4 Part Naming – Multi-Database Query Fully Qualified Names – catalog is database name catalog.schema.table.column-name

29 © 2008 Progress Software Corporation 29 Four level naming convention Example 4 Part Naming – Multi-Database Query Fully Qualified Names – catalog is database name catalog.schema.table.column-name SELECT Pub.Customer.CustNum, SportsPrimary.Pub.Customer.Name, SportsAux1.Pub.Order.OrderNum …

30 © 2008 Progress Software Corporation 30 Four level naming convention Example ABL has 3 level naming convention 4 Part Naming – Multi-Database Query Fully Qualified Names – catalog is database name catalog.schema.table.column-name SELECT Pub.Customer.CustNum, SportsPrimary.Pub.Customer.Name, SportsAux1.Pub.Order.OrderNum … catalog.table.column-name

31 © 2008 Progress Software Corporation 31 OpenEdge Specifics SQL is a standard, but each vendor has its own dialect

32 © 2008 Progress Software Corporation 32 OpenEdge SQL Specifics - Quoting Hyphenated names: Non-SQL standard names SELECT cust-num FROM PUB.Customer; Column CUST cannot be found (13865) Solution: quoting (double quotes) Most reporting applications will do this automatically.

33 © 2008 Progress Software Corporation 33 Overstuffed fields - error ABL allows more data than column definition SQL restricted to _field._sql-width value Column name in table PUB.customer has value exceeding its max length. SELECT name from PUB.customer; Solution: ALTER table… ALTER column… SET PRO_SQL_WIDTH ; Fix _sql-width via SQL ALTER TABLE or Data Dictionary

34 © 2008 Progress Software Corporation 34 OpenEdge Specifics - Overstuffed fields Strategies for managing: Dbtool : percentage option ($DLC/bin/dbtool) 1. SQL Width & Date Scan w/Report Option 2. SQL Width Scan w/Fix Option Choice: 2 : (0=single-user 1=self-service >1=#threads)? 3 Padding % above current max: 25 : (Table number or all)? all : (Area number or all)? all

35 © 2008 Progress Software Corporation 35 OpenEdge Specifics - Overstuffed fields Strategies for managing ABL client startup parameter –checkwidth n where "n" can be one of the following: 0 Ignore: Default is to ignore _width value. 1 WARNING: Store the data and generate a warning. 2 ERROR: Do not store data and generate an error..lg and screen: Width of data is greater than x.customer.Name _width.

36 © 2008 Progress Software Corporation 36 OpenEdge Specifics – Arrays / Extents Selecting array columns as a whole Result: semi-colon separated varchar value ; ; ; Selecting array column individually – SQL99 (10.1a) Result: numeric value SELECT quarterlySales from PUB.MySales; SELECT quarterlySales[1] from PUB.MySales;

37 © 2008 Progress Software Corporation 37 OpenEdge Specifics – Arrays / Extents Using views to break out array element CREATE VIEW pubView.QuarterSalesView (qS1, qS2, qS3, qS4) AS SELECT quarterlySales[1], quarterlySales[2], quarterlySales[3], quarterlySales[4] FROM PUB.MySales; Result: numeric values SELECT qS1, qS2, qS3, qS4 FROM pubView.QuarterSalesView; GRANT select ON pubView.QuarterSalevVIew TO PUBLIC;

38 © 2008 Progress Software Corporation 38 Q: What is it going to cost to run my query? TIME = ? Query Performance

39 © 2008 Progress Software Corporation 39 Q: What is it going to cost to run my query? TIME = Query Performance

40 © 2008 Progress Software Corporation 40 Basic Performance: What is the cost? Database without statistics 10K rows 50K 100K SalesHist Parts OrderLines Orders Customer Optimizer: How many rows do I think you have?

41 © 2008 Progress Software Corporation 41 Basic Performance: Heres the cost. Database with Update Statistics SalesHist Parts OrderLines Orders 10K rows 50K 100K Customer

42 © 2008 Progress Software Corporation 42 All Statistics: Table Cardinality, indexes and all columns Query Performance: Update Statistics UPDATE TABLE STATISTICS AND INDEX STATISTICS AND [ALL] COLUMN STATISTICS; UPDATE STATISTICS syntax UPDATE TABLE STATISTICS AND INDEX STATISTICS AND [ALL] COLUMN STATISTICS FOR pub.customer; Statistics - particular table

43 © 2008 Progress Software Corporation 43 Query trees : Defined relational algebraic tree representation (query tree / execution tree ) Result set Database access Data

44 © 2008 Progress Software Corporation 44 Basic Performance: Viewing Query Plans Query Plans Located in VST _Sql_Qplan SELECT SUBSTRING("_Description",1,80) FROM pub."_Sql_Qplan WHERE "_Pnumber" = (SELECT MAX( "_Pnumber" ) FROM pub."_Sql_Qplan" WHERE "_Ptype" > 0 ); Viewing query plan constructed by cost-based optimizer Remembers last 10 queries for a client SET PRO_SERVER LOG [ ON | OFF ] [ WITH ( { STATEMENT, QUERY_PLAN } ) ];

45 © 2008 Progress Software Corporation 45 Simple single table select SELECT … FROM pub.customer WHERE cust-num between 1000 and 1100 [ NoExecute ] Query plan: What to look for table index index keys, predicates SELECT COMMAND. PROJECT [66] ( | PROJECT [64] ( | | PUB.CUSTOMER. [0]( | | | INDEX SCAN OF ( | | | | cust-num, | | | | | (PUB.CUSTOMER.cust-num) between (1000,1100))

46 © 2008 Progress Software Corporation 46 Simple single table select SELECT … FROM pub.customer WHERE cust-num between 3000 and 3100 [ NoExecute ] Query plan: What to look for table index index keys, predicates SELECT COMMAND. PROJECT [66] ( | PROJECT [64] ( | | PUB.CUSTOMER. [0]( | | | INDEX SCAN OF ( | | | | cust-num, | | | | | (PUB.CUSTOMER.cust-num) between (3000,3100)) WITH (INDEX (name)) with index hint

47 © 2008 Progress Software Corporation 47 In Summary Initial SQL connection Setup and maintenance in OpenEdge database for security and performance Specifics of OpenEdge with SQL applications

48 © 2008 Progress Software Corporation 48 For More Information, go to… PSDN Developing Performance-Oriented ODBC/JDBC OpenEdge Applications OpenEdge SQL: Authorization Explained OpenEdge SQL in a 10.1B Multi-Database Environment OpenEdge ® Database Run-time Security Revealed OpenEdge Technical Support - KBases Basic Guide to Defining Progress SQL Database Permissions & Security Progress eLearning Community Using OpenEdge SQL Documentation 10.1C OpenEdge Data Management: SQL Development 10.1C OpenEdge Data Management: SQL Reference

49 © 2008 Progress Software Corporation 49 Questions ?

50 © 2008 Progress Software Corporation 50 Some Questions Answered Is there a way to grant a user select privilege for all tables in one statement? There is no way to grant privileges for all tables in one statement. Other than grant dba ;) Does the field level extent (array fields) reporting where members are separated by ";" work for ALL data type? yes If so, then how is a ";" handled within a character field? Is it quoted when encountered to differentiate between an array entry separator? An embedded semi-colon in a varchar array will be preceded by a ~

51 © 2008 Progress Software Corporation 51 Thank You

52 © 2008 Progress Software Corporation 52
