Section 11.1 Summary – pages 281 - 287 Replication of DNA Before a cell can divide by mitosis or meiosis, it must first make a copy of its chromosomes.

Similar presentations


Presentation on theme: "Section 11.1 Summary – pages 281 - 287 Replication of DNA Before a cell can divide by mitosis or meiosis, it must first make a copy of its chromosomes."— Presentation transcript:

1

2

3 Section 11.1 Summary – pages Replication of DNA Before a cell can divide by mitosis or meiosis, it must first make a copy of its chromosomes. The DNA in the chromosomes is copied in a process called DNA replication. Without DNA replication, new cells would have only half the DNA of their parents.

4 Section 11.1 Summary – pages Replication of DNA DNA Replication

5 Section 11.1 Summary – pages Replication of DNA Click this image to view movie

6 Section 11.1 Summary – pages DNA is copied during interphase prior to mitosis and meiosis. It is important that the new copies are exactly like the original molecules. Copying DNA

7 Section 11.1 Summary – pages Copying DNA Original DNA Original DNA Strand Free Nucleotides New DNA molecule New DNA Strand New DNA molecule

8 Section 1 Check Question 2 Which of the following is NOT a component of DNA? D. proteins C. nitrogenous bases B. phosphate groups A. simple sugars The answer is D.

9 Section 1 Check Question 3 Which of the following correctly comprises a complimentary base pair? D. cytosine – thymine C. guanine – adenine B. thymine – guanine A. adenine – thymine The answer is A.

10 Section 2 Objectives – page 288 Section Objectives Sequence the steps involved in protein synthesis. Relate the concept of the gene to the sequence of nucleotides in DNA.

11 Section 11.2 Summary – pages The sequence of nucleotides in DNA contain information. Genes and Proteins This information is put to work through the production of proteins. Proteins fold into complex, three- dimensional shapes to become key cell structures and regulators of cell functions.

12 Section 11.2 Summary – pages Some proteins become important structures, such as the filaments in muscle tissue. Other proteins, such as enzymes, control chemical reactions that perform key life functionsbreaking down glucose molecules in cellular respiration, digesting food, or making spindle fibers during mitosis. Genes and Proteins

13 Section 11.2 Summary – page Thus, by encoding the instructions for making proteins, DNA controls cells. In fact, enzymes control all the chemical reactions of an organism. Genes and Proteins

14 Section 11.2 Summary – page You learned earlier that proteins are polymers of amino acids. The sequence of nucleotides in each gene contains information for assembling the string of amino acids that make up a single protein. Genes and Proteins

15 Section 11.2 Summary – pages RNA like DNA, is a nucleic acid. RNA structure differs from DNA structure in three ways. First, RNA is single strandedit looks like one-half of a zipper whereas DNA is double stranded. RNA

16 Section 11.2 Summary – pages The sugar in RNA is ribose; DNAs sugar is deoxyribose. Ribose RNA

17 Section 11.2 Summary – pages Both DNA and RNA contain four nitrogenous bases, but rather than thymine, RNA contains a similar base called uracil (U). Uracil forms a base pair with adenine in RNA, just as thymine does in DNA. Uracil Hydrogen bonds Adenine RNA

18 Section 11.2 Summary – pages DNA provides workers with the instructions for making the proteins, and workers build the proteins. The workers for protein synthesis are RNA molecules. RNA

19 Section 11.2 Summary – pages DNA provides workers with the instructions for making the proteins, and workers build the proteins. The workers for protein synthesis are RNA molecules. They take from DNA the instructions on how the protein should be assembled, then amino acid by amino acidthey assemble the protein. RNA

20 Section 11.2 Summary – pages There are three types of RNA that help build proteins. Messenger RNA (mRNA), brings instructions from DNA in the nucleus to the cells factory floor, the cytoplasm. On the factory floor, mRNA moves to the assembly line, a ribosome. RNA

21 Section 11.2 Summary – pages The ribosome, made of ribosomal RNA (rRNA), binds to the mRNA and uses the instructions to assemble the amino acids in the correct order. RNA

22 Section 11.2 Summary – pages Transfer RNA (tRNA) is the supplier. Transfer RNA delivers amino acids to the ribosome to be assembled into a protein. RNA Click image to view movie

23 Section 11.2 Summary – pages Transcription In the nucleus, enzymes make an RNA copy of a portion of a DNA strand in a process called transcription.

24 Section 11.2 Summary – pages Transcription

25 Section 11.2 Summary – pages Transcription The main difference between transcription and DNA replication is that transcription results in the formation of one single- stranded RNA molecule rather than a double- stranded DNA molecule.

26 Section 11.2 Summary – pages Not all the nucleotides in the DNA of eukaryotic cells carry instructionsor codefor making proteins. Genes usually contain many long noncoding nucleotide sequences, called introns, that are scattered among the coding sequences. RNA Processing

27 Section 11.2 Summary – pages RNA Processing Regions that contain information are called exons because they are expressed. When mRNA is transcribed from DNA, both introns and exons are copied. The introns must be removed from the mRNA before it can function to make a protein.

28 Section 11.2 Summary – pages Enzymes in the nucleus cut out the intron segments and paste the mRNA back together. The mRNA then leaves the nucleus and travels to the ribosome. RNA Processing

29 Section 11.2 Summary – pages The nucleotide sequence transcribed from DNA to a strand of messenger RNA acts as a genetic message, the complete information for the building of a protein. As you know, proteins contain chains of amino acids. You could say that the language of proteins uses an alphabet of amino acids. The Genetic Code

30 Biochemists began to crack the genetic code when they discovered that a group of three nitrogenous bases in mRNA code for one amino acid. Each group is known as a codon. A code is needed to convert the language of mRNA into the language of proteins. The Genetic Code

31 Section 11.2 Summary – pages Sixty-four combinations are possible when a sequence of three bases is used; thus, 64 different mRNA codons are in the genetic code. The Genetic Code

32 Section 11.2 Summary – pages The Genetic Code The Messenger RNA Genetic Code First Letter Second Letter U U C A G Third Letter U C A G U C A G U C A G U C A G C A G Phenylalanine (UUU) Phenylalanine (UUC) Leucine (UUA) Leucine (UUG) Leucine (CUU) Leucine (CUC) Leucine (CUA) Leucine (CUG) Isoleucine (AUU) Isoleucine (AUC) Isoleucine (AUA) Methionine; Start (AUG) Valine (GUU) Valine (GUC) Valine (GUA) Valine (GUG) Serine (UCU) Serine (UCC) Serine (UCA) Serine (UCG) Proline (CCU) Proline (CCC) Proline (CCA) Proline (CCG) Threonine (ACU) Threonine (ACC) Threonine (ACA) Threonine (ACG) Alanine (GCU) Alanine (GCC) Alanine (GCA) Alanine (GCG) Tyrosine (UAU) Tyrosine (UAC) Stop (UAA) Stop (UAG) Histadine (CAU) Histadine (CAC) Glutamine (CAA) Glutamine (CAG) Asparagine (AAU) Asparagine (AAC) Lysine (AAA) Lysine (AAG) Aspartate (GAU) Aspartate (GAC) Glutamate (GAA) Glutamate (GAG) Cysteine (UGU) Cysteine (UGC) Stop (UGA) Tryptophan (UGG) Arginine (CGU) Arginine (CGC) Arginine (CGA) Arginine (CGG) Serine (AGU) Serine (AGC) Arginine (AGA) Arginine (AGG) Glycine (GGU) Glycine (GGC) Glycine (GGA) Glycine (GGG)

33 Section 11.2 Summary – pages Some codons do not code for amino acids; they provide instructions for making the protein. More than one codon can code for the same amino acid. However, for any one codon, there can be only one amino acid. The Genetic Code

34 Section 11.2 Summary – pages All organisms use the same genetic code. This provides evidence that all life on Earth evolved from a common origin. The Genetic Code

35 Section 11.2 Summary – pages Translation: From mRNA to Protein The process of converting the information in a sequence of nitrogenous bases in mRNA into a sequence of amino acids in protein is known as translation. Translation takes place at the ribosomes in the cytoplasm. In prokaryotic cells, which have no nucleus, the mRNA is made in the cytoplasm.

36 Section 11.2 Summary – pages Translation: From mRNA to Protein In eukaryotic cells, mRNA is made in the nucleus and travels to the cytoplasm. In cytoplasm, a ribosome attaches to the strand of mRNA like a clothespin clamped onto a clothesline.

37 Section 11.2 Summary – pages For proteins to be built, the 20 different amino acids dissolved in the cytoplasm must be brought to the ribosomes. This is the role of transfer RNA. The role of transfer RNA

38 Section 11.2 Summary – pages Each tRNA molecule attaches to only one type of amino acid. Amino acid Chain of RNA nucleotides Transfer RNA molecule Anticondon The role of transfer RNA

39 Section 11.2 Summary – pages Translation

40 Section 11.2 Summary – pages The role of transfer RNA Ribosome mRNA codon

41 Section 11.2 Summary – pages Usually, the first codon on mRNA is AUG, which codes for the amino acid methionine. AUG signals the start of protein synthesis. When this signal is given, the ribosome slides along the mRNA to the next codon. The role of transfer RNA

42 Section 11.2 Summary – pages tRNA anticodon Methionine The role of transfer RNA

43 Section 11.2 Summary – pages A new tRNA molecule carrying an amino acid pairs with the second mRNA codon. Alanine The role of transfer RNA

44 Section 11.2 Summary – pages The amino acids are joined when a peptide bond is formed between them. Alanine Methionine Peptide bond The role of transfer RNA

45 Section 11.2 Summary – pages A chain of amino acids is formed until the stop codon is reached on the mRNA strand. Stop codon The role of transfer RNA

46 Section 2 Check What are the three chemical differences between RNA and DNA? Question 1 Answer RNA consists of a single strand of nucleotides whereas DNA is a double strand. RNA contains ribose as its sugar and DNA contains deoxyribose as its sugar. Uracil in RNA replaces thymine in DNA as the nitrogenous base.

47 Section 2 Check What is the role of rRNA in protein synthesis? Question 2 Answer Ribosomal RNA binds to messenger RNA and assembles the amino acids in the order needed for the protein to be synthesized.

48 Section 2 Check Which regions of the mRNA travel to the ribosome; introns, exons, or both? Question 3 Answer Only exons, which contain coding information, travel to the ribosome. Introns, noncoding nucleotide sequences, do not travel to the ribosome.

49 Section 2 Check What is an anticodon, and what does it represent? Question 4 Answer An anticodon is a sequence of three nucleotides on the tRNA molecule that binds to a codon of the mRNA strand.

50 11.3 Section Objectives – page 296 Categorize the different kinds of mutations that can occur in DNA. Section Objectives: Compare the effects of different kinds of mutations on cells and organisms.

51 11.3 Section Summary 6.3 – pages Organisms have evolved many ways to protect their DNA from changes. Mutations In spite of these mechanisms, however, changes in the DNA occasionally do occur. Any change in DNA sequence is called a mutation. Mutations can be caused by errors in replication, transcription, cell division, or by external agents.

52 11.3 Section Summary 6.3 – pages Mutations can affect the reproductive cells of an organism by changing the sequence of nucleotides within a gene in a sperm or an egg cell. Mutations in reproductive cells If this cell takes part in fertilization, the altered gene would become part of the genetic makeup of the offspring.

53 11.3 Section Summary 6.3 – pages Mutations in reproductive cells The mutation may produce a new trait or it may result in a protein that does not work correctly. Sometimes, the mutation results in a protein that is nonfunctional, and the embryo may not survive. In some rare cases a gene mutation may have positive effects.

54 11.3 Section Summary 6.3 – pages What happens if powerful radiation, such as gamma radiation, hits the DNA of a nonreproductive cell, a cell of the body such as in skin, muscle, or bone? If the cells DNA is changed, this mutation would not be passed on to offspring. However, the mutation may cause problems for the individual. Mutations in body cells

55 11.3 Section Summary 6.3 – pages Mutations in body cells Damage to a gene may impair the function of the cell. When that cell divides, the new cells also will have the same mutation. Some mutations of DNA in body cells affect genes that control cell division. This can result in the cells growing and dividing rapidly, producing cancer.

56 11.3 Section Summary 6.3 – pages A point mutation is a change in a single base pair in DNA. A change in a single nitrogenous base can change the entire structure of a protein because a change in a single amino acid can affect the shape of the protein. The effects of point mutations

57 11.3 Section Summary 6.3 – pages The effects of point mutations Normal Point mutation mRNA Protein Stop mRNA Protein Replace G with A

58 11.3 Section Summary 6.3 – pages Frameshift mutations What would happen if a single base were lost from a DNA strand? This new sequence with the deleted base would be transcribed into mRNA. But then, the mRNA would be out of position by one base. As a result, every codon after the deleted base would be different.

59 11.3 Section Summary 6.3 – pages Frameshift mutations mRNA Protein Frameshift mutation Deletion of U

60 11.3 Section Summary 6.3 – pages Frameshift mutations This mutation would cause nearly every amino acid in the protein after the deletion to be changed. A mutation in which a single base is added or deleted from DNA is called a frameshift mutation because it shifts the reading of codons by one base.

61 11.3 Section Summary 6.3 – pages Changes may occur in chromosomes as well as in genes. Alterations to chromosomes may occur in a variety of ways. Structural changes in chromosomes are called chromosomal mutations. Chromosomal Alterations

62 11.3 Section Summary 6.3 – pages Chromosomal mutations occur in all living organisms, but they are especially common in plants. Few chromosomal mutations are passed on to the next generation because the zygote usually dies. Chromosomal Alterations

63 11.3 Section Summary 6.3 – pages In cases where the zygote lives and develops, the mature organism is often sterile and thus incapable of producing offspring. When a part of a chromosome is left out, a deletion occurs. Deletion A B C D E F G HA B C E F G H Chromosomal Alterations

64 11.3 Section Summary 6.3 – pages When part of a chromatid breaks off and attaches to its sister chromatid, an insertion occurs. The result is a duplication of genes on the same chromosome. Insertion A B C D E F G H A B C B C D E F G H Chromosomal Alterations

65 11.3 Section Summary 6.3 – pages When part of a chromosome breaks off and reattaches backwards, an inversion occurs. Inversion A B C D E F G H A D C B E F G H Chromosomal Alterations

66 11.3 Section Summary 6.3 – pages When part of one chromosome breaks off and is added to a different chromosome, a translocation occurs. A B E F DCBX A W C H G G E H D F W XYZYZ Translocation Chromosomal Alterations

67 11.3 Section Summary 6.3 – pages Some mutations seem to just happen, perhaps as a mistake in base pairing during DNA replication. These mutations are said to be spontaneous. However, many mutations are caused by factors in the environment. Causes of Mutations

68 11.3 Section Summary 6.3 – pages Any agent that can cause a change in DNA is called a mutagen. Mutagens include radiation, chemicals, and even high temperatures. Forms of radiation, such as X rays, cosmic rays, ultraviolet light, and nuclear radiation, are dangerous mutagens because the energy they contain can damage or break apart DNA. Causes of Mutations

69 11.3 Section Summary 6.3 – pages Causes of Mutations The breaking and reforming of a double- stranded DNA molecule can result in deletions. Chemical mutagens include dioxins, asbestos, benzene, and formaldehyde, substances that are commonly found in buildings and in the environment. Chemical mutagens usually cause substitution mutations.

70 11.3 Section Summary 6.3 – pages Repairing DNA Repair mechanisms that fix mutations in cells have evolved. Enzymes proofread the DNA and replace incorrect nucleotides with correct nucleotides. These repair mechanisms work extremely well, but they are not perfect. The greater the exposure to a mutagen such as UV light, the more likely is the chance that a mistake will not be corrected.

71 Section 3 Check Any change in DNA sequences is called a _______. Question 1 D. translation C. transcription B. mutation A. replication The answer is B.

72 Section 3 Check Which is more serious, a point mutation or a frameshift mutation? Why? Question 2 Answer A frameshift mutation is more serious than a point mutation because it disrupts more codons than a point mutation.

73 Section 3 Check Why are chromosomal mutations rarely passed on to the next generation? Question 3 Answer Few chromosomal changes are passed on to the next generation because the zygote usually dies. If the zygote survives, it is often sterile and incapable of producing offspring.

74 Chapter Summary – 11.1 Alfred Hershey and Martha Chase demonstrated that DNA is the genetic material. DNA: The Molecule of Heredity Because adenine can pair only with thymine, and guanine can pair only with cytosine, DNA can replicate itself with great accuracy.

75 Chapter Summary – 11.1 DNA: The Molecule of Heredity DNA, the genetic material of organisms, is composed of four kinds of nucleotides. A DNA molecule consists of two strands of nucleotides with sugars and phosphates on the outside and bases paired by hydrogen bonding on the inside. The paired strands form a twisted-zipper shape called a double helix.

76 Chapter Summary – 11.2 Genes are small sections of DNA. Most sequences of three bases in the DNA of a gene code for a single amino acid in a protein. From DNA to Protein Messenger RNA is made in a process called transcription. The order of nucleotides in DNA determines the order of nucleotides in messenger RNA.

77 Chapter Summary – 11.2 From DNA to Protein Translation is a process through which the order of bases in messenger RNA codes for the order of amino acids in a protein.

78 Chapter Summary – 11.3 Genetic Changes A mutation is a change in the base sequence of DNA. Mutations may affect only one gene, or they may affect whole chromosomes. Mutations in eggs or sperm affect future generations by producing offspring with new characteristics. Mutations in body cells affect only the individual and may result in cancer.

79 Chapter Assessment Question 1 How does DNA control the structures and functions of a cell? Answer DNA determines the structure of proteins. Some proteins become important cell structures. Other proteins, such as enzymes, control chemical reactions that perform key life functions.

80 Chapter Assessment Question 2 The process through which the order of bases in messenger RNA codes for the order of amino acids in a protein is: D. point mutation C. replication B. translation A. transcription The answer is B.

81 Chapter Assessment Question 3 Why would scientists use nucleotide sequences to identify bodies of crime victims? Answer In comparing nucleotide sequences in the DNA of a crime victim with nucleotide sequences from a possible close relative of the crime victim, scientists can determine if the two are related.

82 Chapter Assessment Question 4 What happens when a stop codon is reached during translation? Answer When a stop codon is reached, translation ends and the amino acid strand is released from the ribosome.

83 Chapter Assessment Question 5 A ________ bond forms between adjacent amino acids during translation. D. peptide C. hydrogen B. phosphate A. nucleotide The answer is D.

84 Chapter Assessment Question 6 What is the difference between a purine and a pyrimidine? Answer A purine is a double-ringed nitrogenous base. A pyrimidine is a single-ringed nitrogenous base.

85 Chapter Assessment Question 7 Why is DNA replication important to cell division? Answer Without DNA replication, new cells would have only half the DNA of their parents. Species could not survive and individuals could not grow or reproduce successfully.

86 Chapter Assessment Question 8 At the beginning and end of replication, which of the following are instrumental in breaking and bonding the hydrogen bonds between bases? D. enzymes C. nucleotides B. purines A. pyrimidines The answer is D.

87 Chapter Assessment Question 9 What is the role of mRNA in protein synthesis? Answer The messenger RNA acts as a genetic message, providing the complete information, in sequences of codons, for the building of a protein.

88 Chapter Assessment Question 10 The DNA sequences of a parrot _________. D. contain exactly the same nucleotides as those of a beetle C. are exactly the same as those of a human B. are more similar to a fern than a dog A. are more similar to those of a clam than a robin The answer is D.

89 To advance to the next item or next page click on any of the following keys: mouse, space bar, enter, down or forward arrow. Click on this icon to return to the table of contents Click on this icon to return to the previous slide Click on this icon to move to the next slide Click on this icon to open the resources file.

90 End of Chapter 11 Show
