1 Water & Irrigation Control Solutions 1

2 2  MIR1080 - 1974  MIR2000 - 1979  MIR3000 - 1986  MIR5000 - 1991  IRRInet - 1996  ICC SW - 2000  IRRInet XL - 2002 MOTOROLA in the Water & Irrigation Control Market for over than 25 Years

3 Water & Irrigation Control Solutions 3 IRRInet XL - System Concept ICC Piccolo RTU Store & Forward IRRIcom IRRInet XL FIU IRRInet XL Field Unit IRRInet XM Piccolo XR

4 Water & Irrigation Control Solutions 4 IRRInet XL Field Unit Basic unit

5 Water & Irrigation Control Solutions 5 IRRInet XL Field Unit Low-Power Radio CPU 3AH Backup Battery Available I/O Modules: AC I/O, DC I/O, S.C., Analog I/O 24V AC Transformer Piccolo Interface Unit

6 Water & Irrigation Control Solutions 6 IRRInet XL Field Unit  Consists of:  CPU  Up to 3 I/O modules: AC I/O, DC I/O, Single Cable, Analog I/O  Power supply module  Radio and/or line modem  Operates also as Field Interface Unit (FIU)  Operates with:  conventional UHF/VHF  TETRA  Spread Spectrum  RS232  RS485  TCP/IP (LAN)  Leased line  Dial-up  Wi-Fi (WLAN)  Fiber Optic interface  GSM\GPRS interface

7 Water & Irrigation Control Solutions 7 IRRInet XL Field Unit  IRRinet XL controls :  500 Outputs (valves, pumps, relays etc.)  500 inputs (including 250 water meters)  500 irrigation programs  100 fertilizing pumps  100 filter batteries  IRRInet XL may control and monitor reservoirs, pumps, valves, water meters, water pressure, water level, flow sensors, temperature, humidity  IRRInet XL has unique condition programs for local process  The IRRInet XL communicates with the central unit and field units (IRRIcom, IRRInet XL,Piccolo XR ) with one or two radios  IRRInet XL has a unique Single Cable (S.C.) module which controls Piccolo RTUs  The IRRInet XL is designed to operate in rough environment conditions (-30 to +60°C)

8 Water & Irrigation Control Solutions 8 Store & Forward Application Area 2 Area 1 Node IRRInet XL allows radio Communication between IRRInet-to-Central and IRRInet-to-IRRInet, using existing units as nodes in the network Store & Forward feature may be utilized to pass information from IRRInet to IRRInet throughout the system

9 Water & Irrigation Control Solutions 9 IRRInet XL - Single Cable Concept Up to 3 Single Cable modules Up to 189 water meters Up to 63 Piccolo RTUs on one 2 X 1.5mm cable Up to 10km cable length

10 Water & Irrigation Control Solutions 10 Piccolo RTU and Single Cable Advantages  Operates via 2 X 1.5mm cable from IRRInet single cable module  Controls one solenoid and receives two digital inputs  Up to 63 piccolo units on one cable  Up to 10km cable length  IP65 plastic box housing  No energy is required in the field. The single cable module provides the energy to operate solenoids and to receive back information data  Optional Lightning Protection Unit (LPU) is available for the Single Cable module (better and advantageous protection ) latched solenoid electronic board A1A2A3A4A5A6 1 0 + - + -

11 Water & Irrigation Control Solutions 11 Radio Piccolo-XR PIU – Piccolo Interface Unit Piccolo-XR

12 Water & Irrigation Control Solutions 12 The Piccolo-XR RTU is a small sized unit consists of electronic board packed in an IP68 sealed waterproof plastic housing The unit operates up to 4 solenoids and receives up to 8 inputs (depends on the model). The Piccolo-XR has also the options of analog I/O The Piccolo-XR communicates via low-power radio to IRRInet-XL and other Piccolo-XR units for a distance of approximately 3 km Up to 256 digital inputs, 256 digital outputs, 32 analog inputs and 32 analog outputs of Piccolo-XR are supported per IRRInet-XL unit Power: external 6VDC battery Ambient Temperature -30 ºC to +60 ºC (-22 ºF to +140 ºF) I/o options : 1 solenoid output + 1 digital input 2 solenoid outputs + 2 digital inputs 4 solenoid outputs + 4 digital inputs 8 solenoid inputs 1 analog input 1 analog output

13 Water & Irrigation Control Solutions 13 Piccolo-XR Communication Network IRRInet-XL Control Center The Piccolo-XR units may communicate with the central IRRInet-XL and with each other. This unique feature allows to communicate over large areas.

14 Water & Irrigation Control Solutions 14 Piccolo-XR I/O Capabilities Solenoid Outputs Water Meter Inputs Analog I/O

15 Water & Irrigation Control Solutions 15 IRRIcom AC & DC  Remotely controlled RTU from IRRInet/IRRInet XL FIU  External 1-4W standard UHF/VHF radio  Power Save Mode. Power is provided only to the circuits and elements activated by the application program. This unique capability is reducing battery/solar pannel sizes

16 Water & Irrigation Control Solutions 16 IRRIcom Basic Hardware Capacity:  DC model: 12 DC latched outputs  AC model: 12 AC outputs  4 dry contacts (digital) inputs Expansions:  12 outputs+4 digital inputs  18 digital inputs Future I/O expansion: 4 analog inputs+1 analog output+3 digital inputs

17 Water & Irrigation Control Solutions 17 Connecting up to 16 IRRIcoms via line, for up to 10km cable length Software Capacity:  50 outputs  50 inputs  20 main lines  100 programs  50 groups  10 virtual meters  20 fertilizing pumps  20 fertilizing farms  300 conditions (by three condition types) IRRIcom Communication Capabilities:  RS232  RS485  Line  Radio

18 Water & Irrigation Control Solutions 18 Power Source:  External 12VDC (DC model) or 24VAC (AC model)  Internal 4.5V DC (3 standard C-Type 1.5V batteries)  Internal power source for external radio Extra Features:  Selecting solenoid’s operating voltage (6-20V in DC model)  Selecting input pulse width (50-1000 mSec) IRRIcom

19 Water & Irrigation Control Solutions 19 Future Operation Modes:  Remote Mode - slave of IRRInet XL or another IRRIcom  Stand-alone Mode - the IRRIcom operates a preset program – no radio is required  Auto Mode - switching from remote to stand-alone mode  Stand-alone & Remote Mode - the IRRIcom runs its own programs and may receive commands from an IRRInet XL or another IRRIcom IRRIcom

20 Water & Irrigation Control Solutions 20 ICC XL- IRRInet Control Center  SCADA software package  Fully graphical software  5 password levels  New interrogation concept  Graphics screens for field elements status (on-off elements, levels, pressures, flows, quantities, temperatures etc.)  Multi-lingual software (English, Spanish, Portuguese, Italian, French and more)

21 Water & Irrigation Control Solutions 21 ICC XL – an Open System ICC XL – an Open System  Windows 2000/XP Professional compatible  Compatibility with IRRInet/IRRInet XL/XM units  Controls up to 999 IRRInet field units  “Open architecture” system - provides easy files and database transfer (ODBC* interface) Client/Server System many users may operate the system concurrently, using several computers connected through modem and/or TCP/IP. *ODBC - Open Database Connectivity Microsoft database programming interface that provides a common language for Windows applications to use in accessing databases across a computer network.

22 Water & Irrigation Control Solutions 22 ICC – Networking Method ICC Client Dial-up MODEM IRRInet FIU ICC SCADA Client Radio Communication Between IRRInet Units ICC Server TCP/IP (LAN) ICC Client Through dial-up

23 Water & Irrigation Control Solutions 23

24 Water & Irrigation Control Solutions 24

25 Water & Irrigation Control Solutions 25

26 Water & Irrigation Control Solutions 26 Local Area Network (LAN) System Concept Regional Center A ICC Server IRRInet XL FIU LAN (TCP/IP) IRRInet XL Field Unit 3 Regional Center B IRRInet XL Field Unit 4 RS232 IRRInet XL Field Unit 1 IRRInet XL Field Unit 2

27 Water & Irrigation Control Solutions 27 Mixed System Concept Central PC IRRInet XL FIU No. 1 RS232 Piccolo RTUs Single Cable Line RS232 IRRInet FIU No. 2 IRRInet Field Unit IRRInet XL Field Unit IRRInet XM Field Unit RS485/232 Piccolo RTUs IRRIcom Single Cable Line IRRIcom Store & Forward IRRInet System IRRInet XL System Piccolo XR RTUs

28 Water & Irrigation Control Solutions 28 Upgrading Existing IRRInet System to IRRInet XL  IRRInet XM Existing IRRInet Replacing the Super CPU with CPU420 Downloading system software to the CPU420 IRRInet XM IN A SHORT PROCESS ALL IRRINET XL FEATURES ARE IN YOUR EXISTING IRRINET SYSTEM

29 Water & Irrigation Control Solutions 29 Scorpio - Radio Controlled Unit  8/16 outputs, 2/4 inputs  Operates 24V AC and 24V DC latched solenoids  Local programming (by keyboard)  Communication to IRRInet/IRRInet XL via external radio

30 Water & Irrigation Control Solutions 30 Scorpio With External Radio  External 1-4 Watt conventional UHF / VHF radio  Two Scorpios can be connected with RS232 sharing one radio  Wall mount installation  Standard BNC connection for external antenna  Power source: 230V AC 115V AC 12V DC  Low power consumption

31 Water & Irrigation Control Solutions 31 Impact - Radio Valve  Operates one solenoid  Powered by 3 standard AA 1.5V batteries  Includes a built-in UHF/VHF radio receiver  Internal antenna  Avoids trenching and cables installation  Minimizes lightning damage risk
