1 Introduction Unit 1: Safety Unit 2: Introduction to Engines Unit 3: Experiencing Small Engines Modularly Unit 4: Introduction to Alternative Energy Unit 5: Experiencing Alternative Energy Modularly

2 The Portfolio There is no text book for this course. You will need a 2” binder to keep all of the handouts, assignments and course work. The portfolio will be collected periodically and evaluated as a part of your overall grade.

3 Power and Energy 3201 Unit 1 Safety

4 Every year more than 700 Canadians die in workplace accidents. Canada has twice as many workplace accidents as the UK, which has twice our population.

5 There are about 1 million 'mishaps' every year – half of them result in time lost from work

6 Treatment of occupational injuries costs about $1.2 billion /year Work related injuries cost the economy about $10 billion / year Research shows that most workplace accidents are predictable and preventable.

7 In 2001 in Canada: 18,505 workers between years of age lost time from work 57 workers between years of age died 44,394 workers between years of age lost time from work

8 Video: Young and new workers (5:41) Handout: Young and new Workers video sheet Video: Lost Youth

9 Safety must be a part of the shop culture. Everyone working in or visiting a shop environment has a responsibility to be constantly on guard, to identify actual and potential hazards, and to use personal protective equipment in the shop. Handout: Personal Conduct Sheet

10 Personal Rules of Conduct Wear all safety equipment No baggy clothing Proper footwear Use push-sticks Don’t remove safely guards No horseplay Keep work area clean No eating Extension cords stored neatly Tie back long hair Pay attention to work and surroundings Look out for your partner

11 Personal Rules of Conduct Read all safety warnings Follow all safety warnings Use appropriate materials and appropriate tools Keep tools in good shape Use good lighting Unplug tools when not in use Work in well ventilated areas Have a first aid kit and know how to address injuries Be aware of your personal condition Wear visible clothing Follow instructions

12 Activity: Safety Poster Design a poster for one of the safety rules discussed. -Do a rough draft first -Final draft should be on 11x17 paper -Colour

13 General Shop Rules Keep all hand tools clean and in good working condition. Report any defective tools, machines or other equipment to the instructor. Handout: Shop Safety Worksheet

14 General Shop Rules Always use a tool for the purpose it is intended. Report all accidents. Be neat and orderly.

15 Personal Safety Rules Wear appropriate clothing for the job.

16 Personal Safety Rules Practical jokes and fooling around is not permitted in the shop at anytime. Be certain to wash-up after you are finished.

17 Gasoline Safety

18 Handling Gasoline Handout: Handling Gasoline worksheet Gasoline contains many toxic chemicals that can be absorbed through the skin. Avoid breathing gasoline fumes.

19 Handling Gasoline Never use gasoline as a cleaning solvent. Vaporous gasoline is extremely flammable.

20 Gasoline spills must be cleaned up immediately and disposed of in proper containers. Handling Gasoline

21 Draining Gas Tank Gasoline must be stored in proper containers. Once the gas can is emptied, run hot steaming water in the can to remove vapors.

22 Quiz Quiz #1 Slides 1-22 Topics: -Young Workers Video -Personal Rules of Conduct -Shop Safety -Handling gasoline Just for Fun

23 Fire Safety

24 Handout: Fire Safety Worksheet

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48 Video: How Fires Extinguishers Work

49 Handout: Fire Extinguisher classification

50 Video: How Fires Extinguishers Work (2:55) Video: Fire Extinguisher – Fire safety Handout: Fire Extinguisher – Fire Safety Worksheet

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71 Video: Fire Safety (4 Mins)

72 JHA JOB Hazard Analysis JHA JOB Hazard Analysis

73 Definition handout: Job Hazard Analysis A hazard is anything (including work practices or procedures) that has the potential to harm the health or safety of a person. Hazards can arise from: –the workplace environment –the use of plant and substances –poor work design or practices –Inappropriate management systems and practices –Human behaviour

74 Job Hazard Analysis A job hazard analysis is an exercise in detective work. Your goal is to discover the following: –What can go wrong? –What are the consequences? –How could it arise? –What are other contributing factors? –How likely is it that the hazard will occur?

75 Common Hazards in the Workplace StressorHazard Type ChemicalCorrosiveFire Explosion Toxic ElectricalShockShort CircuitFire-Static MechanicalMoving Parts FailureNoise Pressure ErgonomicStrainHuman ErrorFatigue

76 Common Hazards in the Workplace StressorHazard Type Hazard Type RadiationIonizingNon Ionizing ContactStruck ByStruck Against Caught In EnvironmentTemp.VisibilityWeather Misc.SlipsTripsFalls

77 Radiation

78 Hazard Controls The are three methods to control Hazards. These should be done in the following order. 1. Engineering controls. 2. Administrative controls. 3. Personal protective equipment.

79 Engineering Controls Engineering controls include the following: –Substitution of equipment to decrease hazard –Isolation of the hazard with interlocks, machine guards, blast shields, etc –Removal the hazard such as with local and exhaust ventilation.

80 Administrative Controls Administrative controls include the following: –Written procedures, work permits, and safe work practices; –Exposure time limitations –Alarms, signs, and warnings –Buddy system; and training

81 PPE Personal Protective Equipment is acceptable as a control method in the following circumstances: –When engineering controls are not feasible –While engineering controls are being developed; –When safe work practices do not provide sufficient additional protection; and

82 PPE

83 Video: Job Hazard Analysis
