Gardena Specialized Processing Providing the highest quality metal finishing services for the aerospace industry for over 40 years.

Similar presentations


Presentation on theme: "Gardena Specialized Processing Providing the highest quality metal finishing services for the aerospace industry for over 40 years."— Presentation transcript:

1 Gardena Specialized Processing Providing the highest quality metal finishing services for the aerospace industry for over 40 years.

2 What We Do Anodize (Types I, II, III) – Tanks to 24’ – Dyeing & Teflon – Aluminum (MIL-A-8625 and many others) – Titanium (AMS 2487) Chem Film (MIL-DTL-5541) Passivate (ASTM A967, B318, QQ-P-35, AMS 2700) Electropolish (HP4-116) Brush Plating (Nickel and Cad) Prime/Bond Prime/Paint (MIL-PRF-23377, BMS 10-11, Solid Film Lube (MIL-L and 23398) Non Destructive Test – Penetrant (ASTM E1410, HP6-13) Glass Bead/Grit Blast

3 Finishing Parts For and many others….

4 Nadcap and ISO Accredited

5 Cover Plate - Type I (chromic acid) anodize, Class 2 (sky blue color)

6 R&D Project: Tesla Automotive Lettering - Type II (soft sulfuric acid) anodize, Class 2 (several different shades of grey)

7 Microphone Booms – Special Racking Hard Black Anodize LOX Tank Caps – Type II anodize, blue dye, chem film on threads.

8 Wear Shoe Bracket: Chem Film, Rack-Through-Masking Contact, Strip, Type III (Hard) Anodize, Black

9 Optical Housing – Chem Film, Mask, Epoxy Prime / Paint, Label, Unmask Valve Body – Chem Film, Mask, Type III Hard Anodize with Teflon

10 Helicopter Driveshaft Tool – Chem Film, Mask, Prime, and Paint

11 Housing: Chem Film, Mask, Strip, Anodize Type I (Chromic Acid)

12 Fuel Line Bracket – Chem Film II, Mask, Anodize (Type II, Class 2, Purple)

13 Gearbox Cover – Chem Film, Mask, Strip, Anodize (Type II, Class 1, Clear)

14 Bracket – Chem Film (RoHS), Mask, Anodize (Type II, Class 2, Black)

15 Desktop Logo – Type II (soft sulfuric) anodize, Class 2 (Spacex Blue)

16 Actuator – Chem Film (3) and Type II, Class 2, Yellow Anodize

17 LOX Fuel Coupling - Mask, Chem Film, Type II (soft sulfuric) Anodize, Blue Dye

18 Optical Housing – Global Hawk Drone - Chem Film, Mask, Type II (soft sulfuric) Anodize, Black Dye, Mask, Brush Nickel Plate

19 40” Tank Cover – Chem Film (1A) and Type II, Class 1 Anodize

20 2219 Aluminum Alloy Control Link Chem Film (Type I), Mask, Anodize, Type III, Teflon Impregnate

21 Clevis Pins – NDT (Liquid Penetrant Inspect) and Titanium Anodize

22 Housing – Chem Film (II – RoHS), Mask, Anodize, Type III, Teflon Impregnate

23 Embraer Foot Pedal Component – Chem Film, Mask, Hard Anodize

24 Cylinder Liner – Electropolish 316 SST to Remove.0001”

25 Housing Cover – Chem Film, Mask, Type III Anodize, Black, Unmask

26 Control Panel –Mask, Type II Anodize, Green, Mask, Type II Anodize Gold

27 EM Wave Guide - Chem Film, Mask, Epoxy Prime, Epoxy Paint

28 Rotor Blade Root Fittings – Clean, Liquid Penetrant Inspect, Bond Primer

29 Heat Sink – Clean, Chem Film, Mask, Type II Anodize, Black, Unmask

30 Wing Stiffeners – Liquid Penetrant Inspect, Chem Film, Chromate Primer

31 Electronic Enclosure – Chem Film, Mask, Anodize Type II, Class 2 Black

32 Main Rotor Blade Weight – Naval Brass – Clean and Bond Primer

33 Supercharger Blower – Blower Drive Sales – Mask, Type III Hard Ano

34 GE Tooling Fixture – Titanium Anodize

35 AIM 9 Missile Rails – Chem Film, Mask, Anodize Type II, Mask, Anodize Type III

36 Electronic Enclosure Heat Sink – Chem Film, Mask, Hard Ano (Black)

37 Missile Fin Actuator Shaft – Mask, Hard Ano, Ultrasonic Clean, Chem Film,

38 Falcon 9 Spacecraft Mating Flange – Chem Film, Mask, Ano Type II

39 Helicopter Rotor Blade Skins – Type I Chromic Anodize, Mask, Bonding Primer, Mask, Strip Chromic Anodize, Hard Anodize Leading Edge Strip
