1 SE Core Database Development Process
ITEC 2011 Make Clear: My pleasure to present the SE Core is an Army Program of Record. SE core does not generate requirements TCM-V is SE Core’s Combat Developer and I receive my requirements from TCM-V. Again, I am providing an Information Brief on SE Core, so you will know what we are doing. We are from PEO STRI, and work in the PM ConSim organization. Mark Johnson Strong Point Research Supporting PEOSTRI – SE Core Orlando, FL USA

2 Authors Robert Cox Connie Perry PEO STRI, PM CONSIM
Mark Johnson Strong Point Research Guillermo Flores Connie Perry PEO STRI, PM CONSIM Dolores Lowe Strong Point Research October 2010

3 SE Core Vision One fight involving multiple simulators, using one SAF, on a common terrain database, resulting in a fair fight environment. One fight involving multiple simulators, using one SAF, on a common terrain database, resulting in a fair fight environment. One simulator cannot have an inherent advantage over an other simulator and the SAF cannot have an advantage either. Cannot be unrealistic. Example – mismatch of ammunition capabilities, ranges not compatible with the weapon system, not being able to see through or fire through tree/buildings. This moves us forward in the ability to train soldiers within and across domains. SE Core is an enabler. The ITE cannot function without SE Core. That is why the program is so important. It is not just that SE Core will save the Army money, it is the enabling capability for training the soldiers. SE Core is going to provide a persistent training capability. Programs will be able to conduct interoperable training on a persistent and repeatable basis. Fort Benning to Fort Rucker, “ We are conducting a training exercise on Wednesday at 1500 using scenario XYZ (ver 1) on database 123 (ver 2). You want to play?”

4 CONSIM Strategic Priorities
Army Integrated Training Environment CCTT Manned Module Embedded OneSAF Entity AVCATT Manned Module Virtual Systems SE CORE Integration SE Core plays an important role in the ConsSim Strategic priorities as we move to the Integrated Training Environment. SE Core is a foundational element of the Integrating Architecture. Moving around the ITE graphic on the left, SE Core is meeting the needs of CCTT and AVCATT in order to make those sims interoperable. Both are already using SE Core terrain and models. Both are actively integrating OneSAF. SE Core provides terrain and models to many TADSS, both system and non-system TADSS, today. Programs such as the CFFT, CDT, COFT SA, and NCM3. The Centers of Excellence play an important role with SE Core. SMEs from the CoEs provide the detailed requirements to SE Core needed to meet training requirements. Training Areas are rendered in a higher fidelity than the rest of the TDB. This is the primary training areas used by the CCTT system. SE Core is working with HITS to adequately meet their needs to interact with the virtual systems. SE Core pays close attention to ranges. CCTT and AVCATT both conduct Unified Constructive Architecture “Supporting the Warfighter”

5 Challenges SE Core is Solving
Multiple types of terrain source data required to support training enterprise Terrain Database requirements for LVC Simulations varied & complex Source data provided is uncorrelated Correlation of source data is labor intensive SE Core has a process established to minimize correlation issues Use of approved standards for terrain data SE Core is standards based (ISO 191xx and ISO/IEC 180xx) SE Core uses industry standards (Shape Files, OpenFlight, etc) Most simulations utilize an application specific runtime database compiled and optimized for the target simulation SE Core provides not only industry standard formats, but runtime formats, too SE Core has developed interoperable databases between AVCATT and CCTT SE Core supports legacy IGs These bullets should look familiar to many. 1 – There are multiple types of source data needed to meet the needs of the training environment. 2 – Source data is not correlated . This continues to be labor intensive. Automated tools has only gotten us so far. 3 – Standards are used by SE Core. We don’t want to develop a unique format that limits the use of our data. 4 – the legacy systems use specific runtime databases. These sims are our primary target; however, we wanted our architecture to be robust enough to reuse what we process for many different simulators and simulations. They legacy systems are the toughest for us. We cannot degrade the current training capability yet we can’t use latest technology. Getting legacy systems ready for interoperability is a challenge. POINT IS SE Core IS MEETING THESE CHALLENGES.

6 Challenges SE Core is Solving
High Resolution Mission Rehearsal Terrain DBs with geo-specific structures and vegetation still require months to create SE Core has developed a process that reduces the time to create terrain databases SE Core has created a model library that is over 500 common moving models Lack of web-based repositories for users to share and re-use existing terrain databases SE Core is working with AMSO to share our products through their web resources SE Core is working with the USAF and Navy to exchange our data in common formats SE Core is entering into exchange agreements with Coalition Allies High resolution for Army Mission Rehearsal takes time. Define Mission Rehearsal: The definition of Mission Rehearsal for us is not the same for others. We are providing Terrain for use in collective simulators. A Rehearsal of a river crossing is different than mission rehearsal for a small special tactics unit. Our rehearsal areas are generally larger than a point target, we have over 500 moving models, but also a very large library of static models, but spo specific and geo typical. Sharing data through web-based repositories is a challenge . We are doing pretty well with sharing with hard drives. SE Core is sharing data with the Air Force and Navy. Moving into these agreements to take advantage of what they are doing. Lots of allies use our contractors and we want the goodness.

7 SE Core Strategy Effective solutions to terrain problems are complex and sometimes costly SE Core is a funded POR Leveraging industry solutions (market for capability) Leverage Service investments by entering into data sharing agreements Have establish requirements pedigree from TRADOC Capabilities Manager – Virtual (TCM-V) SE Core requirements set by out TCM-V TCM-V socialize with stakeholders Includes all requirements for LVC TCM-V is proponent and has established a solid resourcing stream New SE Core contract in source selection This is a complex problem. The Army recognize d this and funded a program to tackle these challenges. SE Core is meeting the requirements of Legacy Systems, and expanding to newer systems. SE Core is funded. We want to use industry solutions, but we also want to drive industry to meet our requirements. Two way street: We want to use other services, but we also want other services to use our products. But, we are learning how to be a good customer. We need to articulate what we need from other services. SE Core has a well defined requirement set. SE Core is now working with our second approval requirement document. TCM-V is my requirements provider. TCM-V gives SE Core the requirements.

8 SE Core Strategy (Continued)
Further resources coming as others embrace SE Core Programs Industry Services Be able to ingest data from in all common formats DTED, CIB, OpenFlight, IFSAR,VMAP, Buckeye, etc SE Core has a list of over 160 data products from a variety of data providers that are available for each database As other programs see the goodness of SE Core ,they have come with resources. We always, like programs who come with resources. Examples of programs coming to SE Core: CDT, CFFT, COFT SA, AGTS We use a good bit of different formats. I want to ingest data of all types rapidly. This is being a good customer to the data providers by telling them what we want from them.

9 SE Core Architecture Overview

10 SE Core Data Formats Program Needs Plug-in Subsystem Use Plug-in Status CCTT AVCATT LVC-IA CFFT LCT Gaming COFT-SA Stryker EPX 50 Image Generator P X OTF OneSAF CCTT PVD Plan View Display TIREM Radio Communications CIB Mission Planning Geo Database Electronic and Paper Map Environment Manager N/A CADRG / Digital Maps Electronic Maps(FBCB2/PFPS) Contour Line ShapeFile Industry Standard Format DTED CTDB SAF OpenFlight Typically Image Generation GRID ASCII Similar to DTED Auto Doc DB Design Doc SEDRIS Interchange Format SAGE S2 Focus Validation Quality Check FID View Working Constructive SAF (OneSAF/WARSIM) ITEMS VBS2 EP8000 AAcuity Future EP5000 MMRS Radar VRSG  X X-IG Vital 9 Aechelon Medallion Note: the programs listed are a sample and for instance CACCTUS uses OTF and thus can be supported) List of current output formats: Format / plug-in down the right Program used across the top Status in the middle = complete and in use Working = Someone has funded the effort and the development has began Future = Programs/people have expressed interest by no work is on delivery What kills me, changes without notification (OneSAF)

11 Database Request Process
Database is determined to be needed, the extents, priority, zones, and unique requirements are defined. Unique data such as navigational aids, new mobile mout sites (Ft Campbell) This is captured in our DBRR and this documents becomes the “Job Packet” for the TDB. It is our agreement with TCM-V Confederates are consulted on this, but this is a TCM-V SE Core agreement. The process on the previous slide. An important part. TDB is provided for integration by the programs. We still help in this. THIS PROCESS WORK TOO!

12 SE Core Tools Lots of tools in use today. Will share GPR tools. ESRI
QA Toolbar Conductor VAZER Google Earth Sync Tool Go Tos Create Buffers MADV Buffered Linears ESRI Conductor (in VAZER) MDB Exporter EDM ArcMap Plugin AOO Tool DVED Attribution Helpers Plugin Adaptive Build Fixer ArcSDE Sync CADRG Tool (Generator) MDB Importer CM2 CCDS Tool CM2 FID SMC Tool Reskeletor Multigen Creator MDB Admin Tool CM2 IR Poly Tool MDB Tools CM2 View Skeletor PVD Plug-in EDM Editor ERDAS EDM Tools Metadata Tool Validator Grid Ascii Plug-in Production Viewer Our tool set is made up of the usual tools used by almost all of VSE. Out of these tools we create many others tools. POINT OUT: VAZER Vector Analizer CADRG Tool Generator OpenFlight Plug-in* Shapefile Plug-in* DTED Plug-in * * THESE PRODUCE THE FORMATS USED BY SYSTEMS The Attributor AutoDoc Plug-in Environment Manager Plug-in Openflight Plug-in Radio Plug-in Shapefile Plug-in Terra Vista Defect KML Generator Photoshop Validation Plug-in SEDRIS Plug-in Supervisor GDB (AutoMap) Plug-in XML Plug-in Light Control EPX Plug-in CCDS Control Interface CTDB Plug-in On-demand Feature Integration Plug-in MDB Tools Terra Vista Plug-in DTED Plug-in Embankment Plug in CIB Plug-in EPX<-> Shape Converter Deterministic Scatter Plug-in 12 Task List

13 SE Core Tools From the toolbox we produce products used by various organizations Terrain Models From those created tools we support many organizations with Terrain, models, and Plug-ins. Plug-ins Industry Partners 13

14 SE Core Can Share Geo-Spatial Content at Various Levels of Fidelity
3D Scene Data: Existing MDB Database  Full MDB Geometry processing to Standard Format 3D Scene Data: New MDB Database  Full MDB Geometry processing to Standard Format Source Data: Existing MDB Database extraction to Standard Format Complex Production: Confederate Capability Analysis, Database Integration Simple Data: Existing Database Documentation Not all customer are equal. Some want a lot, some are happy with what you give them. Simple data / Documentation Refined Source Data = Existing TDB in the MDB with exiting plug-in. Extraction of standard format Full 3D geometry processing New MDB content required. Must go through steps shown earlier Complete production: Interop with legacy system Current support and future user trend is growing 14

15 Successes of SE Core Databases
SE Core has produced databases covering a larger area than those current CCTT terrain databases. These show legacy and new TDBs Yellow are TDB build by SE Core, but also a legacy TDB within CCTT. We are at least double the size of the TDBs POINT OUT: Hood, Riley, and Bliss Afgan East & Hawaii are Both New

16 Cost Effectiveness of SE Core Databases
SE Core databases produced at significant savings over legacy efforts (Normalized to a 100km x 100km area. ) The TDBs have been normalized to 100kwx100kw Not only are we making TDBs large, but also saving $s Not only saving $ per program, but Xs the number of programs using the TDB 16

17 SE Core Map Products JOG-A Map Sample SE Core DVED Map Types Comments
CIB 1meter, 5meter, 10meter available (Controlled Image Base) JOG A 1:250K (Joint Operations Graphic Aeronautical) TLM100 1:100K (Topographic Line Map) TLM50 1:50K (Topographic Line Map) CADRG Compressed ARC Digitized Raster Format Distribution Option Maps how exactly what is in the Simulation Database JOG-A Map Sample SE Core DVED

18 Common Moving Models Over 450 models produced, CAE led the SE Core CM2 architecture development Worked collaboratively to define and refine the CM2 modification and production processes supporting SE Core - programs such as CCTT, AVCATT, CDT, GCTT Blue Prints: Bliss SMEs TCM-V Blesses these models Different levels of fidelity Detect Indelity Recognize CM2 is a process to meet program requirements A participant and technology contributor to common sensor model capabilities for the U.S. Army Skilled in development and use of models for simulated sensor systems including infrared, RADAR, SONOR, and night vision

19 SE Core Terrain Database Production Plan
Future Terrain Database Production Order Ft Hood** Korea* Ft Campbell** FT Drum* FT Stewart** Ft Riley** Ft Carson** Ft Lewis/ Yakima* Ft Bragg* Germany* Ft Polk/ JRTC Ft Knox Ft Benning # Ft Bliss (BCT Mod) Already collecting data on all these locations. Paul Dillman collects specific data. Nav aids jump towers checker board water tower Helps to level on what you are building. * LVC ITE ** LVC ITE Update # Update (not LVCITE)

20 Path Forward Outward Focus Sharing Data Increased Fidelity
Increased capability to use of Imagery International distribution Compatibility with legacy systems Inward Focus Source data ingestion into the MDB More automation in TDB development Communication with programs Good Customers; Know what we need Know what you produce Help you help me!

21 How to Get SE Core Products
Databases Common Moving Models (CM2) Processed Data Software Distribution Agreement/Database Request Mr. Leonard Hobbs, Deputy APM Phone:

22 Don’t Be Left Out in the Cold
