1 Spyder® Introduction

2 2 Agenda Introductions Review Spyder Hardware, Software & Accessories Live Product Demonstration Spyder Tool - Physical Point Programming - Network Point Programming - Logic Programming - Simulation - Commissioning / Downloading / Alarms & Diagnostics Spyder Application Library - Library Migration Spyder Venom Tool

3 3 Best Practices ZIO review Multi-controller & Plant Applications VAV Balancing

4 4 Guy Zebrick Environmental Combustion and Controls division Sales Representative / Contractor Support Specialist 20+ Years Honeywell Branch Commercial Construction Technician Branch Project Manager Branch Application / Lead Application engineer Branch system sales Contractor Support / Product specialist

5 5 Spyder Controller Features Integrated Honeywell Actuator Reduce installation costs. AC synchronous actuator increases life of the controller and reduces life cycle costs Integrated On-board Precision Pressure Sensor Floating Actuator Housing Actuator can float inside housing to increase life due to damper shaft run-out Removable Terminal Blocks Hard to reach places are easy to deal with. Actuator De-Clutch Color Coded Inputs and Outputs Reduce wiring errors and speeds up troubleshooting. Programmable Whatever you need Spyder can be programmed to solve the problem. DC Power Supply Power external field devices without having to add additional power sources. Saves money and time. Network Jack and Service Pin Easy access network Jack and service pin for quick installation and easy service. Sylk Bus A two wire, polarity insensitive bus that provides both 18 Vdc power and communications between a Sylk-enabled sensor and a Sylk-enabled controller.

6 6 Fast Digital Pulse Meter One Universal Input (UI-1*) is user selectable as a fast digital Pulse Meter Pulse meter/Counter Input specification - Pulse input specifications: - Max. frequency: 15Hz (54,000 pulses per hour) - Min. pulse width: 20ms (debounced) - Max. chatter: 5ms

7 7 Spyder VAV Controller with Actuator Controller Model Programmable TypeProtocolUIDIAODO Velocity Pressure Sensor (Microbridge) Series 60 Floating Actuator PVB6436ASVAV BACnet MS/TP6436YES PVL0000ASVAVLonWorks0000YES PVL4022ASVAVLonWorks4a4a 022YES PVL6436ASVAVLonWorks6436YES 2 Digital Outputs reserved for Integrated Actuator Integrated Pressure Sensor

8 8 Spyder VAV Controller w/o Actuator Controller Model Programmable TypeProtocolUIDIAODO Velocity Pressure Sensor (Microbridge) Series 60 Floating Actuator PVB6438NSVAV BACnet MS/TP6438YESNO PVL4024NSVAVLonWorks4a4a 024YESNO PVL6438NSVAVLonWorks6438YESNO Integrated Pressure Sensor

9 9 Spyder Unitary Controller Controller Model Programmable TypeProtocolUIDIAODO Velocity Pressure Sensor (Microbridge) Series 60 Floating Actuator PUB6438SUnitary BACnet MS/TP6438NO PUL1012SUnitaryLonWorks1a1a 012NO PUL4024SUnitaryLonWorks4a4a 024NO PUL6438SUnitaryLonWorks6438NO Extended Temperature Rating

10 Programmable Unitary Control Programmable Unitary Controller Extended Temperature Rated -40° F (-40° C) to 150° F (65.5° C) Programmable Variable Air Volume Controller Integrated actuator Integrated on-board pressure sensor Programmable Variable Air Volume Controller Integrated on-board pressure sensor PUL1012S – LonWorks Inputs 1 universal input 0 digital inputs Outputs 1 analog output 2 digital outputs PUL4024S – LonWorks Inputs 4 universal inputs 0 digital inputs Outputs 2 analog outputs 4 digital outputs PUL6438S – LonWorks Inputs 6 universal inputs 4 digital inputs Outputs 3 analog outputs 8 digital outputs PUB6438S – BACnet Inputs 6 universal inputs 4 digital inputs Outputs 3 analog outputs 8 digital outputs PVL0000AS – LonWorks Inputs 0 universal inputs 0 digital inputs Outputs 0 analog outputs 0 digital outputs PVL4022AS – LonWorks Inputs 4 universal inputs 0 digital inputs Outputs 2 analog outputs 2 digital outputs PVL6436AS – LonWorks Inputs 6 universal inputs 4 digital inputs Outputs 3 analog outputs 6 digital outputs PVB6436AS – BACnet Inputs 6 universal inputs 4 digital inputs Outputs 3 analog outputs 6 digital outputs PVL4024NS – LonWorks Inputs 4 universal inputs 0 digital inputs Outputs 2 analog outputs 4 digital outputs PVL6438NS – LonWorks Inputs 6 universal inputs 4 digital inputs Outputs 3 analog outputs 8 digital outputs PVB6438NS – BACnet Inputs 6 universal inputs 4 digital inputs Outputs 3 analog outputs 8 digital outputs BACnet MS/TP LON Programmable Unitary Controllers Programmable VAV Controllers with Actuator Programmable VAV Controllers w/o Actuator

11 11 New Licensing Scheme The Spyder Tool checks the license for features - As of Spyder Tool 4.X and later There are two Spyder features - SpyderProgrammable for the Lon Spyders - SpyderBACnetProgrammable for the BACnet Spyders Spyder features are only available on WEBS branded JACEs and Supervisor Engineering Demos - W-ENG-AX-DEMO

12 12 Spyder-ILC The Spyder-ILC is an individually licensed controller - Spyder-ILC controllers will accept a download from the Spyder Tool regardless of the brand of workstation/JACE - In other words, features within the license are ignored The Spyder-ILCs have the same OS number with an -ILC suffix - Example: PUL6438S-ILC, PVB6436AS-ILC, PVL4022AS-ILC 20% adder per Spyder-ILC for licensing fee - No one else in the industry offers a programmable controller that can be programmed on ANY AX front end! Like all Spyders, the ILC can only be sold to Honeywell ACS or ACI contractors

13 13 Scenario – WEBS Brand JACE WEBS Brand Workbench WEBS Brand JACE Spyder Feature Honeywell Spyder 3 rd Party Brand Workbench WEBS Brand JACE Spyder Feature Honeywell Spyder

14 14 Scenario – WEBS OPEN Brand JACE WEBS OPEN Brand JACE Spyder Feature Honeywell Spyder Honeywell Spyder-ILC WEBS OPEN Brand JACE Spyder Feature ANY Brand Workbench Not Typical

15 15 Scenario – 3 rd Party JACE ANY Brand Workbench 3 rd Party Brand JACE Honeywell Spyder ANY Brand Workbench 3 rd Party Brand JACE Honeywell Spyder-ILC

16 16 Scenario – No JACE Honeywell Spyder ANY Brand Workbench 3 rd Party Brand Workbench Honeywell Spyder WEBS Brand Engineering Demo Supervisor Honeywell Spyder-ILC

17 17 Scenario – Existing Support Existing WEBS job needs to be expanded - 1. Keep existing workbench and tool; add Spyders as needed License change doesnt affect a job already installed - 2. Get new license with correct Spyder Features If using 403 or 545, the appropriate feature is needed Existing job with 3 rd party JACE and Spyders, needs to be expanded - 1. Keep existing workbench and tool; add Spyders as needed License change doesnt affect a job already installed - 2. Upgrade to latest Spyder Tool and use ILC to expand Previous Spyders must be brought in as 3 rd party devices and you wont be able to download to them

18 18 Freely Programmable Just determine your requirements, then program Spyder to control it all

19 19 Spyder Palette

20 20 Spyder Palette Simple program object palette Drag and drop program objects Simple wire tool to link program objects Object Macros available for easy organization of Control logic Everything you need to create an application in one place

21 21 Application Library

22 22 Application Library Place to store your applications, macros, and configured controllers Allows reuse of previous configured applications Simple drag and drop from Library Allows for easy import and export of control applications Where sample projects from Honeywell will be stored

23 23 Program Simulator and Debug Mode

24 24 Program Simulator and Debug Mode Allows simulation and testing of control programs Allows for easy point override Separate window for easy monitoring of points Sinusoidal forced inputs to simulate varying input ranges

25 25 Macros

26 26 Macros Allows easy grouping of common control functions - Mixed air sequence Can be nested for greater functionality Used to build larger applications Allows for a cleaner programming view and compartmentalization of applications Macros can only contain function blocks - No inputs or outputs - May use constants

27 27 Adaptive Integral Algorithm Honeywells Adaptive Integral Algorithm (AIA) Control is the most accurate control available for space control applications

28 28 Model Numbers P V L A S P – Programmable U – Unitary V – VAV L – LON B – BACnet Number of Universal Inputs Number of available Digital Outputs A – With Actuator N – Without Actuator Number of Digital Inputs Number of Analog Outputs S – Sylk Bus

29 29 Spyder Lon Specific Details Free Topology Transceiver (FTT) - High-speed 78 kilobit communications network Function Blocks Function Blocks max per controller Lon Network Variables total NVs per controller 20 Mandatory NVs 7 Fixed NVs 213 User Defined NVs Support for up to 120 controllers per LonWorks channel

30 30 Spyder BACnet Specific Details BACnet MS/TP LAN communication network - Capable of baud rates between 9.6 and kilobits BTL B-ASC - BACnet Testing Laboratories B-ASC (BACnet Application Specific Controller) - Certification Testing in process BACnet PICS (Protocol Implementation Conformance Statement) - Refer to the PICS for information on: BIBBs – BACnet Interoperability Building Blocks BACnet Device Objects Support for up to 30 controllers per BACnet MS/TP LAN Segment

31 31 Spyder FAQs Should I use a Spyder if the current XL10 meets the sequence or requirements? Do you want to order the Spyder with Actuator when you need to separate the actuator and controller? - What Actuators are recommended for use with the Spyder VAV controllers without Actuators? Depends on application NO ML6161, ML6174, MN6105

32 32 WEB-600 SEC-H-600 Security Elevator Control Access Control Time and Attendance Intrusion Keypad/Display Lighting Control WEB Browser WEB Station 34 pt I/O Video Monitoring and Control RS-485 UV WEB-600 CVAHU Spyder Lon Spyder BACnet HTTP, XML, BACnet, SNMP, oBIX T7350 Architecture Internet

33 33 Architecture Guidelines How many Spyder Controllers per JACE - WEB – Max - WEB – 403 Expanded Memory 60 without router 100 with router - WEB – 545 Standard 25 Max - WEB – 545 Expanded Memory 60 without router 100 with router - WEB – without router 100 with router

34 34 Sylk Bus Sylk is a two wire, polarity insensitive bus that provides both 18 Vdc power and communications between a Sylk-enabled sensor and a Sylk-enabled controller Devices - Zio LCD Wall Module TR70 TR70-H Future - TR20 Series - Sylk IO Addressing the combined needs of the Building Automation and Field Device team

35 35 TR20 Series Wireless Overview Point to Point - Direct replacement for a wired sensor - Can be used with Spyder, XL10, T7350 thermostats, SuitePRO - Not compatible with Commercial VisionPRO & CommercialPRO thermostats Two Sensor options - With temperature only TR21-WK kit or TR21-WS sensor only - With temperature, setpoint knob, and override button TR23-WK kit or TR23-WS sensor only On board signal strength indicator - No need for diagnostic tool Beta in progress – Thank You! Receiver Wireless sensor Replace a wired sensor, without the wires!

36 36 Noteworthy Installations Prairie View School District, Saskatchewan

37 37 Noteworthy Installations Target Field (Twins Stadium) - Minneapolis

38 38 Noteworthy Installations ACS Headquarters – Golden Valley

39 39 Noteworthy Installations Adelphia Labs, New Jersey

40 40 Noteworthy Installations Vectura Pharmaceutical, United Kingdom

41 41 Noteworthy Installations Claridges Hotel, Delhi
