1 REAL-TIME INFORMATION SYSTEMS FOR CONTROL CENTERS Illustrations of company software products installations

2 INSTALLATIONS GEOGRAPHY AND STATISTICS

3 Unified Dispatch Office Middle Volga Automated dispatch control system Software products: Operational and informational software complex CK-2007 Process Dynamic Projection - PDP Electronic LogBook Hedgehog-2 Unified Dispatch Office Middle Volga Control Center INSTALLATIONS PROJECTS ILLUSTRATIONS SYSTEM OPERATOR

4 RUE UDO of Belarus Operator training simulator Automated dispatch control system Software products: Operator training simulator FINIST Operational and informational complex CK-2007 Control room Training room INSTALLATIONS PROJECTS ILLUSTRATIONS REPUBLICAN UNITARY ENTERPRISE UNIFIED DISPATCH OFFICE OF BELARUS INSTALLATIONS PROJECTS ILLUSTRATIONS REPUBLICAN UNITARY ENTERPRISE UNIFIED DISPATCH OFFICE OF BELARUS

5 Staff Training Center SO UPS Operator training simulator Software products: Operator training simulator FINIST Operational and informational complex CK (training version) Staff Training Center SO UPS INSTALLATIONS PROJECTS ILLUSTRATIONS SYSTEM OPERATOR

6 Southern Generating Company Territorial Generating Company No.8 (LUKOIL) Supervisory control and communications system of the companys 20 electric power plants Software products: Operational and informational complex CK-2007 Electronic LogBook Hedgehog-2 Камышинская ТЭЦ Kislovodsk TPP Krasnodar TPP INSTALLATIONS PROJECTS ILLUSTRATIONS POWER GENERATION

7 Rosenergoatom Concern Consolidating control systems in the Crisis Center and in the Center of Commercial Dispatch Supervisory control and communications system of the companys 9 electric power plants Software products: Operational and informational complex CK-2007 Electronic LogBook Hedgehog-2 Center of Commercial Dispatch INSTALLATIONS PROJECTS ILLUSTRATIONS POWER GENERATION

8 Territorial Generating Company No.1 Automated consolidating systems of control centers in three branches Automated mode monitoring systems of 6 electric power plants and a hydroelectric power chain (installation is to be accomplished in 2011) Software products: Operational and informational complex CK-2007 Electronic LogBook Hedgehog-2 TGK-1 Control Center INSTALLATIONS PROJECTS ILLUSTRATIONS POWER GENERATION

9 Interregional Distribution Grid Company of the South, Rostovenergo Automated dispatch control system Software products: Operational and informational complex CK-2003 (transition to CK-2007 is planned to be made in 2011) Electronic LogBook Hedgehog-2 Control room Rostovenergo INSTALLATIONS PROJECTS ILLUSTRATIONS TRANSMISSION AND DISTRIBUTION

10 Interregional Distribution Grid Company of Volga Chuvashenergo Automated system of dispatch and process control of the Northern Production Group Software products: Operational and informational complex CK-2003 (transition to CK-2007 is planned to be made in 2012) Control room Chuvashenergo INSTALLATIONS PROJECTS ILLUSTRATIONS TRANSMISSION AND DISTRIBUTION

11 Tyumen Electricity Sale Company Process monitoring and sales automation system Software products: Operational and informational complex CK System display fragment INSTALLATIONS PROJECTS ILLUSTRATIONS POWER SUPPLY

12 SO UPS Unified Dispatch Office South Automated control of engineering systems Software products: Operational and informational complex CK-2007 Engineering systems Control center INSTALLATIONS PROJECTS ILLUSTRATIONS ENGINEERING SYSTEMS

13 Monitor Electric Engineering systems control and fence intruder detection automated system Software products: Operational and informational complex CK-2007 Guard post INSTALLATIONS PROJECTS ILLUSTRATIONS ENGINEERING SYSTEMS

14 14 Information here is presented for your guidance. We took measures to make sure that all presented data and materials are accurate, current and complete. Monitor Electric is not liable for inaccuracies, errors or other flaws in the posted information. Nor is it liable for any damage arising out of the use of the presented information or materials. Monitor Electric has the right to change contents of this presentation without prior notice. We will be glad to get your comments and suggestions. For any additional information please contact us. © Monitor Electric JSC. All rights reserved. Products and company names, mentioned here, may be registered trademarks of their respective owners. Monitor Electric Joint-stock Company (Monitor Electric JSC) 28 Podstantsionnaya St., Pyatigorsk, Russia tel.: +7 (495) (8793) fax: +7 (8793)
