1 Mechanical heart valves and Anticoagulation Dr. Alkesh ZALA Basic Physician trainee, Dept. of Cardiology, John Hunter hospital.

2 Case review Case review The currently Available and most commonly Used mechanical prostheses. The currently Available and most commonly Used mechanical prostheses. What determines the Choice of valves? What determines the Choice of valves? Risk of Valve Thrombosis WITHOUT Anticoagulation Risk of Valve Thrombosis WITHOUT Anticoagulation What are the INR Targets for these valves? What are the INR Targets for these valves? Are the New Generation Valves Really LESS THORMBOGENIC? Are the New Generation Valves Really LESS THORMBOGENIC? Todays discussion:

3

4 75 year old lady with subdural bleed On warfarin for st. Judes bileaflet AVR alond with Bentall procedure in – Embolic vertebrobassilar embolic stroke – Valve blammed THOUGH INR 3.2 Aspirin added and INR target now INR within target range on presentation Surgical drainage on presentation day 4 Heparin infusion on day 5 & Warfarin recommenced on regular dose on day 7 – TOO EARLY? CASE

5 Day 9 – increasingly confused with headache. Repeat CT – Acute subdural with midline shift Urgent surgical drainage Repeat CT on day13 – subdural stable. No focal Neurological deficit Heparin started Cardiology involved with regards to anticoagulation advise Summary: Elderly lady with st. Judes bileaflet valve along with Bentalls procedure. Prior probable embolic stroke related to the Mechanical valve Risk of valve thrombosis Vs Serious risk of intracranial bleeding

6 Weighing the risk of valve thormbosis and serious significant risk of recurrence of the intracranial bleed: - Go OFF anticoagulation for 1-2 weeks. - Warfarin restarted next week Uneventful recovery without any further complications. Gamble - Turns Out To Be a Winner Or A rational evidence based decision

7 Unidirectional flow Durable : 40million cycles/year Blood compatible: no thrombus, embolus Central flow: Laminar not turbulent Closing not damaging blood cells Last but not the least important – It should be quiet An ideal Prosthetic valve

8 The development of the original ball- and-cage valve design can be attributed to the bottle stopper in 1858 In the early 1950s, it led to the idea of a prosthetic heart valve consisting of a cage with a mobile spherical poppet First implanted in a human in a closed procedure in September of In 1953, marked successful use of the heart and lung machine, paving the way for the 1 st open heart operations Evolution of Prosthetic Heart Valves

9 Early valves In the 1960s, the Starr–Edwards ball-and-cage mechanical prosthesis became the standard replacement valve for nearly a decade. The tilting disc valve became more widely used in the 1970s to overcome some of the inherent problems of the ball-and-cage model. Both of these designs, however, were plagued by hemodynamic limitations and thromboembolic complications. In the 1980s, the St. Jude Medical bileaflet prosthesis supplanted the earlier devices as the most commonly implanted prosthetic heart valve. Since then, additional bileaflet devices with numerous design modifications have been developed and continue to be used today.

10 Different types of prosthetic valves. A, Bileaflet mechanical valve (St. Jude Medical). B, Monoleaflet mechanical valve (Medtronic- Hall). C, Caged ball valve (Starr-Edwards,). D, Stented porcine bioprosthesis (Medtronic Mosaic). E, Stented pericardial bioprosthesis (Carpentier-Edwards Magna). F, Stentless porcine bioprosthesis (Medtronic Freestyle). G, Transcatheter bioprosthesis expanded over a balloon (Edwards SAPIEN). H, Self-expandable percutaneous bioprosthesis (CoreValve,)edtronic).

11 Two semicircular leaflets that rotate about struts attached to the valve housing Good hemodynamic performance - improved flow characteristics, lower transvalvular pressure gradients, less blood flow turbulence, improved hemodynamics at a given annular diameter, a larger orifice area and low bulk and flat profile the least thrombogenic of the artificial valves most commonly implanted mechanical valves Bileaflet valves

12 FDA-approved prosthetic heart valves

13 Haemodynamics of blood flow

14 However, inspite of improved design and haemodynamics – still haunted by numerous complications and the most dreaded one of valve thrombosis

15 Developed primarily to overcome the risk of thromboembolism that is inherent in all mechanical prosthetic valves Major problem – DURABILITY. Cuspal tears, degeneration, fibrin deposition, perforation, fibrosis, and calcification. Rate of tissue failure – by 10 years 30% and upto 60% by 15 years. Why not always use a Bioprosthetic valve !!

16

17 Major task is to weigh the advantage of durability and the disadvantages of the risks of thromboembolism and anticoagulant treatment inherent with mechanical valves The next step is to choose a prosthesis model that provides superior hemodynamic performance to prevent prosthesis-patient mismatch (PPM) and thereby minimize postoperative trans-prosthetic gradients. Choice of Valves

18 Criteria for selection of an aortic valve in patients undergoing aortic valve replacement (AVR) ACC/AHA guideline Data from Bonow, RO, Carabello, BA, Chatterjee, K, et al. ACC/AHA 2006 guidelines for the management of patients with valvular heart disease. A report of the Force on Practice Guidelines (Writing committee to revise the 1998 guidelines for thAmerican College of Cardiology/American Heart Association Task e management of patients with valvular heart disease). J Am Coll Cardiol 2006; 48:e1. Class I - There is evidence and/or general agreement for the choice of a mechanical or bio- prosthetic valve in patients undergoing AVR in the following settings A mechanical valve in patients who already have a mechanical valve in the mitral or tricuspid position. A bioprosthetic valve in patients who will not take or are incapable of taking warfarin or have a major contraindication to warfarin therapy. Class IIa - The weight of evidence or opinion is in favor of the choice of a mechanical or bioprosthetic valve in patients undergoing AVR in the following settings A bioprosthesis in patients 65 years of age who do not have risk factors for thromboembolism. Patient preference can be considered in patients less than 65 years of age: 1. A mechanical valve is reasonable in patients who do not have a contraindication to warfarin therapy. 2. A bioprosthetic valve may be chosen after a detailed discussion of the risks of warfarin therapy compared to the likelihood of repeat valve replacement in the future. A homograft when aortic valve re-replacement is performed for active prosthetic valve endocarditis. Class IIb - The weight of evidence or opinion is less well established for the choice of a mechanical or bioprosthetic valve in patients undergoing AVR in the following setting A bioprosthesis in women of child-bearing age to avoid the problems associated anticoagulation during pregnancy.

19 Criteria for selection of an Mitral valve in patients undergoing Mitral valve replacement (MVR) ACC/AHA guideline Data from Bonow, RO, Carabello, BA, Chatterjee, K, et al. ACC/AHA 2006 guidelines for the management of patients with valvular heart disease. A report of the Force on Practice Guidelines (Writing committee to revise the 1998 guidelines for thAmerican College of Cardiology/American Heart Association Task e management of patients with valvular heart disease). J Am Coll Cardiol 2006; 48:e1. Class I - There is evidence and/or general agreement for the choice of a mechanical or bioprosthetic valve in patients undergoing MVR in the following settings A bioprosthetic valve in patients who will not take or are incapable of taking warfarin or have a major contraindication to warfarin therapy. Class IIa - The weight of evidence or opinion is in favor of the choice of a mechanical or bioprosthetic valve in patients undergoing MVR in the following settings A bioprosthesis in patients 65 years of age who do not have risk factors for thromboembolism. Among patients < 65 years of age 1.Mechanical valve in patients with long standing Atrial fibrillation 2.A bioprosthetic valve may be chosen in patients in sinus rhythm who elect this for lifestyle considerations after a detailed discussion of the risks of warfarin therapy compared to the likelihood of repeat MVR in the future

20 Patient tailored prosthesis

21 Mechanical valves represent about 5 – 10% of total valve replacement ? Reason Preferred mechanical valve – Bileaflet valve Mechanical valves – Mitral > Aortic (However, Repair preferred over Replacement) Apart from co-morbidities and Patient preference AVR- Age 60 MVR – Age 70 JHH Choice Courtesy: Dr. Taranpreet Singh Cardiothoracic surgeon, John Hunter Hospital

22 Mechanical prostheses remains burdened with the risk of thrombosis – potentially fatal Valve thrombosis is any thrombus in the absence of infection attached to or near an operated valve that occludes part of the blood flow path or that interferes with the function of the valve. Risk factors: inadequate or discontinued anticoagulant therapy previous endocarditis the prosthetic valve model used LV dysfunction, LA dilatation Hypercoagulable states Thrombosis with Mechanical valve

23 Low: St Jude Medical, On-X, Carbomedics, Medtronic Hall; Medium: bileaflet valves with insufficient data, Bjork- Shiley; High: Lillehei-Kaster, Omniscience, Starr-Edwards. Philippe PibarotPhilippe Pibarot, P. et al, Selection of the Optimal Prosthesis and Long-Term Management. Circulation. 2009; 119: Prosthesis Thrombogenicity

24 In absence of anticoagulation: 8.6 per 100 patient- years. With anticoagulation: risk is reduced to 1% to 3% per year. Valve thrombosis is increased with valves in the mitral position. Highest in the Tricuspid position. ?? Rate with remote valves Ref: Hurst's the Heart, 12th Edition Rate of thrombosis

25 ACC/AHA guideline summary: Treatment of prosthetic heart valve thrombosis Bonow, RO, Carabello, BA, Chatterjee, K, et al. ACC/AHA 2006 guidelines for the management of patients with valvular heart disease. A report of the American College of Cardiology/American Heart Association Task Force on Practice Guidelines (Writing committee to revise the 1998 guidelines for the management of patients with valvular heart disease). J Am Coll Cardiol 2006; 48:e1. Class IIa - The weight of evidence or opinion is in favor of the usefulness of the following modalities in patients with prosthetic heart valve thrombosis Emergency surgery for thrombosis in a left-sided prosthetic heart valve in patients with New York Heart Association (NYHA) class III-IV symptoms. Emergency surgery for thrombosis in a left-sided prosthetic heart valve with a large clot burden. Fibrinolytic therapy for thrombosis in a right-sided prosthetic heart valve in patients with New York Heart Association (NYHA) class III-IV symptoms and/or a large clot burden. Class IIb - The weight of evidence or opinion is less well established for the usefulness of the following modalities in patients with prosthetic heart valve thrombosis Fibrinolytic therapy as a first-line approach for thrombosis in a left-sided prosthetic heart valve in patients with NYHA class I-II symptoms and a small clot burden. If surgery is either high risk or not available: 1. Fibrinolytic therapy as a first-line approach for thrombosis in a left-sided prosthetic heart valve in patients with NYHA class III-IV symptoms and a small clot burden. 2. Fibrinolytic therapy in patients with an obstructed, thrombosed left-sided prosthetic heart valve, class II-IV symptoms and, a large clot burden. Unfractionated heparin as an alternative to fibrinolytic therapy in patients with NYHA class I-II symptoms and a small clot burden.

26

27 ACC/AHA guideline summary: Antithrombotic therapy in patients with mechanical heart valves Anticoagulation guidelines Bonow RO, Carabello BA, Chatterjee K, et al Focused update incorporated into the ACC/AHA 2006 guidelines for the management of patients with valvular heart disease. A report of the American College of Cardiology/American Heart Association Task Force on Practice Guidelines (Writing committee to revise the 1998 guidelines for the management of patients with valvular heart disease). Circulation 2008; 118:e523. Class I - There is evidence and/or general agreement that antithrombotic therapy is indicated in patients with mechanical heart valves in the following settings: Warfarin to achieve a goal INR of 2.0 to 3.0 after: 1. Aortic valve replacement (AVR) with bileaflet mechanical or Medtronic Hall valves if no risk factors* are present. Warfarin to achieve a goal INR of 2.5 to 3.5 after: 1. AVR with bileaflet mechanical or Medtronic Hall valves if risk factors* are present. 2. AVR with Starr-Edwards or disc valves other than Medtronic Hall if no risk factors* are present. 3. Mitral valve replacement (MVR) with any mechanical valve. Role of aspirin: 1. After AVR or MVR in patients who cannot take warfarin, at a dose of 75 to 325 mg/day. 2. At a dose of 75 to 100 mg/day in addition to warfarin in all patients with mechanical valves and in patients with biological valves who have risk factors*. Class IIa - The weight of evidence or opinion is in favor of the usefulness of antithrombotic therapy in patients with mechanical heart valves in the following setting: In the first three months after AVR, warfarin to achieve a goal INR of 2.5 to 3.5. Class IIb - The weight of evidence or opinion is less well established for the usefulness of antithrombotic therapy in patients with mechanical heart valves in the following setting: In high-risk patients in whom aspirin cannot be used, clopidogrel (75 mg/day) or warfarin to attain a goal INR of 3.5 to 4.5.

28 European College of Cardiology guideline Butchart, EG, Gohlke-Barwolf, C, Antunes, MJ, et al. Recommendations for the management of patients after heart valve surgery. Eur Heart J 2005; 26:2463. General principles Thromboembolic risk is related to two factors: Thrombogenicity of the mechanical valve 1.Low - Medtronic Hall, St Jude Medical (without Silzone), CarboMedics AVR 2.Medium - Bileaflet valves with insufficient data, Bjork-Shiley 3.High - Lillehei Kaster, Omniscience, Starr Edwards Presence or absence of risk factors: atrial fibrillation, left atrial dimension >50 mm, mitral valve gradient, left ventricular ejection fraction <35 percent, spontaneous echo contrast, mitral, tricuspid, or pulmonary valve replacement, or a hypercoagulable state. Recommendations for anticoagulation Until the INR is stable, intravenous unfractionated heparin (to achieve an activated partial thromboplastin time of 1.5 to 2.0) is probably safer than subcutaneous unfractionated heparin or low molecular weight heparin which, is used, should be accompanied by anti-factor XA monitoring, particularly in patients with renal failure or obesity. For low thrombogenicity valves, warfarin (or other vitamin K antagonist) to achieve a goal INR of 2.5 if no risk factors and 3.0 if risk factors. For medium thrombogenicity valves, warfarin (or other vitamin K antagonist) to achieve a goal INR of 3.0 if no risk factors and 3.5 if risk factors. For high thrombogenicity valves, warfarin (or other vitamin K antagonist) to achieve a goal INR of 3.5 if no risk factors and 4.0 if risk factors. Addition of antiplatelet therapy Relative indications 1.Concurrent arterial disease 2.Coronary artery stenting 3.Recurrent embolism, but only after treatment of risk factors and optimization of anticoagulation fail to abolish the problem 4.4. With caged ball valves, with dipyridamole being preferred to aspirin Relative contraindications 1.History of gastrointestinal bleeding, particularly associated with ulcer disease or angiodysplasia. 2.Hyperresponders to aspirin, with excessively prolonged bleeding time. 3.Poorly controlled hypertension, because of the risk of intracerebral hemorrhage. 4.Elderly patients, particularly women over age Patients who take multiple medications, require frequent courses of antibiotics, or have erratic INR control.

29 The AREVA trial compared moderate anticoagulation (INR 2.0–3.0) to the usual regimen of INR 3.0–4.5. A similar risk in thromboembolic events was found in both arms, whereas the bleeding risk was higher in the high intensity group Acar J, Iung B, Boissel JP et al. AREVA. Multicenter randomized trial comparison of low-dose versus standard-dose anticoagulation in patients with mechanical prosthetic heart valves. Circulation 1996; 94:

30 International Normalized Ratio (INR)–specific incidence of all adverse events in patients with mechanical valves (all episodes of thromboembolism, all major bleeding episodes, and unclassified stroke) according to INR (A). The dotted lines represent the 95% confidence interval and according to INR, age, and position of valve (B). Incidence of thromboembolic events according to INR and patient age (upper graph) or prosthesis position (lower graph). S.C. Cannegieter, F.R. Rosendaal, A.R. Wintzen, F.J.M. van der Meer, J.P. Vandenbroucke, and E. Briet N Engl J Med 1995; 333:11-17July 6, 1995July 6, 1995

31 LOWERING-IT trial established that the proposed LOW-INR target is safe and feasible in low-risk patients after bileaflet aortic mechanical valve replacement. prospective open-label, single-center, randomized controlled trial: age 20 to 60 years, a single-valve replacement with a bileaflet valve in the aortic position Low risk 396 patients: 197 in low INR ( ) AND 199 in standard INR group (2.0 – 3.0). Results - similar thrombotic events and a significant reduction of bleeding occurrence in the low INR group Torella, M. Torella, D. LOWERing the INtensity of oral anticoaGulant Therapy in patients with bileaflet mechanical aortic valve replacement: Results from the LOWERING-IT Trial. American heart Journal – Volume 160, Issue 1 (July 2010)

32

33 All Mechanical valves models are vulnerable to thrombus formation due to high shear stress, stagnation, and flow separation. The quest to find a less thormbogenic valve was one of the prime driving force in the development of the newer heart valves Less thrombogenic materials and an improved valve and hinge design has reduced the propensity for thrombus formation and the need for aggressive anticoagulation. Are new generation valves really less thrombogenic?

34 A meta-analysis of 46 trial - a higher risk of embolic complications in patients with a caged-ball valve. The incidence of total thromboembolism was 30% lower for patients with a tilting disk valve, and 50% lower for patients with a bileaflet valve. Cannegieter SC, Rosendaal FR, Torn M. Oral anticoagulant treatment in patients with mechanical heart valves: how to reduce the risk of thromboembolic and bleeding complications. Journal of Internal Medicine,Volume 245, Issue 4, pages 369–374, April 1999Volume 245, Issue 4,

35 In the cohort study of 1608 patients with mechanical heart valves: a clearly higher risk of thromboembolism in patients with caged-ball valves. An incidence of 0.5 per 100 patient-years was found for the bileaflet valves, of 0.7 per 100 patient-years for the tilting disk valves, and of 2.5 per 100 patient-years for the caged-ball valves Cannegieter SC, Rosendaal FR, Wintzen AR, Van Der Meer Fjm, Vandenbroucke JP, Briët E. Optimal oral anticoagulant therapy in patients with mechanical heart valves. N Engl J Med 1995; 333:

36 Which valves are less thormobogenic and safe to be managed with lower INR targets?? Guideline

37 Eight Commandments: Embolism Prevention Durability Ease and Security of Attachment Preservation of Surrounding Tissue Function Reduction of Turbulance Reduction of Blood Trauma Reduction of Noise Use of Materials Compatible with Blood The quest continues…

38 Acar J, Iung B, Boissel JP et al. AREVA. Multicenter randomized trial comparison of low-dose versus standard-dose anticoagulation in patients with mechanical prosthetic heart valves. Circulation 1996; 94: Bonow, RO, Carabello, BA, Chatterjee, K, et al. ACC/AHA 2006 guidelines for the management of patients with valvular heart disease. A report of the American College of Cardiology/American Heart Association Task Force on Practice Guidelines (Writing committee to revise the 1998 guidelines for the management of patients with valvular heart disease). J Am Coll Cardiol 2006; 48:e1. Braunwald's Heart Disease - A Textbook of Cardiovascular Medicine, 9th ed. Cannegieter SC, Rosendaal FR, Wintzen AR, Van Der Meer Fjm, Vandenbroucke JP, Briët E. Optimal oral anticoagulant therapy in patients with mechanical heart valves. N Engl J Med 1995; 333: Cannegieter SC, Rosendaal FR, Wintzen AR, Van Der Meer Fjm, Vandenbroucke JP, Briët E. Optimal oral anticoagulant therapy in patients with mechanical heart valves. N Engl J Med 1995; 333: Hurst's the Heart, 12th Edition Torella, M. Torella, D. LOWERing the INtensity of oral anticoaGulant Therapy in patients with bileaflet mechanical aortic valve replacement: Results from the LOWERING-IT Trial. American heart Journal – Volume 160, Issue 1 (July 2010) Uptodate References

39 Questions?
