1 P2.2.2 Momentum P2 Physics P2.2.2 Momentum P2 Physics Mr D Powell

2 Mr Powell 2012 Index Connection Connect your learning to the content of the lesson Share the process by which the learning will actually take place Explore the outcomes of the learning, emphasising why this will be beneficial for the learner Connection Connect your learning to the content of the lesson Share the process by which the learning will actually take place Explore the outcomes of the learning, emphasising why this will be beneficial for the learner Demonstration Use formative feedback – Assessment for Learning Vary the groupings within the classroom for the purpose of learning – individual; pair; group/team; friendship; teacher selected; single sex; mixed sex Offer different ways for the students to demonstrate their understanding Allow the students to show off their learning Demonstration Use formative feedback – Assessment for Learning Vary the groupings within the classroom for the purpose of learning – individual; pair; group/team; friendship; teacher selected; single sex; mixed sex Offer different ways for the students to demonstrate their understanding Allow the students to show off their learning Activation Construct problem-solving challenges for the students Use a multi-sensory approach – VAK Promote a language of learning to enable the students to talk about their progress or obstacles to it Learning as an active process, so the students arent passive receptors Activation Construct problem-solving challenges for the students Use a multi-sensory approach – VAK Promote a language of learning to enable the students to talk about their progress or obstacles to it Learning as an active process, so the students arent passive receptors Consolidation Structure active reflection on the lesson content and the process of learning Seek transfer between subjects Review the learning from this lesson and preview the learning for the next Promote ways in which the students will remember A news broadcast approach to learning Consolidation Structure active reflection on the lesson content and the process of learning Seek transfer between subjects Review the learning from this lesson and preview the learning for the next Promote ways in which the students will remember A news broadcast approach to learning

3

4 Mr Powell 2012 Index P2.2.2 Momentum a)Momentum is a property of moving objects. p = m x v a)In a closed system the total momentum before an event is equal to the total momentum after the event. This is called conservation of momentum. p is momentum in kilograms metres per second, kg m/s m is the mass in kilograms, kg v is the velocity in metres per second, m/s Candidates may be required to complete calculations involving two objects. Examples of events are collisions and explosions. a)Momentum is a property of moving objects. p = m x v a)In a closed system the total momentum before an event is equal to the total momentum after the event. This is called conservation of momentum. p is momentum in kilograms metres per second, kg m/s m is the mass in kilograms, kg v is the velocity in metres per second, m/s Candidates may be required to complete calculations involving two objects. Examples of events are collisions and explosions.

5 Mr Powell 2012 Index Practical / Demo Suggested ideas for practical/demonstrations to develop skills and understanding include the following: investigating the transfer of Ep to Ek by dropping a card through a light gate. plan and carry out an investigation to measure velocity using trolleys and ramps. running upstairs and calculating work done and power, lifting weights to measure power. a motor lifting a load to show how power changes with load. stretching different materials before using as catapults to show the different amounts of energy transferred, indicated by speed reached by the object or distance travelled.

6 Mr Powell 2012 Index Momentum Defined Momentum is important to anyone who plays a contact sport. In a game of rugby, a player with a lot of momentum is very difficult to stop. The momentum of a moving object = its mass x velocity. momentum = mv The unit of momentum is the kilogram meter/second (kg m/s). a)Calculate the momentum of a 40 kg person running at 6 m/s. b)Calculate the momentum of a 80 kg person running at 3 m/s. c)Calculate the velocity of a 80 kg bike with momentum of 2kg m/s. d)Calculate the mass of a person with momentum of 2kg m/s and velocity of 0.02 m/s a)240kg m/s b)240kg m/s c)0.025m/s d)100kg a)240kg m/s b)240kg m/s c)0.025m/s d)100kg

7 Mr Powell 2012 Index Investigating Momentum Simply... Using only your fingers, a few similar coins, the desk, a stopclock and ruler can you explore the concept of momentum and come up with any rules of thumb or prove the formulae. The momentum of a moving object = its mass x velocity p = mv You could investigate? Distance of travel Mass moved Flick strength Time of travel Average Speed /Velocity 1.Pick a variable to keep the same 2.Pick a variable to change 3.Make a table 4.Record your results 5.Make a comment

8 Mr Powell 2012 Index Results Number of Coins Distance Travelled in m 10.45 20.24 30.16 40.14 50.09 These results broadly show that if we double the mass of the object the distance travelled by the object for the same flick halves. Hence if we doubled the flick force each time we doubled the mass it would make sense that the coin would then move as far each time! Why not think in terms of flick as the intital velocity u Hence: p = mu or p = mass x flick speed Momentum changes as mass changes…..

9 Mr Powell 2012 Index Mars Landers Another interesting idea about momentum is looking at the change in momentum during a collision. When you stop suddenly (i.e. land on mars) your velocity changes quickly and there is an initial and final velocity. Also a force on you and a time that it happens it. The formulae for this is; You are going to explore this idea by making a Mars lander for a fresh egg. The idea is to make the force on the egg as little as possible over the crash as you drop it from as high as possible. If you kill egg your pilot is dead! You have 25 minutes to design your craft & your equipment is; 1 x egg 8 x A4 paper 1 x 3m strip of sticky tape 3 x human brains per team v=final vel u = initial vel t = time F = force

10 Mr Powell 2012 Index Comparing Momentum We can also easily see that an object with; more mass more velocity more mass and velocity Will have a larger momentum; momentum = mass x velocity 25m/s 1000kg 50m/s 1000kg 10m/s 6000kg 30m/s 6000kg 25,000 kg m/s 50,000 kg m/s 180,000 kg m/s 60,000 kg m/s 1 2 3 4

11 Mr Powell 2012 Index Investigating Collisions When two objects collide, the momentum of each object changes.; A.Trolley A is given a push so it collides with a stationary trolley B. B.The two trolleys stick together after the collision. (bluetac) C.The computer gives the velocity of A before the collision and the velocity of both trolleys afterwards. 1.What does each section of the velocity–time graph show? 2.Why does the velocity reduce? 3.Can you come up with any written formulae from what you know about momentum to describe the change? 1.Before and after the collision 2.The mass of trolley B absorbs some of the KE of trolley A 3.m A v A + m B v B = m AB v AB 1.Before and after the collision 2.The mass of trolley B absorbs some of the KE of trolley A 3.m A v A + m B v B = m AB v AB

12 Mr Powell 2012 Index Investigating Collisions In fact we can use the generic formulae; m A v A + m B v B = m AB v AB To describe any change in momentum for this type of collision. Also you may see the trucks called Number 1 & 2 1.For two trolleys of the same mass, the velocity of trolley A is halved by the impact. The combined mass after the collision is twice the moving mass before the collision. So the momentum (mass x velocity) after the collision is the same as before the collision. 2.For a single trolley pushed into a double trolley, the velocity of A is reduced to one- third. The combined mass after the collision is three times the initial mass. So once again, momentum after the collision is the same as the momentum before the collision.

13 Mr Powell 2012 Index Worked Example.. TASK: Read this information here ( stick the print out in your book) Can you do your own worked example which is similar....

14 Mr Powell 2012 Index Car shunts... If a vehicle crashes into the back of a line of cars, each car in turn is shunted into the one in front. Momentum is transferred along the line of cars to the one at the front. 1.If you have ever been in one of these or seen one of these where does the energy eventually go? 2.What do you think that we must assume when completing simple calculations on momentum in the exam? m A v A + m B v B = m AB v AB

15 Mr Powell 2012 Index Summary Questions...

16 Mr Powell 2012 Index Can you see the link... (there are two)

17 Mr Powell 2012 Index Momentum If we are considering mass and velocity we can combine them into a more useful form which describes both at the same time and allows comparisons between events and objects. We can say that momentum = mass x velocity It is also important to realise that velocity is a directional quantity so it can be negative or positive. 30m/s - 30m/s

18 Mr Powell 2012 Index Bounces When these trucks bounce off each other we consider that all the momentum is transferred to the blue truck Crashes / Collision When these trucks connect to each other we consider that the momentum is shared between blue truck & red truck

19 Mr Powell 2012 Index Explosions... In explosion trolley examples: momentum of A after = m A v A momentum of B after = m B v B total momentum before = 0 (because both trolleys were at rest). Using conservation of momentum gives: m A v A + m B v B = 0 Or rearange; m A v A = -m B v B This tells us that A and B move apart with equal and opposite amounts of Momentum and the idea of velocity being a vector is shown! TASK: Read this information then write a note entitled What is an explosion (in terms of momentum)

20 Mr Powell 2012 Index Explosions in guns... When a shell is fired from an artillery gun, the gun barrel recoils backwards. The recoil of the gun barrel is slowed down by a spring. This lessens the backwards motion of the gun. An artillery gun of mass 2000 kg fires a shell of mass 20 kg at a velocity of 120m/s. Calculate the recoil velocity of the gun? m A v A = -m B v B TASK: Write down this example (in brief) for your book & calculate the velocity.....

21 Mr Powell 2012 Index Plenary Question... A 600kg cannon recoils at a speed of 0.5m/s when a 12kg cannon ball is fired from it. 1.Write out the formulae you will use. 2.Rearrange to calculate the velocity of the cannon ball when it leaves the cannon. 3.Make sure you include a unit in your answer m A v A = -m B v B

22 Mr Powell 2012 Index Summary Questions

23 Mr Powell 2012 Index Which word links all of these images...

24 Mr Powell 2012 Index Impacts....

25 Mr Powell 2012 Index Force & Momentum Sub in for a F=ma & (v-u)/t = a

26 Mr Powell 2012 Index What does it mean? The equation shows that: Making the time longer (increasing the value of t) makes the force smaller. Crumple zones in cars are designed to make impact times longer so impact forces are reduced. When a resultant force acts on a moving object, a change of momentum takes place. In general, the force needed to cause a change of momentum is given by:

27 Mr Powell 2012 Index Example..... Scientists at Oxford University have developed new lightweight material for bullet-proof vests. The material is so strong and elastic that bullets bounce off it. A bullet of mass 0.004 kg moving at a velocity of 90 m/s is stopped by a bulletproof vest in 0.0003 s. What is the impact force? 1.Now try the same calculation but with a time of 0.0002s 2.Now try the same calculation but with a mass of 0.008kg? 3.Now try same calculation but with a velocity of 120m/s t = 2/3 so F = -1800N m = x2 so F = -2400N v = 4/3 so F = -1600N

28 Mr Powell 2012 Index Plenary Questions...

29 Mr Powell 2012 Index

30 Mr Powell 2012 Index

31 Mr Powell 2012 Index

32 Mr Powell 2012 Index

33 Mr Powell 2012 Index TASK You have now watched the horizon movie on crash testing can you write an extended paragraph including your own comments and thoughts on; What were they trying to do? What is the Physics of the situation ? What tests were completed; cadavers, live, animals, dummies. Why did they test them? Do you agree or disagree with what was done What part do the car companies play in the grand scheme of things What changes have occurred in society in the past 80 years?

34 Mr Powell 2012 Index

35 P2.2.2 Momentum a)Momentum is a property of moving objects. p = m x v a)In a closed system the total momentum before an event is equal to the total momentum after the event. This is called conservation of momentum. p is momentum in kilograms metres per second, kg m/s m is the mass in kilograms, kg v is the velocity in metres per second, m/s Candidates may be required to complete calculations involving two objects. Examples of events are collisions and explosions. P2.2.2 Momentum a)Momentum is a property of moving objects. p = m x v a)In a closed system the total momentum before an event is equal to the total momentum after the event. This is called conservation of momentum. p is momentum in kilograms metres per second, kg m/s m is the mass in kilograms, kg v is the velocity in metres per second, m/s Candidates may be required to complete calculations involving two objects. Examples of events are collisions and explosions. P2.2.2 Momentum a)Momentum is a property of moving objects. p = m x v a)In a closed system the total momentum before an event is equal to the total momentum after the event. This is called conservation of momentum. p is momentum in kilograms metres per second, kg m/s m is the mass in kilograms, kg v is the velocity in metres per second, m/s Candidates may be required to complete calculations involving two objects. Examples of events are collisions and explosions. P2.2.2 Momentum a)Momentum is a property of moving objects. p = m x v a)In a closed system the total momentum before an event is equal to the total momentum after the event. This is called conservation of momentum. p is momentum in kilograms metres per second, kg m/s m is the mass in kilograms, kg v is the velocity in metres per second, m/s Candidates may be required to complete calculations involving two objects. Examples of events are collisions and explosions. P2.2.2 Momentum a)Momentum is a property of moving objects. p = m x v a)In a closed system the total momentum before an event is equal to the total momentum after the event. This is called conservation of momentum. p is momentum in kilograms metres per second, kg m/s m is the mass in kilograms, kg v is the velocity in metres per second, m/s Candidates may be required to complete calculations involving two objects. Examples of events are collisions and explosions. P2.2.2 Momentum a)Momentum is a property of moving objects. p = m x v a)In a closed system the total momentum before an event is equal to the total momentum after the event. This is called conservation of momentum. p is momentum in kilograms metres per second, kg m/s m is the mass in kilograms, kg v is the velocity in metres per second, m/s Candidates may be required to complete calculations involving two objects. Examples of events are collisions and explosions.
