18/438-A18,Colombo Complex, MM Ali Road,

Similar presentations


Presentation on theme: "18/438-A18,Colombo Complex, MM Ali Road,"— Presentation transcript:

1 18/438-A18,Colombo Complex, MM Ali Road,
Calicut ,Kerala-India Tel: mob: Skype:global.vision3,wwwgvisioncctv.com

2 Brand: TIANDY Model:TC-D3627-CWMI Product Name:27X D/N Speed Dome Camera With CNB Module Features , 22X Speed Dome Camera with CNB Module . 1/4" Sony Super HAD CCD, 480TVL,  1.0lux/0.01 lux . Optical zoom : 27x zoom & digital zoom: 10x  . Manual speed: 0.1°~500°/S preset positions . 8 Auto cruising tracks . 8 groups of Auto scanning . 4 groups of pattern tours, each one with 180s memory . Timing activation function . Preset position remote adjusted . Preset Accuracy: ± 0.1° . Stepper motor . Support environment inspection Specifications . Sensor: 1/4" SONY SUPER HAD CCD . Resolution: 480TVL . Camera: CNB Module . Focus length : f3.25mm-88.0mm . Optical zoom : 27x zoom & 10x digital . Min illumination: 1.0lux/0.05 lux . Back light compensation: Auto . Focus : Auto/manual focus . is : auto/manual iris ,S/N ratio:>50dB . Speed: Manual: 0.1°~500°/S; Preset: 500°S . Angle: Pan:360° continuous Pan Rotation & Tilt: 90°(Auto flip) . Preset positions: 220; Preset Accuracy: ± 0.1° . Pattern Tour: 4 groups of pattern tours, each one with 180s memory . Protocols : Pelco-P, Pelco-D , Motor: Stepper motor  . Baud Rate : 2400/4800/9600bps

3 IR Constant Speed Dome Camera
Model No#:PK900-IC827, PK900-IC822 Features . Dome movement: pan 360° endless, tilt 0°-90° . Dome speed: pan/tilt, Pan 6º/S, 9º/S, 12º/S, 15º/S adjustable . Movement limiting position pan adjustable within the dome movement scope . Max. Acceptable size of the compatible video camera and lens . Seven-inch Constant Speed Dome Camera:140(L)×70(H)×70(W)mm . Ambient temperature:0ºC~49ºC (without temperature controlling de  -35ºC~49ºC (with temperature controlling devices) . Relative Humidity:≤90%RH Specifications . ZOOM:27X Optical zoom camera, 22X Optical zoom camera . IR Led quantity & distance:ф10x8 pcs IR led, ф8x7pcs Led, and 4pcs big IR led, . CCD CHIP:1/4 SONY CCD, TV SYSTEM:PAL/NTSC . Auto iris lens:3.9mm-85.8mm . Horizontal resolution:480TVL . Min. illumination:Color0.5Lux, B/W,0Lux(IR led on) . Focus control: Manual/auto/auto keyboard control . White balance control : Auto . Video output:1.0vp-750hm VBS . Screen Display : Embedded(keyboard control ON/OFF/ON) . Backlight compensation: Embedded(ON/OFF) . Working temp.:0℃-40℃ . Power supply:DC14V---15V (2A), Dome motor:DC14V---15V/0.5A . Camera lens motor:DC12V/100mA . Camera power supply; 12V/1A . Temperature controlling devices ambient : Fan(≤50℃); heater (≥5℃) . Addresses range:1~63 . Communication system:RS485 bus controlling . Communication protocol : supporting multi protocols . Baud rate:1200bps, 2400bps, 4800bps, 9600bps adjustable, 1200bps can be replaced by 19200bps as per customer’s needs . Controlling device : video matrix, hard disk video recorder, DVR controlling keyboard . Preset position quantity:16 preset positions . Auto Scan : Support Left&right scan and 360° scan . Tour group quantity:1 group(16 preset positions can be included) . Default position function : Yes

4 . 1/3 Sony Super HAD CCD Specifications
Brand : HDPRO Model : HD N8442R Product Name:1/3Inch Sony D/N Camera Features . 1/3 Sony Super HAD CCD TV Lines . Third Generation DSP Chip . True Day &Night (ICR-IR Cut filter Removable )-option . C/CS Mount Lens . OSD Control Function . Dual Power (AC 24V/12V)-Option Specifications . TV System :NTSC,PAL . Effective Pixels : NTSC 768(H)*494(V)pal=752(H)*582(v) . Synchronization : Internal . Resolution :54 Lines . Min. illumination :0.1Lux . S/N Ratio :More than 50dB . White Balance : ATW /AWB/ Fixed Manuel . Video Output : CVBS:1.0Vp-p 75ohm . Electronic Shutter Speed :NTSC= Auto Manual (1/60sec ~1/120,000sec) . PAL: Auto /Manual (1/50sec 1/120,000sec) . OSD :Built .in, Gain . Day & Night (Colour /B/W ):Colour /Auto/BW . Privacy :ON/OFF (4 Programmable zone) . Power Supply : DC12V . Lens : C&CS Mount (Lens option) . Dimension:58mm(W) 52mm(H)*100MM(D) . Weight 300g

5 Brand :HDPRO Model:HD-N011R Product Name:1/3 Inch Sony OSD Bullet Color Camera
Features . 1/3” Sony Super HAD CCD . High Resolution of 550 TV Lines . Privacy Mask (4 Zone) . 3.6mm Fixed Board Lens . Motion Detection (64 Area) . OSD Control Function Specifications . Sensor: 1/3" SONY SUPER HAD CCD . Effective Pixels: NTSC=768(H) * 494(V) / PAL=752(H) * 582(V) . Scanning System: 2:1 Interlace . Synchronization: Internal . Resolution: 540TV Lines . Min. Illumination: 0.1Lux . S/N Ratio: More than 50dB . White Balance: ATW / AWB / Manual / Fixed . Gamma Characteristic: r=0.45 . Video Output: CVBS: 1.0Vp-P 75ohm . Electronic Shutter Speed: NTSC=Auto/Manual(1/60sec ~ 1/120,000sec) / PAL=Auto/Manual(1/50sec ~ 1/120,000sec) . O.S.D: Built-in ,AGC: On/Off Privacy: On / Off (4 Programmable Zone) Power: DC 12V Power Consumption: 120mA Storage Temp.: -20 ~ +60° C.RH 95% Max. Dimension: 21mm(W)*21mm(H)*73mm(D) Weight: 60g

6 Features Specifications
Brand: GANZ Model: YC-25P Product Name:1/3 Inch Color CCD C-Mount Camera Features . 1/3" IT. CCD . 330TV Lines, 0.08 lux (F1.2) / 0.36 lux (F0.8) . Compact and Light weight design. . Accepts DC or Video type auto-Iris lenses. . Impressive Color reproduction. . Line lock function with line phase adjustment . DSP controls for Back Light Compensation, and Gain Control Specifications TV System: PAL Scanning System: 2:1 Interlace Image Sensor: 1/3" IT. CCD Effective Elements (H x V): 500 x 582 Scanning Frequency (H / V): kHz / 50Hz Video Output: 1.0V (p-p) / 75 Resolution (Horizontal): 330TV Lines Min. Illumination (50IRE): 0.08 lux (F1.2) / 0.36 lux (F0.8) AGC: +20dB S/N Ratio (AGC Off): More than 48 dB Gamma Characteristic: 0.45 Auto Electric Shutter (AES): 1/ Sec. Sync. System: INT. / L.L. White Balance: AWB / ATW Power Supply: 12V DC / 24V AC Power Comsumption: Less than 3.5W Ambient Temperature: Operation:- 10°C ~ +50°C / Storage:- -20°C ~ +60°C Ambient Humidity: Operation: RH80% Max. (Keep Free From DAMP) / Storage: RH85% External Dimensions: 55 (W) x 40 (H) x (D) mm Weight: 280g approx. Input / Output: Video Output: BNC / Power input: Screwless 2 Pins Terminal

7 Specifications Features:
Brand: TIAND Model:TC-D2636BW-H Product Name:36X D/N Speed Dome Camera with Sony Module Features: 1/4"SONY Super HAD CCD ICR, 530 TV Line(Color) , 0.01Lux in B/W  Optical Zoom: 36X, Digital Zoom: 12X 360° continuous w/o blind area 220 presets at max. Speed: 500° per Second 4 pattern tours, each one with 180s memory 8 cruising tracks, each cruising track has 32 preset positions 6 alarm inputs and 2 outputs 8 Privacy Zones(24 selectable) IP66-rated waterproof Automatic temperature Control (Build-in fan & heater) High die-cast aluminum construction AMP quick installation structure Stepless speed change Auto zoom / speed Matching Auto flip function Pan Tilt accuracy  0.07° Specifications Sub Model: TC-D2636BW Sensor: 1/4" SONY Exview HAD CCD Horizontal Resolution: 530TVL Camera: SONY 1010P Focus Length: F3.4mm~122.4mm Optical Zoom: 36X ,Digital Zoom: 12X Minimum Illumination: 1.4 Lux / 0.01 Lux Video Output: 1Vp-p75 ohms Back Light Compensation: Auto Focus: Auto/Manual, Iris: Auto/Manual, S/N Ratio: >50dB Manual Speed: Pan:0.01°~180°/S, Tilt:0.01°~120°/S Preset Speed: 500°/S, Pan Angle: 360°continuous pan rotation Tilt Angle: 90°(Auto Flip) Auto Scan: 8 auto scan tracks, the left and right boundaries and scan speed can be set Pattern Tour: 4 groups, each one with 180s memory of vacant time Data Communication: RS-485, Baud Rate: 2400/4800/9600bps Operating Temperature: -35°C~ +60°C, Motor: Stepper Motor

8 Features . 1/4"SONY Exview HAD CCD Specifications
Brand: TIANDY Model:TC-D2626IRW-H Product Name:26X IR High Speed Dome Camera Features . 1/4"SONY Exview HAD CCD . Day/Night + ICR, 480 TVL, 0.01Lux . Manual speed 0.01°~120°, Preset speed 120° . 220 preset positions . 8 pattern tours, each one with 180s memory . IP 66 Weatherproof . Pan Tilt accuracy +/- 0.05° meters IR range with 72 IR LED . IR LED service life > 30,000 hours . Linkage between IR LED & optical zoom time Specifications . Sensor: 1/4 inch Sony Exview HAD CCD . Horizontal Resolution: 530TVL . Camera: Sony 990P . Focus Length: F3.5mm~91.0mm . Optical Zoom: 26X, Digital Zoom: 12X . Minimum Illumination: 1.0 Lux / 0.01 Lux . Video Output: 1Vp-p75 ohms . Back Light Compensation: Auto . Focus: Auto/Manual ,Iris: Auto/Manual . S/N Ratio: =50dB, Electric Shutter: 1/1~1/10000s . Power Supply: AC220V . Manual: Manual Speed: 0.01°~120°/S . Preset: 120°/S , Pan Angle: 360°continuous pan rotation . Tilt Angle: 90°(Auto Flip) , Presets: 220 . Preset Accuracy: ±0.05°, Motor: Stepper Motor . Data Communication: RS-485, Protocols: PELCO_P, PELCO_D . Baud Rate: 2400/4800/9600bsp. Operating Humidity: 0~95%

9 Brand: SECURA Model:SXD-1341A Product Name:1/3 Inch Sony IR Dome Camera
Features: . 1/3 Inch Sony IR Dome Camera . Horizontal Resolution 420 TV Lines . Min. Illumination  IR ON 0 LUX Specifications . Sensor: 1/4 inch Sony Exview HAD CCD . Horizontal Resolution: 530TVL . Camera: Sony 990P, Focus Length: F3.5mm~91.0mm . Optical Zoom: 26X, Digital Zoom: 12X . Minimum Illumination: 1.0 Lux / 0.01 Lux , . Video Output: 1Vp-p75 ohms . Back Light Compensation: Auto ,Focus: Auto/Manual . Iris: Auto/Manual ,S/N Ratio: =50dB . Electric Shutter: 1/1~1/10000s . Power Supply: AC220V ,Power Consumption: DC12V 3A . Manual: Manual Speed: 0.01°~120°/S , Preset: 120°/S . Pan Angle: 360°continuous pan rotation . Tilt Angle: 90°(Auto Flip) . Presets: 220 ,Preset Accuracy: ±0.05° . Auto Scan: 8 auto scan tracks, . Data Communication: RS-485 ,Protocols: PELCO_P, PELCO_D . Baud Rate: 2400/4800/9600bsp . Operating Humidity: 0~95% ,Motor: Stepper Motor

10 Brand: SECURA Model:SD-550DIF Product Name:550TVL DOME COLOUR CAMERA
Features: . 550TVL Dome Colour Camera . Min. Illumination 0.01 lux Specifications . Signal System : NTSC/PAL . Image Sensor : Opsie Sensor . Electronic:  Sync System : Internal . Horizontal resolution : 550 TV Lines . Lens : f-3.6mm, f2.0 . Auto White Balance : Auto (2500°K to 9500°K) . Electronic Shutter : Auto ,Aperture : Auto . AGC : Auto ,BLC : Auto (1/3 center) . Minimum Illumination : 0.01 lux . S/N Ratio : > 52 db . Power Supply: DC12V ± 10% . Power Consumption : 0.65w (max) . Operating Temperature :-10°C~50°C(14°F~122°F) . Operating Humidity : 90% RH . Storage Temperature : -20°C~60°C(-4°F~140°F) . Easy Adjustment: External 350° pan direction rotation, 75° tilt direction adjustment . Dimension (d * H) : 107mm * 64mm

11 . 1/4 Inch Sharp IR Color Dome Camera
Brand: SECURA Model:SXD Product Name:1/4 Inch Sharp IR Color Dome Camera Features . 1/4 Inch Sharp IR Color Dome Camera . 420 TV Lines . Min. Illumination 1.0 Lux/1.2 Specifications . Picture Elements: PAL: 500 (H) x 582 (V) / NTSC 510 (H) x 492 (V) . Sensing Area: 3.6mm x 2.7mm . System of Signal: PAL / NTSC . Resolution: 420 TV Lines . Minimum Illumination: 1.0 Lux/1.2 . Electronic Shutter: 1/50 (1/60) -1/100,000 sec . S/N Ratio: More than 48dB . Video Output 1.0Vp-p, 75Ohm . Supply Voltage: DC 12V . Power Consumption: 100mA . Operating Temperature: -10°C ~ + 50°C

12 Features Specifications
Brand: LILIN Model:IPS-1308P Product Name:1/4 Inch EX-View HAD CCD, : 30X D/N IP Speed Dome Camera Features . 1/4 Inch EX-View HAD CCD . 30X D/N IP Speed Dome Camera . Color 520 TVL, B/W 580 TVL Specifications . System : PAL ,Power Supply: AC 100V-240 . Image pick-Up Device: Sony ¼` EX view HAD CCD . Effective Pixles: 752(H)*582(V) . Scanning System: 2:1 Interface . Video Output: CVPS 1.0 Vp-p /75 Ohms . Horizontal Resolution: C 520 TVL B/W 580 TVL . Signal to Noice Ratio: more than 50db(AGC:OFF) . Dimension: 238mm(H) * 145mm(D) . Weight: 2400g ,Panning Range: 360 Deg Endless . Panning mode: Manual, Auto, Manual position, Sequential position . Tilting Range: -6  +96 Deg . Tilting mode: Manual, Auto, Manual position, Sequential position . Zoom Ratio: 30X Optical Zoom . Focal Length : 3.43mm to 102.9mm . Control Interface: RS-485 Transmission . Iris: ALC ( Adjustable Output Target level ) / Manual . BLC: ON /OFF Selectable . White Balance: ATW / PUSH / MWB Selectable . AGC: 0-36db Selectable , (NTSC) / 352*288 (PAL) . Resolution: Full D1: 720*480 (NTSC) / 720*576 (PAL), CIF: 352*240 . Network Protocols: IP, TCP, UDP, HTTP, SMTP, ESMTP, NTP, DDNS, FTP, ARP, DHCP, PPoE, DNS, TELNET . Mobile Phone`s & PDA Supports: Free Mobile Software for Java Phones, Windows Mobile 5/6 , 3GPP H.264 W/ Video and Audio via Podcast . System Integration: HTTPAPI Downloadable . OS: Embedded Linux 2.6.9

13 Specifications Features
Brand: LILIN Model:PIH-7530HPF Product Name:1/4 Inch EX-View HAD CCD, ,30X D/N Speed Dome Camera Features . 1/4 Inch EX-View HAD CCD . 30X D/N Speed Dome Camera . Color 520 TVL, B/W 580 TVL Specifications . Image pick-Up Device: Sony ¼’ EX view HAD CCD . Scanning System: 2:1 Interface . Horizontal Resolution: C 520 TVL B/W 580 TVL . Power Supply: AC 100V-240 . Power Consumption: 22W (Heater ON) . Signal to Noise Ratio: more than 50db (AGC: OFF) . Minimum Illumination: Color 0.1 LUX at F1.6, Mono 0.01 LUX at F1.6 . Dimension: 326mm (H) * 210mm (D) . Weight: 3200g  . Panning mode: Manual, Auto, Manual position, Sequential position . Tilting Range: Deg . Tilting mode: Manual, Auto, Manual position, Sequential position . Zoom Ratio: 30X Optical Zoom . Focal Length: 3.43mm to 102.9mm . Control Functions: Pan & Tilt / Zoom & Focus / Iris & ICR / 128 Preset Position/ Home Position / Patrol . Auto Focus: Auto / One Push . Iris: ALC (Adjustable Output Target level) / Manual . IR Cut Filter: Yes . Electronic Shutter Speed: Auto / Manual Selectable (1/60 – 1 / 100,000 Sec) . BLC: ON /OFF Selectable . White Balance: ATW / PUSH / MWB Selectable . AGC: 0-36db Selectable . Auto Mode: OFF / AUTO / SEQ / TOUR / PATROL (STOP, PLAY LEARN) . Image Negative: ON / OFF Selectable . Alarm In /Out: 6 Input [Alarm in 1-6 (NC/ NO)] , 1 Output [Alarm Out (NC/ NO)] . Schedule Setting: Alarm Input / Auto Mode / Daylight Saving Time

14 Brand: HDPRO Model:HD-1011T-Z Product Name:1/4 Inch Sony OSD 10X True D/N Camera
Features . 1/4 Inch Sony CCD . Zoom factor: 10X optical, 10X digital .  True D/N AF Zoom . 3.8 ~ 38 mm Lens ,520 TVL, Lux ,Built-in OSD . . 4 zone programmable privacy zone . 4 zone programmable motion detection . Up to 255 Camera ID can be set . Communication interface: RS485 . Focus control with wireless remote controller(optional) Specifications . Sensor: 1/4" interline Transfer  CCD . Resolution: 520TVL . Min illumination: 0.005lux . Scanning System: 2:1 interlace system . Lens: 3.8mm to 38mm . Up to 255 Camera ID can be set . Communication interface: RS485 . . Focus control with wireless remote controller (optional) . SNR: >50dB . Gamma: r=.45 . Zoom factor: 10X optical, 10X digital . Power Supply: 12VDC/120mA .Operating Temp: -10 to +50deg . Dimension: 58(W)*52(H)*100(D)m in mm

15 Brand: HDPRO Model:HD-N842R Product Name:1/3 Inch Sony D/NCamera
Features . 1/3" Sony Super HAD CCD . 540 TV Lines . Third-Generation DSP Chip . True Day & Night (ICR-IR Cut FilterRemovable)-Option . C/CS Mount Lens . OSD Control Function . Dual Power (AC 24V / 12V)-Option Specifications . Image Pick-Up Device: 1/3" SONY SUPER HAD CCD . TV System: NTSC, PAL . Effective Pixels: NTSC=768(H)*494(V)/PAL=752(H)*582(V) . Scanning System: NTSC=15.734KHz(H)*59.94Hz(V)/PAL=15.625KHz(H)/50.00Hz(V) . Scanning System: 2:1 Interlace . SynchronizationL: Internal . Resolution: 540TV Lines . Min. lllumination: 0.1 Lux . S/N Ratio: More than 50dB White Balance: ATW / AWB / FIXED / MANUAL Gamma Characteristic: r=0.45 Video Output: CVBS:1.0Vp-p 75ohm OSD: Built-in BLC: ON / OFF AGC: ON / OFF Day & Night (Color / B/W): Color / Auto / B/W Display Adjust: Contrast / Sharpness / CB-Gain / CR Gain Privacy: ON / OFF (4 Programmable Zone) Power Supply: DC 12V Power Consumption: 120mA Lens: C & CS Mount (Lens Option) Operational Temp.: -10°C ~ + 50°C.RH 95% Max. Storage Temp.: -20°C ~ + 60°C.RH 95% Max. Dimension: 58mm(W)*52mm(H)*100mm(D) Weight: 300g

16 Specifications Features
Brand: HDPRO Model:HD-N238DNR Product Name:1/3 Inch Sony OSD Dome Camera Features . 1/3" Sony Super HAD CCD . 3 DNR: Off/On (1~50 Level Adjustable) . D-WDR: Indoor/ Outdoor/ Off . Motion Detection: On/Off (4 Zone, Alarm Output) . Privacy: On/Off (8 Zone) . Freeze: On/Off . Mirror: Off/ Mirror/ V-Rev/ Rotate . Sharpness: 0~31` (Level Adjustable) . D&N Selection: Color/ Auto/ Ext/ BW . Digital Zoom: On(*32)/ Off Specifications . Sensor: 1/3" Sony Super HAD CCD ,. . Synchronization: Internal ,O.S.D: Available . Dynamic Range: 52dB(*128) . Backlight: BLC/HSBLC/Off Selectable . Resolution: 550TV Lines (Color), 600TV Lines (B/W) . S/N (Y signal): 52dB (AGC Off, Weight On) . Min. Illumination: Lux F1.2 (Sens-Up*258X) . White Balance: ATW/ AWB/ Indoor/ Outdoor/ Manual/ AWC . Electronic Shutter Speed: 1/60sec~1/120000sec . Sense-Up: Auto/ Fixed/ Off (Selectable limit *2~*258) . Gain Control: High, Middle, Low, Off Selectable . 3 DNR: Off/On (1~50 Level Adjustable) . D-WDR: Indoor/ Outdoor/ Off . Motion Detection: On/Off (4 Zone, Alarm Output) . Privacy: On/Off (8 Zone) ,Freeze: On/Off . Mirror: Off/ Mirror/ V-Rev/ Rotate .Sharpness: 0~31` (Level Adjustable) . D&N Selection: Color/ Auto/ Ext/ BW . Power consumption:120mA, Weight:300 . Dimension: 110mm(W) * 75mm(H) * 110mm(D)

17 Specifications Features
Brand: HDPRO Model:HD-N722DNR Product Name:1/3 Inch Sony OSD C-Mount Camera Features . 1/3" Sony Super HAD CCD . 550TV Lines , Lux . O.S.D . 3 DNR: Off/On (1~50 Level Adjustable) . D-WDR: Indoor/ Outdoor/ Off . Motion Detection: On/Off (4 Zone, Alarm Output) . Privacy: On/Off (8 Zone) . Freeze: On/Off . Mirror: Off/ Mirror/ V-Rev/ Rotate . Sharpness: 0~31` (Level Adjustable) . D&N Selection: Color/ Auto/ Ext/ BW . Digital Zoom: On(*32)/ Off Specifications Sensor: 1/3" Sony Super HAD CCD Total Pixels: PAL:795(H) * 595(V) Effective Pixels: PAL:752(H) * 582(V) Scanning System: 2:1 Interface Synchronization: Internal O.S.D: Available, Freeze: On/Off Dynamic Range: 52dB(*128) Backlight: BLC/HSBLC/Off Selectable Resolution: 550TV Lines (Color), 600TV Lines (B/W) S/N (Y signal): 52dB (AGC Off, Weight On) White Balance: ATW/ AWB/ Indoor/ Outdoor/ Manual/ AWC Electronic Shutter Speed: 1/60sec~1/120000sec Gain Control: High, Middle, Low, Off Selectable 3 DNR: Off/On (1~50 Level Adjustable) D-WDR: Indoor/ Outdoor/ Off Motion Detection: On/Off (4 Zone, Alarm Output) Privacy: On/Off (8 Zone) Mirror: Off/ Mirror/ V-Rev/ Rotate D&N Selection: Color/ Auto/ Ext/ BW Digital Zoom: On(*32)/ Off Lens: C & CS Mount Lens Weight:350g Dimension: 58mm(W) * 52mm(H) * 100mm(D)

18 Features Specifications
Brand: HDPRO Model:HD-N441R Product Name:1/3 Inch Super HAD CCD OSD Dome Camera Features . 1/3 Inch Super HAD CCD . 540 TVL, 0.1 Lux . 3.6mm fixed board lens(4/6/8/12 mm optional) . Built-in OSD . Selectable AWB, BLC,AGC,DNR . 4programmable privacy zone Specifications . Sensor: 1/3" SONY SUPER HAD  CCD . Scanning System: 2:1 interlace system . Resolution: 540TVL . Min illumination: 0. 1lux . Lens: 3.6mm fixed board lens(4/6/8/12 mm optional) . SNR: >50dB . Gamma: r=.45 . Built-in OSD . Selectable AWB, BLC,AGC,DNR . 4programmable privacy zone . Power Supply: 12VDC/120mA . Operating Temp: -10 to +50deg . Dimension: 120(W)*76(H)*120(D)m in mm

19 Features Specifications . 1/3 Inch Sony Super HAD CCD
Brand: HDPRO Model:HD-D577TDN Product Name:1/3 Inch Sony Super HAD 3 OSD Hood True D/N IR Camera Features . 1/3 Inch Sony Super HAD CCD . Hood True D/N Weather-Proof  IR Camera . 2.8 ~ 12 mm Vari-focal lens . 560 TVL . No. of LEDs:850nM  21pcs . Selectable AWB,  BLC, AGC & DNR . Built-in OSD . 4 zone programmable privacy zone Specifications . Sensor: 1/3" SONY Super HAD  CCD . Resolution: 560TVL . Scanning System: 2:1 interlace system . Electronic Shutter Speed : 1/50sec to 1/120,000 sec . Lens: 2.8mm-12mm . SNR: >50dB . Gamma: r=.45 . No. of LEDs:21pcs . Wavelength : 850nM . Power Supply: 12VDC/350mA . Operating Temp: -10 to +50deg . Dimension: 100(W)*120(H)*255(D)m in mm

20 Specifications Features
Brand: HDPRO Model:HD-N641R Product Name:1/3 Inch Sony OSD Hood Weather-proof IR Camera Features . 1/3" Sony Super HAD CCD .  540 TV Lines, Illumination: CDS OFF 0.1 LUX CDS ON Lux . 6MM Fixed Board Lens  . 850nm IR LED * 24pcs . Third-Generation DSP Chip . Privacy: ON/OFF (4 Programmable Zone) . White Balance: ATW/AWB/FIXED/MANUAL Specifications . Image Pick-Up Device: 1/3" SONY Super HAD CCD . TV System: PAL . Effective Pixels: PAL=752(H)*582(V) . Scanning Frequency: PAL=15.625KHz(H) / 50.00Hz(V) . Scanning System: 2:1 Interlace . Synchronization: Internal . Resolution: 540 TV Lines . Minimum Illumination: CDS OFF 0.1 LUX / CDS ON Lux . S/N Ratio: More than 50dB . White Balance: ATW/AWB/FIXED/MANUAL . Gamma Characteristic: r=0.45 . Video Output: CVBS: 1.0Vp-p 75OHM . Electronic Shutter Speed: PAL=Auto/Manual(1/50sec~1/100000sec) . Privacy: ON/OFF (4 Programmable Zone) . Power Supply: DC 12V . Power Consumption: CDS ON:350mA Max . Lens: 6MM Fixed Board Lens . Operational Temp.: -10~+50° C.RH 95% Max. . Dimension: 63mm(W)*58mm(H)*130mm(D) . Weight: 800g

21 Features Specifications
Brand:HDPRO Model:HD-DW255T Product Name:1/3 Inch Sony WDR OSD True D/N Dome Camera Features . 1/3 Inch Sony WDR OSD . True D/N Weather-Proof Vari-focal Dome . 6 ~ 50 mm Lens ,Built-in OSD . 560 TVL, Lux . Selectable AWB, BLC,AGC,DNR level digital zoom level DNR adjustable . 8programmable privacy zone . 8zone motion detection & alarm output Specifications . Sensor: 1/3" SONY vertical double density interline  CCD . Scanning System: 2:1 interlace system . Resolution: 560TVL . Min illumination: 0.001lux . Lens6mm -50mm . SNR: >52dB . Gamma: r=.45 . Communication interface: RS485 (optional) . Power Supply: 12VDC/120mA . Operating Temp: -10 to +50deg . Dimension: 140(W)*100(H)*140(D)m in mm

22 Brand:HDPRO Model:HD-SP239R Product Name:1/3 Inch Sony Dome Camera
Features . 1/3" Sony Super HAD CCD . 3.6mm Fixed Board Lens (4/6/8/12) - Optional . 540TV Lines , 0.1l .Third-Generation DSP Chip Specifications . Image Pick-Up Device: 1/3" SONY Super HAD CCD . TV System: PALEffective Pixels: PAL=752(H)*582(V) . Scanning Frequency: PAL=15.625KHz(H) / 50.00Hz(V) . Scanning System: 2:1 Interlace . Synchronization: Internal . Resolution: 540 TV Lines . Minimum Illumination: 0.1 LUX . S/N Ratio: More than 46dB . Gamma Characteristic: r=0.45 . Video Output: CVBS: 1.0Vp-p 75OHM . Electronic Shutter Speed: PAL=Auto/Manual(1/50sec~1/100000sec) . Power Supply: DC 12V . Power Consumption: 120mA . Lens: 3.6MM Fixed Board Lens . Operational Temp.: -10~+50° C.RH 95% Max. . Storage Temp.: -20~+60° C.RH 95% Max. . Dimension: 110mm(W)*80mm(H)*110mm(D) . Weight: 300g

23 Brand:SECURA Model:SXD-1341 Product Name:1/3 Inch Sony IR Color Dome Camera
Features . 1/3 Inch Sony IR Color Dome Camera . 420 TV Lines . Min. Illumination: 0.8 Lux / 1.2 Specifications . Pickup Device: 1/4" sony IR Color Dome Camera . Picture Elements: PAL: 500 (H) x 582 (V) / NTSC 510 (H) x 492 (V) . Sensing Area: 4.9mm x 3.7mm . System of Signal: PAL / NTSC . Resolution: 420 TV Lines . .Minimum Illumination: 0.8 Lux/1.2 . Electronic Shutter: 1/50 (1/60) -1/100,000 sec . .S/N Ratio: More than 48dB . Video Output 1.0Vp-p, 75Ohm . Supply Voltage: DC 12V . Power Consumption: 120mA . Operating Temperature: -10°C ~ + 50°C

24 . Outdoor Round Aluminum Housing . Size: 262 (L) x 112 (W) x 122 (H)mm
Brand:SECURA Model:SHG-3012 Aluminum Housing Product Name:Outdoor Round Features . Outdoor Round Aluminum Housing . Size: 262 (L) x 112 (W) x 122 (H)mm

25 . IR Outdoor Housing Features Brand:SECURA Model:SHG-6012
Product Name:IR Outdoor Housing Features . IR Outdoor Housing

26 Brand:SONY Model:SSC-M388CE Product Name:1/3 Inch Interline B/W Camera
Features . 1/3" Interline Transfer B/W Camera . 570 TV Lines . Minimum illumination: 0.04 lx at F1. . Auto Iris Lens: DC/Video servo switchable Specifications . Image device: 1/3" Interline Transfer B/W Camera Sensing area: 1/3 type format (4.8 x 3.6) Picture elements (H x V): 752 x 582 Signal system: CCIR Standard Sync.System: INT/LL Horizontal Resolution: 570 TV Lines AGC: ON/OFF (switchable) CCD IRIS: ON/OFF (switchable), 1/50 to 1/100,000s Back-Light Compensation (BLC): ON/OFF Switchable S/N ratio: More than 50dB (AGC OFF, Weight ON) Video Out: 1.0 V peak to peak at 75, sync. negative Operating temperature:-10°C to 50°C (14°F to 122°F) Storage temperature: -40°C to 60°C (-40°F to 140°F) Power requirements: AC 24 V ± 10%, 50 Hz or DC 12 V ± 10% Power Consumption: 2.6W Mass: 360 g(13 oz) Auto Iris Lens: DC/Video servo switchable Dimensions (w x H x D): 60x54x120mm (2% x 2 1/4x 4 3/4 inches) Supplied accessories: Lens mount cap (1), Operating instruction (1)

27 Brand:SECURA Model:SC-1341 Product Name:1/3 Inch Sony CCD C-Mount Camera
Features . Image Pick-up Device: Sony 1/3" color CCD camera . Scanning System: PAL . Resolution: 420TVL . Min. lllumination: 0.8 Lux . S/N Ratio: >48dB(AGC)off(Color); >52dB(B/W) . Video Output: 1.0Vp-p/75 . White Balance: Auto . Gain Control(AGC): Auto . BLC: Auto . Electronic Shutter Time: On: PAL: 1/50-100,000sec Off: PAL:1/50sec . Gamma Correction: 0.45 . Lens Mount: C/CS Mount . Operation VoltageL:DC12V AV24V/AC/220v/Optional . Operation Environment: Temperature:-10°c~+50°c; Humidification:40%~90% . IR Distance: 10m/ 20m/ 30m/ 50m/ Optional

28 Brand:SECURA Model:SZ22X–1451 Product Name:1/4 Inch - 22X Zoom Camera with 420 TVL
Features . Image Sensor : 1/4"Sony CCD . Horizontal Resolution : 420TV Lines . Scanning System : PAL . Effective Pixels : PAL:500(H)X582(V) . Scan System : 2:1Interface . S/N Ratio : More than 50Db . Electronic Shutter : 1/50-1/100,000sec . White Balance : AUTO . Backlight Compensation : ON/OFF . Auto Gain Control : ON/OFF . Lens : F3.9MM-85.8MM . Minimum Illumination : 0.8Lux/F1.2 . Power : DC12V 250mA . Weight : 600g . Dimensions:110mm x 53mm X 63mm

29 Features Specifications
Brand:YOKO Model:YK-2F49L5 Product Name:1/3 Inch Sony CCD D/N IR LED Camera Features . 1/3" Color Sony Super HAD . 470 TVL ,0.2 Lux . Board Lens 12mm / F2.0 (option:16mm) . 84 pieces IR-LED . Illuminate Distance : 50 M . Waterproofing Criterion : IP 66 Specifications . Image Device : 1/3" Color Sony Super HAD . Picture Elements NTSC:510x492, PAL:500x582 . Resolution 470 TVL . Min. Illumination : 0.2 Lux / F 2.0 (Day), 0 Lux (IR on) . S/N Ratio : More than 48dB . Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000 . Gamma 0.45 , Wavelength : 850 nm . Lens Furnished : Board Lens 12mm / F2.0 (option:16mm) . Video Output : 1 Vp-p / 75 Ohms . Infrared Luminary : 84 pieces IR-LED . Illuminate Distance : 50 M . Waterproofing Criterion : IP 66 . Power Supply : DC12V±10%, AC24V, AC100~240V (option) . Operating Temp. : -10°C ~ 50°C

30 Specifications Features
Brand:YOKO Model:YK-2B49 Product Name:1/3 Inch Sony CCD D/N 12 IR LED Camera Features . 1/3" Color Sony Super HAD . 470 TVL, 0.2 Lux / F 2.0 (Day) . Board Lens 3.6mm / F2.0 (option:4.3/6/8/12/16mm) . 12 pieces IR-LED . Waterproofing Criterion : IP 67 Specifications . Image Device : 1/3" Color Sony Super HAD . Picture Elements NTSC:510x492, PAL:500x582 . Resolution 470 TVL . Min. Illumination : 0.2 Lux / F 2.0 (Day), 0 Lux (IR on) . S/N Ratio : More than 48dB . Lens Furnished : Board Lens 3.6mm / F2.0 (option:4.3/6/8/12/16mm) . Video Output : 1 Vp-p / 75 Ohms . Infrared Luminary : 12 pieces IR-LED . Wavelength : 850 nm ,Illuminate Distance : 10 M . Waterproofing Criterion : IP 67 . Power Supply : DC12V±10% . Power Consumption IR On: 292mA max., IR Off: 117mA max. . Operating Temp. : -10°C ~ 50°C

31 Features Specifications . 1/4" Sharp IR Color CCD Camera
Brand: SECURA Model:SX Product Name:1/4 Inch Sharp IR Color CCD Camera Features . 1/4" Sharp IR Color CCD Camera . 420 TV Lines Specifications . Image Sensor: 1/4"SHARP CCD . Number of Pixels: PAL: 500 (H) x 582 (V) . Scanning System: PAL / NTSc . Sync System: Internal Synchronization . Horizontal Resolution: 420 TV Lines . Minimum Illumination: 0 Lux (Infrared Lamps Turn On) . S/N Ratio: More than 48dB . Characteristic: 0.45 . Electronic Shutter Time: Auto, PAL: 1/50~1/100,000 Sec / NTSC: 1/60~1/100,000 Sec . Video Output: 1.0Vp-p 75 ohm . Power Consumption: 12V± 10% DC, 120mA . Built-in Lens: 6mm / F1.5 . Housing: Aluminum Alloy . Color: Black or Silvery White . Infrared Wavelength:  850nm . Effective distance: 35m . Infrared Lamps Automatis switch: Night / Day Operating / Turn off . LED N0: 24PCS ,Ranging Distance: M

32 Brand: IRLAB Model:CIR-BB32B Product Name:1/3 Inch Super Sensitivity IR Camera
Features . 480 TVL, 1/3" Super Sensitivity CCD . 6mm IR Lens . Color Changes to B/W while IR LED Starts working . Constant current circuit design to make sure the lide span of IR LED . Cable management: Cable through bracket  . Viewing angle: diagonal:53°/ Horizontal:42°/ Vertical:32° . Maximum Outdoor IR Range: 28m Specifications Image Sensor: 1/3" Super Sensitivity CCD Pixels:  NTSC:811(H)×508(V) PAL:795(H)×596(V) Horizontal Resolution:  480TVL  IR LED: 30PCs IR LED Vertical frequency:  NTSC:60Hz PAL:50Hz Horizontal Frequency:  NTSC:15.734KHz PAL:15.625KHz Clock Frequency:  NTSC:28.636MHz PAL:28.375MHz Scanning System:  2:1 Interlace  S / N Ratio:  ≥50dB White Balance: Auto Tracking  IP rating: IP66 Gamma: 0.45 Filter  Double: layers crystal Back Light Compensation:  ON Auto Gain Control:  ON Video Output:  1V p-p,75 ohm Lens: 6mm IR lens Viewing Angle:  Horizontal: D:53° / H:42° / V:32° Current Consumption: 300mA Available IR Distance:  28m (91.80ft) Dimension: 180×140x90mm (0.59×0.46×0.30ft) Weight: 750g , Storage Temperature:  -30°~ +60°C Operating Temperature:  -30°C ~ +40°C

33 IR waterproof camera Features& Specifications
. IR waterproof camera - Double glass - CCD . Minimum illumination: IR on 0 Lux . IR Light Number: 8: : 24/35 . IR Beam Distance: 25~30m . Lens: 6mm . Picture Elements: NTSC/PAL . Water proof housing: IP66 . Video Output: 1.0VP-P75 . Indoor and outdoor available . Power Supply: DC12V . 36pcsø5mm IR LED, . IR range 30m , . 3.6mm-6mm standard lens, . Minimum illumination 0 LUXIR on power supply DC12V, . CCD board power supply part of the adoption of a wide power supply design, . to effectively prevent damage to the chances of high voltage and improve the stability of the product.

34 Model:VG-6078HR product Name:1/3’colour Sony Super HAD CCD
Features: . Outdoor Waterproof IR Camera . Min. illumination lux . IR Distance: 4m IP66 . Lens : 16mm(8mm,12mm optional) . IR LED: 64pcs IR LEDs

35 Model : VG-6076LR product Name:1/3”colour Sony HAD CCD
Features: . Min. illumination lux . IR Distance: 4m IP66 . Lens : 16mm(8mm,12mm optional) . IR LED: 64pcs IR LEDs . Image Sensor:1/3”colour Sony HAD CCD

36 Features& Specifications
Brand: HI-FOCUS Model: GV110D045B Features& Specifications . Model : GV110D045B . Image Device : 1/3 Sony Inter line CCD . Number of pixels : PAL752 (H)x582(H) NTSC768(H) x 494(V) . Scanning System :PAL 725 lines , 50Field/sec . Sysc System : Inter line synchronization . Horizontal resolution : 420 TV Lines . Video Output : 1V p-p 75ohm”s , Negative . S/N ratio : More than 48 db (AGCoff) . Gamma characteristics: 0.45 . White balance : Auto White Balance . B.L.C : Back Light compensation (Auto) . Minimum Illumination : Lux*F1.2 . Electronic Shutter : PAL:1/50-1/ sec . Lens mout : 3.6 Fixed Lens . Power Consumption: 12V+/-10%DC . Operation Temperature : -10 oC 50o RH95o% Max

37 Features& Specifications
Brand: HI-FOCUS Model: GV110D045W Features& Specifications . Model : GV110D045W . Image Device : 1/3 Sony Inter line CCD . Number of pixels : PAL752 (H)x582(H) NTSC768(H) x 494(V) . Scanning System :PAL 725 lines , 50Field/sec . Sysc System : Inter line synchronization . Horizontal resolution : 420 TV Lines . Video Output : 1V p-p 75ohm”s , Negative . S/N ratio : More than 48 db (AGCoff) . Gamma characteristics: 0.45 . White balance : Auto White Balance . B.L.C : Back Light compensation (Auto) . Minimum Illumination : Lux*F1.2 . Electronic Shutter : PAL:1/50-1/ sec . Lens mout : 3.6 Fixed Lens . Power Consumption: 12V+/-10%DC . Operation Temperature : -10 oC 50o RH95o% Max

38 Features Specifications
Brand:HDPRO Model:HD-N1652RT Product Name:1/3 Inch Sony Super HAD CCD D/N OSD Dome Camera Features . 1/3 Inch Sony Super HAD CCD . D/N Vari-focal Auto Iris Dome . 2.8 ~ 12 mm Lens . 540 TVL, 0.1 Lux . Built-in OSD . Selectable AWB, BLC,AGC,DNR . 4programmable privacy zone Specifications . Sensor: 1/3" SONY SUPER HAD  CCD . Scanning System: 2:1 interlace system . Resolution: 540TVL . Min illumination: 0. 1lux . Lens: 2.8mm to 12mm . SNR: >50dB . Gamma: r=.45 . Built-in OSD . Selectable AWB, BLC,AGC,DNR . 4programmable privacy zone . Power Supply: 12VDC/120mA . Operating Temp: -10 to +50deg . Dimension: 139(W)*97(H)*139(D)m in mm

39 ModelDS-2CC502P (N)(-A) Product Name:1/3 inch SONY Super HAD CCD
Features: . Signal System PAL / NTSC . Effective Pixels :PAL: 500 (H) ¡Á 582 (V)NTSC: 510 (H) ¡Á 492 (V) . Min. Illumination F1.2 . Electronic Shutter :1/50 (1/60)s to 1/100,000s . Day& Night : Electronic . F2.0 (2.8mm, 6mm, 8mm, 12mm, 16mm optional) . Horizontal Resolution :420TV . Synchronization :Internal Synchronization . Video Output :1Vp-p Composite Output (75¦¸ / BNC) . S/N Ratio :More than 48 dB . BLC :ON . Working Temperature :-10¡æ ~ 60¡æ . Dimension (mm):¦µ138 x 87 (¦µ5.5¡± x 3.45¡±) . Weight:380g (0.83lbs

40 HIKVISION H.264 IP BASED DOME CAMERAS FULL D1 REAL TIME
 Features: Power over Ethernet (POE) 420, 480 & 540 TVL Versions Available .0 Lux F1.2 12 VDC 3.5mm - 9mm Lens 1/50 - 1/100,000s Shutter Speed Full D1 (704x480) REAL TIME Recording Works with all versions of HIK Client & DVR Server Software Camera, Software & License Included

41 Features: Specifications: . Image Sensor:1/4”CMOS
. Compact design . F1.2 TVL . Pan 0°, Tilt 90° . Day/night with auto switch . Auto white balance, auto gain control, electronic shutter control and backlight compensation . Internal synchronization Specifications: . Image Sensor:1/4”CMOS . Effective Pixel: NTSC:640*480 . Min. F1.2 . Electronic Shutter Speed:1/25s to 1/15,000s . Day & Night:Electronic Shutter . F2.0 . Horizontal Resolution:480 TVL . Sync. System :Internal . S/N Ratio:48dB . BLC: On . Video Output:1Vp-p Composite Output (75ohm / BNC) . Operating Temperature:-10°C ~ 60°C . Power Supply:12VDC . Power Consumption:2W Max. . Dimensions:110mm×62mm . Weight :330 g

42 Features: Brand: Hik vision Model Code:DS-2CD7922PF(NF)-E
. Colour type: colour . Chip inch size:1/3 . Resolution:540 . Sensitivity . Auto Iris: yes . Lens Mount: C/CS . Motion Activated: yes . Picture Elements Hxv:752x582 . Network Properties: Image Frame Rate: 30 fps . Interface: RJ45 10M/100M Ethernet Port . Network Protocols: TCP/IP, HTTP, DHCP, DNS, RTP/ RTCP, PPPoE . Electronic Shutter Range:1/50 ~ 1/100,000 . S/ N (Signal/ Noise) Ratio dB :48 . Signal Mode :PAL, NTSC . Electrical Specifications Power Consumption: 4 W . Voltage: 12 VDC, PoE . Physical Specifications Dimensions mm: 145 x Weight g: Environmental Specifications Operating Temperature oC: -10 ~ Compression Type :H.264, MPEG-4

43 Features . Brand: Hik vision . Model Code:DS-2CD712PF(NF)-E
. Colour type: colour . Chip inch size:1/3 . Resolution:480 . Sensitivity . Auto Iris: yes . Lens Mount: C/CS . Motion Activated: yes . Picture Elements Hxv:752x582 . Network Properties: Image Frame Rate: 30 fps . Interface: RJ45 10M/100M Ethernet Port . Network Protocols: TCP/IP, HTTP, DHCP, DNS, RTP/ RTCP, PPPoE . Electronic Shutter Range:1/50 ~ 1/100,000 . S/ N (Signal/ Noise) Ratio dB :48 . Signal Mode :PAL, NTSC . Electrical Specifications Power Consumption: 4 W . Voltage: 12 VDC, PoE . Physical Specifications Dimensions mm: 145 x Weight g: Environmental Specifications Operating Temperature oC: -10 ~ Compression Type :H.264, MPEG-4

44 Features: . Image Sensor 1/1.8 inch SONY Progressive Scan CCD
. Effective Pixels 1600×1200 . Min. Illumination Color: 0.5 F1.2; B/W: 0.05 F1.2 . Electronic Shutter 1/25s ~1/30,000s . Day&Night IR cut fi lter with auto switch . Lens Mount C / CS mount . Auto IRIS DC Drive . Video Parameter Saturation/Brightness/Contrast/Tue adjustable . Through client software or web browser . Video Compression H.264 . Video Bit Rate 32 Kbps~16Mbps . Audio Compression OggVorbis . Max. Image Resolution 1600×1200 . Frame Rate 30fps . Storage Support SD/SDHC, NAS, ISCSI . Intelligent Alarm Motion Detection, Video Tampering, Video Loss, Network Broken, IP address confl ict, . Protocols TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTCP, PPPoE, FTP, SMTP, NTP, SNMP, HTTPS, SIP,802.1x, IPV6 . Basic Initial Set button, Anti-fl icker, Dual Stream, Heartbeat, Password Protection, watermark . Audio Input 1 channel 3.5mm audio interface (2.0 ~ 2.4Vp-p, 1kΩ) . Audio Output 1 channel 3.5mm audio interface (Line level, 600Ω) . Communication 1 RJ45 10M / 100M self-adaptive Ethernet port and 1 RS-485 . Alarm Input 4 channel . Alarm Output 3 channel . Video Output 1Vp-p Composite Output (75Ω/BNC) . Power Supply DC12V±10% (AC24V optional) . Power Consumption 12W MAX . Working Temperature -10°C ~ 60°C . Working Humidity 90% or less . Dimensions(mm) 68×77.4×154.5 . Weight 1000g

45 Features: . High performance chip of TI DSP
. H.264 video compression, high compression ratio, very . flexible . Functional: heartbeat, PTZ control, alarm, network voice talk function, Subscriber Management . Network function: Support TCP/IP, video, alarm, voice data, Internal . web Explore and IE preview . Minimum illumination: 0.1Lux/F1.2 (0 LUX with IR) . Low illumination auto switch . High S/N ratio (Signal-to-Noise Ratio) . Infrared distance: 10m . 12VDC, ±10%

46 Features: Specifications . Image Sensor :1/4〞CMOS
. Compact design ., 1/4″CMOS . Flickerless mode . Day / Night auto switch . Auto white balance, auto gain control, electronic shutter control . and backlight compensation . CS mount lens (provide adapter for C mount lens) . Internal synchronization   Specifications . Image Sensor :1/4〞CMOS . Signal System PAL / NTSC . Effective Pixels 640 (H) X 480 (V) . Sync. Sysyem Internal . Electronic Shutter Speed 1/25s to 1/15,000s . Horizontal Resolution 480 TVL . Video Output 1 Vp-p Composite Output . S/N Ratio 48 Db . Day & Night Electronic Shutter . Min. Illumination F1.2 . BLC  On / Off . Power Supply 12VDC . Operatiing Temperature -10℃ ~ 60℃ . Power Consumption 2W Max. . Dimension 48mmX52mmX70mm . Weight 550g

47 Features: Specifications
. Compact design . 1/3″Sony CCD . Flickerless mode . Day / Night auto switch . Auto iris with DC / video driver  . Auto white balance, auto gain control, electronic shutter control and backlight compensation . CS mount lens (provide adapter for C mount lens) . Internal synchronization   Specifications . Image Sensor:1/3〞Sony Super HAD CCD . Signal System :PAL / NTSC . Effective Pixels PAL: 500 (H) X 582 (V)NTSC: 510 (H) X 492 (V) . Sync. Sysyem :Internal . Electronic Shutter Speed :1/50(1/60)s to 1/100,000s . Horizontal Resolution :420 TVL . Video Output :1 Vp-p Composite Output . S/N Ratio: Over 48 dB Day & Night :Electronic Shutter Min. Illumination F1.2 BLC  :On / Off Power Supply :12VDC (〝-A〞Series Support 12VDC / 24VAC) Operatiing Temperature :-10℃ ~ 60℃ Power Consumption :2W Max. (〝-A〞Series 3.5W Max.) Dimension :63mmX59mmX114mm Weight :550g Lens Mount: C / CS Mount Auto Iris Input  :Yes

48 Features: Specifications: . Image Sensor:1/3” Sony Super HAD CCD
. Compact design . F1.2 . 420TVL resolution . Pan 0°, Tilt 90° . Day/night with auto switch . Auto white balance, auto gain control, electronic shutter control . and backlight compensation . Internal synchronization Specifications: . Image Sensor:1/3” Sony Super HAD CCD . Effective Pixels:DS-2CC502N: NTSC: 510×492 . Min, IIIumination: . Electronic Shutter Speed:1/50(1/60)s to 1/100,000s . Day& Night :Electronic Shutter . Lens :12mm . Horizontal Resolution:DS-2CC502N: 420 TVL . Sync. System: Internal . Video Output:1Vp-p Composite Output (75 ohms / BNC) . S/N Ratio : 48 dB . BLC: On . Operating Temperature:-10°C ~ 60°C . Power Supply:12VDC . Power Consumption:2W Max. . Dimension:138mmx87mm . Weight :380 g

49 Brand :HDPRO Model:HD-N239D Product Name:1/3 Inch Sony 3D-DNR Dome Camera
Features . 1/3” Sony Super HAD CCD TVL . Built-in Next Generation 3D DNR with 3D Filter . Max. Sens-Up (x258), Lux of Min .Illumination . Convenient OSD Control Function . x32 Digital Zoom . Negative Image Function . Free Area Selectable Function of BLC and MD . Privacy Masking of Maximum 8 Area . Camera OSD Control by RS-485 . ICR-IR Cut Filter Removable (option) . Max 70% of Disk Saving Effect with super DNR . Digital Wide Dynamic Range Function (D-WDR) . Daul Power (AC 24V / DC 12V)-Option Specifications . Sensor: 1/3" SONY SUPER HAD CCD . Total Pixels: NTSC=811(H) * 508(V) / PAL=795(H) * 595(V) . Effective Pixels: NTSC=768(H) * 494(V) / PAL=752(H) * 582(V) . Scanning System: 2:1 Interlace . Synchronization: Internal , O.S.D: Available . Backlight: BLC / HSBLC / Off Selectable . Resolution: 550TV Lines (Color), 600TV Lines (B/W) . S/N (Y signal): 52dB (AGC Off, Weight On) . Min. Illumination: 0.001Lux (Sens-Up X258) . White Balance: ATW / AWB / Manual / AWC→SET . Sense-Up: Off / Auto (Selectable limit *2 ~ *258x) . Gain Control: High, Middle, Low, Off Selectable . 3 DNR: Off/On (1~50 Level Adjustable) . D-WDR: Indoor / Outdoor / Off . Motion Detection: On/Off (4 Zone, Alarm Output) . Privacy: On/Off (8 Zone) , Weight: 300g . Mirror: Off / Mirror / V-Rev / Rotate . Digital Zoom: On(*32) / Off . Lens: DC Auto Iris Varifocal Lens(2.8mm-12mm) Dimension: 110mm(W)*75mm(H)*110mm(D)

50 Specifications Features . Main Board: Intel 845 chipset or higher
Brand: SECURA Model:SDVPC/ Product Name:16 CH Real Time PC Based DVR Features . All the 16 Channels are Real Time Recording & Playback with 25 FPS per camera (Totally 400FPS) and can be allotted variable frame rates for individual cameras. . 160 GB Hard disk - expandable for additional volume of data.   . Supporting to detachable hard-disk drive for taking backup & recording. . Multi Screen Display can be viewed. . Recorded data`s can be viewed from any other PC using the removable Hard Disk with recording. . Backup data can be taken through CD-R/W or DVD-Writer. . Can be controlled Pan / Tilt Cameras & Speed Dome Cameras with many protocols. Dedicated embedded keyboard available as optional. . Provision for user defined Motion / Sensor detection. . Recorded format is having playback facility for the same software only. . Scheduled record timing on weekdays & holidays. . Provision for LAN / WAN. . Industrial Based DVR Cabinet, exhaust fan facility with dust filters, . Multi level user password.   Specifications . Main Board: Intel 845 chipset or higher . Memory: Minimum 256MB DDR . Video Memory : Minimum 64MB . Hard Disk: IDE drive. At least two partition (C and D). 4MB for System Application . Operating System: Windows XP/2000 . Other Driver: DirectX 9.0 or above

51 Features Specifications
Brand: RAYSHARP Model:DF9008 Product Name:8CH StandAlone DVR H.264 Features . Stand-alone Linux2.6 operation system . Graphics & Windows OSD interface . Removable SATA HDD tray with key lock . ADPCM audio compression . Support pentaplex operation: live, record, playback, backup . Support to operate with USB mouse . Support to backup & upgrade with USB flash disk . Support to real-time remote view with IE (Internet Explorer) . Support PTZ control via built-in RS-485 port . Selectable packing time for recording files . Self-recovery after power reconnected . Optional DVD-RW for backup Specifications . Video System: NTSC / PAL . Video Compression: H.264 . Operation System: Linux . Video Input / Output:  BNC 8-channel inputs / 2-channel outputs . Audio Compression:  8kHz*16bit ADPCM . Audio Input / Output:  RCA 1-channel input / 1-channel output .Display Frame Rate: PAL: 200fps / NTSC: 240fps . Playback Resolution:  PAL: CIF(352x288) / NTSC: CIF(352x240) . Total Recording Frame Rate: PAL: / NTSC: . Recording Mode:  Always / schedule / motion detection / sensor triggered . Recording Pack Time: 15/30/45/60mins selectable . HDD Interface: Default: 1 removable SATA HDD tray, support up to 1TB HDD . With DVD-RW: 1 fixed SATA HDD rack, support up to 1TB HDD . Network Interface: RJ45, 10M/100M . Network Protocol: Support TCP/IP, UDP, DHCP, DNNS, PPPoE . Network Function: Support to live view with IE (Internet Explorer) & with Mobile phones . USB2.0: USB mouse, USB disk (backup, upgrade) . Playback Local: playback 1 channel simultaneously . Network: playback 1 channel simultaneously . Senor & Alarm: I/O 8 sensor inputs / 1 alarm output . Power Supply: DC 12V/3A (power adaptor included) . Dimension: 400 x 275 x 70mm (W)

52 Brand: RAYSHARP Model:DF9004 Product Name:4CH StandAlone DVRH.264
Features . H.264 real-time high compression, . Stand-alone Linux2.6 operation system . Graphics & Windows OSD interface . Removable SATA HDD tray with key lock . Support D1, HD1 and CIF recording resolution . ADPCM audio compression . Support Pentaplex operation: live, record, . Support to operate with USB mouse . Support remote view with Mobile Phones (based on Windows Mobile, Symbian S60 3rd& iPhone) . Support to backup & upgrade with USB flash disk . Support to real-time remote view with IE (Internet Explorer) . Support to transmit audio via network . Support PTZ control via built-in RS-485 port . Selectable packing time for recording files . Optional VGA output Specifications Video Compression: H.264 Video System: NTSC / PAL Operation System: Linux , Dimension: 400 x 275 x 70mm (W x D x H) Video Input / Output:  BNC 4-channel inputs / 2-channel outputs Audio Compression:  8kHz*16bit ADPCM Audio Input / Output:  RCA 4-channel input / 2-channel outputs Display Frame Rate PAL: 100fps / NTSC: 120fps Playback Resolution  PAL: CIF(352x288), HD1(704x288), D1(704x576) NTSC: CIF(352x240), HD1(704x240), D1(704x480) Total Recording Frame Rate PAL: /  NTSC: Recording Mode:  Always / schedule / motion detection / sensor triggered Recording Pack Time: 15/30/45/60mins selectable Playback Local: playback 4 channels simultaneously Network: playback 1 channel simultaneously Playback Mode: Normal play, fast forward, fast rewind, frame by frame Backup Methods:  USB flash disk, USB disk, built-in or USB CD/DVD-RW, Network PTZ Control: Built-in RS485, support PELCO-P & PELCO-D Alarm Mode: Motion Detection, Sensor triggered, video loss, HDD error, HDD full Senor & Alarm: I/O 4 sensor inputs / 1 alarm output

53 Features DS-8004 HCI Real Time OS Embedded MCU
High performance DSP hardware compression. Specifications Video compression :H.264 Resolution :4CIF real time(PAL: 704*576) Playback resolution :CIF/QCIF real time Video input :4 BNC (1.0Vp-p, 750) Composite video output :1 channel, BNC (1.0Vp-p, 75O Frame rate :PAL: PAL: 1/16 ~ 25FPS Keyboard interface :2 RJ45 ports USB interface :1 USB 1.1 port Power supply :100~240VAC, 6.3A, 50~60Hz Power consumption :20-42W (without HDD and CD-R/W) Working humidity :10%--90% Size :19” Standard (450mm*450mm*95mm) Weight :≤8Kg (without HDD and CD-R/W Working temperature :-10℃--+55℃

54 Features DS-8004HSI Specifications
Real Time OS Embedded MCU High performance DSP hardware compression. Specifications Video compression :H.264 Resolution :4CIF real time (PAL: 704*576,  NTSC: 704*480) Playback resolution :CIF/QCIF real time Video input :4 BNC (1.0Vp-p, 75Ω) Main video output :channel, BNC (1.0Vp-p, 75Ω) Frame rate :PAL: 1/16—25FPS,  NTSC: 1/16—30FPS RS-485 Port :1 Port (T+, T-, R+, R-) Keyboard interface :1 Port (D+, D-) USB interface :1 USB interface, USB1.1, can support USB flash memory Power supply :100~240VAC, 6.3A, 50~60Hz Power consumption :20-42W (without HDD and CD-R/W) Working humidity :10%--90% Size :19” Standard (450mm*450mm*95mm) Weight :≤8Kg (without HDD and CD-R/W Working temperature :-10°C ~ +55°C

55 DS-8004HFI Features Specifications Real Time OS Embedded MCU
High performance DSP hardware compression. Specifications . Video compression: H.264 . Preview resolution: 4CIF . Compress resolution: DCIF real time . Video input: 4/8/12/16 channels BNC (1.0Vp-p, 75O . Monitor video output: 1 channel BNC (1.0Vp-p, 75O)) . Frame rate/Ch: PAL: 1/16~25 FPS . Audio output: 1 channel BNC (liner output, 600O) . Audio compression: Audio compression . Voice interface: 1 BNC (Liner in, 1KO) . Keyboard interface: 2 RJ45 port (support device cascade) . VGA interface: 1, Support 800x600/60Hz,800x600/75Hz,1024x768/60Hz . Power supply: 100~240VAC, 6.3A, 50~60Hz . Power consumption: 22W ~42W (without HDD . Working humidity: 10% ~ 90% . Weight: 7.6Kg (without HDD)

56 4Channel DS7204HVI-S Features:
. HIKVISION 4ch video, 1ch audio, H.264 Compression . Support DUAL STREAM, 1 main output & 1 spot output. . 120/100 FPS. Resolution CIF Realtime every Ch. . Storage 1*HDD SATA (up to 2TB) . Remote Control, Mouse Control, USB, VGA, PTZ, Audio Rec, DDNS . Include Total client software & SDK . Advanced motion detection,including privacy mask ,tampering and video loss alerts . Pre/ Post –recording of alarm & motion detected events . System logging Including operation, alram & user defined events . Support mouse & IR Remote . Built in reporting of various alarms ,including hard disk errors unauthorized log ins and network conflits . Full feature remote access with client software and web browser . Upload of alarm events to remote management host

57 Features: Specifications Brand: RAYSHARP Model:D9216-AV
Product Name:16CH H.264 A/V StandAlone DVR Features: . 4 SATA HDD Is Supported (Tested with 750GB) . Good GUI Interface . In Live Mode 2x Zooming . Pentaplex operation at a time. . Supports single channel & 4Ch playback with Max. 16X Fast Forward . Mobile Surveillance Is Possible . CMS Software Supports 144 Channels . Supports IE LAN, Static IP and DDNS. . Pelco-D, Pelco-P Protocol Is Supported. . Supports Preset and Tour functions. . Support Keyboard Controller. . E Mail Notification Available . USB backup supports Pen drive & HDD &DVD-RW with help Of Player Software Can Be viewed. . . Backup Can Be Played In AVI Format Through Media player 9 and above. . Client software is supported for this stand alone DVR Specifications . 16 Ch Video & 16 Ch Audio Input . 2 Ch Video   &   2 Ch Audio output . 16 Ch Loop Out & 1 Ch Line In & 1 VGA . 2nos USB Ports available . RJ-45, RS-485 & RS-232 . 16Ch Alarm Input & 4 Ch Alarm Output . Control trough front panel buttons Remote controller & USB Mouse. . Supports Full Audio. . Supports internally 4HDDs. . Supports Loop through function. . Standard Resolution. . Power Off  Function Is Possible

58 Specifications DS-8000HSI Features Embedded OS; Embedded MCU;
High performance DSP hardware compression; Specifications . Video compression:H.264 . Preview resolution :PAL: 704*576(4CIF)     NTSC: 704*480(4CIF) . Video input  :4/9/16 channels BNC (1.0Vp-p, 75Ω) . Video loop  :4/9/16 channels BNC (1.0Vp-p, 75Ω) . Monitor video output  :1 channel BNC (1.0Vp-p, 75Ω) . Aux video output :16 x 4 (DS-8016HSI) BNC (1.0Vp-p, 75Ω) . Frame rate  :PAL: 1/ FPS;    NTSC: 1/ FPS . Stream type  :Video stream . Bit rate  :32kbps--2Mbps (Self definition) . Communication interface  : 1 RJ45 port . Keyboard interface :1 RJ45 port . Device cascade interface:1 RJ45 port . Relay output : DS-8004HSI: 2 output . Weight :7.6Kg (without HDD) . Working temperature :-10℃--+55℃ . Working humidity  :10%--90%

59 Specifications Brand: Hikvision Product Name:16CH DVR
FEATURES: . Hard drive standby function . Hard drive file system is compatible with Windows . Supports DDNS . alert configuration . PTZ Supported . VGA: 1280x1024 . CMS Software included . Pentaplex operation enables simultaneous recording, live view, playback, back-up and network operations .Internet Ready for remote viewing & cell phone access (Blackberry & Windows Based phones) Advanced motion detection and analytics, including privacy mask, tampering and video loss alerts . Pre/Post-recording of alarm and motion detected events . PTZ controls with preset, patrol and pattern settings . Multi-user level management with password protection . Full system logging including operation, alarm and defined events . Supports input from front panel, mouse, IR remote and keyboard operation . Built-in reporting of various alarms, including hard disk errors, unauthorized log-ins & network conflicts . Full feature remote access with client software and web browser . Easy backup to USB and optical drives . Lock and unlock video files . Supports NTP (Network Time Protocol) and SADP (Search Activated Device Protocol) . Rack mountable ears included Specifications . Operating System: EMDEDDED MCU & LINUX OS FOR DUAL STREAMING . Camera Inputs: 16 Channel . Video Outputs:  1 VGA (1280x1024) / 1 BNC; 1 BNC SPOT MONITOR . Compression:  H.264 . Recording Frame Per Channel: 2CIF: 30 FPS / 4CIF: 15 FPS Display Frame: 480 FPS (NTSC) . Recording Resolution: 704x480 (4CIF), 704x240 (2 CIF), 352x240 (CIF) .  Pentaflex: LIVE, RECORDING, PLAYBACK, NETWORKING, BACKUP AT THE SAME TIME . Sensor In/ Alarm Out:  16 IN / 4 OUT . Audio:  16 IN/ 2 OUT (OggVorbis, 16Kbps COMPRESSION) .  Bit Rate:  32Kbps ~ 2Mbps; USER DEFINED . System Control:  FRONT BUTTONS, IR REMOTE CONTROL, MOUSE SUPPORTED . Recording Modes: NORMAL, EVENT, ALWAYS + EVENT, SENSOR, SCHEDULE, MANUAL.

60 Features Specifications . 4" B/W Flat CRT Monitor . Support 2 Cameras
Brand: COMMAX Model:DPV-4HP2+DRC-4BP Product Name:4 Inch B/W Flat CRT Monitor Product Warranty:365 Days Features . 4" B/W Flat CRT Monitor . Support 2 Cameras . Extendable video door phone & interphone . Easy installation 4 wires . Free Voltage (AC 100V ~ 240V) . Wall surface mount type Specifications . Rating Voltage: AC V ~ 50/Hz ,Consumption: Operation:16W . Wiring method: To a Camera unit: 4 wires polarity, To an . Interphone: 4wires polarity , Monitor: 4" CRT . Communication method: Full duplex (Handset) . Call tone: Call sound from camera: electronic chime, . Interphone: electronic buzzer ,Monitor Display: 90 ± 22sec . Distance from camera: 28m (0.5)/50m(0.65)/70m(0.8) . Working Temperature: 0 ~ + 40°C (32°F~104°F) . Weight: 1.2Kg , Dimension(mm): 189(W) x 208(H) x 56.5(D) . DRC-4BP/4CP,Resolution: pixel CCd . Rated voltage: DC 12V (supplied from the monitor) . Wiring method (household): 4-wire polarity . Effective Viewing Angle: Horizontal: 55°, Vertical: 40° . Angle Adjustment: 30° Left, 30° Right, Center . Horizontal/Vertical Scanning Frequency: kHz/60Hz, kHz/50Hz . Ambient Temperature: -10°C ~ +50°C,Weight(g): 250g (including B/K) . External Dimensions(mm): 50.2(W) x 118(H) x 52(D)mm

61 Features: Specifications Input Voltage 100 to 270V AC
Brand :SECURA Model:F16-200S12-18 Product Name : SMPS Power Supply Unit Features: Removable type 3pin power card for input. 18CH Screw terminals for Output There is no Voltage drop at 750mA Power On Indicator with fuse is Available for independent Output. Can connect up to 18Nos PCB Cameras Metal Box with Lock & Key feature CE Certified. Specifications Input Voltage 100 to 270V AC Frequency 50 to 60 Hz Output 12V - 5Amp. X 2Nos 18CH Terminal with independent Power on Indicator & Fuse.

62 Specifications Features
Brand: TIANDY Model:TC-FD16013T/R Product Name:16CH Digitally Encoded Video/ CH Bi-Directional Data Multiplexer Features . 16ch video/1ch bi directional data . 8-Bit Digitally Encoded Video Transmission . Transmit up to 30km without Optical Attenuation . Simultaneous Transmission of Video and Data . No EMI, RFI, Cross Talk and Ground Loop . LED Indicators Instantly Monitoring System Performance . Wide Optical Dynamic Range . No Electrical or Optical Adjustments Required. . NTSC, PAL or SECAM Compatible Specifications . Video Input: 1 volt pk-pk (75 ohms) ,Input/Output Channels: 16 . Bandwidth: 5 Hz - 8 MHz ,Bit Resolution: 8-bit . Differential Gain: < 2% ,Differential Phase: < 0.6° . Tilt: < 1% ,S/N Ratio: 67dB (Weighed) . Optical Emitter: Laser Diode ,Number of Fibers: 1 . Data Interface: RS-485 ,Data Rate: 0~256 Kbps . Optical: ST (SC & FC Optional) ,Video: BNC . Data: DB9F ,Power Supply: AC 110 / 220V . Size: 482mm×248mm×68mm ,Construction: Aluminum . Finish: Black Paint ,MTBF: > 100,000 hours . Operating Temp: -30°C to +75°C . Relative Humidity: 0% to 95% (no condensing) . WAVELENGTH: 1310/1550nm Single mode

63 Specifications Features
Brand: TIANDY Model:TC-FD8228T/R Product Name:8CH Digitally Features . 8ch video/2ch data . 8-Bit Digitally Encoded Video Transmission . Transmit up to 30km without Optical Attenuation . Simultaneous Transmission of Video and Data . No EMI, RFI, Cross Talk and Ground Loop . LED Indicators Instantly Monitoring System Performance . Rack or Standlone type . WDM Technology for Highest Quality Video Transmission . Wide Optical Dynamic Range . No Electrical or Optical Adjustments Required. . NTSC, PAL or SECAM Compatible Specifications . Video Input: 1 volt pk-pk (75 ohms) . Input/Output Channels: 8 . Bandwidth: 5 Hz - 8 MHz ,MTBF: > 100,000 hours , . it Resolution: 8-bit ,Differential Gain: < 2% . Differential Phase: < 0.6° . Tilt: < 1% ,S/N Ratio: 67dB (Weighed) . Data Rate: 100Kbps ,Data Interface: RS-485 . Data Channels: 2 ,Data Rate: 100Kbps . Optical Emitter: Laser Diode . Number of Fibers: 1 . Optical: ST (SC & FC Optional) . Video: BNC .Data: DB9F . Power Supply: AC 110/ 220V . Size: 482mm×248mm×45mm . Construction: Aluminum ,Finish: Black Paint . WAVELENGTHl: 850/1310nm, Multimode & 1310/1550nm, Singlemode

64 Specifications Features
Brand:TIANDY Model:TC-FD4419K4BT/R Product Name:4CH OFC Transmiter Reciever Features . 4ch video/1ch bi directional data/ 4ch bi directional audio/4ch bi directional contact closure . 8-Bit Digitally Encoded Video Transmission . Transmit up to 30km without Optical Attenuation . Simultaneous Transmission of Video and Data . No EMI, RFI, Cross Talk and Ground Loop . LED Indicators Instantly Monitoring System Performance . Rack or Standlone type . WDM Technology for Highest Quality Video Transmission . Wide Optical Dynamic Range . No Electrical or Optical Adjustments Required. . NTSC, PAL or SECAM Compatible Specifications . Video Input: 1 volt pk-pk (75 ohms) . Input/Output Channels: 4 . Bandwidth: 5 Hz - 8 MHz . Bit Resolution: 8-bit Differential Gain: < 2% . Differential Phase: < 0.6° . Tilt: < 1%, S/N Ratio: 67dB (Weighed) . WAVELENGTH: 1310nm, Multimode & 1310nm, Singlemode . OPTICAL EMITTER: Laser Diode . NUMBER OF FIBERS: 1 Construction: Aluminum . Optical: ST (SC & FC Optional) . Video: BNC ,Power Supply: 300mA . Size: 195mm×191mm×36mm . Finish: Black Paint , MTBF: > 100,000 hours . Operating Temp: -30°c to +50°C ,Storage Temp: -40°C to +85°C . Relative Humidity: 0% to 95% (no condensing)

65 Specifications Features
Brand: TIANDY Model:TC-FD2119TRS-ST Product Name:2-CH Digitally Encoded Video/ BI-Directional Data & Audio Features . 2ch video/1ch bi directional data/1ch bi directional audio . 8-Bit Digitally Encoded Video Transmission . 24-Bit Digitally Encoded Stereo Audio Transmission . Transmit up to 30km without Optical Attenuation . Simultaneous Transmission of Video and Data . No EMI, RFI, Cross Talk and Ground Loop . LED Indicators Instantly Monitoring System Performance . Rack or Standalone type . WDM Technology for Highest Quality Video Transmission . Wide Optical Dynamic Range . No Electrical or Optical Adjustments Required. . NTSC, PAL or SECAM Compatible Specifications . Video Input: 1 volt pk-pk (75 ohms) . Input/Output Channels: 2 . Bandwidth: 5 Hz - 8 MHz ,Bit Resolution: 8-bit . Differential Gain: < 2% ,Differential Phase: < 0.6° . Tilt: < 1% ,S/N Ratio: 67dB (Weighed) . Data Interface: RS-485, RS-422, RS-232 . Data Rate: 100Kbps ,Bit Error Rate: 10 . Audio Impedance: 600 ohms . Input/output Level: 0dBm(typical) . Bit Resolution: 24-bit ,S/N Ratio: 88dB . Wavelength: 850/1310nm, Multimode / 1310/1550nm, Singlemode . Laser: Diode , Size: 195mm×191mm×36mm .Number of Fibers: 1 , Video: BNC . Optical: ST (SC & FC Optional) . Data/Audio: Shield RJ-45 Plug . Construction: Aluminum . Finish: Black Paint , MTBF: > 100,000 hours

66 Features Specifications
Brand: TIANDY Model:TC-FD2013T/R Product Name:2CH Video / 1CH Di-Directional Data T/R Features . 2ch video/1ch bi directional data . 8-Bit Digitally Encoded Video Transmission . Transmit up to 30km without Optical Attenuation . Simultaneous Transmission of Video and Data . No EMI, RFI, Cross Talk and Ground Loop . LED Indicators Instantly Monitoring System Performance . Rack or Standalone type . WDM Technology for Highest Quality Video Transmission . Wide Optical Dynamic Range . No Electrical or Optical Adjustments Required. . NTSC, PAL or SECAM Compatible Specifications . Video Input: 1 volt pk-pk (75 ohms) . Input/Output Channels: 2 . Bandwidth: 5 Hz - 8 MHz . Bit Resolution: 8-bit . Differential Gain: < 2% ,Differential Phase: < 0.6° . Tilt: < 1% ,S/N Ratio: 67dB (Weighed) . Data Interface: RS-485, RS-422, RS-232 . Data Rate: 100Kbps ,Bit Error Rate: 10 . Optical: ST (SC & FC Optional) . Video: BNC ,Data: Shield RJ-45 Plug . Power Supply: 300mA . Size: 195mm×191mm×36mm . Construction; Aluminum ,Finish: Black Paint . MTBF: > 100,000 hours . Operating Temp: -30°C to +50°C . Storage Temp: -40°C to +85°C . Relative Humidity: 0% to 95% (no condensing) . Wavelength: 850/1310nm, Multimode & 1310/1550nm, Singlemode . Optical Emitter: Laser Diode ,Number of Fibers: 1

67 Brand: IANDY Model:TC-FD1013T/R Product Name:1CH Video / 1CH Bi-Directional Data T/R
Features . 1ch video/1ch bi directional data . 8-Bit Digitally Encoded Video Transmission . Transmit up to 30km without Optical Attenuation . Simultaneous Transmission of Video and Data . No EMI, RFI, Cross Talk and Ground Loop . LED Indicators Instantly Monitoring System Performance . Rack or Standlone type . WDM Technology for Highest Quality Video Transmission . Wide Optical Dynamic Range . No Electrical or Optical Adjustments Required. . NTSC, PAL or SECAM Compatible Specifications Video Input: 1 volt pk-pk (75 ohms) Bandwidth: 5 Hz - 8 MHz Bit Resolution: 8-bit Differential Gain: < 2% Differential Phase: < 0.6° Tilt: < 1% S/N Ratio: 67dB (Weighed) Data Interface: RS-485, RS-422, RS-232 Data Rate: 100Kbps Optical: ST (SC & FC Optional) Video: BNC Data: Shield RJ-45 Plug Optical Emitter : Laser Diode Power Supply: 300mA Size: 119mm×135mm×36mm Construction: Aluminum MTBF: > 100,000 hours Operating Temp: -30°C to +50°C Storage Temp: -40°C to +85°C Humidity: 0% to 95% (no condensing) Wavelength: 850/1310nm, Multimode & 1310/1550nm, Singlemode

68 Specifications Features:
Brand: TIANDY Model:TC-FD1012T/R Product Name:1CH Video Transmiter / Reciever Features: . 1-channel Video/ 1-channel return data   . 8-Bit Digitally Encoded Video Transmission . Transmit up to 30km without Optical Attenuation . Simultaneous Transmission of Video and Data . No EMI, RFI, Cross Talk and Ground Loop . LED Indicators Instantly Monitoring System Performance . Rack or Standlone type . WDM Technology for Highest Quality Video Transmission . Wide Optical Dynamic Range . No Electrical or Optical Adjustments Required. . NTSC, PAL or SECAM Compatible Specifications . Video Input: 1 volt pk-pk (75 ohms) . Bandwidth: 5 Hz - 8 MHz . Bit Resolution: 8-bit . Differential Gain: < 2% . Differential Phase: < 0.6° . Tilt: < 1% . Finish: Black Paint . S/N Ratio: 67dB (Weighed) . Data Interface: RS-485, RS-422, RS-232 . Data Rate: 100Kbps . Optical: ST (SC & FC Optional) . Video: BNC . Number of Fibers: 1 . Data: Shield RJ-45 Plug . Optical Emitter : Laser Diode . Power Supply: 300mA . Size: 119mm×135mm×36mm . Construction: Aluminum . Operating Temp: -30°C to +50°C . MTBF: > 100,000 hours. Storage Temp: -40°C to +85°C . Humidity: 0% to 95% (no condensing) . Wavelength: 850/1310nm, Multimode & 1310/1550nm, Singlemode

69 Features: Specifications
Brand:TIANDY Model:TC-FD1001T/R Product Name:1CH Video Transmiter / Reciever Features: . 1-channel Video . 8-Bit Digitally Encoded Video Transmission . Transmit up to 30km without Optical Attenuation . Simultaneous Transmission of Video and Data . No EMI, RFI, Cross Talk and Ground Loop . LED Indicators Instantly Monitoring System Performance . WDM Technology for Highest Quality Video Transmission. Wide Optical Dynamic Range . No Electrical or Optical Adjustments Required. . NTSC, PAL or SECAM Compatible Specifications . Video Input: 1volt pk-pk (75 ohms) . Bandwidth: 5 Hz - 8 MHz . Bit Resolution: 8-bit . Differential Gain: < 2% . Differential Phase: < 0.6° . Tilt: < 1% . S/N Ratio: 67dB (Weighed) . Optical: ST (SC & FC Optional) . Video: BNC . Power Supply: 300mA . Size: 119mm×135mm×36mm . Construction: Aluminum ,Finish: Black Paint . MTBF: > 100,000 hours . Operating Temp: -30°C to +50°C . Storage Temp: -40°C to +85°C . Relative Humidity: 0% to 95%(no condensing) . Wavelength: 1310nm, Multimode & 1310nm, Singlemode . Optical Emitter: Laser Diode . Number of Fibers: 1

70 •DS –PCI Comression Card
Features • H.264 (MPEG-4/Part 10) real-time video compression • OggVorbis real-time audio compression • Up to real-time 4CIF recording • PCI 2.2 standard • Support Windows 2000/XP/2003/Vista and Linux operating system • Provide full SDK and demo source code • Support variable bit rate and frame rate • Motion detection • Support OSD, LOGO, and MASK overlay Specifications . Video compression H.264 . Video input 4-ch 8-ch 16-ch . Video input interface BNC (1.0Vp-p, 75Ω) . Audio compression OggVorbis, 16Kbps . Audio input 4-ch 8-ch 16-ch . Audio input interface BNC(2Vp-p, 1kΩ) . Preview resolution 4CIF real time . Video bit rate 32Kbps ~ 2Mbps . Stream type Video/Video&Audio . Dual stream Yes . Power consumption < 3.5W < 7W < 22W . Working temperature -10°C~+50°C . Working humidity 10%~90% . Dimension 155mmx95mm 201mmx109mm 250mmx106mm . OS Windows 2000/XP/Server 2003/Vista, Fedora 8 . CPU Intel series . Memory 256MB or above . Display Adapter

71 Brand: SECURA Model:SVD-8160 Product Name:16CH Video 8CH Audio
Features . 16CH PCI or PCI-Ex High Speed Interface. . Enhanced H.264 compression, watermark supported. . 10-Bit Comb Noise Filter ADC, better video quality. . Support Up to 32 Video Channels for One Server. . Network Client Side 32 Channels Previewing. . Remote Access / Contral / Playback via IE Browser or Client Software. . Support Dynamic DNS. . Support High Resolution VGA display, . Playback Backup Files on third part video player, such as Medial Player. . Recording mode: Motion detection / Continuous / Alarm / Schedule. Specifications . Pre-Recording When Motion Detection is triggered. . Motion Detection Sensibility Adjustable Respectively. . Video Lost Voice Alarm, Motion Detection Voice Alarm. . Alarm to in motion detection mode (Optional). . PTZ (Pan Tilt Zoom) Camera Control Locally & Remotely. . ulti Level Authorization Protection. . Multi Language Letter, Date and Time Embedded in Clips for Law Enforcement.

72 Features Specifications
Brand: SECURA Model:SVD Product Name:4 CH MPEG-4 Video / Audio DVR Card Features . 4 CH  Real Time Audio & Video Compression . Total Frame Rate per Card : 100 FPS (PAL) . Audio Code output rate: 8kbps . Audio Compression: G.729; Video: H.264 . One PC supports maximum 6 cards     . Real-time video compression, never loss frame . Compression resolution: 352x288 (PAL) . Code stream output: 70kbps-l000kbps . Support Motion Detect & log information . Bright, contrast, Chroma and saturation of video signal adjustable. . Be able to set water-mark. . Using H.264 video compression standard, high video quality, bandwidth just 8kbps .Resolution of previewing image is CIF. . Video signal and audio signal don`t interface. . Support Motion Detect & log information . Bright, contrast, Chroma and saturation of video signal adjustable. . Be able to set water-mark. . Using H.264 video compression standard, high video quality, . Resolution of previewing image is CIF. . Video signal and audio signal don't interface. Specifications . Main Board: Intel 845 chipset or higher . Memory: Minimum 256MB DDR . Video Memory : Minimum 64MB . Hard Disk: IDE drive. At least two partition (C and D). 4MB for System Application . Operating System: Windows XP/2000 . Other Driver: DirectX 9.0 or above

73 Brand: SECURA Model:SVD-9004 Product Name:4Ch DVR Card
Features . 4 CH  Real Time Audio & Video Compression . Total Frame Rate per Card : 100 FPS (PAL) . Video: H.264 . One PC supports maximum 6 cards     . Real-time video compression, never loss frame . Compression resolution: 352x288 (PAL) . Code stream output: 70kbps-l000kbps . Support Motion Detect & log information . Bright, contrast, Chroma and saturation of video signal adjustable. . Be able to set water-mark. . Using H.264 video compression standard, high video quality, , each channel supports ClF compression . Standard, bandwidth just 8kbps   . Resolution of previewing image is CIF. . Support motion detection, time machine, water-mark . Be able to set frame and image. Specifications . Main Board: Intel 845 chipset or higher . Memory: Minimum 256MB DDR . Video Memory : Minimum 64MB . Hard Disk: IDE drive. At least two partition (C and D). 4MB for System Application . Operating System: Windows XP/2000 . Other Driver: DirectX 9.0 or above

74 Features Specifications
Brand: LOOKMAN Model:LH-804T Product Name:4 CH - H.264 Audio / Video DVR Card Features . H.264 encoder cards in LH-800 series are based on H.264/A_law compression standard and powerful DSP DM645 from TI. Video and audio can be kept entirely synchronous, video resolution supports CIF or Full D1 and frame ratio of video is adjustable continuously which can be up to 25frames/sec(PAL) or 30frames/sec(NTSC). Multiple boards can be installed on one PC and up to 32 channels encoding with max frame rate working together on one PC. . LH-800 series supports more than 64 channels real-time video preview.  It provides full functions as required by DVR applications: such as encoding and playback, motion detection, OSD, video and audio preview, series ID number etc. All above functions do not need extra CPU resource of host PC. Specifications . Encoder Real time H.264 Base Profile (MPEG4 Part 10) . Supports Constant Bit Rate (CBR) and Variable Bit Rate (VBR) . Support up to 64 channels encoding at the same time on one PC . Resolution CIF compression: 352x240 (NTSC), 352x288 (PAL) . Video Bit Rate:  60kbit/sec to 2Mbit/sec (Variable Bit Rate) . 384kbit/sec to 2Mbit/sec (Constant Bit Rate) . Frame Rate:  30 fps per channel (NTSC), 25 fps per channel (PAL) . Real time preview, recording and playback . Setup: Setup all parameters while encoding  . Video Filter:  Hardware filter to de-interlace and reduce noise . Video Input:  4 channels CVBS signal Composite video/BNC 1 Vp-p, 75Ω  . Motion Detection:  Multi-area detection powered by hardware . Detection by active area and sensitive priority . Time Code:  Add TT: MM: DD and HH: MM: SS: FF format data in video . Logo: Add fixed picture and set mosaic area in video . Video Masks:  Provide video mosaic region for each channel . Alarm: Video loss alarm . Security: Each card has its unique serial number . Power: Usage  Less than 1W for each channel

75 Brand: SECURA Model:SVD-8080 Product Name:8CH Video 4CH Audio
Features . 8CHPCI or PCI-Ex High Speed Interface. . Enhanced H.264 compression, watermark supported. . 10-Bit Comb Noise Filter ADC, better video quality. . Support Up to 32 Video Channels for One Server. . Network Client Side 32 Channels Previewing. . Remote Access / Contral / Playback via IE Browser or Client Software. . Support Dynamic DNS.. . Support High Resolution VGA display, automatically detect. 1024x768, . Video Previewing Disable Function, Protecting Private Monitoring. . Playback Backup Files on third part video player, such as Medial Player. Specifications . Playback Backup Files on third part video player, such as Medial Player. . Recording mode: Motion detection / Continuous / Alarm / Schedule. . Pre-Recording When Motion Detection is triggered. . Motion Detection Sensibility Adjustable Respectively. . Video Lost Voice Alarm, Motion Detection Voice Alarm. . Alarm to in motion detection mode (Optional). . PTZ (Pan Tilt Zoom) Camera Control Locally & Remotely. . Multi Level Authorization Protection. . Multi Language Letter, Date and Time Embedded in Clips for Law Enforcement.

76 Brand: SECURA Model:SVD-8080 Product Name:8CH Video 4CH Audio
Features . 8CHPCI or PCI-Ex High Speed Interface. . Enhanced H.264 compression, watermark supported. . 10-Bit Comb Noise Filter ADC, better video quality. . Support Up to 32 Video Channels for One Server. . Network Client Side 32 Channels Previewing. . Remote Access / Contral / Playback via IE Browser or Client Software. . Support Dynamic DNS. . Support High Resolution VGA display, automatically detect 1024x768, 1280x1024, 1440x900 . Video Previewing Disable Function, Protecting Private Monitoring. . Playback Backup Files on third part video player, such as Medial Player. . Recording mode: Motion detection / Continuous / Alarm / Schedule. Specifications . Playback Backup Files on third part video player, such as Medial Player. . Recording mode: Motion detection / Continuous / Alarm / Schedule. . Pre-Recording When Motion Detection is triggered. . Motion Detection Sensibility Adjustable Respectively. . Video Lost Voice Alarm, Motion Detection Voice Alarm. . Alarm to in motion detection mode (Optional). . PTZ (Pan Tilt Zoom) Camera Control Locally & Remotely. . Multi Level Authorization Protection. . Multi Language Letter, Date and Time Embedded in Clips for Law Enforcement.

77 Brand: SECURA Model:SVD-9008 Product Name:8Ch DVR Card
Specifications . Video Input : 8 Channels . Compression : MPEG-4  . Resolution : 352x288(PAL) . Frame Rate :  200fps  . Motion Detection : Yes Features: . Combination of local and remote-end control function . Intelligent search and reply of Video materials, reliable way of storing video materials, multi-picture division and alternate display, unlimited expansion through network . 8 CH Real Time Recording & Monitoring (200 FPS). . Remote control and recording through transmission network (local network, Internet, ISTN, Leased line) . Intelligent and dynamic frame monitoring compression . Adjustable picture size, picture quality and recording speed, capable of catching pictures to print out through printer, Random catch and storage while replaying video materials.

78 Features Specifications
Brand: LOOKMAN Model:LH-816T Product Name:16 CH - H.264 Audio /Video DVR Card Features . H.264 encoder cards in LH-800 series are based on H.264/A_law compression standard and powerful DSP DM645 from TI. Video and audio can be kept entirely synchronous, video resolution supports CIF or Full D1 and frame ratio of video is adjustable continuously which can be up to 25frames/sec(PAL) or 30frames/sec(NTSC). Multiple boards can be installed on one PC and up to 32 channels encoding with max frame rate working together on one PC. . LH-800 series supports more than 64 channels real-time video preview.  It provides full functions as required by DVR applications: such as encoding and playback, motion detection, OSD, video and audio preview, series ID number etc. All above functions do not need extra CPU resource of host PC. Specifications . Encoder Real time H.264 Base Profile (MPEG4 Part 10) . Supports Constant Bit Rate (CBR) and Variable Bit Rate (VBR) . Support up to 64 channels encoding at the same time on one PC . Resolution CIF compression: 352x240 (NTSC), 352x288 (PAL) . Video Bit Rate:  60kbit/sec to 2Mbit/sec (Variable Bit Rate) . 384kbit/sec to 2Mbit/sec (Constant Bit Rate) . Frame Rate:  30 fps per channel (NTSC), 25 fps per channel (PAL)  . Real time preview, recording and playback . Setup: Setup all parameters while encoding  . Video Filter:  Hardware filter to de-interlace and reduce noise . Video Input:  16 channels CVBS signal Composite video/BNC 1 Vp-p, 75Ω . Time Code:  Add TT: MM: DD and HH: MM: SS: FF format data in video . Logo: Add fixed picture and set mosaic area in video . Video Masks:  Provide video mosaic region for each channel . Alarm: Video loss alarm . Security: Each card has its unique serial number . Power: Usage  Less than 1W for each channel 0

79 Specifications Features
Brand: LOOKMAN Model:LH-808T Product Name:8 CH - H.264 Audio / Video DVR Card Features . H.264 encoder cards in LH-800 series are based on H.264/A_law compression standard and powerful DSP DM645 from TI. Video and audio can be kept entirely synchronous, video resolution supports CIF or Full D1 and frame ratio of video is adjustable continuously which can be up to 25frames/sec(PAL) or 30frames/sec(NTSC). Multiple boards can be installed on one PC and up to 32 channels encoding with max frame rate working together on one PC. . LH-800 series supports more than 64 channels real-time video preview.  It provides full functions as required by DVR applications: such as encoding and playback, motion detection, OSD, video and audio preview, series ID number etc. All above functions do not need extra CPU resource of host PC. Specifications . Encoder Real time H.264 Base Profile (MPEG4 Part 10) . Supports Constant Bit Rate (CBR) and Variable Bit Rate (VBR) . Support up to 64 channels encoding at the same time on one PC Resolution . CIF compression: 352x240 (NTSC), 352x288 (PAL) . Video Bit Rate:  60kbit/sec to 2Mbit/sec (Variable Bit Rate) . 384kbit/sec to 2Mbit/sec (Constant Bit Rate) . Frame Rate:  30 fps per channel (NTSC), 25 fps per channel (PAL) Real time preview, recording and playback . Setup: Setup all parameters while encoding  . Video Filter:  Hardware filter to de-interlace and reduce noise . Video Input:  8 channels CVBS signal Composite video/BNC 1 Vp-p, 75 . Encoder: G.729 Audio 8kbit/sec and PCM 64kbit/sec . Audio Input: 8 channels audio input , 10K¦¸, Vp-p=2.0V Line in . Motion Detection:  Multi-area detection powered by hardware Detection by active area and sensitive priority . Time Code:  Add TT: MM: DD and HH: MM: SS: FF format data in video . Logo: Add fixed picture and set mosaic area in video . Video Masks:  Provide video mosaic region for each channel . Alarm: Video loss alarm . Security: Each card has its unique serial number . Power: Usage  Less than 1W for each channel

80 Features: Wireless Video Door Phone Security System Model:YL-007VDP
. 2.4G lauch frequency, the power is no more than 20dbm, non-obstacle remote control is rough m; . With micro-dealing technology; auto-remote control, fine characteristics and high reliability; . The TFT 2.4" digital color display screen for indoor video intercom; . CMOS 30 pixel camera for outdoor phone; . Clear night-viewing, 24 hour monitoring, calling , speaking and unlocking remote controlling, etc; . One indoor video phone can control Max.5 pcs outdoor phones at most; . USB delivery for indoor video phone and many Li-ion rechargeable batteries; . Indoor video phone can take/save/view photos with above 500 photos at least by internal memory.

81 Features: Specifications Model;YL-007M8
Category :Security & Protection / Alarm Keywords: GSM Alarm, GSMAlarm System , GSM Alarm with DVR Features: Support GSM 900/1800/1900MHz, alarm without the limit of distance. Support CDMA, can arm/disarm/listen-in/photo-taking remotely by SMS. Listen-in function: can clearly hear the voice on the scene. Support motion detecting which can capture thief ‘s photo and send to user’s cell phone or box, or stored into the SD card. The picture size is adjustable: QCIF (160x128), CIF (320x240), VGA (640x480). Can pre-set 5 groups of alarm phone number. With password input, can set various functions via SMS or phone. Can control home appliances remotely through the relay output. The system has two input ports, which can connect wired devices (normally open). Siren port for shift between silence and siren. Work with wireless detectors like PIR sensors, beams, gas/smoke detectors, panic buttons. Adopts wireless signal transmission, no need to connect to wire and easy for installation. Aesthetic metal cover with neat design, endurable and stable application. Specifications . Stand-to current: 50mA . Working volt. : 9V-12V . Working temperature: -40℃~85℃ . Support GSM900, 1800, and 1900MHz . Support PHASE 2/2 agreement (including data business) . Sending power: Class10 (2 w)/ EGSM900 and CLASS 1(1W)/GSM Receiving code: ASK . Receiving frequency: 315/433/868 MHz . Remote distance: 100 meters .

82 Specifications 32 defense zone house/commercial intruderalarm system
Model:YL-007K3 Memo:house intruder alarm,commercial intruder alarm, security system Specifications Power supply:AC 220V DC 9V nner Power: Ni-Mh battery, DC=7.2V Static Current:≤50mA Alarm Current:≤300mA Wireless Frequency: 315/433/868±0.5MHz Wireless Receiving Sensitivity:5mV/ m Outer Alarm Siren Volume:110dB Working Condition:Temperature-10℃~40℃ Humidity:≤90% Capacity for Wireless Device:99pcs Wire Device:7pcs Weight: 1.2Kg/set Size : 160*110*35 mm Features: . With digital show(1-32, 91-97) on the host panel. . Support anti-decode with remote control. . Digital LED Defense zone display. Users can know which defense zone is triggered. . 32 wireless defense zone display (1 to 32) and 7 wired defense zone display (91-97). . Every defense zone can set independently arm, disarm, delay alarm and so on. . Have the function of “one-key arm”. User can start “Home arm” or “Out arm” freely by keeping pressing one key on remote control Can set the reminder sound of defense zones. Will remind users of remembering arm the alarm system when going out. . It stores 3 groups of monitoring center and 6 groups of user phone numbers to dial out and play the recorded message if there is an alarm Can arm/disarm with remote control or keypad on the host panel; . Can arm/disarm/listen-in by calling the host phone number (The phone numbers of the host). . Have the function of reminder for circuitry failure. For example, if telephone line is cut or short, the control panel will alarm. . Have in-built backup battery and can continue to work and last for 24 hours when electricity is cut or in failure.

83 Features: GSM/GPRS home alarm system with photo-taking Model:YL-007M4
Memo:GSM alarm system,home/business alarm,photo-taking alarm Features: . Operating Voltage: DC 12V . Static Current: ≤150 mA . Alarm Current: ≤600mA . Wireless Frequency: 315/433/868±0.5MHz . Anti-interference: 1V/m(frequency: MHz) . GSM frequency: 900/1800/1900MHZ . Outer Alarm siren volume: 110dB . Temperature: -10℃~40℃ . Humidity: ≤90% . Capacity for wireless detectors: 16pcs . wired detectors: 3pcs . Support GSM/CDMA,adopt Tri- bands, 900/1800/1900MHz. . Can pre-set 5 groups of alarm phone numbers with room number. . Auto-dial and send SMS & MMS to the 5 phone numbers via GSM. . The camera can detect the moving objects,can capture illegal intruder ‘s photo and send to owner’s cell phone or box, which provides evidence for case. . Can remotely control 3 home appliance with the three output ports by phone . Listen-in function: Can clearly hear the voice on the spot. . Can control the host by remote controllers or SMS commands, e.g: arm ,disarm,monitor,listen-in. . Has 3 input ports, which can be connected with 3 wired detectors. . Has 1 output port,which can link the video,lights and other device when alarming. .Intelligent recognize if the ower receive the alarm call. .Image size is adjustable: QCIF(160×128),CIF(320×240),VGA(640×480).

84 Features: Model No:YL-007EK . Power supply : DC 9~15 V
. Static current : ﹤20mA . Alarm current : ﹤300mA . Transmission Frequency: 315MHZ . Wireless receiver sensitivity : 5mV/m . Anti-nterference intensity: 1V / m . Temperature :–10~+ 40Humidity : ≤ 90% . Static Current: ≤25mA Wireless Receiving . Frequency:315/433MHZ±0.5MHz . Has single/ two-way intercom function. . Auto-dial 6 groups of telephone numbers . Built-in battery with high performance. . Long distance to monitor

85 Specifications Features: Model:YL-007AF Brand: wolf guard
Keywords: GSM alarm system , burglar alarm system , security alarm system Specifications . Operating Voltage: DC 12V . Static Current: ≤150Ma . Alarm Current: ≤600mA . Support GSM900/1800/1900 MHz, three working modes switched automatically . Support PHASE 2/2+ agreement (including data business) . Sending power:(2W)/EGSM900,(1W)/GSM1800 GSM1800 . Gable input port: three . Support power supply: AC380V (PHASE 3/4), AC 220V (PHASE 2/2+) . Wireless Receiving Frequency: 315MHz±0.5MHz . Wireless Receiving Sensitivity: 315MHz±0.5MHz . Anti-interference: 1V/m(frequency: MHz) . Outer Alarm siren volume: 110dB . Working temperature: -40deg C ~ +55deg C . Humidity: ≤90% Features: Using the BenQ M23 GSM module of high-performance, and supporting the tri-band GSM network. Support the three phase electrical power alarming. Have the unique function of taking photos and send the pictures(MMS), and will taking photos of the spot automatically and also send pictures(MMS) to the mobile phone. Have the function of anti-demolition alarming. When alarming, the alarm system will ring the alarm siren, and send messages and dial out the number to alarming for five mobile phones at the same time. Have three defense, which can connect the wire detectors. Different messages to different alarming situation, and the message can edit by that. Can arm/ disarm through send message and remote control the telephone, and can set up a number of parameters. Can alarm linked with the YL-007 monitoring center. Have one linkage output ports, and can link with lights and other equipments when alarming. (Have a built-in 7 AH battery backup, which can standby up to ten days without power supply and charge automatically.)

86 Features: Multi-functional burglar alarm with 2.4GHz DVR and 3.5 LCD
Model:YL-007KV Features: . Burglar alarm & photo taking & video monitoring in one . Unique anti-interfer function, if someone interferes the system with same wireless frequency, host will ring to alarm. . Can video and take photos of defense zones , image motion detection alarm function. . Unique anti-decode function, can shield the disarm signal of remote controller . . Unique large 3.5-inch LCD screen, friendly menu interface and display images at the scene. . When occurred alarm, the siren will ring to alarm, the system will video or take photo immediately, at the same time cyclic dial 2 group center numbers and 6 group user numbers automatically, and play alarm message. . Image files and video files stored in the SD card directly, convenience to enquire alarm records. . One wired video input and one 2.4G wireless video input . . 3 wired input alarm function and 3 wired controllable output function. . Alarm call has the priority to the normal call . . Can arm/disarm with remote controller or password keypad. . Can work with the received alarm center, compatible with “Wolf-Guard 01” and “Contact ID” protocol.

87 GSM alarm system with self-recording alarm voice
Model:YL-007M3D Features: . 10 seconds self-recording alarm voice will be sent out when alarming. . Auto alarm or disarm will be set according to your need. . Adopts GSM 900/1800/1900 bands ,can be used all over the world. . Full duplex communication with the base. . Monitor living surrounding. . Voice and message alert. . Set alarm on or off by remote controller. . Call in to set alarm On¡¢Off¡¢Monitor¡¢Output. . Send SMS to set alarm On¡¢Off¡¢Monitor¡¢Output. . 5 group phone+room number. . 1 group alarm center monitor phone. . 2 group phone number to report arm and disarm status. . Programable 7 group alarm TEXT messages. . 3 zone for wired detector zone for wireless detector. . Easily set on or off every wired or wireless detector. . 1 relay output to power on camera when alarming. . 2 output for cooker ¡¢air-condition and other home appliance. . SMS inform external power failure or recovery. . Indoor and outdoor alarm controller. . Arm delay function and alarm delay function, the delay time is adjustable (00~99 second).

88 Model:YL-007 M3B Features:
GSM security system with intercom and home appliance controlling Model:YL-007 M3B Features: . GSM 900/1800/1900 bands, can be used in most parts of the world . SMS to set alarm ON, OFF, Monitor, Output . 5 group phone + room number .1 group alarm monitor center phone number . 2 group phone to report arm and disarm status . Can program 7 groups of alarm messages . 3 zones for wired detector . 16 zones for wireless detector . 2 outputs, can be used with external circuit to control home appliance . Easily set ON or OFF for every wired or wireless detector . SMS inform if external power failure or recovery • Operating Voltage: DC 12V • Static Current: ≤20mA . Alarm Current: ≤400mA • Wireless Receiving Frequency: 315/433±0.5MHz • Wireless Receiving Sensitivity: 315/433±0.5MHz • Anti-interference: 1V/m£¨frequency: MHz£© • GSM frequency: 900/1800/1900MHz • Outer Alarm siren volume: 110dB • Working condition: Temperature: -10¡æ¡«40¡æ • Humidity : ≤90% • Wired detector : 3 pcs • Wireless detector : 16 pcs

89 GSM alarm system with MMS&SMS function
Model:YL-007M8A Memo: GSM alarm system, SMS/MMS burglar system, house/ commercial security systems Features: . Support GSM 900/1800/1900MHz, alarm remotely without the limit of distance . Standby current: 50mA . Working volt: DC 9~12V . Working temperature: -40℃~85℃ . GSM frequency: 900/1800/1900MHz,3 working modes. . Senfing frequency: Support PHASE 2/2 agreement (including data business) . Sending power: (2 W)/GSM900 ,(1W)/GSM1800/1900 . Receiving code: ASK . Receiving frequency: 315/ 433/868 MHz . Remote distance: No obstacle 100m . Detectors:16 . Support 1 output for relay linkage,remote controlling appliance switch. . Support two-way intercom,can turn on the siren remotely, speak to the alarm scene. . Listen-in function: Can clearly hear the voice, footstep, and so on . Support CDMA, remotely arm/ disarm/listen-in/photo-taking by SMS. . The picture size is adjustable: VGA (640x480), CIF (320x240),QCIF (160x128). . Remotely arm/disarm/listen-in/photo-taking/send MMS by remote controller or SMS.

90 Model No:YL-007EK Features:
Keywords: GSM Alarm System , Burglar Alarm System , Intruder Alarm Features: . With 8 wireless defense zones, and 8 wired defense zones, can program each zone independently. Can make voice recording and replay it, which won’t lose once power off. When alarm is triggered, . can hear the recorded voice alert by phone. . Have the function of reminder for circuitry failure. . There are arm/disarm/SOS buttons on the host panel. . Can arm/disarm/listen-in by calling the phone number of the host. . Supports any combination of wired/wireless sensors as your need. . Alarm call has the priority of the normal call, in order to prevent people from destroy. . Has single/ two-way intercom function. . Auto-dial 6 groups of telephone numbers. . Built-in battery with high performance.

91 Features: Model No;YL-007FX Category:Security & Protection / Alarm
Keywords:telephone line alarm , burglar alarm system , wireless alarm system Features: .With digital show(1-32, 91-97) on the panel. . Support anti-decode with remote control. . Digital LED Defense zone display. Users can know which defense zone is triggered. . 32 wireless defense zone display (1 to 32) and 7 wired defense zone display (91-97). . Every defense zone can set independently arm, disarm, delay alarm and so on. . Have the function of “one-key arm”. User can start “Home arm” or “Out arm” freely by keeping pressing one key on . \ remote control . Can set the reminder sound of defense zones. Will remind users of remembering arm the alarm system when going out. . It stores 3 groups of monitoring center and 6 groups of user phone numbers to dial out and play the recorded message . if there is an alarm. . Can arm/disarm with remote control or keypad on the control panel . Can arm/disarm/listen-in by calling the host phone number (The phone numbers of control panel). . Have the function of reminder for circuitry failure. For example, if telephone line is cut or short, the control panel will alarm. . Have in-built backup battery and can continue to work and last for 24 hours when electricity is cut or in failure. . With international Ademco Contact ID,can work with the monitoring center.

92 Features: Model:YL-007AF Brand: wolf guard
Keywords: alarm system, siren , flashing light Features: . Combine the alarm host and the siren with flash together . Sound alarm with a bright flash to make more powerful warning on spot . With waterpoof functioncan, can be installed outdoor . With the host to control other sensors . Can not dial out phone number when alarming . Can work with 20 wireless detectors . Alarm sound: 120 db . Easy to operate, arm/disarm/emergency help function . Frequency: 315/433 MHZ

93 Features & Specifications
Model:YL-007M3 Brand: wolf guard Keywords :GSM alarm , GSM home alarm , GSM burglar alarm Features & Specifications . Adopt the GSM network, no distance limit when alarming. . Can surpport the GSM/CDMA cell phone, with sending the English message function. . Can store five alarm phone number and the room number message, which can send to the owers, policeman and the monitoring center. . Long distance to arm/diarm/panic alarm/monitor, monitor function: the people can hear clearly the voice on the spot. . To start to work with the passport, which guarantee the safety of the system. . The owners can control the small household through the cell phone or telephone when they are out. . All kinds of wireless detector can be compatible with the system, such as door sensor, P.I.R detector, remote controller, gas sensor, smoke senspanic button, infrared baluster. . No need the telephone line, very suitable for the garage, store, house, warehouse, shop and other places without network. . Operating Voltage: DC 12V . Static Current: ≤20Ma . Alarm Current: ≤400mA . Wireless Receiving Frequency: 315MHz±0.5MHz . Wireless Receiving Sensitivity: 315MHz±0.5MHz . Anti-interference: 1V/m(frequency: MHz) . GSM frequency: 850/900/1800/1900MHZ . Outer Alarm siren volume: 110dB . Working condition: Temperature: -10℃~40℃ . Humidity: ≤90% . Capacity for wireless device: 10pcs . Kits:1 main panel, 1 wireless PIR sensor, 1 wireless door sensor, 1 siren, 2 remote controllers, 1 power supply and manual Certificates: CE, FCC, Rohs and ISO9001:2000

94 Features: Specifications Model:YL-007K Brand: wolf guard
Keywords :burglar alarm , burglar alarm kits , security alarms Features: . Anti-interfere function. When someone interferes it with same frequency . Support anti-decode with remote control . 6 programmable Defense zone available, with status LED. The control panel can register 99 sensors and detectors. Every defense zone can set independently arm, disarm, delay alarm and so on. . Have the function of “one-key arm”. User can start “Home arm” or “Out arm” freely by keeping pressing one key on remote control to satisfy your need. . Can set the reminder sound of defense zones. Will remind users of remembering arm the alarm system when going out. . It stores 2 groups of monitoring center and 6 groups of user phone numbers to dial out and play the recorded message if there is an alarm. . Can arm/disarm with remote control or keypad on the control panel . Can arm/disarm/listen-in by calling the host phone number (The phone numbers of control panel). . Have the function of reminder for circuitry failure. For example, if telephone line is cut or short, the control panel will alarm. . Have in-built backup battery and can continue to work and last for hours when electricity is cut or in failure. . With international Ademco Contact ID, can work with the monitoring center Specifications . Power supply:AC=220V±10% DC=9V -12V . Inner Power: Ni-Mh battery, DC=7.2V . Static Current:I ≤50mA . Alarm Current:I ≤300mA . Wireless Frequency:315/433MHz±0.5MHz . Wireless Receiving Sensitivity:5mV/ m . Outer Alarm Siren Volume:110db . Working ConditionTemperature-10~40℃ . Humidity:≤90% . Capacity for Wireless Device:99pcs

95 Features & Specifications
Model:JA-01 Brand: wolf guard Keywords: alarm system , alarm accessories , panic button Features & Specifications . Efficient frequency: MHz . Temperature condition: -10℃ to + 55℃ . Transmission distance: 80m(Open field) . Battery:12V,23A

96 Specifications/Features :
Product Category : Car GPS Navigation Systems Model/Item No : GT-710 Specifications/Features : . CPU: ARM 9400 MHz processor . . SDRAM: 64 MB . . NAND flash: 32 MB (MAX up to 2 GB) . . Windows CE 5.0 . Channels: 20 . Accuracy . . Position: < 10 meters . Velocity: 0.1 m/s . . Time: 0.01s to GPS time . Antenna: Embedded antenna . Audio Format: MP3 (up to 44 KHz), . WMA (up to 44 KHz), WAV . Video Format: MPEG-2, MPEG-4, AVI . Format: JPEG, BMP, GIF, PNG . Screen size: 3.5 inch . . Resolution: QVGA 320 x 240 pixels, 65,536 possible colors . . Display type: digital TFT LCD with 4-wire resistive touch panel . Standard SD (secure digital) card slot: MAX up to 2 GB SD card . USB: USB 2.0 full speed . Max consumption: 350 5V (active), 5V (sleep) mAh lithium ion battery . Main unit dimensions (W x H x D): 95 mm x 82.5 mm x 22.5 mm . Main unit weight: 190 g . 10 languages . . Our navigator is able to support up to 30 languages . Well and High Quality Control . Prompt Delivery . New Product . Customer's Designs and Logos are Welcome . Competitive Prices . Fit for Gifts & Premiums . Earth-friendly Products . In a Variety of Designs . ODM Accepted . OEM Accepted

97 Specifications Model: RG-B09
Category:Consumer Electronics & Lighting / Lighting / Lighting Fixtures Keywords:fire spray , flame spray machine , stage light Specifications . Power Supply: AC230V-50Hz . Power Consumption: 200W . Size: 56*17*17cm . Weight: 6.4kg

98 Smoke detector Features Model :TA-2688
Category: Security & Protection / Fire Fighting Keywords: Smoke detector , compound detector, Smoke detectors Features photoelectric smoke alarm  with 9VDC battery  CEILING TYPE SMOKE ALARM WITH CE APPROVAL  ALARM Ceiling or wall mounting - Easy to install with mounting hardware included - 9VDC battery - Suitable for any room - Flash alarm indicator (red) - Test button for easy recommended monthly testing - Low battery signal - Safety clip feature, not allow mounting of smoke alarm without battery installed - photoelectric  chamber for early detection from all directions - Loud 85dB alarm signal Specifications Power Source : 9VDC battery  Operating Current : 10 uA (normal) and mA (alarm working) Sensitivity to smoke : In comply with UL217 & BS5446: Part Operating Temperature : 40oF - 100oF (4. 4C oC) Ambient Humidity : 10% - 90%. Horn Level : 85 Decibels at 10 feet. Battery life : 1 year min

99 Specifications Model:HW-04A Brand: wolf-guard Features:
Category: Security & Protection / Burglarproof Features: It adopts self-designed DSP chip with patented frequency adjustment calculation technology. It works as an anti strong light detector and decreases misinformation. It can effectively recognize weight and size of intruder, so it prevents misinformation when pet interferes. Good at auto temperature adjustment. Have excellent detecting functions. Specifications . sensor:Imports low yawp double detect . Pet weight:10kg . Detecting range: :6~12m . Detecting angle: horizontal110° Vertical 60° . Anti-light:2000Lux . Anti-interfere:>30V/m . Transmission frequency:433MHz±0.5 Mhz . Sending distance: No obstacle 80m . static current:≤75uA . Alarm current:≤25mA . Battery type:9V . Batter life :6 months . . Work condition: temperature -10~40℃ . Humidity ≤90%

100 Specifications Features: Model: ACE-V269
Keywords: mini PIR dvr Camera , PIR-Sensor mini dvr , night-vision PIR dvr Features: . CMOS camera for high definition video recording  . PIR detection trigger to record . Internal Microphone for high quality audio recording  . Working with wireless burglar alarm system . IR lights for night vision use  . Real-Time & Date stamp on each video images for playback . Support recycled recording: overwrite previous files automatically for new recordings when memory is full . USB cable for data transmission Rechargeable and movable battery for spare use in case of DC power cut . Support Micro SD card up to 32GB maximally . Easy operation & DIY installation Specifications . Power supply: DC 5V . Electric current : 150mA-400mA . Battery standby time: ≤6 hours . Recharge time: ≤2.5 hours . PIR detect distance : ≤10 meters . AVI Resolution : 640*480 . Frame: 10-22 f/s (automatically adjust) . File formats: AVI . Memory : Micro SD card  . Memory card capacity: 64M-32GB maximum . Memory card usage time: min(2GB) . Playback: PC . Built-in camera:  digital CMOS camera . Battery capacity; 800mAH . PIR detect angle : ≤120° . Wireless frequency: 315MHZ/433MHZ(optional) . Alarm chip: PT2262 . Surge resistance: 4.7MΩ . Microphone distance; ≤5 meters . Position code: Random . Data code: D1 low, D2 high, D3 empty, D4 empty:

101 Specifications Model :TA-2988
Brand :conventional photoelectric smoke alarm Features . Advanced photoelectric smoke sensing technology . durable sensor head; excellent smoke access . ar (auto reset) function for security systems . (optional for 4 wire models) . n/c (normal/close)-n/o (normal/open) selectable relay output . easy installation and maintenance . modern design (white and beige colors) . freq. :3~5 sec . five-year limited warranty . available options . sensor base: standard and shottky diode . remote led . comply with en54 and ce Specifications . smoke sensitivity :EN 54-5/7:2000 standard . detection range :100 square meters rating for smoke sensor; 50 square meters rating for heat sensor . start-up current

102 Model: TA-2288 Brand :AC powered smoke alarm TA-2288 ProductName: Smoke Alarm Features: CEILING TYPE SMOKE ALARM WITH CE APPROVAL ALARM . Ceiling or wall mounting -. Easy to install with mounting hardware included VAC/230VAC with 9VDC battery backup can be interconnected up to 39pcs of GB series of smoke alarm . Suitable for any room . Flash alarm indicator (red) Test button for easy recommended monthly testing . Low battery signal . Safety clip feature, not allow mounting of smoke alarm . without battery installed . photoelectric  chamber for early detection from all directions . Loud 85dB alarm signal Specifications . Power Source : 110VAC/230VAC with 9VDC battery backup . Operating Current : 10 uA (normal) and mA . (alarm working) . Sensitivity to smoke : In comply with UL217 & . BS5446: Part ~1.42%/FT . Operating Temperature : 40oF - 100oF (4. 4C oC)

103 Features: Specifications Model: SS100H-0HW
. Microwave and infrared double detection, highly accurate. Only gives Alarm to real body movement. . Adopting patented full-scope precision temperature compensation, the detecting sensitivity is always stable and consistent within working temperature despite temperature changes. . Wireless construction, built-in power, radio transmission, totally wireless. Easy installation and usage. . Power-saving design and high capacity battery enables the detector to continuously work for a long period. . Built-in expansion slot, be compatible with control panels from other suppliers Specifications . Working current: Standby: 100m, . External Antenna> 300m( without any interference). . Working mode: USE mode: Alarm interval is min. 1minute. . TEST mode: Alarm interval is min. 20 seconds. Sensor: Quiet, duel-core PIR sensors. . LED indication: When it detects body movement. Red LED .Flashes for about 2 seconds, detector sends out alarm signal to control panel . Lens qty: Pulse count: Detecting scope: 110, 9 x9m (typical). . Temperature compensation: Auto compensation. . Low battery indication LED: Detector generates and . Sends out alarm signal once battery is lower than 2.5v. Demension: 138x75x46mm . Microwave Frequency: 2.45GHz

104 Features . Installation height: from 2 to 2.5 meters;
Model: PIR-527PRO Keywords: PIR , motion detector , SENSOR Features . Installation height: from 2 to 2.5 meters; . coverage:8m/110°; . Detection speed: from 0.1m/s to 4m/s . Start up time:180 seconds; working . Range:max.150m(open area), . Temperature compensation, . Anti RFI/EMI interference

105 Features Specifications Model:DA-310A . Product Image
. High accuracy passive dual infrared detector.  Signal with energy accumulative logic processing, and random dynamic time partition processing. Selectable three levels of sensitivity (high/medium/low). High capability of preventing radio frequency interference (Match CE standard) via SMD wiring. Insensitive to the white and the closed shell preventing the system damaged With automatic temperature compensation and self-diagnostics Capability to save alarm information, and output the anti-demolition signal Stable and reliable performance, and easy installation Specifications . Product Image . Power supply:10-15V DC Static . state current: 5mA(normally-open relay) 20mA(normally-closed relay) . Monitor speed range:0.1m/s - 4 m/s . Monitor coverage range:12 m / 120 degrees . Installation high: m . Relay output:60V/1.5A(normally-open or normally-closed) . Anti-demolition switch output:60V/0.1A(normally-closed) . Operation temperature range:-10 ~ 50o C(14F~122F) . Anti- radio frequency interference ability:1GHz 20V/m   . Size:9.1cm×6.1cm×4.6cm

106 Features Specifications Model:Tiger -911
. Circulatory dialing four telephone, cell phone, numbers, and each phone number could be up to 16 digits. Easy programming, parameters and data will be saved and will not lost during power down;  Alarm report dial could be triggered by normally-open relay, normally- closed relay,or 12V DC power supply Alarm reporting will include a 20-second recorded voice message and this recorded message could be updated   Alarm can be used for any host connected to realize telephone voice alarm   Specifications . Power supply: V DC Static . . state current:20mA . Telephone recording time:20 seconds   . Telephone numbers:Four sets Dial method: . Audio Alarm report input: . normally-open relay, normally-closed relay, or . 12 DC line

107 Features Model No:CTD-007M5B (NEW)
Related Keywords : alarm system , security, GSM alarm system PIR detector Features . SIMCOM300(340)GSM module (3 or 4 frequency) . GSM antenna:acetabula antenna: gain 4dBi, cable length 3-5M, SMA connector . Whip like antenna: gain 2dBi, height 10CM, SMA connector . Receiving frequency:315/433MHZ . Receiving sensitivity:≤0.1uv . Alarming mode:Short Message . Environment requirements:Temperature -10℃~+60℃ humidity≤85% . Power supply adapter and back up battery: . Input:AC 110~240V outup:DC7.5V 1.5A (optional) .Back up battery:lithium polymer 500~2500mAh 3.7V . Weight:Package weight: 1.8Kg/pcs . Package size(mm):325*310*72

108 Features Model: YK-828 Keywords: gas alarm , lpg alarm , gas detector
. Gas alarm description: . High stability sensor . Independent and optional network required . Auto reset after alarm . Power: 12VDC, 220VAC/230VAC/240VAC . Working temperature: 0 to 60°C . Alarm density: . Coal gas: 1,000 to 5,000ppm . Liquid petroleum gas: 1, 000 to 10,000ppm . Natural gas: 1,000 to 5,000ppm . Interconnecting gas detector: . Circuit for normally closed relay contacts (optional) . Circuit for normally opened relay contacts (optional) . Operating frequency: 433 or 315MHz (optional) . Size: 115 x 70 x 36mm . Weight: 228g/pieces

109 Features Model:QG-01 Brand: wolf guard
Keywords: Gas detecotr , Gas sensor , Gas alarm Features . Power supply: AC 220V . static power:: <1.3W . Alarm power: <1.7W . Work condition . Temperature :-10℃~45℃ . Humidity:30%~90% . Alarm density: natural gas:10~25%LEL . LPG:10~25%LEL . Civil gas:2~5%LEL

110 smoke detector Model: YG-01 Brand :wolf guard Keywords: smoke detector, smoke alarm, smoke sensor Features: . It adopts Ion smoke detector element, with siren. It can work individually as well as with other alarm systems. . Technical parameters: . power:9~15VDC . current:Static current <10mA . smoke sensitivity:Suitable for UL 217 standard . Temperature:40℃~45℃ . Humidity 10%~90% . Alarm voice: Within 10 inch can be 85 db

111 Features: wireless gas detector (AF-21) Model:AF-21
Keywords:gas detector , gas alarm , gas sensor Features: High reliability sensor Auto-reset after alarm MCU processing adopted Auto detect sensor failure Induced Gas Natural gas /LPG SMT DESIGN ,High stability SPECIFICATION Operating voltage:  220V AC Static Current : 90Ma      ≤ 30mA( low power consumption type) Alarm Current: ≤ 100 mA       ≤ 40mA( low power consumption type) Warm-up time: about 120s Alarm level: 10% LEL Alarm indicator: Red LED flash Sound level : ≥85dB/m Operating temperature: -10℃ to 50℃ Environment Humidity : ≤ 95%RH Installation Mode : wall mounted Alarm output: Relay output/sound & flash alarm RF 315MHZ or 433MHZ (wireless type) Radio Distance: 100m in open area (wireless type) Outline Size: 110*70*40mm

112 Specifications/Features
Wireless Gas Leakage Detector gas alarm supplier in Shenzhen Model:PST-GD201 Keywords: wireless gas alarm , gas detector , wired gas detector Specifications/Features . Power:110VAC/220VAC/230VAC, 9V-20VDC . Working temperature: -10degree~60 degree . Alarm density: Coal gas: 1000~5000ppm, Liquid petroleum gas:1000~10000ppm, natural gas: 1000ppm~5000ppm . Interconnecting Gas detector     (1)Circuit for normally closed rely contacts   (2)Circuit for normally opened rely contacts   (3)Operating Frequency: 433 MHZ/315MHZ (optional) . Size:115mm*70mm*40mm . Weight:228g/pcs . Package size:58.5cm*28.5cm*53.3cm . Quantity/Box:100pcs

113 Model Number:CTD-3108 Features:
. MJPEG compression format. Linux embedded operation System . NTSC/PAL . Life display:NTSC:480f/s; PAL:400f/s . RS485 Port, PTZ control . Recording(MAX):NTSC,120f/s;PAL,100f/s . Chinese and English language operation . 8 channel video input, 2 channel BNC video output, and 1 channel S port output. . 1 channel audio input,1 channel output . High quality image for each channel, and the quality can be adjusted independently . Keyboard locked function . The recording can resume quickly when power-on and the recorded image keep normal . Support Zoom, Single image can auto switch, watermark check the safe. . Image quality optional: higher, high, low, lower . Multiplex display mode: 1 image,4 image,8 image . Recording mode: manual recording, time recording, alarm recording and motion detection recording . Searching mode: search by recording time, search by recording group, search by event recording group . 8 channel alarm input,1 channel alarm output . Support video signal loss alarm . Life display, recording and playback can be operated at the same time . Support IE browse: remote monitor, remote playback, recording playback etc. . Playback check speed or drawback with ×2, ×4,×8,×16 . Recording backup mode: internet backup, USB backup

114 Technical specifications:
Products Introduction . Support WCDMA/HSDPA/GSM/GPRS/EDGE working model. . Built-in 2,000,000 pixels night vision camera,suitable for night use. . Support PIR motion detecting,can take photos once trigged alarm. . Send scene photos(MMS) to user phone/ e-mai address/IP address. . Support video/MMS/SMS/voice call/video phone/e-mai/IP network to alarm. . SMS content of each zone can be edited. . Support 2GB SD Card to storage image and video. . Image size:UXGA(1600×1200),video size: QVGA(320×240). . 16 wireless zones,each can be programmed independently,eg:arm,disarm and 24-hour arm. . Can dail to 5 user phones and 1 monitor center and 1 SMS center when alarming. . Set the time of reporting,timing report to monitor center. . Supports GPS positioning,applied to automotive systems.(optional) Technical specifications: . Power adapter: Input 100V~240V/50Hz Output DC 5..0V/2A . Receive coding: ASK . Receive frequency: 315/433 MHz . Wireless detectors: 16 pcs . Wireless remote distance: 80m . Camera pixel: 2,000,000 pixels . Video format: QVGA(320×240) . Image format: UXGA(1600×1200) . View angle: 100° Horizontal,60° vertical . Camera distance: 8~10 . Battery life (standby): 24 hours . Working temperature: 10℃~+45℃ . Humidity: 10-90% . Frequency : WCDMA/HSDPA 850/1900/2100 MHz . EDGE/GPRS/GSM 850/900/1800/1900 MHz . Camera Dimension: 130×90×40mm (LxWxH)

115 Multifunctional GSM MMS Alarm System with Night Vision Camera
products introduction . Built-in 300,000 pixels night vision digital camera. . Support 2G SD card , convenient for long-term storage. . Support PIR motion detecting with photo-taking. . Support SMS, MMS,phone, to alarm. . Image size is adjustable: QCIF(160×128),CIF(320×240),VGA(640×480) . . Can pre-set arm / disarm time,convenient for user or alarm center to control. . Can record 10 second voice message. . Remote control to arm/disarm/listen-in. . Can set 5 user phone numbers ,can listen-in when alarming. .Can set 2 mial address: send scene image alarm infor to E-mial. .Support GSM/CDMA mobile phone to receive SMS alarm and send SMS commands to control . .Wireless remote controller,convenient for user to arm,disarm,panic alarm and take photo. .Can send scene color images to mibile phone immediately after alarming . .Can capture scene color photos and send to user by sending SMS command. .Adopt tri-band GSM 900/1800/1900 MHz wireless network, no distance limit to alarm.

116

117

118

119 310---3.5” GPS Navigator GENERAL SPECIFICATIONS
Blutooth hands free version is available! . Centrality Atlas III ARM9 Core 300MHz processor  . Most Compact & very Slim 3.5 inch GPS PND . Most Compact & Slim Bluetooth Hands free GPS PND . 20 Channel High Sensitivity . Real Multimedia Player ( Audio / Video ) , support almost full formats . Photo Viewer & E-book . Kinds of UI interface for choices . Strong & Experienced manufacture system GENERAL SPECIFICATIONS ·   CPU: ARM9 application processor ·   Frequencies: 300 MHz (ARM core), 200 MHz (DSP core), 100 MHz (system),) ·   SDRAM: 64 MB ·   NAND flash: 64MB ( max to 1GB ) ·   OS: Windows CE 5.0 ·   GPS ,Frequency: L1, MHz Sensitivity: -156 dBm . Channels: 20Position: <10 meters . Velocity: 0.1m/s ,Time: 0.01s to GPS time . TTFF (Open sky) ,Reacquisition: <1 sec, average . Hot start: 3 sec, average ,Cold Start: 34 sec, average . Warm Start: 31 sec, average . Antenna: Embedded antenna and optional external antenna connection . Audio Format: MP3 (up to 44KHz), WMA ( up to 44KHz), WAV . Video Format: MPEG-2, MPEG-4, AVI , ASFFormat: JPEG, BMP, GIF, PNG . Screen size: 3.5” . Resolution: QVGA 320 x 240 pixels, 65,536 possible colors . Display type: Digital TFT LCD with 4-wire resistive touch panel . Brightness: 200 lumen . Integrated speaker ( 1W ) . Stereo headphone jack . Buttons: Power(On/Off ) . Standard SD (Secure Digital) card slot: MAX up to 2 GB SD card . USB: USB 2.0 full speed . Stereo headphone jack: 3.5 mm . Max consumption: 350 5V (active), 5V (sleep) . Handheld mode: 1.5A (via AC adapter) or 3.7V (via 1,150 mAh lithium ion battery) . Main Unit Dimensions (W x H x D): 91.5 mm x80 mm x 19.5 mm . Main Unit Weight: 170 g

120 Applications: VT-8 GPS vehicle monitor Features:
1.   Track by text message (SMS) on mobile phone, and via internet (GPRS) on computer 2.   Configure the unit by sending text message from mobile phone, or with our PC software on computer. 3.   If the stealer cuts off the vehicle battery, the tracker will inform the car owner via text message. 4.   The car owner can stop / re-start the car engine by sending a text message. 5.   Motion sensor: it senses the movement of the car. 6.   The tracker will auto power on once the battery is connected. 7.   A SOS button for emergency help 8.   Geofence for parking safety: leaving out the defined circle will cause an alert message. 9.   SOS button & Geofence button are wired out. 10.   Speeding Alert for parents disciplining the teenage driver’s behavior. 11.   Waypoints recording for history path replay on map of Google earth. 12.   Add photo tags to waypoints with our software. 13.   External GPS / GSM antenna ports. Applications: . For vehicle anti-theft and recovery . For fleet management . For emergency help . For covert tracking & surveillance Specifications: . GSM/GPRS module: Simcom300 Tri-Band GSM module (Quad-band for option) . GPS module: SiRF III 20 channels . Accuracy: 1-5m . Start time: Cold start: 42s  Warm start: 35s . Hot start : 1s . Battery: rechargeable replaceable 1100mAh 3.7v Li-ion battery . Size: 90mm*70mm*28mm . Weight: 85g (including battery)

121 BT-9 Solar GPS BT Receiver
Features . Always power on . Fashion look,Ultra slim design . Built-in rechargeable 900 mAh Lithium battery . Automotive fleet management, asset tracking . Personal, portable navigation (PDA, smart phone) . Location based services . Sports and recreation . Geographic surveying Specifications . GPS technology: SiRF star III GPS module  . Channels: 20 channels all in view tracking . Sensitivity: better than -159dBm . Position :10 meters CEP without SA . Velocity: 0.1 m/s, without SA . Time: ±100ns synchronized to GPS time . Datum: WGS-84,Reacquisition: <2 seconds . Hot start: 1 seconds, average . Warm start: 34 seconds, average . Cold start: 42 seconds, average . GPS output data: NMEA 0183 (V3.01) - GGA, GSA, GSV, RMC (default); VTG, . Baud rate 9600 bps, data bit: 8, stop bit: 1 (default) . Acceleration limit: <2G . Altitude limit: <18,000 meters . Velocity limit: <515 m/s, Jerk limit: 20m/s . Battery: built-in rechargeable 900mAh Lithium battery . 32mA at 3.7V (with Bluetooth) . Operation time: up to 20 hours . Charging time: 3 hours (typical) . Charger protection: built-in over temperature/over voltage protection . Operating: -5 to 60oC ,Storage: -20 to 60oC . Humidity: 5% to 95% non-condensing . Standard: fully compliant with Bluetooth V 1.1 . Output power: 0dBm (typical), Class II . Range: up to 10 meters , Security: yes . Bluetooth profile: serial port profile (SPP) . Frequency: 2.4 GHz ISM band . Minimum operating voltage, Vop (with 150 ohms load) . Minimum operating current, Iop (with 150 ohms load

122 4339--4.3” GPS Navigator Features
. 3” (16:9) WQVGA, 480x272 pixels, TFT LCD,touch panel. . CPU: Centrality Atlas III 372 MHz, ARM926J . O/S: Microsoft WinCE.NET 5.0 Core Version . Memory: 64MB SDRAM and 64MB Nand Flash built in. . Tracking Sensitivity: -157dBm . Battery: 1400mAH Li-ion battery Working time: up to 3.5 hours . Expansion slot: SD/MMC slot . High Speed USD Hot start: ≤9 sec; Warm start: ≤38 sec; Cold start: ≤43 sec . Satellite reacquisition time: 0.1 sec . Position Accuracy: up to 3m . Other Functions:Audio & Video player\E-Book reader\Photo browser

123 PT-11 GPS/GSM tracker (very SOS!)
Features: . Track by text message (SMS) on mobile phone, and via internet (GPRS) on computer . Configure by mobile phone sending test commands OR via USB cable on computer. . SOS button and Very SOS pull ring two way for emergency help . Geofence for parking safety: leaving out the defined circle will cause an alert message. . Speeding Alert for parents disciplining the teenage driver’s behavior. . Battery Monitor for warning of a low battery. . Waypoints recording for history path replay on map of Google earth. . Add photo tags to waypoints with custom software. . Full Memory Alert for waypoints recording. Hanging in front of the chest to operate more easy and fast for providing help with shortest time. . Tracking through Cell ID or GPS as well. . Built-in the lithium polymer battery causes the operation to be safer, felt relieved. . Motion senser for falling down and hold still alarm (optional) Specifications: . GSM/GPRS module: Simcom300 Tri-Band . GSM module (GSM900/1800/1900MHz) . GPS module: SiRF III 20 channels . Accuracy: 1-5m Start time: . Cold start: 42s . Warm start: 35s . Hot start : 1s . Battery: rechargeable replaceable 1100mAh 3.7v Li-ion battery. . Size: 68mm*47mm*17mm Weight: 45g

124 GENERAL DESCRIPTION GPS-BTS8 Bluetooth GPS receiver, a total solution of GPS Bluetooth wireless technology, is dedicated design for the user who is usually carry the portable device such as PDAs/smart phones all the time. GPS-BTS8 Bluetooth GPS receiver works to all Bluetooth smart phones, lap-top, PDA regardless of brand in an operating range of more than 10 meters. The high performance high sensitivity GPS-BTS8 is an ideal receiver to be used in any strict weather condition, so to easily find your way. FEATURES channels All-In-View  tracking . Cold/Warm/Hot start time: 42/38/1 sec. (average) . Superior sensitivity: -159dBm tracking . Reacquisition time: 0.1 sec. . Build-in ceramic patch antenna . Replaced rechargeable Li-ion battery . Support standard NMEA-0183 at 9600 bps baud rate . Compatible with Bluetooth devices with Serial Port Profile (SPP) . Ultra low power consumption: up to 10 hours continuous use by using 900mAh battery . Time to full recharge: 3 hours . 3 LEDS display GPS/Bluetooth status/Power . Size: 69.5 (L) X 44.5 (W) X 19.5 (H) mm . Weight: 53.8g (battery included) . Non-slip back pad for a secure placement . Automotive . Fleet management/Asset tracking . Personal/Portable Navigation (PDA, Pocket PC etc.) . Location Based Services enabled devices . Sports and Recreation . Geographic Surveying

125 4339--4.3” GPS Navigator Features:
. 4.3” (16:9) WQVGA, 480x272 pixels, TFT LCD,touch panel. . CPU: Centrality Atlas III 372 MHz, ARM926J . O/S: Microsoft WinCE.NET 5.0 Core Version . Memory: 64MB SDRAM and 64MB Nand Flash built in. . Tracking Sensitivity: -157dBm . Battery: 1400mAH Li-ion battery Working time: up to 3.5 hours . Expansion slot: SD/MMC slot . High Speed USD Hot start: ≤9 sec; Warm start: ≤38 sec; Cold start: ≤43 sec . Satellite reacquisition time: 0.1 sec . Position Accuracy: up to 3m . Other Functions:Audio & Video player\E-Book reader\Photo browser

126 ” GPS Navigator . 4.3” (16:9) WQVGA, 480x272 pixels, TFT LCD,touch panel. . CPU: Centrality Atlas III 372 MHz, ARM926J . O/S: Microsoft WinCE.NET 5.0 Core Version . Memory: 64MB SDRAM and 64MB Nand Flash built in. . Tracking Sensitivity: -157dBm . Battery: 1400mAH Li-ion battery Working time: up to 3.5 hours . Expansion slot: SD/MMC slot . High Speed USD Hot start: ≤9 sec; Warm start: ≤38 sec; Cold start: ≤43 sec . Satellite reacquisition time: 0.1 sec . Position Accuracy: up to 3m . Other Functions:Audio & Video player\E-Book reader\Photo browser(16:9) WQVGA, 480x272 pixels, TFT LCD . CPU: Centrality Atlas III 372 MHz, ARM926J . O/S: Microsoft WinCE.NET 5.0 Core Version . Memory: 64MB SDRAM and 64MB Nand Flash built in. . Tracking Sensitivity: -157dBm . Battery: 1400mAH Li-ion battery Working time: up to 3.5 hours . Expansion slot: SD/MMC slot . High Speed USD Hot start: ≤9 sec; Warm start: ≤38 sec; Cold start: ≤43 sec . Satellite reacquisition time: 0.1 sec . Position Accuracy: up to 3m . Other Functions:Audio & Video player\E-Book reader\Photo browser

127 4.3' and 5.0' GPS Navigator (Iphone outlook)
Features . CPU: Centrality Atlas-IV AT840/533MHz . Flash(64M/128M/256M/512M/1G/2G Byte Options)    . DDR RAM: 64Mbytes . LCD: 4.3/5.0 inch 64K TFT . TSP: Touch Screen Supported . USB: Mini Slot . GPS Receiver: Module and Antenna Built In . O/S: Win CE 6.0  . Language: support multi-languages . Video Player: WMV9, DIVX 5.0, 4.0, 3.11, XVID and MPEG2 . Audio Player: WMA9, MP3 up to 320k bps and WAV . Photo Viewer: JPG, GIF, BMP and PNG . Battery: mAh Li-ion (1.5~4 hours operation) . Car Adapter: 12VDC to 5VDC 1.5A . Operating Temperature: 0 °C to 60 °C . Storage Temperature: -20 °C to 60 °C . Dimension:(L)127mmX(H)82mmX(W)12mm . FM transmit:  (optional) . AV in: (optional) . Bluetooth:  (optional) . TMC (optional)

128 4.3' and 5.0' GPS Navigator (Diamond outlook) Features
. CPU: Centrality Atlas-IV AT840/533MHz . Flash(64M/128M/256M/512M/1G/2G Byte Options)    . DDR RAM: 64Mbytes . LCD: 5.0 inch 64K TFT . TSP: Touch Screen Supported . USB: Mini Slot . GPS Receiver: Module and Antenna Built In . O/S: Win CE 6.0  . Language: support multi-languages . Video Player: WMV9, DIVX 5.0, 4.0, 3.11, XVID and MPEG2 . Audio Player: WMA9, MP3 up to 320k bps and WAV . Photo Viewer: JPG, GIF, BMP and PNG . Battery: mAh Li-ion (1.5~4 hours operation) . Car Adapter: 12VDC to 5VDC 1.5A . Operating Temperature: 0 °C to 60 °C . Storage Temperature: -20 °C to 60 °C . Dimension:(L)127mmX(H)82mmX(W)12mm . FM transmit:  (optional) . AV in: (optional) . Bluetooth:  (optional) . TMC (optional)

129 ” GPS Navigator . 4.3” (16:9) WQVGA, 480x272 pixels, TFT LCD,touch panel. . CPU: Centrality Atlas III 372 MHz, ARM926J . O/S: Microsoft WinCE.NET 5.0 Core Version . Memory: 64MB SDRAM and 64MB Nand Flash built in. . Tracking Sensitivity: -157dBm . Battery: 1400mAH Li-ion battery Working time: up to 3.5 hours . Expansion slot: SD/MMC slot . High Speed USD Hot start: ≤9 sec; Warm start: ≤38 sec; Cold start: ≤43 sec .Satellite reacquisition time: 0.1 sec . Position Accuracy: up to 3m . Other Functions:Audio & Video player\E-Book reader\Photo browser

130

131

132


Download ppt "18/438-A18,Colombo Complex, MM Ali Road,"

Similar presentations


Ads by Google
