1. Exploring Windows Phone Features Chris Koenig chris.koenig@microsoft.com 214-385-5616 @chriskoenig | http://chriskoenig.net WIRELESS: softlayer - techwild

2. Windows Phone 30-to-Launch Program Overview Session 1 Overview of Windows Phone Metro Design Tour: Expression Blend Tour: Visual Studio Building, Running and Debugging Your First App Online Resources Signup for Marketplace Session 2 Exploring Windows Phone Capabilities Live Tiles Sensors & Camera Launchers Choosers Search Integration Advertisements Session 3 Working with Data App Resources Isolated Storage Database Networking Stack Social Integration Session 4 Windows Phone Marketplace Application submittal process How to handle rejection Promoting your application Help submitting your app to the Marketplace 2

3. Windows Phone Today’s Agenda  Live Tiles  Sensors & Camera  Launchers & Choosers  Advertisements  Push Notifications  Background Tasks  Search Integration 3

4. Live Tiles

5. Windows Phone Live Tiles  Interactive windows into your application  Personalize them to be meaningful to your users  Built-in support for data for basic communications  Custom image wizardry for more advanced scenarios

6. Windows Phone Live Tiles – Local Tile API  Local tile updates (these are *not* push)  Full control of all properties when your app is in the foreground or background  Calorie counter, sticky notes, deep linking  MultiTile!  Create/Update/Delete  Launches directly to page/experience 6

7. Windows Phone  Back of tile updates  Full control of all properties when your app is in the foreground or background  Content, Title, Background  Flips from front to back at random interval  Smart logic to make flips asynchronous Live Tiles – Local Tile API Continued… Title Content Title Background Content string is bigger 7

8. Demo http://github.com/ChrisKoenig/MangoTiles Working with Live Tiles

9. Sensors and Cameras and Launchers and Choosers!

10. Windows Phone Accelerometer Compass Not Mandatory in HW (but present if Gyro is) Gyro Not Mandatory in HW MotionSensor All the Sensor + Math Use whenever available Also works w/o Gyro Individual APIs available for all Sensors HARDWARE APIs Windows Phone Sensors 10

11. Windows Phone Exciting Scenarios Enabled 11

12. Windows Phone Augmented Reality Scenarios?  GART Toolkit  http://gart.codeplex.com http://gart.codeplex.com  Written by my teammate!

13. Demo Live demo! Sensors, Camera, Launchers and Choosers

14. Advertisements

15. Windows Phone Advertising SDK  The Advertising SDK is now part of the Windows Phone SDK  You can include a Silverlight Ad control in an application or an XNA Drawable Ad into a game  This is very easy to do 15

16. Windows Phone Microsoft pubCenter  Sign up here so that you can incorporate ads in your games: http://pubcenter.microsoft.com  Find out more about Windows Phone Advertising: http://advertising.microsoft.com/mobile-apps 16

17. Demo Live demo! Adding the Ad SDK to a Project

18. Push Notifications

19. Windows Phone Push Notifications  Server-initiated communication  Enable key background scenarios  Preserve battery life and user experience  Prevent polling for updates 19

20. Windows Phone Push Notification Data Flow URI to the service: "http://notify.live.com/throttledthirdparty/01.00/AAFRQH giiMWNTYrRDXAHQtz- AgrNpzcDAwAAAAQOMDAwMDAwMDAwMDAwMDA" Push enabled applications Notifications service HTTP POST the message Push endpoint is established. URI is created for the endpoint. 1 2 3 3 rd party service Windows Live Push Notification service Send PN Message 4 20

21. Windows Phone Three Kinds of Notifications  Raw  Notification message content is application-specific  Delivered directly to app only if it is running  Toast  Specific XML schema  Content delivered to app if it is running  If app is not running, system displays Toast popup using notification message content  Tile  Specific XML schema  Never delivered to app  If user has pinned app tile to Start screen, system updates it using notification message content 21

22. Windows Phone Toast Notification  App icon and two text fields  Time critical and personally relevant  Users must opt-in via app UI 22

23. Demo http://github.com/ChrisKoenig/PushNotificatio ns Push Notification Weather Sample

24. Multitasking

25. Windows Phone Multitasking Themes  Fast Application Switching  Ability to resume applications that the user has recently used  Apps stay in memory unless memory is needed for other apps  Use IsApplicationInstancePreserved in App.Activate event to determine actions  Background Agents  Ability to run your code in the background  Audio, Timed or on Idle  Notifications  Ability to create alarms and reminders  UX and behavior is the same as the phone Alarms and Calendar items  Background Transfer Service  Application can queue up transfers in the background 25

26. Windows Phone Generic Agent Types Periodic Agents  Occurrence  Every 30 min  Duration  15 seconds  Scenarios  Incremental data sync  Location  Others… On Idle Agents  Occurrence  External power, non-cell network  Duration  10 minutes  Scenarios  Data feasting  Initial sync  Others… 26

27. Windows Phone Background Notification Service using Microsoft.Phone.Scheduler; private void AddReminder(object sender, RoutedEventArgs e) { Reminder reminder = new Reminder("CompanyMeeting"); reminder.BeginTime = DateTime.Now.AddSeconds(15); reminder.Content = "Soccer Fields by The Commons"; reminder.Title = "Microsoft Annual Company Product Fair 2009"; reminder.RecurrenceType = RecurrenceInterval.Yearly; reminder.NavigationUri = new Uri("/Reminder.xaml", UriKind.Relative); ScheduledActionService.Add(reminder); } AlarmsReminders using Microsoft.Phone.Scheduler; private void AddAlarm(object sender, RoutedEventArgs e) { Alarm alarm = new Alarm("Long Day"); alarm.BeginTime = DateTime.Now.AddSeconds(15); alarm.Content = "It's been a long day. Go to bed."; alarm.Title = "Alarm"; ScheduledActionService.Add(alarm); } 27

28. Windows Phone Background Transfer Service downloads My WP Book App Cheese & Win Great Mysterie WP Tips & Tric Cloud Background Transfer Service <2 GB <20 MB <~5.0 MB GET POST void DownloadWithBTS(Uri sourceUri, Uri destinationPath) { btr = new BackgroundTransferRequest(sourceUri, destinationUri); btr.TransferStatusChanged += BtsStatusChanged; btr.TransferProgressChanged += BtsProgressChanged; BackgroundTransferService.Add(btr); } void BtsProgressChanged(object sender, BackgroundTransferEventArgs e) { DrawProgressBar(e.Request.BytesReceived); } using Microsoft.Phone.BackgroundTransfer; void GetCurrentProgress() { DrawProgressBar(btr.BytesReceived); } completed My WP Book App ISO Store no limit 28

29. Windows Phone Multitasking Cheat Sheet JobTool Resume quickly from the lock screenFast App Switching (it’s free!) Set an alarm or reminder at a precise timeBackground Notification Large file downloadsBackground Transfer Event-based toast/tile updatesPush Notifications Location-based services; regular toast/tile updates; data pre-caching; etc. Periodic Background Agent Play music in the backgroundBackground Audio Player Synchronize data; SETI@home; etc.Resource-Intensive Agent Real-time GPS trackingRun under the lock screen 29

30. Demo http://github.com/chriskoenig/backgroundage ntsample Background Agents

31. Search Integration

32. Demo http://github.com/ChrisKoenig/AppConnect Using Search Integration via AppConnect

33. Windows Phone NuGet  Package management system for.NET  Simplifies incorporating 3rd party libraries  Developer focused  Free, open source  Install NuGet using the Visual Studio Extension Manager  Use NuGet to add libraries such as the Silverlight Toolkit to your project 33

34. Windows Phone Silverlight Toolkit for Windows Phone  A product of the Microsoft Silverlight team  The Silverlight Toolkit adds tons of additional controls ‘out of band’ from the official product control set  Includes full open source code, samples, documentation, and design-time support for controls  Refresh every 3 months or so  Bug fixes  New controls  http://silverlight.codeplex.com http://silverlight.codeplex.com  Download from NuGet! 34

35. Windows Phone Homework  Keep cranking on your project  Ping me for help with roadblocks  Explore more of the training videos and training kits at http://create.msdn.comhttp://create.msdn.com  Have fun! 35
