1. Istituto Tecnico Industriale A.Monaco EURLAB European Robotic LABoratory HOW TO Transmit and RECEIVE Datas

2. Istituto Tecnico Industriale A.Monaco EURLAB 1-How TO SeND TEXT TO ARDUINO 1.1-PRESENTATION This activity involves sending datas (text) from computer to arduino Uno Board, then Arduino board sends received datas to computer To do this, you need : Computer, Arduino Uno Board, USB cable, Arduino software Ardublock program (10-SerialPortArduino.abp)

3. Istituto Tecnico Industriale A.Monaco EURLAB 1-How TO SeND TEXT TO ARDUINO 1.2-Connect ARDUINO TO COMPUTER At first you have to connect Arduino Uno to computer thanks to USB cable.

4. Istituto Tecnico Industriale A.Monaco EURLAB 1-How TO SeND TEXT TO ARDUINO 1.3-OPEN ARDUINO SOFTWARE and CHECK CONNEXION WITH ARDUINO UNO Com 7 or an other 1 2

5. Istituto Tecnico Industriale A.Monaco EURLAB 1-How TO SeND TEXT TO ARDUINO 1.4-OPEN ARDUBLOCK PROGRAM Get the number of bytes (characters) available for reading from the serial port Reads incoming serial data from Rx Arduino port Sends incoming serial data from Tx Arduino port USB Cable Arduino Uno

6. Istituto Tecnico Industriale A.Monaco EURLAB 1-How TO SeND TEXT TO ARDUINO 1.5-UPLOAD TO ARDUINO Select Upload to Arduino in order to : create Arduino program, check it, upload it to Arduino uno board.

7. Istituto Tecnico Industriale A.Monaco EURLAB 1-How TO SeND TEXT TO ARDUINO 1.6-Communicate to ARDUINO UNO In order to communicate to arduino uno Board, open serial monitor and write a text. Then, Arduino uno receives your text and sends an answer Write a text in the gap
